INSTALLATION AND OPERATION

MANUAL

Document Number: 570-0049 Revision B

2-WIRE REMOTE SWITCH INTERFACE 455-0032

AND ELT INTERFACE 455-0041 INSTALLATION

ACR Electronics, Inc.

5757 Ravenswood Rd.

Fort Lauderdale, FL 33312 USA

Phone 954-981-3333, Fax 954-983-5087

E-mail service@acrartex.com

www.acrartex.com

Summary of content (30 pages)

PAGE 1
INSTALLATION AND OPERATION MANUAL Document Number: 570-0049 Revision B 2-WIRE REMOTE SWITCH INTERFACE 455-0032 AND ELT INTERFACE 455-0041 INSTALLATION ACR Electronics, Inc. 5757 Ravenswood Rd. Fort Lauderdale, FL 33312 USA Phone 954-981-3333, Fax 954-983-5087 E-mail service@acrartex.com www.acrartex.
PAGE 2
ACR Electronics, Inc. 570-0049 Revision B NOTICES 1. This document discloses subject matter in which ACR Electronics, Inc. has proprietary rights. Neither receipt nor possession thereof confers or transfers any right to reproduce or disclose the document, any part thereof, any information therein, or any physical article or device, or practice any method or process except by written permission from or written agreement with ACR Electronics, Inc. 2.
PAGE 3
ACR Electronics, Inc.
PAGE 4
ACR Electronics, Inc. 570-0049 Revision B REVISION HISTORY REVISION ENGINEERING CHANGE ORDER DATE - RELEASE 02-02-09 A DCN 3556 11/16/09 B ECO 15419 Update branding to ACR throughout manual.
PAGE 5
ACR Electronics, Inc. 570-0049 Revision B TABLE OF CONTENTS 1. INTRODUCTION ................................................................................................................................... 7 2. PARTS LIST .......................................................................................................................................... 7 3. INSTALLATION AND WIRING OVERVIEW ......................................................................................... 9 3.
PAGE 6
ACR Electronics, Inc. 570-0049 Revision B LIST OF FIGURES Figure 1: Installation Overview ...................................................................................................................... 9 Figure 2: Tyco Crimping Tool ...................................................................................................................... 13 Figure 3: Crimp Overview ...........................................................................................................................
PAGE 7
ACR Electronics, Inc. 1. 570-0049 Revision B INTRODUCTION This manual contains detailed information about the installation and operation of the interfaces 453-0032 and 453-0041 with any Artex Emergency Locator Transmitters. The interfaces do not function with the ELT-200 series. The intent of the interface system is to provide a cost effective means to our customers to retrofit existing ELT installations using 2-wire connection between the ELT and a toggle switch.
PAGE 8
ACR Electronics, Inc. QUANTITY 570-0049 Revision B PART NUMBER DESCRIPTION 455-0049 Pack List, 2-Wire ELT/RSWT Interface 2 ea. 120-4007 Diode, 1N4007 1 ea. 140-3349 Switch, DPDT W/LED Tip 2-Pos. 1 ea. 455-0032 Pack List, 2-Wire RSWT Interface 453-0032 1 ea. 455-0041 Pack List, 2-Wire ELT Interface 453-0041 1 ea. 570-0049 Manual, 2-Wire RSWT Interface 455-0032 & ELT Interface 455-0041 1 ea. 591-0037 Label, Toggle Switch Horizontal 1 ea.
PAGE 9
ACR Electronics, Inc. 570-0049 Revision B 3. INSTALLATION AND WIRING OVERVIEW 3.1 INSTALLATION OVERVIEW The installation below is shown without an ELT.
PAGE 10
ACR Electronics, Inc. 3.2 570-0049 Revision B WIRING OVERVIEW Due to the range of ELT installation available, this manual does not illustrate each single wiring diagram pertaining to a specific ELT because the wiring is in fact very generic to all Artex beacons. All Artex ELTs follow the same wiring criteria, and have 5 basic electrical lines connecting the toggle switch to the beacon: 1. Light: This pin turns ON the toggle switch LED. The ELT output is a square wave pulse with 280 millisecond period.
PAGE 11
ACR Electronics, Inc. 4. 570-0049 Revision B CABLE HARNESS Due to the large array of configurations possible, ACR Electronics, Inc. does not provide a harness as part of the installation of the ELT. Accordingly, it is the responsibility of the installer: 1. To manufacture the required harness(es) and ensure that the wires are adequate for the installation. 2. To check the integrity of the 2-communication wires installed across the aircraft. 3.
PAGE 12
ACR Electronics, Inc. 4.2 570-0049 Revision B CRIMPING INSTRUCTIONS NOTES: This section is used in conjunction with the ELT and remote switch wiring sections Refer to Tyco CERTI-CRIMP II Straight Action Hand Tools document 408-8547 for further information if required (Tyco web site). 4.2.1 Read the instructions before proceeding to familiarize yourself with the process. 4.2.2 Ensure that the wire intended for use is compatible with the wire size of the contact crimp. 4.2.
PAGE 13
ACR Electronics, Inc. 570-0049 Revision B Figure 2: Tyco Crimping Tool Figure 3: Crimp Overview 4.2.11 Hold the contact in this position and squeeze the tool handles together until the insulation anvil starts entry into the insulation crimper (usually two ratchet clicks). Do NOT deform the insulation barrel or wire barrel. 4.2.12 Insert a properly stripped wire through the locator slot and into the wire barrel of the contact until the insulation butts against the locator/insulation stop. 4.2.
PAGE 14
ACR Electronics, Inc. 4.2.20 Install the D-sub connector inside a backshell (151-0006). 570-0049 Revision B 4.2.21 Secure the strain relief using the screws provided in the backshell kit. 4.2.22 Install the thumbscrews and close the backshell with the screws. 5. 453-0041 WIRING TO ELT 5.1 INSTRUCTIONS 5.1.1 The mating connector and contacts connecting to the ELT are found in the install kit included in the pack list at the time the beacon is purchased.
PAGE 15
ACR Electronics, Inc. 570-0049 Revision B Table 4: ELT Interface 453-0041 Front View Example: The following information highlights the wiring of the ME406 ELT series to the ELT interface 4530041: ME406 SERIES ELT 453-0041 ELT INTERFACE PIN OUT PIN OUT Light 2 6 Reset 1 6 3 Reset 2 13 4 External ON 14 8 Ground 7 7 and 9 Horn power 8 5 Horn ground 7 or aircraft ground 7 DESCRIPTION 5.1.
PAGE 16
ACR Electronics, Inc. 570-0049 Revision B 6. 453-0032 WIRING TO 453-0041 6.1 INSTRUCTIONS 6.1.1 The size of the two wires is based on the D-sub crimp contact 151-0042 accepting 22 to 26 gauge wires. 6.1.2 The color of the two communication wires between the interfaces is inconsequential, but each wire must be properly connected to the appropriate contact on the D-sub mating connector. 6.1.
PAGE 17
ACR Electronics, Inc. 7. 570-0049 Revision B 453-0032 WIRING TO 140-3349 TOGGLE SWITCH The interface has two connections available on the D-sub connector to connect either aircraft power 14 VDC or 28 VDC. The connections have internal current limiting resistors to protect the built-in LED on the toggle switch, so it is critical to establish the proper connection between the interface, the toggle switch, and the aircraft power. The power supply inside the interface is designed to operate on 6.
PAGE 18
ACR Electronics, Inc. 7.2 570-0049 Revision B 140-3349 TOGGLE SWITCH WIRING (14 VDC INSTALLATION) Improperly wiring the aircraft power to the D-sub will irreversibly damage the interface. 7.2.1 Solder the wires from the 453-0032 interface to the toggle switch according to the following information for 14 VDC aircraft power: Table 7: 14 VDC Aircraft Power CONTACT LOCATION Diodes not shown 453-0032 INTERFACE TOGGLE SWITCH CONTACT # DESCRIPTION CONTACT # 1 N/A N/A 2 Ground 9 3 Ext.
PAGE 19
ACR Electronics, Inc. 7.3 570-0049 Revision B 140-3349 TOGGLE SWITCH WIRING (14 VDC INSTALLATION) Improperly wiring the aircraft power to the D-sub will irreversibly damage the interface. 7.3.1 Solder the wires from the 453-0032 interface to the toggle switch according to the following information for 28 VDC aircraft power: Table 8: 28 VDC Aircraft Power CONTACT LOCATION Diodes not shown 453-0032 INTERFACE TOGGLE SWITCH CONTACT # DESCRIPTION CONTACT # 1 N/A N/A 2 Ground 9 3 Ext.
PAGE 20
ACR Electronics, Inc. 7.4 570-0049 Revision B 453-0032 WIRING Table 9: Remote Switch Interface 453-0032 Front View VIEW 7.4.1 PIN # SIGNAL DESCRIPTION 1 N/A 2 N/A 3 Reset 2 4 Aircraft Power (14 or 28 VDC) 5 Light (28 VDC Installation) 6 Reset 1 7 External ON 8 Light (14 VDC Installation) 9 Aircraft Ground The wires for the interface 453-0032 are crimped and inserted inside the D-sub connector 1500022 using the same procedure highlighted in the “Cable Harness” section.
PAGE 21
ACR Electronics, Inc. 570-0049 Revision B 8. INTERFACE INSTALLATION 8.1 INSTRUCTIONS 8.1.1 Secure the interfaces 453-0032 and 453-0041 to a structural member using the hardware found in the 455-0032 and 455-0041 respectively. 8.1.2 2 ea. 201-0810 Screw, PHP 8-32 x 5/8 SS 2 ea. 241-0832 Nut, Hex 8-32 x ¼ SS 2 ea. 246-0001 Washer, Flat #8 OD3/8 SS 2 ea. 247-0800 Washer, Lock Internal Tooth #8 Torque the screws to 8 in-lb (0.90 Nm) ±1 in-lb (0.11 Nm).
PAGE 22
ACR Electronics, Inc. 570-0049 Revision B 9. PANEL CUTOUT/TOGGLE SWITCH INSTALLATION 9.1 INSTRUCTIONS NOTE: The toggle switch 140-3349 is not available with a protective guard. 9.1.1 Select a mounting location where the toggle switch can be seen from the pilot’s seated location, easily be reached by the pilot, out of direct sunlight, and can accommodate the switch and the label. 9.1.2 Choose the appropriate label based on the orientation on the control panel.
PAGE 23
9.1.8 ACR Electronics, Inc. Slide the locking ring on the toggle switch. 570-0049 Revision B Locking Ring Bat Tongue Figure 8: Toggle Switch Locking Ring 9.1.9 Slide the bat of the toggle switch through the cutout and insert the tongue of the locking ring inside the smaller hole. 9.1.10 Install the lockwasher and the mounting nut over the thread of the toggle switch. 9.1.11 Secure the nut using a torque screwdriver set to 6 lb-in (.67 Nm).
PAGE 24
ACR Electronics, Inc. 10. SPECIFICATIONS 10.1 INTERFACE MATERIAL 570-0049 Revision B 10.1.1 Both interfaces 453-0032 and 453-0041 are made with flame retardant ABS plastic, UL94V-0. 10.1.2 The surface of each interface is polished finish. 10.
PAGE 25
ACR Electronics, Inc. 570-0049 Revision B Figure 11: 453-0041 Interface 10.3 INTERFACE WEIGHT PART NUMBER DESCRIPTION WEIGHT 453-0032 2-Wire Remote Switch Interface 2.07 oz (59 gr.) Max. 453-0041 2-Wire ELT Interface 2.78 oz (79 gr.) Max.
PAGE 26
ACR Electronics, Inc. 10.4 570-0049 Revision B TOGGLE SWITCH DIMENSIONS Figure 12: 140-3349 Toggle Switch 10.5 TOGGLE SWITCH WEIGHT PART NUMBER DESCRIPTION WEIGHT 140-3349 Switch, DPDT W/LED Tip 2-Pos. .35 oz (10 gr.) Max.
PAGE 27
ACR Electronics, Inc. 10.
PAGE 28
ACR Electronics, Inc. 570-0049 Revision B Table 10: Components Specifications COMPONENT SPECIFICATIONS Mechanical Life 50000 operation minimum Locking Mechanism No Nut Mounting Torque 6 lb-in (.
PAGE 29
ACR Electronics, Inc. 10.7 570-0049 Revision B ENVIRONMENTAL CATEGORIES DO-160D Env. Cat.
PAGE 30
11.
