CG-WLBARGS Wireless 108M Broadband Router User Manual
Contents WLBARGS Manual 1. Product Introduction 1.1 Package Contents................................................................................... 3 1.2 Features..................................................................................................... 3 1.3 Hardware Introduction........................................................................ 4 2. Hardware Installation 2.1 WLBARGS should be connecting to PC and modem............ 5 2.2 Installation Procedure .........................
Contents WLBARGS Manual ...................................................... 30 ........................................... 33 ............................................. 34 ............................................................. 34 ................................................ 35 .................................................
1 Product Introduction WLBARGS Manual corega ‘s WLBARGS is an advanced model of broadband Router as well as an IEEE802.11g wireless access point which can speeds up to 108Mbps. Its management interface is straightforward for ease in setting up, while it supports various security features to effectively prevent hackers from attacking your networks, such as firewall, WPA, Mac Address filtering, VPN pass through, hidden ESSID and no respond to the WAN ping function.
WLBARGS Manual 1.3 Hardware Introduction Back Front 6 Bottom 1 2 3 4 AP R outer 7 11 5 8 9 10 1. Power LED (Green) Indicate power status 6. Detachable Antenna Connector 2.Status LED (Red) ON:Reboot/Hung up/FirmWare upgrade 7. LAN port(1-4) Connected with PC 3. WAN LED (Green) ON: Connected Blink:Transmitting or receiving data 8. WAN port Connected with modem 4. Wireless LED (Green) ON: Wireless function enable Blink:Transmitting or receiving data 5.
2 Hardware Installation WLBARGS Manual 2.1 WLBARGS should be connecting to PC and modem Following the steps below to set up WLBARGS and the connection. (1) Insert the cable connector into the Network Adapter embeded in PC, and insert the other side into one of LAN ports (1~4) of the Router. (2) Insert the connect into the WAN port of the Router and insert the other side into the WAN port of the modem. (3) Connect the Power Adapter, and plug in the AC power. Modem WAN LAN PC corega WLBARGS 2.
PC Setting WLBARGS Manual 3 3.1 TCP/IP Configuration The following steps and screenshots maybe dissimilar in different operating systems. This manual takes Windows XP/200, 95/98/ME, and Mac O/S as examples: 3.1.1 Windows XP O/S (1) Enter [Control Panel] -> click [Network Connection] -> right click and select [Open]. (2) Click [Local Area Connection] and right click and select [Properties].
WLBARGS Manual (3) Click [General] -> click [Internet Protocol (TCP/IP), and click [Properties]. (4) Click [General], select [Obtaining an IP Address Automatically], and [Obtain DNS Server address automatically], and press [Advance].
WLBARGS Manual (5) Click [DNS] tab, unselect [Register this connection’s address in DNS], and press [OK]. (6) Go back to [Internet Protocol TCP/IP] and press [OK]. (7) Press [OK] to close [Local Area Connection Properties]. 3.1.2 Windows 2000 O/S (1) Go to [My Computer], and enter [Control Panel], click open [Network and Dial Up Connections].
WLBARGS Manual (2) Right click [Local Area Connection], and select [Properties] *Note: Please check if TCP/IP had been installed in the [Local Area Connection]. If not, consult [Add TCP/IP] steps in this chapter. (3) Click [Internet protocol (TCP/IP)] and click [Properties].
WLBARGS Manual (4) Select [Obtain an IP address automatically], and [Obtain DNS server address automatically]. And click [Advance]. (5) Click [DNS] tab in [Advance TCP/IP setting] page, and unselect [Register this connection’s DNS address, and press [OK].
WLBARGS Manual 3.1.3 Windows 98/95/ME O/S The configurations in all Windows 98/95/ME are the same, and this manual takes Windows 98 as an example. (1) Enter [Control Panel], and double click [Network]. (2) Click [Configuration] tab, and select [TCP/IP], click [Properties]. (3) Select [IP Address], and select [Obtain IP address automatically. Press [OK].
WLBARGS Manual (4) Click [Gateway] tab, remove all the gateways, and press [OK] to close the window. (5) Go to [Network] and press [OK] to close the page. (6) The [Restart the windows] screen will pop-up, press [OK] to restart the PC. If the PC is not shown this message, restart the PC manually. 3.1.4 Mac OS 8.x~9.x O/S (1) Open the [TCP/IP] configuration from [Control Panel]. (2) Select [Ethernet Network] in the [connection methods]; select [DHCP server] in [Configuration], and close this page. 3.1.
WLBARGS Manual 3.2 Browser Configuration 3.2.1 Windows O/S The following examples are for Windows XP O/S, skip this chapter if you are using Windows 200/98/ME. (1) Open Internet Explorer (IE 6.0), select [Tools] menu and click [Internet Options]. If a [Dial-up Connection] window is pop-up, close it, and do not connect to the Internet now. (2) Click [Connections] tab -> select [Never dial a connection] -> click [LAN Settings].
WLBARGS Manual (3) Unselect all three options in the [Local Area Network LAN Setting]. (4) Press [OK] in the [Internet Options]. 3.2.2 Mac O/S (1) Open Internet Explorer (IE 5.0) Go to [Edit] in the menu bar, select [Internet Explorer Preferences]. (2) Select [Proxies] options in [Network] on the left-side configuration items. (3) Do not select [Web Proxy], press [OK].
4 Network Configuration WLBARGS Manual 4.1 Quick Network Configuration Basic configuration is required before connection your computer to the internet via WLBARGS. The connection methods may be differed by your contract to the ISP. Please reconfirm your connection conditions with your ISP prior to configure this router. The configuration procedures are as follow: *Note: Anti-virus or Firewall software may prevent this router from being set-up properly.
WLBARGS Manual (5) Please select your region. e.g.) Singapore. Click on [Save]. (6) Click [Quick Installation Setting], and click [Next] to enter the Setup Wizard. (7) When seeing this screen shot, click on [Next].
WLBARGS Manual (8) Select your connection type. Please make sure that your ADSL connection type is correct as you enter; the correct information can be obtained from the documents given by your ISP. If not, consult with your ISP before setting. 4.1.1 Auto obtain IP (DHCP) (1) If you are subscribing to auto obtain IP service ( or DHCP Dynamic IP) from your ISP, such as Cable Modem that obtain an IP automatically for connection, please select [Auto obtain IP(DHCP)]. Click on [Next].
WLBARGS Manual (2) Press [Mac address clone] to obtain the Ethernet card’s Mac address. Then press [Next]. (3) Click on [Save] to perform connection tests.
WLBARGS Manual (4) Within seconds, the result of the connection test will be appeared in the dialogue box to indicate the connection status. When [Connection ok] appears, click on [Close]. (5) Open the web browser (IE 6.0), and test with any website for testing the connection. * Note: if the connection to the website fails. Restart your Cable Modem, and check the installation of CG-WLABARGS properly, such as the LAN/WAN connections. After verifying that, restart this chapter again for installation. 4.1.
WLBARGS Manual (2) Configure the network setting provided by your ISP. Then click on [Next]. (3) Click on [Save] to perform connection tests.
WLBARGS Manual (4) Within seconds, the result of the connection test will be appeared in the dialogue box to indicate the connection status. When [Connection OK] appears, click on [Close]. (5) Open the web browser (IE 6.0), and test with any website for testing the connection. *Note: If the connection to the website fails. Please make sure the data you entered are correct , or any mistake occured in the process of the installation, such as the LAN/WAN connections.
WLBARGS Manual (2) Enter the username and password provided by your ISP, and click on [Next]. ＊Note: If you are a Hinet subscriber, type @hinet.net following the 8-digit account number, for instance: xxxxxxxx@hinet.net. Be careful, username and password are sensitive to capitals. (3) Click on [Save] to perform connection tests.
WLBARGS Manual (4) Within seconds, the result of the connection test will be appeared in the dialogue box to indicate the connection status. When [Connection OK] appears, click on [Close]. (5) Open the web browser (IE 6.0), and test with any website for testing the connection. *Note: If the connection to the website fails. Please make sure the data you entered are correct , or any mistake occured in the process of the installation, such as the LAN/WAN connections.
WLBARGS Manual Splitters Link to telephone Modem Power Adapter RJ-45 Hereunder is the setting on Centrino Notebook as an example, for wireless adapters in other brands, please refers to the original manuals. (1) Go [Control Panel] -> double click on [Network connection] -> right click on [Wireless Network Connection] -> select [properties] -> click on [Wireless Network] tab -> select [Use Windows to configure my wireless networks setting] , and press [OK].
WLBARGS Manual (2) Go [Control Panel] - [Network connection] again -> click [Wireless network connection] and hold right button to select [Available wireless network connection], choose one available network e.g. ) corega , and click [Connect]. (3) Connection status will appear in the bottom right of the screen.
WLBARGS Manual (2) Go [Control Panel] - [Network connection] again -> click [Wireless network connection] and hold Mouse’s right button to select [Available wireless network connection], e.g. ) corega , and click [Connect]. (3) Connection status will appear in the bottom right of the screen. *Note: The wireless connection has been established now. Please go to corega’s website at http://www.corega-asia.com to check the connection to the Internet.
5 Wireless Security Configuration WLBARGS Manual To prevent from unlawful access to your network, you are recommended to perform wireless security setting. Enter the function menu, ad click on [802.11g/b Security setting] item. And select WEP or WPA setting. 5.1 WEP Setting In order to prevent your information from being hacked, it is recommended to use WEP encryption when using wireless connection. (1) [Open System] or [Shared Key].Select [Open System] or [Share Key] from Authentication menu.
WLBARGS Manual (5) Recommended to keep default values of [DTIM] and [Preamble Mode]. (6) Save your settings by [Apply]. (7) Parameters can be output by [Output Info.] 5.2 WPA Setting WPA is encrypted by a periodic update, making it more difficult to be hacked. Home users and company users are recommended to use and respectively. (1) Select [WPA2-PSK] or [WPA/WPA2-PSK] in the column of [Authentication] (Recommended). a.
WLBARGS Manual (4) Recommended to keep default values of [DTIM]and [Rekey Interval]. (5) Press [Apply] to save setting. (6) Parameters can be output by [Output Info]. (1) Select [WPA2-EAP] or [WPA/WPA2-EAP](Recommended). in the column of [Authentication] a. [WPA2-EAP]: The 2nd generation encryption skill performs stricter protection than before. Before selection, please check the function availability of your network adapter, or select b. b.
Function Introduction WLBARGS Manual 6 The chapter will briefly introduce all functions of this product, and spell them out. Log in the management program and the below interface will appear. 6.1 Features Wireless Function Wireless Enable: enable the wireless function. Wireless Disable: disable the wireless function. The internet setting can be configured, according to your internet connection type, [Link connection speed] - default setting is recommended.
WLBARGS Manual A. For auto obtain IP (DHCP): Type Press [MAC clone] to obtain the Ethernet card's Mac address. Domain name Please refer to your ISP internet service information, add/edit [Domain name]. Computer name Please refer to your ISP internet service information, add/edit [Computer name]. MTU value Maximum Transmission Unit.deafault setting:1500 Byte. DNS server Select [Auto Setting] or [Manual Setting] to configure DNS1 and DNS2 servers. B.
WLBARGS Manual Username Password Confirm password Connection type MTU value DNS server C. For fixed IP 32 Please enter username, given by your ISP. Please enter password, given by your ISP. Please type your password again. [Auto Reconnect]: always on line (recommended). [On Demand]: connect when accessing to Internet. [manual connection]: manually connecting to internet. Maximum Transmission Unit. when [Auto Reconnect] is disable, MTU can be edited. Default setting: 1454 Byte.
WLBARGS Manual WAN ip address Subnet mask Default gateway MTU DNS server Please refer to your ISP internet service information. Maximum Transmission Unit. Deafault setting :1500 Byte. When [Manual Connection] is enable, two DNS server addresses can be inserted: DNS1 and DNS2 Dynamic DNS is a connection of LAN’s virtual server through URL internet access or called dynamic IP (No fixed IP address) that also can connect through URL internet access.
WLBARGS Manual (1) select available dynamic DNS services. (2) enter username for dynamic DNS. (3) enter passwod for dynamic DNS. (4) enter domain name. (5) IP update interval. (6) Click [Apply]. Direct PPPoE PPPoE pass-through function enable/disable. VPN pass through VPN pass-through function enable/disable. 34 LAN IP address The device ip address, not recommended to change this address.Default setting: [192.168.1.1].
WLBARGS Manual (1) Select [Enable] to enable DHCP server function. Default is [enable]. (2) Enter DHCP servers start ip and end ip. (3) Then click on save button to save the setting. the following table display the current connected users information, you can add/edit/delete users data. *Add a pc data : click on [add] to add a new user data.
WLBARGS Manual (1) Enter the pc name and select network connection type. (2) Configure the mac address data. (3) Click [Add PC Data] to complete the setting. ESSID Default ESSID is [corega]. Mode . 802.11b/g: auto connect in either 802.11b or 802.11g. . 802.11g: connect in 802.11g (54Mbps) mode. Channel When there is interruption, other channels can be selected. SuperG mode If your Wireless LAN Card supports Super G Mode transmit rate.
WLBARGS Manual Wireless to wireless communication Configure wireless communication between clients. [Enable]/[Disable]: enable or disable wireless communication between clients. Wireless to wire communication Configure wireless and wired communication between clients. [Enable]/[Disable]: enable or disable connection between wireless and wired communication. MAC address filter list Use MAC address filter to control network communication.
WLBARGS Manual (3) Select one of protocol. (4) Enter the range of limited port number. (5) Select one of the time schedule limitations. (6) After clicking on [Time Setting] button, a time schedule table is shown, once complete the setting, please click on [save] button to store the information. This function can forbid certain users or website on the network: (1) Enter filter description. (2) Enter the forbidden user ip range.
WLBARGS Manual Virtual server is an appointed port opened by the PC in connection with the product, allowing other users connecting up via WAN. Open servers or special online games can take advantage of this function. Setting processes are as follows: (1) Select a PC to be the virtual server. (2) Select Service. (3) Enter Port Range of internet connection with the server, and Port Range used by the server software. (4) Select Protocol.
WLBARGS Manual *Note: 1. The PC becomes vulnerable to being hacked if DMZ function starts. Please only use it in need. 2. The PC with DMZ function needs a fixed IP address. 3. DMZ function can only be used in one PC. Activating this function can detect the device or software of LAN, supporting UPnP. For example: online games supporting UPnP or Windows Messenger (Ver. 4.7 or above), MSN Messenger (Ver. 5.0 or above) and so forth. Set its status usable.
WLBARGS Manual Admin login name User name for login this management program. Default setting is [root]. Admin login password Default password is empty. Password comfirmation Please retype password. Connection Timeout Enter connection time-out time. Time setup The default value is [Auto Setup]. Back to default setting Click [Proceed] to restore all default values. Reboot New changes only effect after the system reboots. Save Setting Click [Save] to save your setting values as a file.
WLBARGS Manual *Remote control The setting allows accessing the management program via remote control. The activation processes are as follows: (1) Select [Enable]. (2) Indicate 1 ~ 9600 for parameters of port range. e.g. ) 8080 (Recommended keeping default values). (3) Click on [Apply] after completing settings. e.g. ) Assume the port value is 8080, enter IP address as the type : [http://xxx.xxx.xxx.xxx: 80] to access the management program by remote control.
WLBARGS Manual Connection status log is displayed in the table. Dos attack log is displayed in a table. DHCP server log is displayed in a table.
WLBARGS Manual System log is displayed in the table. An E-mail address can be set below. Special incidents will be recorded and sent to the appointed E-mail address. After entering all information, click [Save] to save and complete the setting. 6.2 Additional Functions Besides the functions displayed in the tables, there are some additional features available to set up. Please open the IE browser and enter 192.168.1.1/ core_rc.
WLBARGS Manual Two DNS server addresses can be set in the table. If the primary DNS server does not function, the system will use them as secondary addresses. Add/ Edit/ Delete static router can be set in the table. After key-in of static router information, click [Save]. The setting log will be displayed afterward. The table allows dynamic routing setting.
AP/Router Switching WLBARGS Manual 7 If you would like to use AP (Access Point) function, please use the switch button in the bottom of the product. The operations are as the below: (1) Cut off the power. (2) Switch AP/Router to the left (AP side). AP R outer (3) Plug in the product. (4) Now the product is in AP mode. Open browser to access setting page and enter [192.168.1.220] into the address bar, then press [Enter]. ** Warrning ** This is a special application.
8 FAQ WLBARGS Manual When the installation fails or the connection doesn’t succeed, it’s recommended to take the following actions against the problems. (1) Find your problem in the troubleshooting collection. (2) Go to our official website at http://www.corega-asia.com, then click [Support] and click the [Online Customer Support] item. To fill the form page and note following information We will contact you as soon as possible. • Product name: e.g.
WLBARGS Manual (9) Are the settings of your web browser correct? Q2. Not able to log in the management program. A: You have 4 ways to check and solve the problem: (1) Close and re-open the IE browser and login the program again. (2) Log out and re-login the Windows OS. Then login the program again. (3) Probably the management program is accessed from the other user. Wait until that user exits the program. (4) Reset to default settings (Refer to Q8. for more details) and re-login the program. Q3.
WLBARGS Manual (1) Click [Start] => Click [Run]. (2) Input [winipcfg] in the column => press [Enter]. (3) Select your network adapter to display IP address. The IP should be 192.168.1. x ,if none, please click [Release] => Click [Renew]. Q7. How to reboot the product? A: Reboot to get new setting values applied. The steps are as follows: open the management program-> Click on [Management]-> Click on [Proceed] in the [Reboot] column.
Specifications WLBARGS Manual 9 Compliance Standard WLAN: IEEE802.11/IEEE802.11b/IEEE802.11g LAN: IEEE802.3/IEEE802.3u/IEEE802.3x Interface WAN: 10/100Mbps x 1 Port (RJ-45, Auto MDI/MDI-X) LAN: 10/100Mbps x 4 Ports (RJ-45, Auto MDI/MDI-X) Frequency Band 2.412~2.462 GHz Transmission speed IEEE802.11b: 11/5.5/2/1Mbps IEEE802.11g: 54/48/36/24/18/12/9/6Mbps Transmission Power 11b: 19.8 dBm / 11g: 20.
About corega WLBARGS Manual corega可瑞加科技於1996年成立於日本新橫濱，致力於提供多元化的家用 網路產品：包括乙太網路交換器、無線區域網路系列產品、路由器、藍芽 系列產品、以及與網路相關的產品應用及服務。corega目前已是日本專業 家用網路產品的暢銷品牌，並且於 2002年2月於台北成立可瑞加科技，專 注於台灣市場推廣高品質的日系家用網路設備。corega以使用者的需求導 向為最重要的營運方針，多樣化的產品行銷以及通路服務營造corega為最 親切適用的家庭網路設備第一品牌！ 竭誠感謝您購買corega可瑞加系列產品，期待本產品為您帶來更快速便捷 的連線體驗，更期盼日後您家用網路擴充/升級的機會，corega能繼續陪 伴您！ corega K.K.
Appendix WLBARGS Manual Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
