INSTRUCTION MANUAL Steelcraft Strid er Co m pa ct St ri d er IMPORTANT: KEEP THIS BOOKLET IN A SAFE PLACE FOR FUTURE REFERENCE. Note: Second Seat, Bassinet, Infant Carrier & Footmuff are all sold separately.
INDEX Stroller Features ....................................................................................... 4 Quick Reference Guide to Compact Single Mode Configurations ............ 6 Quick Reference Guide to Compact Double Mode Configurations ........... 7 Folding with the Second Seat Warning ..................................................... 8 1 Stroller .................................................................................................. 9 1.1 Stroller General Warnings...............
INDEX 1.25 1.26 1.27 1.28 To use the foot muff................................................................................ 31 Fitting the mesh cover............................................................................ 32 Fitting the rain cover............................................................................... 34 To fold/close the Stroller......................................................................... 36 Optional Accessories (Bassinet, Infant Carrier & Second Seat) ........
STROLLER FEATURES S1 S2 S3 S12 S4 S5 S13 S14 S15 S6 S16 S17 S18 S7 S8 S19 S9 S10 S20 S11 S21 S22 S1. Adjustable & removable canopy S2. Peek a boo window S3. Pivotal handle S4. Tether Strap S5. Frame fold mouldings (on both sides) S6. Canopy mesh (under zip) S7. Stroller seat release buttons (on both sides) S8. Frame sockets (on both sides) accepts Stroller, seat, Infant Carrier, bassinet or adaptors. S9. Frame lock S10. Wheel guards 4 S11. Side access zip pocket (on both sides) S12.
STROLLER FEATURES cont... S23. Canopy window S24. Backrest recline lever S25. Back pocket S26. Accessory bag S27. Brake S28. Rear wheel release S29. Mouldings (for attachment to Second seat connecting pins) S30. Second lock (for Second seat) S31. Lower mouldings (for attachment to second seat frame) S23 S24 S25 S26 S27 S28 S29 S30 S29 *Accessory bag and Stroller seat have been removed from the frame shown on the right.
QUICK REFERENCE GUIDE - SINGLE MODE Stroller - Forward Facing Page: 19 Stroller - Rear Facing Page: 22 Bassinet Page: 41 Infant Carrier - Rearward Facing Page: 45 Shown with optional accessories (sold separately) 6
QUICK REFERENCE GUIDE - DOUBLE MODE Stroller Forward Facing + Second Seat Pages: 19 + 49 With Adaptors: 58 + 59 Stroller Forward Facing + Infant Carrier Pages: 19 + 60 With Adaptors: 58 + 59 Infant Carrier + Second Seat Pages: 45 + 49 With Adaptors: 58 + 59 Recommended to use the adaptors in this mode Infant Carrier + Infant Carrier Pages: 45 + 60 With Adaptors: 58 + 59 Shown with optional accessories (sold separately) 7
FOLDING WITH THE SECOND SEAT WARNING WARNING: INCORRECT FOLDING MAY CAUSE DAMAGE THE STROLLER & FRAME. PLEASE FOLLOW THE FOLDING INSTRUCTIONS CAREFULLY. NOTE: If folding the Stroller with the Second Seat attached, you must adjust the stroller pivot handle to the regular or highest position, to prevent the handle from coming in contact with the second seat and causing damage to the stroller. Please refer to section 4.10 for detailed folding instructions.
SECTION ONE: STROLLER
1.1 STROLLER GENERAL WARNINGS WARNINGS: TO AVOID INJURY OR DEATH: ALWAYS APPLY THE BRAKES WHENEVER THE STROLLER IS STATIONARY. • RETAIN FOR FUTURE REFERENCE. • READ ALL INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY AND USE OF THIS STROLLER. • ALWAYS FOLLOW THE INSTRUCTIONS. • THE CORRECT USE AND MAINTENANCE OF THIS PRODUCT IS ESSENTIAL. • FOLLOW THE MANUFACTURERS INSTRUCTIONS. • DO NOT LEAVE CHILDREN UNATTENDED. • SECURE THE CHILD IN THE HARNESS AT ALL TIMES.
1.1 STROLLER GENERAL WARNINGS cont... WARNINGS: TO AVOID INJURY OR DEATH: • Do not run while using this product. • To prevent the risk of the stroller catching fire, do not park it near an exposed heat source such as a radiator, an open fire or a barbecue, etc. • Always lock swivel wheels when on rough surfaces as this will help eliminate wheel wobble. • Always raise the leg support (where fitted) to its highest position when transporting a baby.
1.
1.3 STROLLER FRAME OPENING A Lay the frame on a flat surface. C Continue to lift the handle up to open the frame until the left and right side frame mouldings engage and lock together. B Release the frame lock and lift up the handle to partially open frame. D Push down on the handle to confirm the frame is locked open. NOTE: To fold/close the frame see Section 1.28.
1.4 FIT & REMOVE THE WHEEL GUARDS A Position the left and right guards beside the frame as shown. B Fit each guard onto the moulding at the base of the leg tubes. Push down until they lock into position. C Pull on each guard in the direction shown, to make sure they are locked on correctly. 1.5 REAR WHEEL FITTING & REMOVAL A To fit the rear wheels, align the wheel axle/rod with the hole in the wheel moulding. Press in and hold the central button, then push the rear wheel fully into the wheel moulding.
1.6 FRONT WHEEL FITTING & REMOVAL NOTE: Tip the frame backwards for more convenient assembly. A Take each front wheel assembly and push the axle into the wheel housing, until it locks in. B Pull on both front wheel sets to make sure they are locked on. C To remove the wheel assembly, turn top knob to the left to unlock and release the wheel.
1.7 SWIVEL/FIXED FRONT WHEEL OPERATION NOTE: Always lock the front swivel wheels when on uneven surfaces. A For swivel wheel mode, slide both red latches up until they lock it into position. B To lock the front wheels into the fixed position, slide both red latches down until they lock. C The front wheels will automatically lock into the fixed position when you move the Stroller forward by approximately one metre. 1.8 TO OPERATE THE BRAKE WARNING - Always apply the brakes when parking the Stroller.
1.9 TO ADJUST THE PIVOTAL HANDLE 7 POSITIONS A There is an adjusting button on the inside of each handle moulding. B Press both buttons in together and hold. Now rotate the handle up or down to the desired height position. C When the desired height position has been achieved, release both buttons. 1.10 TO FIT THE ACCESSORY BAG A The bag firstly needs to be attached to the hook and loop tab on the inside of the Stroller basket. B Hold the bag up by the black back flap on the rear side of the bag.
1.10 TO FIT THE ACCESSORY BAG Cont... D Now thread each hook and loop tab through the frame moulding brackets as shown. NOTE: 18 E Attach each strap to the hook and loop tab sewn onto the bag to hold in place. F The accessory bag is now ready for use. Remove the bag when using the second seat.
1.11 FITTING THE STROLLER SEAT TO THE FRAME WARNING - Always remove your child from the Stroller seat before installing, removing or changing seat direction. NOTE: The seat is reversible so it can face in either forward or rearward position. A Hold the Stroller seat over the frame. B Align the Stroller seat mouldings on both sides, over the frame connection sockets located in the middle of the Stroller. C Push the Stroller seat down until both seat mouldings are locked into the frame sockets.
1.12 TO FIT THE ARMBAR CAUTION: When Child is in the Stroller, keep the arm bar attached to the frame at all times. 20 A One side at a time, align the arm bar pin with the frame moulding as shown. B Press in and hold the engaging / release button, then insert the pin all the way in. C Release the button, then pull on the arm bar to make sure it is engaged. Repeat steps A, B & C for the other side.
1.13 ADJUSTING THE BACKREST CAUTION: Ensure that your child’s limbs are inside the seating area before adjusting the backrest. be prepared to support your child’s weight when adjusting the backrest. A To adjust up or down, fully lift the adjusting lever all the way up. B Continue to hold the lever up and adjust the seat to any one of three positions. C There are 3 indicated seat positions while the seat is facing forward or rearward. 1. Upright position 2. Semi recline position 3. Layback position 1.
1.15 TO FACE SEAT IN OPPOSITE DIRECTION WARNING - Always remove your child from the Stroller seat before changing seat direction. A Refer to section 1.14 for removing the seat from the frame. WARNING B Turn the Stroller seat around to face handle. Refer to section 1.11 for fitting the seat to the frame. - IT IS NOT RECOMMENDED TO USE THE TOP SEAT FACING IN THIS POSITION IF YOU ARE USING EITHER THE SECOND SEAT OR THE INFANT CARRIER IN THE LOWER FRAME POSITION.
1.16 TO ADJUST THE HEAD PILLOW HEIGHT NOTE: The head pillow has a small height adjusting range for additional comfort. A The head pillow height is adjustable via the pile strip on the seat back. Adjust the head pillow height to suit the chosen shoulder strap slots. 1.17 TO FIT, USE & REMOVE THE CANOPY A To attach the canopy, adjust the backrest to the upright position, then slide the canopy mouldings on the frame mouldings until they connect together. Pull up to confirm they are locked on.
1.17 TO FIT, USE & REMOVE THE CANOPY cont... D For extra protection, pull visor out from under the front of canopy. E To expose the mesh section of the canopy, unzip the center section. H To open the window G The window cover is cover, simply lift the cover kept in place by a hidden and over the centre bow. magnet located at the bottom of the window cover. F The zip should be fully unzipped to expose the centre mesh section. Use the fabric to expose or enclose the mesh section.
1.18 HARNESS ADJUSTMENT cont... Shoulder strap A A A Position the shoulder strap tongue (A) on the top of the waist buckle tongue (B) one side at a time. Buckle housing Waist B strap C Waist strap B Crotch strap Shoulder strap Shoulder strap Buckle housing C Waist strap B Push the buckle tongues combinations (A+B) into the buckle housing (C) until the buckle tongues lock into position.
1.18 HARNESS ADJUSTMENT cont... 4 bar slider D Tighten or loosen the waist straps, hold and lift the 4 bar slider and then pull the harness strap, to adjust to the desired fit. E The waist strap needs to fit firmly around the child. Always adjust the harness strap when changing the seating position of the child. F To release the buckle, carefully squeeze the top and bottom buckle tongues.
1.18 HARNESS ADJUSTMENT cont... G The Stroller Seat has 3 sets of harness slots at different heights to accommodate the child. To change the shoulder harness height, push the shoulder harness tongue out of the current harness slot and through the back of the seat fabric. H To reposition harness, pull the shoulder buckle tongue through the desired slot.
1.19 TETHER STRAP WARNING - USE THE TETHER STRAP TO PREVENT THE STROLLER FROM ROLLING AWAY. NOTE: A tether strap is fitted to this Stroller, always place the loop over desired wrist when using the Stroller. A Slide your hand through the tether strap whenever you use the Stroller. 1.20 TO FIT THE REVERSIBLE SEAT PAD NOTE: To assist with installing, release one side of the arm bar, see section 1.12 (D) and release the harness buckles.
1.21 TO USE THE REVERSIBLE SHOULDER PADS NOTE: The shoulder pads are reversible. A Fit the reversible shoulder pads by fitting around the harness shoulder strap and attach the hook and pile. B Repeat for the other reversible shoulder pad. C The reverse side of the shoulder pad has a different fabric pattern. To reverse, undo the hook and pile and reattach on the reverse side. 1.22 ADJUSTING THE LEG SUPPORT A To lower or raise leg support, press in and hold both left and right buttons.
1.23 TO FIT THE BOOTCOVER A Raise the leg support to the horizontal position. Hook the boot cover ‘pocket’ under the leg support. B Pull the top of bootcover under the arm bar and then back over the top. C Connect the press studs to keep in place. The Boot cover is now ready for use. NOTE: Boot cover can be used on second seat, see section 4.9. 1.24 TO USE THE BASKET NOTE: When a child is in the Second Seat, basket access is recommended only from the sides, or from the front.
1.25 TO USE THE FOOT MUFF* *PURCHASED SEPARATELY NOTE: Always secure the harness through the strap holes before use. NOTE: Remove all accessories before installing the foot muff. A To fit the foot muff, ensure the head pillow height is correctly adjusted for your child, (section 1.16). Fold the canopy back, disengage one side of the arm bar and rotate to the side of the frame (section 1.12 (D)). D Thread both waist strap buckle tongues through the pair of slots in the middle section of the foot muff.
1.25 TO USE THE FOOT MUFF cont... G Place the child in the Stroller and connect the harness buckle. Ensure the harness buckle is correctly engaged (see section 1.18). Zip together the top & bottom sections of the foot muff. H Engage the other side of the arm bar (see section 1.12). 1.26 TO FIT THE MESH COVER A To fit the mesh cover over the Stroller seat, place the elastic section of the mesh cover over the front section of the canopy.
1.26 TO FIT THE MESH COVER cont... D Lift the top fabric cover as required or lower for most protection. The mesh cover can be used on both seat directions. E To fit the mesh cover over the bassinet, place the elastic section of the mesh cover over the front section of the canopy. G To fit the mesh cover over the Second Seat, place the elastic section of the mesh cover over the front section of the canopy. H Wrap the elastic loops and clip around the bars at both sides of the Second Seat.
1.27 TO FIT THE RAIN COVER 34 A To fit the rain cover to the Stroller - Place over the Stroller canopy as shown. Loop the elastic section over the Stroller seat leg support, then pull the rear rain cover section down between the handle. B Join the hook and pile around the handle tube. C The rain cover can be fitted to the Stroller seat when in forward or rear facing mode. E To fit the rain cover to the Infant Carrier - Place over the Infant Carrier canopy as shown.
1.27 TO FIT THE RAIN COVER cont... F Join the hook and pile around the handle tube. G To fit the rain cover to the Infant Carrier and Second Seat or second Infant Carrier - Follow Step E, but ensure to pull the rear rain cover section over the back of the Second Seat or lower Infant Carrier as shown. Join the hook and pile around the handle tube. I To fit the rain cover to the Bassinet- Place over the Bassinet canopy as shown. Loop the elastic over the front of Bassinet.
1.28 TO FOLD/CLOSE THE STROLLER • Remove the Bassinet or Infant Carrier if connected to the frame prior to folding. • The Second Seat can either be removed or folded up prior to folding. • The rain cover must also be removed if fitted. NOTE: Stroller Seat and wheels can be removed to reduce the total folded size. See sections 1.6 & 1.14 for reference. With Stroller Seat attached, folding the leg support will also help to reduce the folded size. FOLDING TIPS 1.
1.28 TO FOLD/CLOSE THE STROLLER cont... WARNING: INCORRECT FOLDING MAY CAUSE DAMAGE TO THE STROLLER & FRAME. PLEASE FOLLOW THE FOLDING INSTRUCTIONS CAREFULLY. • Release the front wheels into swivel mode to fold. • Ensure the front wheels are in swivel mode, so the front wheels will automatically position under the stroller during folding. 4 wheel model 2 1 C For swivel wheel mode, lift the swivel latch up on both front wheels until they lock into position.
1.28 TO FOLD/CLOSE THE STROLLER cont... G Frame lock engaged. H The two separate components shown after folding. I Separation of the Stroller seat and frame promotes easier handling and storage. NOTE: Make sure the frame lock is engaged before lifting up and always bend the knees when lifting. If you have chosen not to remove the Stroller Seat, follow the procedure below. Note: Ensure the Stroller seat is forward facing. This will achieve a more compact fold. J Follow step A.
Section Three: Infant Carrier OPTIONAL ACCESSORIES Section Two: Bassinet Section Four: Second Seat 39
2.1 BASSINET WARNINGS WARNINGS: PLEASE FOLLOW THESE WARNINGS IF YOU ARE USING THESE ACCESSORIES. • THE COMPACT & STRIDER BASSINETS ARE THE ONLY BASSINETS DESIGNED TO FIT THE COMPACT STROLLER. • REMOVE STROLLER SEAT OR INFANT CARRIER FROM THE FRAME BEFORE FITTING BASSINET. • ALWAYS REMOVE YOUR CHILD FROM THE BASSINET BEFORE FITTING OR REMOVING FROM THE STROLLER FRAME. • THE BASSINET MUST ALWAYS FACE TOWARDS THE HANDLE. • THE BASSINET MUST BE REMOVED FROM THE FRAME BEFORE FOLDING.
2.3 BASSINET ASSEMBLY, FITTING & REMOVAL A To assemble bassinet, locate straps in the centre of the frame support rods and pull straps slowly outwards until each rod slides and locks under all 4 clips. B Frame support rods are locked under all four clips. C Push down lightly on the top edges of the bassinet to check that the frame supports are firmly locked in place.
2.3 BASSINET ASSEMBLY, FITTING & REMOVAL cont... 42 I Attach hook and loop tabs on canopy to the liner on both side and in 2 places near the main locking lever. G Fasten hook and loop tabs around the handle mouldings and stretch the liner over the other two corners of the bassinet. H Fold canopy down (see section 2.3 (D)). Insert the pad into the bassinet with head rest located at the canopy end. J To expose the mesh section of the canopy, fully unzip the center section.
2.3 BASSINET ASSEMBLY, FITTING & REMOVAL cont... NOTE: The bassinet can only be installed rearward (facing mother position) on the Stroller frame. The frame will not fold with bassinet installed so it must be removed before folding. L Line up plastic moulding on sides of Bassinet with sockets in the middle of Stroller frame. M Lower the Bassinet all the way down until it engages into the sockets on both sides. N Ensure Bassinet is securely locked on by trying to pull up.
3.1 INFANT CARRIER WARNINGS (Optional Accessory) WARNINGS: PLEASE FOLLOW THESE WARNINGS IF YOU ARE USING THESE ACCESSORIES. • THE STEELCRAFT & STRIDER INFANT CARRIERS ARE THE ONLY COMPATIBLE INFANT CARRIERS DESIGNED TO FIT COMPACT STROLLER AND COMPACT SECOND SEAT FRAME. • THE INFANT CARRIER OR INFANT CARRIERS MUST BE CORRECTLY FITTED AND LOCKED ONTO THE STROLLER FRAME OR SECOND SEAT FRAME.
3.2 INFANT CARRIER FITTING & REMOVAL A Remove Stroller seat or Bassinet from frame, (see sections 1.14 (B) & 2.3 (O)). The Infant Carrier must face the Stroller handle. With the Infant Carrier handle in the upright position, locate the Infant Carrier handle mouldings on either side, directly over the frame mouldings. Notice the indicator is GREEN. C By squeezing in and holding the latches on either side of the handle, rotate the handle backwards. The GREEN Indicator will now turn to RED.
3.2 INFANT CARRIER FITTING & REMOVAL cont... 46 10 F IMPORTANT: Pull up on both sides of the Infant Carrier and confirm it is locked into the frame. If not locked in on both sides, repeat steps A to E. G Secure your baby into the Infant Carrier by the harness provided. (Refer to Instruction manual that comes with Infant carrier). I Continue to rotate the handle forward until it returns to the upright position. Release the latches, the indicator should now be GREEN.
4.1 SECOND SEAT WARNINGS (Optional Accessory) WARNINGS: PLEASE FOLLOW THESE WARNINGS IF YOU ARE USING THESE ACCESSORIES. • DO NOT USE THIS SEAT WITH ANY OTHER MODELS OF STROLLER. • THE SECOND SEAT TO BE USED ONLY IN FORWARD FACING POSITION. THAT IS CONNECTED TO THE REAR OF THE STROLLER. • THE SECOND SEAT MUST BE CORRECTLY FITTED AND LOCKED ONTO THE STROLLER. • THE MAXIMUM WEIGHT OF THE CHILD USING THIS PRODUCT IS NOT TO EXCEED 17KG. • OVERLOADING WILL CAUSE THE STROLLER TO TIP BACKWARDS. DO NOT OVERLOAD.
4.2 SECOND SEAT PARTS SS1. Second Seat assembly SS2. Second Seat engaging pins (2) SS3. One hand, 4 position reclining backrest SS4. Adjustable /removable canopy SS5. Canopy Release Buttons SS6. Adaptors (2) SS7. Head Pillow SS8. Shoulder pads (2) SS9.
4.3 FITTING SECOND SEAT TO THE STROLLER NOTE: For easier installation, rotate the Pivotal Handle in the most upright position. SS2 SS2 S29 S29 SS9 A Remove the Accessory Bag if fitted. Apply the Stroller brake, rotate the pivot handle up to create more assembly space. Adjust the Stroller seat to the most upright position. B The Second Seat connecting pins (SS2) need to lock into the frame mouldings (S29).
4.4 TO ADJUST INTO SEATING POSITIONS A Adjust to desired seating position by using the one hand backrest adjusting lever. Lift the lever all the way up and at the same time, lift up on the seat. B The seat will slide up and down the frame. Lock into any one of 4 seating positions by releasing the backrest adjusting lever and allow the seat to engage at the desired position. 4.
4.5 TO FIT, USE & REMOVE THE CANOPY cont... D To expose the mesh section of the canopy, unzip the center section. E The zip should be fully unzipped to expose the center mesh section. Use the fabric to expose or enclose the mesh section. 4.6 HARNESS ADJUSTMENT WARNING : USE THIS HARNESS AT ALL TIMES. WHEN NOT IN USE ALWAYS DISCONNECT THE SHOULDER STRAPS FROM THE WAIST STRAPS AND BUCKLE TO PREVENT STRANGULATION. NOTE: A five-point harness is provided to restrain your child.
4.6 HARNESS ADJUSTMENT cont... Shoulder strap A A A Position the shoulder strap tongue (A) on the top of the waist buckle tongue (B) on both sides one side at a time. Buckle housing Waist B strap C Waist strap B Crotch strap Shoulder strap Shoulder strap Buckle housing Waist strap A+B C B Push the buckle tongues combinations (A+B) into the buckle housing (C) until the buckle tongues lock into position.
4.6 HARNESS ADJUSTMENT cont... 4 bar slider D Tighten or loosen the waist straps, hold and lift the 4 bar slider and then pull the harness strap, to adjust to the desired fit. E The waist strap needs to fit firmly around the child. Always adjust the harness strap when changing the seating position of the child. F To release the buckle, carefully squeeze the top and bottom buckle tongues.
4.6 HARNESS ADJUSTMENT cont... G The second seat has 2 sets of harness slots at different heights to accommodate the child. To change the shoulder harness height, push the shoulder harness tongue out of the current harness slot and through the back of the seat fabric. H To reposition harness, pull the shoulder buckle tongue through the desired slot. 4.7 ADJUSTING THE HEAD PILLOW HEIGHT POSITION A The head pillow has a small height adjusting range.
4.8 TO USE THE REVERSIBLE SHOULDER PADS A Fit the reversible shoulder pads by fitting around the harness shoulder strap and attach the hook and pile. B Repeat for the other reversible shoulder pad. C The reverse side of the shoulder pad has a different fabric pattern. To reverse, undo the hook and pile and reattach on the reverse side. 4.
4.10 FOLDING THE SECOND SEAT WITH THE FRAME CAUTION: Remove the child from the Second Seat before folding. NOTE: Fold the Second Seat before folding the Stroller. A Fold the canopy back, then fully lift up the backrest adjusting lever and lower the Second Seat to the lowest position. S30 S30 D While still holding the backrest adjusting lever up, press the safety lock button (S30), and continue to lower the head end of the Second Seat.
4.11 REMOVING THE SECOND SEAT FROM THE FRAME CAUTION: Remove the child from the Second Seat before folding. SS5 SS5 A First, fold the Second Seat up under the frame - see section 4.10. B With the Second Seat in the folded position, locate the release buttons (SS5) on the sides of the Second Seat frame. SS5 C Wrap your hands around the Second Seat Frame and fully depress the release buttons until you see the adjacent buttons pop out of the mouldings.
4.12 TO USE THE ADAPTORS NOTE: Adaptors are supplied to create more space if required, when using the Second Seat or Infant Carrier on Second Seat frame. S8 S8 S8 A Align the adaptor with the Stroller frame mouldings as the adaptor extends towards the front of the Stroller and the ribbed section of the mouldings face inwards. C Pull up on the adaptors to make sure they are locked on. 58 B Press down on the adaptors to lock into the Stroller frame mouldings (S8).
4.13 TO INSTALL THE STROLLER SEAT USING THE ADAPTORS A Lock the Stroller seat into the adaptors in the forward facing position. B Adjust the Stroller backrest angle as required. CAUTION: Stroller seat must be correctly attached, see fitting and removal sections 1.11 & 1.14. 4.14 TO INSTALL THE INFANT CARRIER USING THE ADAPTORS CAUTION: Infant Carrier must be correctly attached, see fitting and removal, section 3.2 & 4.12.
4.15 FITTING & REMOVING SOFT GOODS FROM SECOND SEAT FRAME A To fit the infant carrier to the second seat frame, you must first remove the second seat from the stroller and remove the softgoods. (A) B Lay the Second Seat frame on a flat surface facing upwards. Release hook and loop tabs which attach the canopy to the top of the Second Seat. C To remove the canopy, press in and hold the release tabs while pulling the canopy out of the frame mouldings.
4.15 FITTING & REMOVING SOFT GOODS FROM SECOND SEAT FRAME cont... G Release hook and loop tab on both sides. H Release hook and loop tab. I Pull the fabric pocket off from both bottom frame posts. SS2 S29 SS9 J Pull the fabric clear of the mouldings and pull the fabric off the frame. The following steps explain how to fit the Second Seat frame to the stroller. K The Second Seat connecting pins (SS2) need to lock into the frame mouldings (S29).
4.16 FITTING & REMOVING INFANT CARRIER FROM SECOND FRAME S30 S31 62 A Lower the Second Seat frame and push down to lock the legtubes (SS9) into the lower Stroller frame mouldings (S31). Repeat step L if the frame doesn’t lock into place. B Raise the backrest adjusting lever and lift the head end of the Second Seat so that the foot end slides down the Stroller frame and engages into the second lock (S30). When locked, frame is slightly above horizontal.
4.16 FITTING & REMOVING INFANT CARRIER FROM SECOND FRAME cont... G The handle indicator should now be GREEN and the Infant Carrier should be locked into the frame. If indicator is RED the Infant Carrier handle is not in the locked position, repeat steps E & F. H IMPORTANT: Pull up on both sides of the Infant Carrier and confirm it is locked into the frame. If not locked in on both sides, repeat steps E to G. I Secure your baby into the Infant Carrier by the harness provided.
4.17 REFIT THE SOFTGOODS TO THE SECOND SEAT FRAME A Lay the Second Seat frame on a flat surface as shown above. B Pull the fabric over the frame. C Ensure the latch at the top of the frame is pulled through the cutout in the fabric cover. (3) (1) (2) (4) (1) D Stretch the bottom of the cover to refit the fabric pocket on the bottom frame post. Repeat for both sides. 64 (2) (3) E Re-attach all the hook and loop tabs and pull the mouldings through the holes in the softgoods.
4.17 REFIT THE SOFTGOODS TO THE SECOND SEAT FRAME cont... G Attach hook and loop tab (3) on both sides. H Attach hook and loop tab (2) on both sides making sure the canopy moulding on the top side of the frame is exposed. J Turn the Second Seat over so it is facing upwards. To attach the canopy, insert the canopy mouldings onto the frame mouldings until they snap in. K Attach the canopy hook strips to the pile strips around the top and sides.
STROLLER FOLDING CONFIGURATIONS The following are recommended configurations for storage and transportation in a vehicle. Shown with second seat (optional accessory, sold separately). Note: The easiest method is to remove the top seat and optional accessories from the stroller frame and place the accessories and stroller frame into the vehicle separately.
CARE AND MAINTENANCE • To prolong the life of your stroller and accessories keep it clean and do not leave it in the direct sunlight or in the car boot for extended periods of time. • Removable fabric covers and trims may be cleaned using warm water with a household soap or mild detergent. Allow it to dry fully, preferably away from the direct sunlight. • Non removable fabric covers and trims may be spot cleaned using a damp sponge with soap or a mild detergent.
