Instructions / Assembly

Congratulations on purchasing this Hammock
Stand, We hope it provides hours of relaxation with
your hammock. If you have any questions
regarding this hammock stand please call our
customer service department at [phone].
Do Not Return to Retailer,
Please call customer service for missing parts.
Your box should contain:
2 – leg assemblies with elbow pipe.
2 – upright poles with attached S-hooks.
1- center base pole.
2 – hanging chains with attached S-hook.
Pole end caps and leg end caps have been pre-
attached for your convenience.
Upright poles have pre-attached S-hooks for your
convenience.
No-Tool-Assembly Instructions
1. Locate leg assemblies with attached elbow pipe and place on the ground.
2. Locate center base pole (pole without attached S-hook), and insert one end onto the horizontal end of the elbow pipe of one of the
leg assemblies by pressing down on the silver lock pin while pushing the center pole onto the elbow. Repeat procedure for other leg
assembly to the other end of the center pole. Figure 1. - - - make sure all lock pins fully engage by popping through the holes
in the center poles and upright poles as in Figure 2.
3. Locate either of the upright poles with S-Hook assembly. Place the non-capped end onto the upright elbow pipe of the leg assembly
making sure the silver lock pin fully engages the hole on the end of the pipe as shown in Figure 3. Repeat the procedure for the
other upright pole with S-hook.
4. Place one of two hanging chains onto each S-hook on each upright pole as shown in Figure 4. The S-hook on the end of each chain
is designed to attach to the O-rings on the end of your hammock. Adjust the height of the hammock to your liking by looping a
different link of chain onto the S-hook on each end of the stand.
CAUTION:
Before each use, examine the stand to make sure all poles are locked into place with the lock-pins fully engaged.
After moving or adjusting your hammock stand, always inspect it to make sure all pieces are properly in place and lock-pins are still
engaged.
Never Exceed the weight limit of 450 lbs. or the weight limit of your hammock.
Hammock stand should be placed on level ground for safe operation.
Try not to drag your stand. Have someone help you carry it by lifting from both ends.
CARE INSTRUCTIONS:
Your hammock stand has a powder coated finish to resist the elements. However you can extend the life of your stand by wiping off moisture
and not leaving it out in the elements in months you will not be using your hammock. When storing, please store in a dry location to prevent
rust.
Large Hammock 2-Pt Stand
Model # 4780
Assembly Instructions
Do not exceed load limit of 450lbs, or the
load limit on your hammock.
The Algoma Net Company, Div, of Gleason Corp.
1525Mueller St. Algoma, WI 54201
Email: [e-mail]
10/2011
Figure 1 Figure 2 Figure 3
Figure 4
