Industrial PCs MCR5000

REMOVING THE RETAINING CLIP

2) The battery is kept in place with a plugged in retaining clip. The retaining clip can be

removed from the battery compartment by carefully lifting the external tabs by using a

flat-bladed tool (screw driver).

EPLACING THE BATTERY

3) Now the lithium battery can be removed. It must be replaced by the same battery

type, only. The type of battery to be used is:

Saft LS 14250 / 1/2AA 3.6V 1000mAh / Lithium battery

Please observe the correct polarity when replacing the battery.

Warning:

There is a risk of explosion if the battery is replaced with the wrong type or with the

wrong polarity. Adhere to the valid regulations for environmentally-friendly disposal of

batteries if the battery has reached the end of its life cycle.
