AP1600R-E2 (CS3) 1U Rackmount Barebone Server User Guide
E1643 First Edition V1 January 2005 Copyright © 2005 ASUSTeK COMPUTER INC. All Rights Reserved. No part of this manual, including the products and software described in it, may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except documentation kept by the purchaser for backup purposes, without the express written permission of ASUSTeK COMPUTER INC. (“ASUS”).
Contents Notices ............................................................................................... vii Safety information ............................................................................ viii About this guide ................................................................................. ix Chapter 1: Product introduction ....................... 1 - 1 1.1 System package contents .................................................... 1-2 1.2 System specifications ...............
2.7 2.8 Cable connections .............................................................. 2-18 2.7.1 Motherboard ......................................................... 2-19 2.7.2 SCSI backplane ..................................................... 2-20 Removable components ..................................................... 2-21 2.8.1 System/Device fans ............................................. 2-21 2.8.2 Power supply module ............................................ 2-23 2.8.
.3 5.4 5.5 5.6 5.7 Main menu .......................................................................... 5-14 5.3.1 System Time [xx:xx:xxxx] ..................................... 5-14 5.3.2 System Date [Day xx/xx/xxxx] ............................ 5-14 5.3.3 Legacy Diskette A [1.44M, 3.5 in.] ...................... 5-14 5.3.4 Primary, Third and Fourth IDE Master/Slave ......... 5-15 5.3.5 IDE Configuration .................................................. 5-17 5.3.6 System Information .....
Notices Federal Communications Commission Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
Safety information Electrical Safety • Before installing or removing signal cables, ensure that the power cables for the system unit and all attached devices are unplugged. • To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. • When adding or removing any additional devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected.
About this guide Audience This user guide is intended for system integrators, and experienced users with at least basic knowledge of configuring a server. Contents This guide contains the following parts: viii 1. Chapter 1: Product Introduction This chapter describes the general features of the server, including sections on front panel and rear panel specifications. 2.
Conventions To make sure that you perform certain tasks properly, take note of the following symbols used throughout this manual. W A R N I N G : Information to prevent injury to yourself when trying to complete a task. C A U T I O N : Information to prevent damage to the components when trying to complete a task. I M P O R T A N T : Instructions that you MUST follow to complete a task. N O T E : Tips and information to aid in completing a task.
x
This chapter describes the general features of the chassis kit. It includes sections on front panel and rear panel specifications.
1.1 System package contents The items in the ASUS AP1600R-E2 (CS3) product package vary depending on the model your purchased. Check your package for the standard items listed in the following table.
1.2 System specifications The ASUS AP1600R-E2 (CS3) is a 1U barebone server system featuring the ASUS NCL-DS1R1 motherboard. The server supports dual Intel® Xeon™ processors, and includes the latest technologies through the chipsets embedded on the motherboard.
1.3 Front panel features The barebone server displays a simple yet stylish front panel with easily accessible features. The power and reset buttons, LED indicators, location switch, optical drive, and two USB ports are located on the front panel. Refer to section “1.6.1 Front panel LEDs” for the LED descriptions.
1.4 Rear panel features The rear panel includes the expansion slot, system power socket, and rear fans. The middle part includes the I/O shield with openings for the rear panel connectors on the motherboard. The ports for the PS/2 keyboard, PS/2 mouse, USB, VGA, and Gigabit LAN do not appear on the rear panel if motherboard is not present. Expansion slot LAN port1 LAN port2 VGA port Serial port USB ports PS/2 keyboard port PS/2 mouse port Rear fans AC power socket Refer to section “1.6.
1.5 Internal features The barebone server includes the basic components as shown. 2 1 3 4 7 6 5 8 9 10 11 13 12 1-6 1. PCI-X riser card bracket 7. Device fan 2. Rear fans 8. SCSI backplane 3. ASUS NCL-DS1R1 motherboard 9. Hot-swap HDD tray 1 10. Hot-swap HDD tray 2 4. Power supply 11. Hot-swap HDD tray 3 5. Device fan 12. Slim optical drive 6. System fans (8 fans) 13.
1.6 LED information 1.6.
1.6.
This chapter lists the hardware setup procedures that you have to perform when installing or removing system components.
2.1 Chassis cover 2.1.1 Removing the cover 1. Use a Phillips screwdriver to remove the screw on each front end of the top cover. Thumbscrews 2. Loosen the two thumbscrews on the rear panel to release the top cover from the chassis. 3. Firmly hold the cover and slide it toward the rear panel for about half an inch until it is disengaged from the chassis. 1/2 inch distance 4. 2-2 Lift the cover from the chassis.
2.1.2 1. Installing the cover Position the cover on top of the chassis with the thumbscrews on the rear, and leaving a gap of about half an inch from the front panel. Side markings 2. Make sure that the side markings on the cover (two on each side) are aligned to the grooves on the chassis. Grooves 3. Slide the cover toward the front until it snaps in place. 4. Tighten the thumbscrews on the rear to secure the cover.
2.2 Central Processing Unit (CPU) The motherboard comes with surface mount 604-pin Zero Insertion Force (ZIF) sockets. The sockets are designed for the Intel® Xeon™ processor in the 604-pin package with 1 MB L2 cache. The new generation Xeon™ processor supports 800 MHz system bus and Extended Memory 64-bit Technology (EM64T). Gold Arrow Pin A1 NCL-DS1R1 ® Intel Xeon NCL-DS1R1 CPU Socket 604 The motherboard supports either one or two CPUs.
3. Position the CPU above the socket as shown. 4. Carefully insert the CPU into the socket until it fits in place. The CPU fits only in one correct orientation. DO NOT force the CPU into the socket to prevent bending the pins and damaging the CPU! Marked corner (gold arrow) 5. Carefully push down the socket lever to secure the CPU. The lever clicks on the side tab to indicate that it is locked. 6. Apply the thermal interface material (thermal grease) to the top of the CPU.
2.2.2 Installing the CPU heatsink To install the CPU heatsink: 2-6 1. Carefully place the heatsink on top of the installed CPU. 2. Twist each of the four screws with a Philips (cross) screwdriver just enough to attach the heatsink to the motherboard. When the four screws are attached, tighten them one by one to completely secure the heatsink. 3. Follow steps 1 and 2 to install the second CPU heatsink.
2.4 System memory 2.4.1 Overview The motherboard comes with four Double Data Rate (DDR) Dual Inline Memory Modules (DIMM) sockets. 104 Pins 80 Pins NCL-DS1R1 ® DIMM_B4 DIMM_A4 DIMM_B3 DIMM_A3 DIMM_B2 DIMM_A2 DIMM_B1 DIMM_A1 NCL-DS1R1 184-pin DDR DIMM sockets 2.4.2 Memory configurations You may install 256 MB, 512 MB, 1 GB, and 2 GB registered ECC DDR DIMMs into the DIMM sockets. • Always install DIMMs with the same CAS latency.
2.4.3 Installing a DIMM Make sure to unplug the power supply before adding or removing DIMMs or other system components. Failure to do so may cause severe damage to both the motherboard and the components. 2 1. Unlock a DIMM socket by pressing the retaining clips outward. 2. Align a DIMM on the socket such that the notch on the DIMM matches the break on the socket. DDR DIMM notch 1 1 Unlocked retaining clip A DDR DIMM is keyed with a notch so that it fits in only one direction.
2.4 Hot-swap hard disk drives To install a hot-swap HDD: 1. Release a drive tray by pushing the spring lock to the right, then pulling the tray lever outward. The drive tray ejects slightly after you pull out the lever. 2. Firmly hold the tray lever and pull the drive tray out of the bay. 3. Take note of the drive tray holes. Each side has three holes to fit different types of hard disk drives. Use two screws on each side to secure the hard disk drive. 4.
5. Carefully insert the drive tray and push it all the way to the depth of the bay until just a small fraction of the tray edge protrudes. SCSI interface on the backplane inside the system When installed, the SCSI connector on the drive connects to the SCSI interface on the backplane. 6. Push the tray lever until it clicks, and secures the drive tray in place. The drive tray is correctly placed when its front edge aligns with the bay edge. 7.
2.5 Expansion slot The barebone server comes with a riser card bracket installed on the 64-bit expansion slot. You need to remove the bracket if you wish to install a PCIX expansion card. 2.5.1 Installing a short expansion card To install a short expansion card: 1. Use a Phillips (cross) screwdriver to remove the screw that secures the riser card to the chassis. 2. Firmly hold a riser card bracket, then pull it up to detach it from the PCI-X slot on the motherboard. 3.
5. Take note of the holes on the riser card bay. The two pegs on the riser card bracket should match these holes to ensure that the bracket is properly in place. Peg on the riser card bracket 6. Install the riser card bracket with the card into the PCI-X slot on the motherboard. 7. Make sure that the golden connectors completely fit the slot and the bracket aligns with the rear panel. 8. Secure the riser card bracket to the chassis with the screw that you removed earlier. 9.
2.5.2 Installing a long expansion card To install a long expansion card: 1. Follow steps 1 to 3 in “2.5.2 Installing a short expansion card.” 2. Press the end of the plastic long card lock, then pull it up. 3. Connect a card extension to the long card using two screws. (This card extension usually comes with the card package). Card extension 4. Install the long PCI-X card to the bracket as shown, then secure the card with a screw. 5.
7. Secure the riser card bracket to the chassis with the screw that you removed earlier. 8. Hold the end of the card lock and flip it over the card extension to lock the card in place. The long card and lock appear as shown when properly installed.
2.5.3 Configuring an expansion card After installing the expansion card, configure the it by adjusting the software settings. 1. Turn on the system and change the necessary BIOS settings, if any. See Chapter 5 for information on BIOS setup. 2. Assign an IRQ to the card. Refer to the following tables. 3. Install the software drivers for the expansion card.
2.6 External SCSI port The barebone system includes a slot on the rear panel for the external SCSI port. You need to install the SCSI cable that came with your system package if you wish to connect additional SCSI drives. External SCSI slot 2.6.1 Removing the slot cover To remove the external SCSI slot cover, insert the end of a flat screw driver into the hole at the center of the slot cover to knock it out. The slot opening appears as shown after you have removed the slot cover.
2.6.2 Installing the external SCSI cable To install the external SCSI cable: 1. Locate the SCSI-B connector on the motherboard, and connect one end (with the white tab) of the SCSI cable. 2. Remove the two screws on the other end (external SCSI port) of the cable, and set them aside. Pin 1 Screws 3. Insert the external SCSI port into the slot opening on the rear panel. 4. Secure the port with the two screws that you removed earlier.
2.7 Cable connections 1 2 3 5 6 7 4 8 9 10 11 12 14 13 15 16 Pre-connected system cables Description From To 1. Rear fan 1 cable Rear fan MB REAR_FAN1 conn. 2. Rear fan 2 cable Rear fan MB REAR_FAN2 conn. 3. 24-pin SSI power cable Power supply MB ATXPWR1 conn. 4. 8-pin SSI power cable Power supply MB ATX12V1 conn. 5. Backplane SMBus cable MB BPSMB1 conn. BP J1 conn. 6. Floppy disk cable MB FLOPPY1 conn. BP FLOPPY1 conn. 7.
Motherboard 2.7.1 The following illustration describes the cables for the specific connectors on the motherboard.
2.7.2 SCSI backplane The following illustration describes the cables/devices that are connected to the SCSI backplane board.
2.8 Removable components You may need to remove previously installed system components when installing or removing system devices, or when you need to replace defective components. This section tells how to remove the following components: 1. System/Device fans 2. Power supply module 3. Optical drive 4. Floppy disk drive 2.8.1 System/Device fans The eight (8) system fans and two device fans come in a screw-less design. To uninstall a fan or pair of system fans: 1.
To install a fan or pair of system fans: 1. Hold the plastic flap and position the fan over a fan compartment. Carefully insert the fan, or pair of fans, until it fits in place. 2. Connect the corresponding fan cable from the connector on the backplane board.
2.8.2 Power supply module To remove the power supply module: 1. Disconnect all the power supply plugs connected to all the system devices. Refer to section “2.7 Cable connections” for the locations of pre-connected cables. 2. Disconnect the main power cable from the rear of the power supply. Main power cable Screw 3. Use a Phillips screwdriver (cross) to remove the four screws that secure the power supply to the chassis. 4. Carefully lift the power supply module from the chassis.
2.8.3 Optical drive To uninstall the slim optical drive: 1. Use a Phillips screwdriver (cross) to remove the screw that secures the drive. 2. Disconnect the IDE cable and the 4-pin power plug from the connectors on the back of the drive. 3. Carefully slide the optical drive inward for about half an inch, then lift it out of the bay. 4. Remove the screws that secure the optical drive to its metal bracket. 2.8.4 Floppy disk drive To uninstall the floppy disk drive: 1.
This chapter describes how to install the optional components and devices into the barebone server.
3.1 Rackmount rail kit items If you have the rackmount rail kit, it contains two pairs of rails (one pair for each side of the barebone system), and eight (8) pairs of nut-and-bolt type screws. Nuts Bolts Left pair Right pair 3.2 Rack rails assembly To assemble the rack rails: 1. Determine the depth of the rack where you wish to install the system. 2. Match one long and one short rail to your desired length, and fix them together using four (4) pairs of nuts and bolts. 3.
3.3 Attaching the rails to the rack To attach the rails to the rack: 1. Select one unit of space (1U) on the rack where you wish to install the barebone server. 2. Remove the screws from the 1U space on the rack front. 1U space 3. Align the front end holes of a rack rail pair to the 1U space. 4. Drive in two screws on the outer holes to secure the front end. 5. Find the r e a r 1 U s p a c e that corresponds to the f r o n t 1 U s p a c e where you attached the rail. 6.
3.4 Rackmounting the server To mount the server to the rack: 1. Firmly hold the server on both sides and insert the rear panel side to the front end of the rack rail, then carefully push the server all the way to the back until the front panel fits the front end of the rack, and the rack screws on the server match the middle hole on the rack.. 2. Tighten the two rack screws to secure the server to the rack.
This chapter includes the motherboard layout, and brief descriptions of the jumpers and internal connectors.
4.
Layout contents Switches and jumpers Page DIP switch (DSW1) 4-4 SCSI controller setting (3-pin SCSI_EN1) 4-4 Clear RTC RAM (CLRTC1) 4-5 CPU fan pin selection (3-pin FM_CPU1, FM_CPU2) 4-6 USB device wake-up (3-pin USBPW12, USBPW34) 4-6 Keyboard power (3-pin KBPWR1) 4-7 Gigabit LAN1 controller setting (3-pin LAN_EN1) 4-7 Gigabit LAN2 controller setting (3-pin LAN_EN2) 4-8 Integrated graphics controller (3-pin VGA_EN1) 4-8 Force BIOS recovery (3-pin RECOVERY) 4-9 Internal connectors Page
4.2 Switches and jumpers 4.2.1 Switches The DIP switches (DSW1) allow you to select either DDR333 or DDR266 memory speed depending on the installed DDR DIMMs. 1 2 3 4 5 ON DDR 333 setting ON NCL-DS1R1 1 2 3 4 5 ® DSW1 DDR 266 setting NCL-DS1R1 CPU external frequency selection 4.2.2 SCSI controller setting (3-pin SCSI_EN1) This jumper allows you to enable or disable the onboard Adaptec AIC-7902W SCSI U320 controller.
2. Clear RTC RAM (CLRTC1) This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can clear the CMOS memory of date, time, and system setup parameters by erasing the CMOS RTC RAM data. The onboard button cell battery powers the RAM data in CMOS, which include system setup information such as system passwords. To erase the RTC RAM: 1. Turn OFF the computer and unplug the power cord. 2. Remove the onboard battery. 3. Move the jumper cap from pins 1-2 (default) to pins 2-3.
3. CPU fan pin selection (3-pin FM_CPU1, FM_CPU2) These jumpers allow you to connect either a 3-pin or a 4-pin CPU fan cable plug to the CPU fan connectors (CPU_FAN1, CPU_FAN2). Set these jumpers to pins 1-2 if you are using a 3-pin fan cable plug, or to pins 2-3 if you are using a 4-pin plug. FM_CPU1 NCL-DS1R1 ® 2 1 DC mode (Default) 3 2 PWM FM_CPU2 2 1 DC mode (Default) NCL-DS1R1 FM_CPU setting 4.
5. Keyboard power (3-pin KBPWR1) This jumper allows you to enable or disable the keyboard wake-up feature. Set this jumper to pins 2-3 (+5VSB) to wake up the computer when you press a key on the keyboard (the default is the Space Bar). This feature requires an ATX power supply that can supply at least 1A on the +5VSB lead, and a corresponding setting in the BIOS. KBPWR1 NCL-DS1R1 ® 1 2 +5V (Default) 2 3 +5VSB NCL-DS1R1 Keyboard power setting 6.
Gigabit LAN2 controller setting (3-pin LAN_EN2) This jumper allows you to enable or disable the Intel® 82541GI Gigabit LAN controller (32-bit) that controls the LAN2 port. Place a jumper cap on pins 1-2 to activate the Gigabit LAN2 controller. LAN2_EN1 NCL-DS1R1 ® 7. 2 1 Enable (Default) 3 2 Disable NCL-DS1R1 LAN2_EN setting 8. Integrated graphics controller (3-pin VGA_EN1) NCL-DS1R1 ® This jumper allows you to enable or disable the onboard graphics controller.
9. Force BIOS recovery (3-pin RECOVERY) This jumper allows you to update or recover the BIOS settings when it gets corrupted or destroyed.This jumper allows you to update/recover the BIOS quickly. To update the BIOS: Prepare a floppy disk that contains the latest BIOS for the motherboard (xxxx-xxx.BIN) and the AWDFLASH.EXE utility. 2. Set the jumper to pins 2-3. 3. Insert the floppy disk, then turn on the system to update the BIOS. 4. Shut down the system. 5. Set the jumper back to pins 1-2. 6.
4.3 1. Connectors Floppy disk drive connector (34-1 pin FLOPPY) This connector is for the provided floppy disk drive (FDD) signal cable. Insert one end of the cable to this connector, then connect the other end to the signal connector at the back of the floppy disk drive. NCL-DS1R1 ® Pin 5 on the connector is removed to prevent incorrect cable connection when using a FDD cable with a covered Pin 5. FLOPPY1 PIN 1 NOTE: Orient the red markings on the floppy ribbon cable to PIN 1.
3. Serial ATA connectors (7-pin SATA1, SATA2) These connectors are for the Serial ATA signal cables for Serial ATA hard disk drives. If you installed Serial ATA hard disk drives, you can create a RAID 0 or RAID 1 configuration with the Adaptec® HostRAID™ technology supported by the Intel® 6300ESB South bridge chip.
4. Ultra320 SCSI connectors (two 68-pin SCSIA1, SCSIB1) This motherboard comes with the Adaptec® AIC-7902 SCSI U320 controller that support two 68-Pin Ultra320 SCSI connectors, one for each of the two channels. Each channel can support a maximum of 15 devices as specified by Ultra320 standards.
5. Hard disk activity LED connector (4-pin HDLED1) For some storage cards, such as SCSI card, with access signals for external LEDs, this connector allows the access signals to go through the front panel IDE_LED lead. HDLED1 NCL-DS1R1 ® SCSI_ACTLED+ SCSI_ACTLEDSCSI_ACTLEDSCSI_ACTLED+ 1 NCL-DS1R1 SCSI/SATA card activity LED connector 6. CPU and system fan connectors (4-pin CPU_FAN1/2, 3-pin REAR_FAN1/2, FRNT_FAN1/2) The fan connectors support cooling fans of 350 mA ~ 740 mA (8.88 W max.
7. USB port connector (10-1 pin USB34) This connector is for additional USB 2.0 ports. Connect the USB module cable to this connector, then install the module to a slot opening at the back of the system chassis. NCL-DS1R1 ® GND USB PortA(+) USB PortA(-) Power Never connect a 1 3 9 4 c a b l e to the USB connectors. Doing so will damage the motherboard! 1 NC GND USB PortB(+) USB PortB(-) Power USB34 NCL-DS1R1 USB connector The USB port module is purchased separately. 8.
S S I power connectors (24-pin ATXPWR1, 8 8-- p i n A T X 1 2 V 1 1)) These connectors are for SSI power supply plugs. The power supply plugs are designed to fit these connectors in only one orientation. Find the proper orientation and push down firmly until the connectors completely fit. • Use of an SSI 12 V Specification 2.0-compliant power supply unit (PSU) that provides a minimum power of 450 W is recommended for a fully-configured system.
NCL-DS1R1 ® I2C_7_CLK# I2C_7_DATA# NC GND +3.3V Remote Sense 1 0 . Power supply SMBus connector (5-pin PSUSMB1) This connects SMBus (System Management Bus) devices to the power supply unit. Devices communicate with an SMBus host and/or other SMBus devices using the SMBus interface. PSUSMB1 NCL-DS1R1 Power supply SMBus connector 1 1 . Backplane SMBus connector (6-1 pin BPSMB1) This connector allows you to connect SMBus (System Management Bus) devices.
BMCCONN1 +5VSB +5VSB BMC SMBDATA 12CDATA1 FP_PWRBTN# BMC_PRESENT# BMC_SMI# GND NCL-DS1R1 ® +5VSB +5VSB BMC SMBCLK 12CCLK1 PSON# BMC_RST# PWROK PSONEN# 1 2 . BMC connector (16-pin BMCCONN1) This connector is for the optional ASUS server management card. NCL-DS1R1 BMC connector 1 3 . Auxiliary panel connector (20-pin AUX_PANEL1) This connector is for additional front panel features including front panel SMB, locator LED and switch, chassis intrusion, and LAN LEDs.
1 4 . System panel connector (20-pin PANEL1) NCL-DS1R1 ® POWERLED+ NC POWERLEDMLED+ MLEDNC +5V GND GND SPKROUT This connector supports several chassis-mounted functions. NCL-DS1R1 System panel connector NMIBTN# GND POWERBTN# GND NC RESETBTN# GND HDLED+ HDLED- PANEL1 The sytem panel connector is color-coded for easy connection. • • • • • • • 4-18 System power LED (Green 3-pin PLED) This 3-pin connector is for the system power LED. Connect the chassis power LED cable to this connector.
Chapter 5 BIOS setup This chapter lists the hardware setup procedures that you have to perform when installing or removing system components.
5.1 Managing and updating your BIOS The following utilities allow you to manage and update the motherboard Basic Input/Output System (BIOS) setup. 1. 2. 3. A S U S A F U D O S (Updates the BIOS in DOS mode using a floppy disk.) A S U S C r a s h F r e e B I O S 2 (Updates the BIOS using a bootable floppy disk or the motherboard support CD when the BIOS file fails or gets corrupted.) A S U S U p d a t e (Updates the BIOS in Windows® environment.
Windows® 2000 environment To create a set of boot disks for Windows® 2000: a. Insert a formatted, high density 1.44 MB floppy disk into the drive. b. Insert the Windows® 2000 CD to the optical drive. c. Click S t a r tt, then select R u n n. d. In the O p e n field, type D:\bootdisk\makeboot a: assuming that D is your optical drive letter. e. Press , then follow screen instructions to continue. 2. Copy the original or the latest motherboard BIOS file to the bootable floppy disk. 5.1.
3. Press . The utility copies the current BIOS file to the floppy disk. A:\>afudos /oOLDBIOS1.rom AMI Firmware Update Utility - Version 1.19(ASUS V2.07(03.11.24BB)) Copyright (C) 2002 American Megatrends, Inc. All rights reserved. Reading flash ..... done Write to file...... ok A:\> The utility returns to the DOS prompt after copying the current BIOS file. Updating the BIOS file To update the BIOS file using the AFUDOS utility: 1. Visit the ASUS website (www.asus.
4. The utility verifies the file and starts updating the BIOS. A:\>afudos /iNCLDS1R1.ROM /pbnc AMI Firmware Update Utility - Version 1.19 (ASUS V2.07(03.11.24BB)) Copyright (C) 2002 American Megatrends, Inc. All rights reserved. WARNING!! Do not turn off power during flash BIOS Reading file ....... done Reading flash ...... done Advance Check ...... Erasing flash ...... done Writing flash ...... 0x0008CC00 (9%) Do not shut down or reset the system while updating the BIOS to prevent system boot failure! 5.
5.1.3 ASUS CrashFree BIOS 2 utility The ASUS CrashFree BIOS 2 is an auto recovery tool that allows you to restore the BIOS file when it fails or gets corrupted during the updating process. You can update a corrupted BIOS file using the motherboard support CD or the floppy disk that contains the updated BIOS file. • Prepare the motherboard support CD or the floppy disk containing the updated motherboard BIOS before using this utility.
Recovering the BIOS from the support CD To recover the BIOS from the support CD: 1. Remove any floppy disk from the floppy disk drive, then turn on the system. 2. Insert the support CD to the optical drive. 3. The utility displays the following message and automatically checks the floppy disk for the original or updated BIOS file. Bad BIOS checksum. Starting BIOS recovery... Checking for floppy...
5.1.4 ASUS Update utility The ASUS Update is a utility that allows you to manage, save, and update the motherboard BIOS in Windows® environment. The ASUS Update utility allows you to: • Save the current BIOS file • Download the latest BIOS file from the Internet • Update the BIOS from an updated BIOS file • Update the BIOS directly from the Internet, and • View the BIOS version information. This utility is available in the support CD that comes with the motherboard package.
Updating the BIOS through the Internet To update the BIOS through the Internet: 1. Launch the ASUS Update utility from the Windows® desktop by clicking Start > Programs > ASUS > ASUSUpdate > ASUSUpdate e. The ASUS Update main window appears. 2. Select U p d a t e B I O S f r o m t h e I n t e r n e t option from the drop-down menu, then click N e x tt. ASUS AP1600R-E2 (CS3) 3. Select the ASUS FTP site nearest you to avoid network traffic, or click A u t o S e l e c tt. Click N e x tt.
4. From the FTP site, select the BIOS version that you wish to download. Click Next. 5. Follow the screen instructions to complete the update process. The ASUS Update utility is capable of updating itself through the Internet. Always update the utility to avail all its features. Updating the BIOS through a BIOS file To update the BIOS through a BIOS file: 1. 2.
5.2 BIOS setup program This motherboard supports a programmable firmware chip that you can update using the provided utility described in section “5.1 Managing and updating your BIOS.” Use the BIOS Setup program when you are installing a motherboard, reconfiguring your system, or prompted to “Run Setup”. This section explains how to configure your system using this utility. Even if you are not prompted to use the Setup program, you can change the configuration of your computer in the future.
5.2.1 BIOS menu screen Menu items Configuration fields Menu bar System Time System Date Legacy Diskette A Primary IDE Master Primary IDE Slave Third IDE Master Third IDE Slave Fourth IDE Master Fourth IDE Slave IDE Configuration : : : : : : [11:10:19] [Fri 08/06/2004] [1.44M, 3.5 in] Use [ENTER], [TAB] or [SHIFT-TAB] to select a field. [ST320413A] [ASUS CD-S520/A] [Not Detected] [Not Detected] [Not Detected] [Not Detected] Use [+] or [-] to configure system time.
5.2.4 Menu items The highlighted item on the menu bar displays the specific items for that menu. For example, selecting M a i n shows the Main menu items. The other items (Advanced, Power, Boot, and Exit) on the menu bar have their respective menu items. 5.2.5 System Time System Date Legacy Diskette A Primary IDE Master Primary IDE Slave Third IDE Master Third IDE Slave Fourth IDE Master Fourth IDE Slave IDE Configuration System Information [11:51:19] [Thu 05/07/2004] [1.44M, 3.
5.3 Main menu When you enter the BIOS Setup program, the M a i n menu screen appears, giving you an overview of the basic system information. Refer to section “5.2.1 BIOS menu screen” for information on the menu screen items and how to navigate through them. System Time System Date Legacy Diskette A Primary IDE Master Primary IDE Slave Third IDE Master Third IDE Slave Fourth IDE Master Fourth IDE Slave IDE Configuration : : : : : : [11:10:19] [Fri 08/06/2004] [1.44M, 3.
5.3.4 Primary, Third and Fourth IDE Master/Slave The BIOS automatically detects the connected IDE devices. There is a separate sub-menu for each IDE device. Select a device item, then press to display the IDE device information. Primary IDE Master Device : Hard Disk Vendor : ST320413A Size : 20.
PIO Mode [Auto] Selects the PIO mode. Configuration options: [Auto] [0] [1] [2] [3] [4] DMA Mode [Auto] Selects the DMA mode. Configuration options: [Auto] SMART Monitoring [Auto] Sets the Smart Monitoring, Analysis, and Reporting Technology. Configuration options: [Auto] [Disabled] [Enabled] 32Bit Data Transfer [Disabled] Enables or disables 32-bit data transfer.
5.3.5 IDE Configuration The items in this menu allow you to set or change the configurations for the IDE devices installed in the system. Select an item then press if you wish to configure the item. IDE Configuration Onboard IDE Operate Mode Enhanced Mode Support On Configure S-ATA as RAID IDE Detect Time Out (Sec) [Enhanced Mode] [S-ATA] [No] [35] When in AHCI/RAID mode SATA controller is forced to Native mode.
5.3.6 System Information This menu gives you an overview of the general system specifications. The BIOS automatically detects the items in this menu. AMIBIOS Version : 08.00.10 Build Date : 07/23/04 Processor Type Speed Count : Intel(R) Xeon(TM) CPU 2.
5.4 Advanced menu The Advanced menu items allow you to change the settings for the CPU and other system devices. Take caution when changing the settings of the Advanced menu items. Incorrect field values can cause the system to malfunction. USB Configuration MPS Configuration Remote Access Configuration Configure the USB support. CPU Configuration Chipset Onboard Devices Configuration PCI PnP 5.4.1 USB Configuration The items in this menu allows you to change the USB-related features.
USB Function [4 USB Ports] Allows you to enable a specific number of USB ports, or disable the USB function. Configuration options: [Disabled] [2 USB Ports] [4 USB Ports] Legacy USB Support [Auto] Allows you to enable or disable support for legacy USB devices. Setting to [Auto] allows the system to detect the presence of legacy USB devices at startup. If detected, the USB controller legacy mode is enabled. If no legacy USB device is detected, the legacy USB support is disabled.
Emulation Type [N/A] When set to Auto, USB devices less than 530MB will be emulated as floppy drive, and the remaining drives as hard drives. Forced FDD option can be used to force an HDD formatted drive to boot as FDD (for example, ZIP drive). The Device and Emulation Type items appear only when there are installed USB devices. 5.4.2 MPS Configuration The items in this menu allows you to configure the Multi-Processor Table. Select an item then press to display the configuration options.
5.4.3 Remote Access Configuration The items in this menu allows you to configure the Remote Access features. Select an item then press to display the configuration options. Configure Remote Access type and parameters Remote Access Select Remote Access type. [Disabled] Remote Access [Disabled] Enables or disables the remote access feature. Configuration options: [Disabled] [Enabled] 5.4.
Execute Disable Function [Enabled] Configuration options: [Disabled] [Enabled] Enhance C1 Control [Auto] Configuration options: [Auto] [Disabled] CPU Internal Thermal Control [Auto] Configuration options: [Auto] [Disabled] Intel(R) SpeedStep Tech [Automatic] Configuration options: [Automatic] [Maximum Speed] [Minimum Speed] [Disabled] 5.4.5 Chipset The Chipset menu allows you to change the advanced chipset settings. Select an item then press to display the sub-menu. Options for NB.
NorthBridge Configuration The NorthBridge Configuration menu allows you to change the Northbridge settings. NorthBridge Chipset Configuration DIMM Speed: DDR 333 Memory Remap Feature Memory Mirroring/Sparing [Enabled] [Disabled] ENABLE: Allow remapping of overlapped PCI memory above the total physical memory. DISABLE: Do not allow remapping of memory. +F1 F10 ESC Select Screen Select Item Change Option General Help Save and Exit Exit DIMM Speed Displays the installed DIMM type and speed.
5.4.6 Onboard Devices Configuration Configure Win627EHF Super IO Chipset Serial Port1 Address Serial Port2 Address Serial Port2 Mode [3F8/IRQ4] [2F8/IRQ3] [Normal] Allows BIOS to Select Serial Port1 Base Addresses. Serial Port1 Address [3F8/IRQ4] Allows you to select the Serial Port1 base address. Configuration options: [Disabled] [3F8/IRQ4] [3E8/IRQ4] [2E8/IRQ3] Serial Port2 Address [2F8/IRQ3] Allows you to select the Serial Port2 base address.
5.4.7 PCI PnP The PCI PnP menu items allow you to change the advanced settings for PCI/PnP devices. The menu includes setting the IRQ and DMA channel resources for either PCI/PnP or legacy ISA devices, and setting the memory size block for legacy ISA devices. Take caution when changing the settings of the PCI PnP menu items. Incorrect field values can cause the system to malfunction! Advanced PCI/PnP Settings WARNING: Setting wrong values in below sections may cause system to malfunction.
PCI IDE BusMaster [Enabled] Allows BIOS to use PCI bus mastering when reading/writing to IDE devices. Configuration options: [Disabled] [Enabled] Offboard PCI/ISA IDE Card [Auto] Allows you to assign a PCI slot to a PCI IDE card, when required. Configuration options: [Auto] [PCI Slot1] [PCI Slot2] [PCI Slot3] [PCI Slot4] [PCI Slot5] [PCI Slot6] IRQ-xx assigned to [PCI Device] When set to [PCI Device], the specific IRQ is free for use of PCI/PnP devices.
5.5 Power menu The Power menu items allow you to change the settings for the ACPI and Advanced Power Management (APM) features. Select an item then press to display the configuration options. ACPI APIC Support [Enabled] APM Configuration Hardware Monitor 5.5.1 Include ACPI APIC table pointer to RSDT pointer list. IMPORTANT! Do not change the APIC support settings after OS installation; otherwise, a system boot failure may occur.
Power Management [Enabled] Allows you to enable or disable the motherboard Advance Power Management (APM) feature.
Power On Ring [Disabled] When set to [Enabled], the system enables the RI to generate a wake event while the computer is in Soft-off mode. Configuration options: [Disabled] [Enabled] Power On By PME# [Disabled] When set to [Enabled], the system enables the PME to generate a wake event while the computer is in Soft-off mode. Configuration options: [Disabled] [Enabled] Power On By RTC Alarm [Disabled] Allows you to enable or disable RTC to generate a wake event.
5.5.3 Hardware Monitor Hardware Monitor CPU1 Temperature CPU2 Temperature MB Temperature CPU1 Fan Speed CPU2 Fan Speed Front1 Fan Speed Front2 Fan Speed Rear1 Fan Speed Rear2 Fan Speed [49ºC/120ºF] [47ºC/114ºF] [47ºC/114ºF] [3884RPM] [2871RPM] [N/A] [N/A] [N/A] [N/A] Smart Fan Control CPU1 Temperature CPU2 Temperature MB Temperature [Enabled] [60] [60] [50] VCORE1 Voltage [ 1.356V] Use the arrow down key to display additional items. VCORE2 Voltage 3.
The C P U 1 T e m p e r a t u r e e, C P U 2 T e m p e r a t u r e e, and F r o n t 1 T e m p e r a t u r e items do not appear when you disable the S m a r t F a n C o n t r o l feature. CPU1/CPU2 Temperature [XXX] MB Temperature [XXX] Displays the detected CPU and system threshold temperatures when the Smart Fan Control feature is enabled. VCORE1 Voltage, VCORE2 Voltage, 3.
5.6 Boot menu The Boot menu items allow you to change the system boot options. Select an item then press to display the sub-menu. APM Configuration Boot Device Priority Boot Settings Configuration Security Select Screen Select Item Enter Go to Sub-screen F1 General Help F10 Save and Exit ESC Exit 5.6.1 Boot Device Priority Boot Device Priority 1st Boot Device 2nd Boot Device 3rd Boot Device 4th Boot Device [1st FLOPPY DRIVE] [PM-ST330620A] [PS-ASUS CD-S360] [MBA v7.5.
5.6.2 Boot Settings Configuration Boot Settings Configuration Quick Boot Full Screen Logo Bootup Num-Lock PS/2 Mouse Support Wait For ‘F1’ If Error Hit ‘DEL’ Message Display Interrupt 19 Capture [Enabled] [Enabled] [On] [Auto] [Enabled] [Enabled] [Enabled] Allows BIOS to skip certain tests while booting. This will decrease the time needed to boot the system.
Wait for ‘F1’ If Error [Enabled] When set to Enabled, the system waits for the F1 key to be pressed when error occurs. Configuration options: [Disabled] [Enabled] Hit ‘DEL’ Message Display [Enabled] When set to Enabled, the system displays the message “Press DEL to run Setup” during POST. Configuration options: [Disabled] [Enabled] Interrupt 19 Capture [Enabled] When set to [Enabled], this function allows the option ROMs to trap Interrupt 19.
5.6.3 Security The Security menu items allow you to change the system security settings. Select an item then press to display the configuration options. Security Settings Supervisor Password User Password : Not Installed : Not Installed to change password. again to disabled password.
After you have set a supervisor password, the other items appear to allow you to change other security settings. Security Settings Supervisor Password User Password : Installed : Not Installed Change Supervisor Password User Access Level Change User Password Clear User Password Password Check [Full Access] [Setup] +F1 F10 ESC Select Screen Select Item Change Option General Help Save and Exit Exit User Access Level [Full Access] This item allows you to select the access restriction to the Setup items.
Clear User Password Select this item to clear the user password. Password Check [Setup] When set to [Setup], BIOS checks for user password when accessing the Setup utility. When set to [Always], BIOS checks for user password both when accessing Setup and booting the system.
5.7 Exit menu The Exit menu items allow you to load the optimal or failsafe default values for the BIOS items, and save or discard your changes to the BIOS items. Exit Options Exit & Save Changes Exit & Discard Changes Discard Changes Load Setup Defaults Exit system setup after saving the changes. F10 key can be used for this operation.
Load Setup Defaults Select this option then press to load the optimized settings for each of the Setup menu items. When a confirmation window appears, select [OK] then press to load the default settings. If you wish to cancel the command, select [Cancel] then press to return to the Exit menu.
