Operation Manual

R22 MODELS
(HEATPUMP)
MODEL : ACM 28ER / ALC 30CR
COOLING MODE
HEATING MODE
75
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15
8.897 5.879 8.367 5.441 7.837 5.003 7.307 4.564 6.778 4.126 6.142 3.600
16
9.245 5.407 8.681 5.018 8.117 4.629 7.553 4.240 6.989 3.851 6.312 3.385
16
9.245 6.675 8.681 6.286 8.117 5.897 7.553 5.508 6.989 5.119 6.312 4.653
17
9.594 6.203 8.995 5.863 8.397 5.524 7.798 5.184 7.200 4.844 6.482 4.437
18
9.942 5.731 9.309 5.441 8.677 5.150 8.044 4.860 7.411 4.570 6.652 4.221
19
10.290 5.259 9.623 5.018 8.956 4.777 8.289 4.536 7.622 4.295 6.822 4.006
20
10.640 4.786 9.952 4.589 9.263 4.392 8.575 4.195 7.886 3.997 7.060 3.761
18
9.942 6.999 9.309 6.708 8.677 6.418 8.044 6.128 7.411 5.837 6.652 5.489
19
10.290 6.527 9.623 6.286 8.956 6.045 8.289 5.804 7.622 5.563 6.822 5.273
20
10.640 6.054 9.952 5.857 9.263 5.660 8.575 5.462 7.886 5.265 7.060 5.028
21
10.992 5.581 10.290 5.424 9.588 5.267 8.887 5.109 8.185 4.952 7.344 4.764
22
11.343 5.108 10.628 4.991 9.914 4.874 9.199 4.757 8.485 4.639 7.627 4.499
23
11.694 4.635 10.966 4.558 10.239 4.481 9.511 4.404 8.784 4.326 7.911 4.234
24
12.045 4.162 11.304 4.125 10.564 4.088 9.823 4.051 9.083 4.014 8.195 3.969
20
10.640 6.688 9.952 6.491 9.263 6.293 8.575 6.096 7.886 5.899 7.060 5.662
21
10.992 6.215 10.290 6.058 9.588 5.901 8.887 5.743 8.185 5.586 7.344 5.397
22
11.343 5.742 10.628 5.625 9.914 5.508 9.199 5.390 8.485 5.273 7.627 5.133
23
11.694 5.269 10.966 5.192 10.239 5.115 9.511 5.037 8.784 4.960 7.911 4.868
24
12.045 4.796 11.304 4.759 10.564 4.722 9.823 4.685 9.083 4.648 8.195 4.603
ID DB°C ID WB°C
Outdoor DB°C
20 25 30 35 40 46
20
24
28
30
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15
3.707 3.707 4.621 4.621 4.926 4.926 8.276 8.276 10.103 10.103 11.017 11.017 11.931 11.931
17
3.619 3.619 4.529 4.529 4.832 4.832 8.122 8.122 9.828 9.828 10.710 10.710 11.591 11.591
19
3.531 3.531 4.437 4.437 4.739 4.739 7.969 7.969 9.553 9.553 10.402 10.402 11.252 11.252
21
3.443 3.443 4.344 4.344 4.645 4.645 7.816 7.816 9.278 9.278 10.095 10.095 10.913 10.913
23
3.431 3.431 4.271 4.271 4.552 4.552 7.544 7.544 9.003 9.003 9.788 9.788 10.573 10.573
25
3.420 3.420 4.198 4.198 4.458 4.458 7.272 7.272 8.727 8.727 9.481 9.481 10.234 10.234
27
3.409 3.409 4.125 4.125 4.364 4.364 7.000 7.000 8.452 8.452 9.173 9.173 9.895 9.895
FROST REGION
ID DB°C
Outdoor WB°C
-9 -6 -5 6 12 15 18
