2N® SmartGate GSM gateway User guide Version 1.1.2 www.2n.
The 2N TELEKOMUNIKACE a.s. joint-stock company is a Czech manufacturer and supplier of telecommunications equipment. The product family developed by 2N TELEKOMUNIKACE a.s. includes GSM gateways, private branch exchanges (PBX), and door and lift communicators. 2N TELEKOMUNIKACE a.s. has been ranked among the Czech top companies for years and represented a symbol of stability and prosperity on the telecommunications market for almost two decades.
Table of Contents 1. Product Overview............................................................... 7 1.1 Product Description ....................................................................................................... 8 Basic Features.................................................................................................................. 8 Advantages of 2N® SmartGate use ................................................................................. 8 Safety Precautions ............
Telephone interface FXS parameters ............................................................................ 30 Telephone interface FXO parameters ............................................................................ 35 FXS routing table parameters ........................................................................................ 39 FXO routing table parameters ........................................................................................ 43 GSM routing table ......................
.1 Technical Parameters .................................................................................................. 78 GSM ............................................................................................................................... 78 Power Supply ................................................................................................................. 78 Telephone Interface FXS (for PBX external line or phone set) ......................................
1 1. Product Overview In this section, we introduce the 2N® SmartGate product, outline its application options and highlight the advantages following from its use. This chapter also includes safety instructions. Here is what you can find in this section: Product Description Manual changes description Abbreviations, Terms and Pictograms Used.
Product Description 1.1 1.1 Product Description Basic Features The primary purpose of 2N® SmartGate is to transmit voice between GSM network and attached phone terminals. You can connect terminal with FXO interface (trunk line of PBX, phone set, answering machine etc.) to FXS interface on 2N® SmartGate (connector with phone icon) and terminal with FXS interface (extension line of PBX) to FXO interface on 2N® SmartGate (connector with crossed out phone icon).
Product Description 1.1 Safety Precautions Do not switch on 2N® SmartGate in the vicinity of medical apparatuses to avoid interference. The minimum distance of the antenna and pacemakers should be 0.5m. Do not switch on 2N® SmartGate aboard of a plane. Do not switch on 2N® SmartGate near petrol stations, chemical facilities or sites where explosives are used. Any mobile telephone use prohibition based on RF energy radiation applies to 2N® SmartGate too.
Changes 1.2 1.2 Changes Manual Version Amendments to Earlier Versions 1.0.0 The User Manual applies to 2N® SmartGate FW Version 1.00A. 1.0.1 Analogue FAX support. (optionally). 1.0.2 Analogue Modem support, Network directing services support 1.0.3 Quadband version 1.0.4 Programming parameters using phone line (DTMF programming) 1.1.1 New design of manual New version of PCManager (PCManagerUNI 2.04), Digital DTMF option AMR set on/off Quadband version only Free minutes option – only FW 1.
Terms and Symbols Used 1.3 1.3 Terms and Symbols Used Manual Symbols Safety Always abide by this information to prevent persons from injury. Warning Always abide by this information to prevent damage to the device. Caution Important information for system functionality. Tip Useful information for quick and efficient functionality. Note Routines or advice for efficient use of the device.
2 2. Description and Installation This section describes the2N® SmartGate product and its installation.
Description 2.1 2.1 Description 2N® SmartGate consites of GSM gateway in white plastic cover, removable antenna and cables for connecting to phone set and PC 2N® SmartGate‟s status is indicated by LED diodes on its front side. All possible states are described in the following figure. Figure 2.
Description 2.1 Telephone Line Tones – Operational Tones The GSM gateway sends tones to the telephone line to indicate the line status. The tone frequency is 425 Hz in initial setting. Frequency is programmable; it is possible to set up double frequency tones. Dial tone continuous or morse A 2N® SmartGate is ready to receive dialing. Ringing tone Only The called subscriber's telephone is ringing. The GSM network or connected PBX transmits this tone.
Description 2.1 Dialing end signaling Only Dialing reception has been terminated. Connection is being established. PIN tone Enter the PIN code. This tone is transmitted upon power up if the PIN has to be entered manually. PUK tone Enter the PUK code. This tone is transmitted upon repeated wrong PIN entering attempts. SIM card is blocked. Telephone Line Tones – Programming Mode Tones confirming/refusing the values entered are transmitted during telephone line based programming.
Before You Start 2.2 2.
Before You Start 2.2 2N® SmartGate can disturb other telecommunication systems. Place phone lines and connected terminals and PBX‟s faraway from antenna. It is impossible to operate 2N® SmartGate on sites exposed to direct solar radiation or near heat sources. 2N® SmartGate is designed for indoor use. It may not be exposed to rain, flowing water, condensed moisture, fog, etc. 2N® SmartGate may not be exposed to aggressive gas, acid vapours, solvents, etc.
Mounting 2.3 2.3 Mounting External Antenna Connection Screw the antenna enclosed into the SMA antenna connector. Caution Tighten the antenna connector gently with your hand – never use wrenches! Note The antenna enclosed has a sufficient gain for trouble-free operation in normal conditions. If the GSM signal is poor or you want to place your antenna separately from SmartGate, you can use an antenna with an SMA-connector terminated cable. The antenna should be mounted vertically.
Mounting 2.3 Wall mounting 2N® SmartGate is equipped with two hangings on the back side for wall mounting. For drilling holes to the wall could be used drill pattern in QuickStart. Figure 2.4 Zavěšení 2N® SmartGate na zeď Power Supply Connection 2N® SmartGate is fed with 10-16V DC. Where a source other than the included power supply adapter is used, the voltage range and polarity shown on the 2N® SmartGate power supply connector have to be maintained.
Telephone line connection 2.4 2.4 Telephone line connection DialThru gateway – basic connection Phone set is normally connected to extension line of PBX. Wire up 2N® SmartGate between phone set and PBX. Link extension line of PBX to FXO interface and phone set to FXS interface on SmartGate. Optionally you can connect analogue fax (special model of SmartGate).
SMS Sending Input Connection 2.5 2.5 SMS Sending Input Connection You have got a special connector for easy connection to SmartGate. The connector is equipped with screwing clamps to connect wires from a switching contact (device to be monitored). The other connector end can be connected to the respective 2N® SmartGate panel connector. The input is designed for the contact of relay connected between the input pins. The input is activated by contact closing (pin interconnection).
3 3. Configuration 2N® SmartGate This section describes configuration of the product 2N® SmartGate.
2N® SmartGate parameters configuration 3.1 3.1 2N® SmartGate parameters configuration PC Connection You have got a serial cable for PC connection. It is a modem cable where all of the 9 pins are 1:1 interconnected – in case you want to use another cable. Caution Make sure that a longer cable works properly to avoid errors at high transmission rates. 2N® SmartGate Parameter Programming Most of SmartGate‟s parameters have such default values that meet most users‟ demands and need not be changed.
2N® SmartGate parameters configuration 3.1 Numeric parameters are programmed using numbers in units included in the parameter description. The step for setting must be respected. For parameters with different setting are values defined in the parameters description (in parenthesis). To cancel any programming step in the programming mode, press a . Having done so, you can hear the refusal tone and can enter a new parameter number. Parameters are saved when the saving tone is transmitted.
2N® SmartGate parameters configuration 3.1 the table for setting parameters will open. If you point at a parameter with the mouse, the help text is displayed. 7. When the setting is finished, save data into the gateway. If the gateway is not in its special programming mode, you are invited to set this mode again according point 5. 8. You can use service Monitor to view parameters of connection and some more information.
2N® SmartGate parameters configuration 3.1 Further Data Handling Options The gateway configuration settings can be saved in a PC file and reloaded into the PCManager. This is recommended for backing up of current configuration Caution The table Security includes the PIN code and service password. These parameters have a special handling. They are not saved in a PC file for security reasons.
2N® SmartGate parameters configuration 3.1 Monitoring Monitoring is active when the gateway is in operation and registered to the GSM network. If the gateway is not registered to GSM, the COM is blocked and no monitoring can be made.
2N® SmartGate parameters configuration 3.1 Firmware Upgrade The manufacturer responds to clients' requirements with periodical firmware updating. The current 2N® SmartGate firmware, PCManager and User Manual are available on www.2n.cz. The latest firmware version is always included in every new PCManager installation. Upgrading procedure: 1. Run the PCManager, select the language for displaying texts on the right-hand side. 2.
Table of Parameters 3.2 3.2 Table of Parameters All programmable parameters are listed in this section. Each parameter is accompanied with the unit used, function number (if avaliable) for programming via a telephone line, description of SmartGate's behavior, setting options, setting step and default (initialization) value. Numeric parameters must be set in unit listed in the parameter description.
Table of Parameters DTMF during call 3.2 Function No.: When DTMF is transmitted in voice channel of GSM network problem with quality can occur, because the GSM compression can damage the signal. You can set digital transmission mode, than SmartGate mutes original DTMF signal from telephone line, and instead of this transmits digital DTMF in signaling channel.
Table of Parameters 3.2 Tone settings Dial tone – Double frequency tone[Hz] Function No.: - Parameter can be set for all three types of tone (Dial tone, Busy tone,Ringbacktone). This parameter is intended for switching between single tone and double tone setting. When the parameter is set, the second frequency of appropriate tone must be set too. When this parameter isn‟t set, the second frequency is automatically set to the same value, which results in single tone generation.
Table of Parameters Busy tone - cadence Function No.: 3.2 125 Busy tone cadence setting. Setting options: 330/330 200/200 250/250 375/375 500/500 ms ms ms ms ms Default setting: 330/330 ms (0) (1) (2) (3) (4) -cadence -cadence -cadence -cadence -cadence Ring back tone – frequency 1 [Hz] 330 200 250 375 500 ms ms ms ms ms tone, tone, tone, tone, tone, 330 200 250 375 500 Function No.: ms ms ms ms ms pause pause pause pause pause 126 Setting of frequency 1 of ringback tone.
Table of Parameters Setting step: 1 Default setting: 3 = medium volume level Reception volume Function No.: 3.2 191 Volume setting for GSM reception with a 4 dB step. Setting options: 1-5 Setting step: 1 Default setting: 3 = medium volume level Ringing signal settings Ringing signal – frequency [Hz] Function No.: 140 Ringing signal frequency setting.
Table of Parameters Replace character + in CLI by Function No.: 3.2 149 If this parameter is filled, the + character in the international prefix of CLI is replaced by the defined string. The + character can neither be transmitted by the FSK protocol nor dialed by the DTMF from a terminal. Setting options: 0-4 characters (0-9,*,#) Default setting: blank „BabyCall“ – Automatic call BabyCall number Function No.: 180 A number to be dialed for the automatic call function.
Table of Parameters Timeout for dialing end recognize [s] 3.2 Function No.: 201 If 2N® SmartGate is programmed as FXO gateway, parameter defines timeout during which 2N® SmartGate waits for further digits to be dialed. It starts to establish connection when this timeout passes. Setting options: 1-255 s Setting step: 1s Default setting: 5s Type of transmitted dialing Function No.: 204 Set type of dialing for automatic dial-in from GSM and for dialing during outgoing call from FXS interface.
Table of Parameters Beep after dialing end 3.2 Function No.: 203 If 2N® SmartGate is programmed as FXO gateway, parameter enables a beep to signal the end of dialing (beginning of outgoing call establishing). Setting options: YES(1)/NO(0) Default setting: YES Signaling Busy tone detection Function No.: 210 Set number of busy tone periods for detection of call disconnection from your PBX. The "0" setting disables busy tone detection. For reliable detection is recommended to use value 3 or more.
Table of Parameters Dial tone – frequency 2[Hz] 3.2 Function No.: 221 Function No.: 222 Setting of frequency 2 of dial tone. Setting options: 1-3400 Hz Setting step: 1 Hz Default setting: 425 Hz Dial tone - cadence Dial tone cadence setting. Setting options: Continuous ( 0) -2N® SmartGate generate continuous dial tone Morse A (1) -2N® SmartGate generate dial tone with 330/330/660/660 ms timing Default setting: Continuous Ring back tone – frequency 1 [Hz] Function No.
Table of Parameters 3.2 „BabyCall“ – Automatic call BabyCall number Function No.: 280 If 2N® SmartGate is programmed as FXO gateway, parameter defines a number to be dialed for the automatic call function. If this item is blank, the function is disabled. If only character „#‟ is included, after BabyCall timeout elapsed the interfaces FXO and FXS are connected and dialing to PSTN over FXO interface is possible.
Table of Parameters 3.2 Accelerate connection establishing by knowing the number length for the given prefix; Accelerate connection establishing by allowing to terminate dialing with a #; Modify the number to be dialed by removing and/or adding prefix.
Table of Parameters 3.2 Remember to complete the "Other prefixes" line for a number whose prefix is not found in the table. An example in the figure shows how to bar all international calls with the exception of calls to Slovakia. Calls to Slovakia are routed through FXO interface and the call is established immediately after 14 digits are dialed. All other calls are enabled and they are routed to GSM network.
Table of Parameters End with # 3.2 Function No.: 394 This parameter enables to establish the call when a # is received. The # character is removed from the dialed number. If a # should be part of the dialed number, this function cannot be used for the given prefix. Setting options: YES(1)/NO(0) Default setting: NO Remove Function No.: 395 The Remove parameter is used for automatic call routing. A defined count of digits (prefix) is removed from the number beginning.
Table of Parameters 3.2 Bank No. Special option for gateways with Free minutes option support. This option is for gateways with FW version 1.5x and 3.5x only and it is described in separate part of manual. FXO routing table parameters All parameters related to the dialed number and call routing are arranged in three routing tables. Each table pertains to one interface: FXS, FXO and GSM. Calls from FXO interface are routed according to “FXO calls rote to” parameter.
Table of Parameters Setting options: 0-16 characters (0-9,*,#,+) Default setting: blank Mobility Extension - number of rings 3.2 Function No.: 402 If you program 2N® SmartGate as DialThru gateway and ME number is filled in, 2N® SmartGate starts to establish GSM call to ME number after defined number of rings. Then you can receive incoming FXO call on telephone line or in GSM network.
Table of Parameters Setting options: 0-16 characters (0-9,*,#) Default setting: blank Call enable 3.2 Function No.: 491 This parameter allows/bars calls with corresponding prefixes. Setting options: YES(1)/NO(0) Default setting: YES Number length Function No.: 493 The parameter defines the expected length of dialed number. It enables to start dialing into GSM or FXO interface immediately after the last digit is dialed. If the telephone number to be dialed is shorter, a timeout is respected.
Table of Parameters 3.2 Bank No. Special option for gateways with Free minutes option support. This option is for gateways with FW version 1.5x and 3.5x only and it is described in separate part of manual. GSM routing table All parameters related to the dialed number and call routing are arranged in three routing tables. Each table pertains to one interface: FXS, FXO and GSM. Incoming calls from GSM contain the CLI.
Table of Parameters 3.2 Callback he just doesn't hang up and the call is handled as a standard incoming call. Setting options: 0-255 s Setting step: 1 s Default setting: 5 s FAX from GSM route to Function No.: 509 Incoming FAX call from GSM network you can route to telephone line FXS, or to COM (PCFax). Parameter takes place only on models with FAX converter, on other models FAX calls are routed always to COM. Setting options: FXS line - Incoming FAX call is routed to FAX machine on FXS line.
Table of Parameters +420 603198222 603 3.2 any setting 4, or more 4, or more Setting options: 0-15 Step: 1 Default setting: 0 Route to Function No.: 591 It is possible to route incoming GSM call to FXS or FXO interface, or reject it. When the call is routed to FXS port you can use the CallBack feature. For correct functionality please set up "Max. ring time for Callback" parameter.
Table of Parameters Send if activated longer than [ms] 3.2 Function No.: 601 Set the SMS activation time necessary for SMS sending. This parameter prevents SMS sending in the event of short-time activation. If a "0" is selected, SMS is sent immediately upon the input activation. Setting options: 0-25500 ms Setting step: 100 ms Default setting: 0 ms Timeout after sending [s] Function No.: 602 Set the Time of inactivity after SMS sending.
Table of Parameters Call Handover workaround Function No.: 3.2 703 This parameter offers a workaround to prevent problems during call handover into the 1900 MHz (or 1800 MHz) band, caused by non-conforming configurations of the 1900 MHz (or 1800 MHz) GSM network. Setting options: -Disable (0) - Disable workaround. -Enable (1) - Enable workaround. Select only when handover into a 1800/1900MHz band fails. Default setting: Disable GPRS APN Function No.
Table of Parameters Setting options: 3.2 - Enable - Disable Default setting: Disable Call transfer service prefix Function No.: - Fill in relevant service code. For help see call transfer in virtual GSM PBX description. Setting options: 0-8 character Default setting: blank Time period for low credit checking [h]Function No.: 710 Set to change time interval between credit checks. If your credit drops under defined value, 2N® SmartGate sends SMS "LOW CREDIT".
Table of Parameters Telephone number for service SMS Function No.: 3.2 714 Telephone number for service SMS. The number is common for GGMC SMS and "LOW CREDIT" SMS on prepaid SIM cards. Setting options: 0-16 characters (0-9,*,#,+) Default setting: blank Service Parameters Hardware version Function No.: - 2N® SmartGate hardware version - for information only (cannot be modified). Must be used for communication with the manufacturer. Firmware version Function No.
Table of Parameters Telephone number for service SMS 3.2 Function No.:714 Telephone number for service SMS. The number is common for GGMC SMS and "LOW CREDIT" SMS on prepaid SIM cards. Setting options: 0-16 characters (0-9,*,#,+) Default setting: blank Initialization All programmable parameters are arranged in tables according to their functions. You can initialize either all parameters at once or one table of parameters. Telephone line initialization FXS Function No.
Table of Parameters 3.2 Security Parameters PIN – value Function No.: 700 Fill in the PIN value for automatic PIN entering upon 2N® SmartGate power up. It is applied only if the SIM card is PIN secured. If the given PIN fails to match the SIM, it is deleted automatically. If entered via a telephone line upon 2N® SmartGate start, the PIN is stored automatically. Setting options: 0, 4-8 characters (0-9) Upon full initialization: blank Service password Function No.
4 4. Function and Use This section describes the basic and extending functions of the product 2N® SmartGate . Here is what you can find in this section: Voice function FAX and Data function SMS Sending Input COM – Serial Interface SIM Card PIN protection.
Voice function 4.1 4.1 Voice function Outgoing and incoming call establishing procedures is for illustration described for analog phone connected to FXS interface and extension line of PBX connected to FXO interface on SmartGate. In case of other equipment connection, please check SmartGate‟s function by connecting a phone.
Voice function 4.1 Incoming call on FXO interface 1. 2N® SmartGate detects a ringing signal and immediately interconnects it to FXS interface – the phone starts to ring. 2. The CLIP transmitting must provide connected PBX. 3. If you hook off the phone the call is established. Automatic Call ("BabyCall") If the BabyCall function is enabled on FXS interface, a pre-programmed timeout is counted down after off-hook.
Voice function 4.1 numbers. Tariff metering is transmitted only during calls to GSM network. Connected PBX must provide the tariff metering during calls to FXO interface. You can also program 2N® SmartGate to transmit tariff pulses as call connect/disconnect signaling if your PBX cannot receive telephone line polarity reversal signaling. Gateway for extension line of PBX Extension line of PBX is connected to FXO interface on SmartGate. FXS interface remains unconnected.
Voice function 4.1 Gateway for trunk line of PBX Outgoing and incoming call establishing procedures is for illustration described for analog phone connected to FXS interface. The rules for call establishing in case of trunk line connection are the same, you have to program your PBX to route GSM calls to SmartGate. We strongly recommend to check SmartGate‟s function by connecting a phone in case of interconnection with PBX trunk line. Outgoing call on FXS interface 1.
Voice function 4.1 3. Wait for information tone. You may wait about 3 seconds. 4. Hook on. Information tones: Confirmation - OK: Confirms that the service was configured correctly. Confirmation - bad: Service was not correctly configured Service isn‟t activated by your provider Confirmation - service activated: Confirms that the service was configured correctly and the service is activated.
Voice function 4.1 Status check: Call forwarding if busy If activated, incoming calls will be forwarded to the configured telephone number if there is call in progress on SmartGate. Activation for all call types: Activation for selected call type: Deactivation: Status check: Call forwarding if no answer If activated, incoming calls will be forwarded to the configured telephone number if incoming call isn‟t answered during specified timeout.
Voice function 4.1 Status check: Call forwarding if not accessible If activated, incoming calls will be forwarded to the configured telephone number if your 2N® SmartGate is not accessible in the GSM network. Activation for all call types: Activation for selected call type: Deactivation: Status check: Call waiting If the call waiting is activated the incoming call isn‟t refuse if there is call in progress on SmartGate.
Voice function 4.
FAX and Data function 4.2 4.2 FAX and Data function Only 2N® SmartGate with fax converter supports fax and data functions. Sending fax message or modem connection to and from PSTN FAX and data call to PSTN routed from FXS to FXO interface (DialThru gateway) works on every model and needn‟t any other settings.
FAX and Data function 4.2 analogue channel of GSM network and the connection is not successful. In this case it is possible to set the gateway using DTMF commands using device connected to FXS line. This commands can be used for data and fax routing to FXS line or serial line.
FAX and Data function 4.2 connection, to avoid data errors. The data rate for GPRS connection is limited by actual speed of GPRS transfer in GSM network too. This speed is often affected by network load.
SMS Sending Input 4.3 4.3 SMS Sending Input This universal input is intended especially for reporting alarm or error statuses of any equipment provided with the appropriate contact (a relay contact, e.g.). By activating this input (electric input pin interconnection) you send one SMS to one pre-programmed telephone number. Caution Do not use in life-supporting or property-protection applications because of the character of SMS service and 2N® SmartGate equipment.
COM – Serial Interface 4.4 4.4 COM – Serial Interface The complete serial interface RS-232C on a 9-pin connector is identical with any external modem. The transmission rate ranges from 1200 to 115200 bps (2N® SmartGate supports autobauding, i.e. responds to an AT command at a rate identical with the AT command transmission rate, and retains set on this rate). The transmission setup must be 8 bits, no parity and one STOP bit (8N1).
COM – Serial Interface 4.4 CSD PC-PC Data Transmission The CSD mode provides data transmission in the GSM network at the maximum transmission rate of 14400 bps. It works like a classic connection of two modems (AT commands ATD, ATH, ATA, etc.). Connection can be made with another GSM modem or a PSTN modem. Caution Data calls and fax calls from the PSTN come as voice calls (the telephone line on 2N® SmartGate rings) because an analog network is unable to distinguish a modem/fax call.
COM – Serial Interface 4.4 SMS Sending and Receiving It is possible to send and receive SMS units using appropriate AT commands. There are a number of PC programs that are based on this principle. Install SW designed for SIEMENS GSM modules (SIEMENS mobile telephone SW can also be used). You can send and receive SMS even during 2N® SmartGate voice calls. Combination of COM Traffic with Voice Calls As already mentioned, SMS transmission can be made even during telephone calls.
SIM Card PIN protection 4.5 4.5 SIM Card PIN protection If a SIM card is PIN-protected and the PIN is not programmed in SmartGate, GSM LED indicates the state and the PIN tone is transmitted on telephone line. PIN Entering by PCManager Like other parameters, the PIN code can be entered using a PC programming tool. The PIN will be entered automatically upon every 2N® SmartGate power up. PIN Entering via Telephone Line PIN entering via a telephone line connected to FXS interface: 1.
SIM Card PIN protection 4.5 Automatic PIN Entering You need not enter the PIN upon power up if it is stored in 2N® SmartGate – it is entered automatically. This function is useful in case of power failure; 2N® SmartGate is operable in a short time after power recovery without any intervention by the operating staff. Caution! One PIN entering option is exhausted by the attempt to enter the PIN automatically upon SIM card or PIN change.
Free minutes option 4.6 4.6 Free minutes option Basic description With Firmware 1.5x and 3.5x only! Free minutes option allows user to control amount of minutes used for four groups of operators in one month period. The user than knows, if performed calls are included in free minutes bundle, or if he has to pay extra price for it. Calls for extra price can be disabled. All setting done by customer is accessible by DTMF setting. Setting of prefixes (operators) in four banks can be changed using PCManager.
Free minutes option Free minutes 4.6 Function No.: 32x The number of minutes that will be used to refill banks. The selection x is 1 to 4, according to bank number. Setting options: 0-65535 Default setting: 0 Initial time Function No.: 33x Initial time interval in seconds, which is charged for every call, although the call is shorter. The selection x is 1 to 4, according to bank number. Setting options: 0-255 Default setting: 0 Time step Function No.
Free minutes option DD: day in month hh: hour mm: minute 4.6 When the date is valid, the confirmation - OK is generated otherwise there is there confirmation – bad. Refill now The command is intended for refilling of free minutes banks with predefined values (free minutes) manually just now. This command is to be used for initialization or for manual handling of system.
Free minutes option 4.6 Using Free minutes option – step by step 1. If your gateway is preset by supplier to be used with some billing scheme, you can continue with step 6 2. Collect all information about billing scheme you use from your operator. 3. You have to set parameters by PCManager. Connect the gateway to your PC by serial cable and to power by adapter. When the gateway is connected to network, you can set it by PCManager. 4. Set the table “FXS routing table”.
5 5. Technical parameters This section describes the technical parameters of the product 2N® SmartGate.
Technical Parameters 5.1 5.1 Technical Parameters GSM GSM module, GSM bandwidth MC55i: EGSM 900/850MHz, GSM 1800/1900MHz Transmission power Receiver sensitivity SIM card 1W GSM 1800/1900 MHz HR+FR+EFR Half rate+Full rate+Enhanced full rate Echo cancellation, Echo suppression GPRS Class 10, 4+2 max. 85.6 kbps downlink DATA Antenna EGSM 850/900 MHz, -104 dBm Audio Analog Fax and Data models with FAX converter 2W CSD max. 14.
Technical Parameters Telephone connector type RJ 12, 6/2 Line impedance 600 Loop voltage on hook 48 V DC Loop current max. 40 mA Loop resistance max. 800 Tone frequency adjustable, default 425 Hz Dialing type tone (DTMF) or pulse Ringing voltage 42 Vrms 50/25 Hz Calling line identification CLI during ringing according to ETSI FSK Tariff pulses f=16/12 kHz ; Umin=100 mVef on 200 Answer supervision polarity reversal, 12/16 kHz pulses 5.
Technical Parameters Closed loop resistance max. 1 k Open loop resistance Min. 25 k Input overvoltage protection max. +/- 12 V 5.
6 6. Supplementary Information This section describes supplementary information of the product. Here is what you can find in this section: Regulations and directives Troubleshooting List of Abbreviations General Instructions and Cautions.
Regulations and directives 6.1 6.
Troubleshooting 6.2 6.2 Troubleshooting For tips for the solution of other potential problems see faq.2n.cz. No LED is on after power up All LEDs are on. No call is currently in progress. 2N® SmartGate is in the special PCManager-based programming mode exit the PCManager to reset SmartGate Try to switch 2N® SmartGate off and on, the LEDs should go off in 3s and signal the status of SmartGate 2N® SmartGate does not register to GSM Check the SIM card. Check the PIN.
Troubleshooting 6.2 2N® SmartGate does not communicate with PC Check the serial cable connection. Check the COM number setting on PC. Check the COM parameters (1200-115200 bps, 8N1). 2N® SmartGate is not registered to GSM network. A dialing or outgoing call establishing process takes place on SmartGate. An incoming call is ringing on SmartGate.
List of Abbreviations 6.3 6.3 List of Abbreviations APN (Access Point Name) Necessary for the GPRS service. CLIP (Calling Line Identification Presentation) CSD (Circuit Switched Data) COM A PC Serial port. DTMF (Dual Tone MultiFrequency) Tone dialling. FSK (Frequency Shift Keying) A transmission protocol using variable signal frequencies for logic level encoding. FXO An interface electrically identical with a standard telephone (opposite side = FXS interface).
List of Abbreviations SW Software. TTL (Transistor-Transistor Logic) A standard digital technology defining voltage for levels 0 and 1. PSTN Public Switched Telephone Network. 6.
General Instructions and Cautions 6.4 6.4 General Instructions and Cautions Please read this User Manual carefully before using the product. Follow all instructions and recommendations included herein. Any use of the product that is in contradiction with the instructions provided herein may result in malfunction, damage or destruction of the product.
General Instructions and Cautions 6.4 Electric Waste and Used Battery Pack Handling Do not place used electric devices and battery packs into municipal waste containers. An undue disposal thereof might impair the environment! Deliver your expired electric appliances and battery packs removed therefrom to dedicated dumpsites or containers or give them back to the dealer or manufacturer for environmental-friendly disposal.
2N TELEKOMUNIKACE a.s. Modřanská 621, 143 01 Prague 4, Czech Republic Tel.: +420 261 301 500, Fax: +420 261 301 599 E-mail: sales@2n.cz Web: www.2n.cz 1575v1.1.
