Operation Manual

81
R410A MODELS
(HEATPUMP)
MODEL : A5CM 20ER / A5LC 20CR (1 PHASE)
COOLING MODE
HEATING MODE
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15
5.715 3.788 5.176 3.247 4.622 2.692 4.068 2.137 3.514 1.581 2.849 0.915
16
5.842 3.492 5.340 2.990 4.830 2.481 4.320 1.971 3.811 1.462 3.199 0.850
16
5.842 4.601 5.340 4.099 4.830 3.590 4.320 3.080 3.811 2.570 3.199 1.959
17
5.968 4.306 5.503 3.842 5.038 3.378 4.573 2.914 4.107 2.451 3.549 1.894
18
6.102 4.017 5.678 3.596 5.255 3.176 4.831 2.755 4.408 2.334 3.899 1.829
19
6.238 3.737 5.868 3.403 5.498 3.068 5.128 2.733 4.729 2.293 4.249 1.764
20
6.360 3.431 5.971 3.051 5.582 2.671 5.194 2.290 4.805 1.910 4.339 1.454
18
6.102 5.126 5.678 4.705 5.255 4.285 4.831 3.864 4.408 3.443 3.899 2.938
19
6.238 4.846 5.868 4.512 5.498 4.177 5.128 3.842 4.729 3.402 4.249 2.873
20
6.360 4.540 5.971 4.160 5.582 3.780 5.194 3.399 4.805 3.019 4.339 2.563
21
6.484 4.243 6.088 3.860 5.693 3.477 5.298 3.094 4.902 2.712 4.428 2.252
22
6.608 3.945 6.206 3.560 5.804 3.175 5.402 2.789 4.999 2.404 4.517 1.942
23
6.732 3.648 6.323 3.260 5.914 2.872 5.505 2.484 5.097 2.097 4.606 1.631
24
6.856 3.350 6.440 2.960 6.025 2.570 5.609 2.180 5.194 1.789 4.695 1.321
20
6.360 5.095 5.971 4.714 5.582 4.334 5.194 3.954 4.805 3.574 4.339 3.117
21
6.484 4.797 6.088 4.414 5.693 4.032 5.298 3.649 4.902 3.266 4.428 2.807
22
6.608 4.500 6.206 4.115 5.804 3.729 5.402 3.344 4.999 2.959 4.517 2.496
23
6.732 4.202 6.323 3.815 5.914 3.427 5.505 3.039 5.097 2.651 4.606 2.186
24
6.856 3.905 6.440 3.515 6.025 3.124 5.609 2.734 5.194 2.344 4.695 1.875
20
24
28
30
ID DB°C ID WB°C
Outdoor DB°C
20 25 30 35 40 46
TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW)
15
3.278 3.278 3.710 3.710 3.854 3.854 5.438 5.438 6.302 6.302 6.735 6.735 7.167 7.167
17
3.192 3.192 3.680 3.680 3.770 3.770 5.432 5.432 6.228 6.228 6.662 6.662 7.096 7.096
19
3.106 3.106 3.649 3.649 3.686 3.686 5.425 5.425 6.154 6.154 6.589 6.589 7.025 7.025
21
3.020 3.020 3.573 3.573 3.603 3.603 5.358 5.358 6.080 6.080 6.517 6.517 6.954 6.954
23
2.934 2.934 3.450 3.450 3.519 3.519 5.229 5.229 6.005 6.005 6.444 6.444 6.883 6.883
25
2.848 2.848 3.327 3.327 3.435 3.435 5.101 5.101 5.931 5.931 6.371 6.371 6.812 6.812
27
2.762 2.762 3.204 3.204 3.352 3.352 4.973 4.973 5.857 5.857 6.299 6.299 6.741 6.741
FROST REGION
ID DB°C
Outdoor WB°C
-9 -6 -5 6 12 15 18
