Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Please open this page for an ‘at a glance’ guide to your Quartet 3500
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Please open this page for a further ‘at a glance’ guide to your Quartet 3500
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 At a glance Handset Handset fascias Can be changed to suit your personal preference, see page 13. Aerial Should be extended to obtain the best signal and reception available, see page 10. Option buttons Lets you select options within each menu that are shown on the display, see page 14. Clear button Use to delete unwanted digits or characters and to exit the menu, see page 20. u en Talk button Press to make or receive a call, see page 14.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Power/In use/1571 light Aerial Base unit The green light comes on when connected to the power supply and flashes when in use, or when you have a new BT Answer 1571 message, see page 33. Should be extended to obtain the best signal and reception available, see page 10. Message display LEDS Charging light The red light comes on to indicate charging when the handset is on the base.
Quartet 3500 User Guide ~ 5th Edition ~ 3rd March ’03 ~ 5271 MENU STRUCTURE Answer Off On Record Memo Answer Settings Answer Mode Answer and Record Answer Only Outgoing Message Day Setting Answer and Record Outgoing Message New OK/Play Answer Only Outgoing Message New OK/Play Sunday. . .
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Quick guide to handset display icons Battery icon – flashes when handset is on base and being charged. Battery icon – to indicate battery low. Directory icon * Telephone icon – flashes to indicate that new calls have been received in the Calls list. * BT 1571 icon – indicates that the 1571 voice mail detection feature is switched on. Flashes to indicate new voice mail messages have been received.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Quick guide Quick guide to most commonly used handset settings and functions Function Button combination Answer a call/End a call Make a call Redial a number from the redial list , , to scroll through to entry, displayed. to dial number Store a number in the directory , NEW , display shows Enter Name, enter name using keypad, OK , display shows Enter Number, enter the number, SAVE .
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Quick guide Quick guide to most commonly used answering machine settings and functions Function Button combination Switch answering machine ON/OFF: Using the base Press and release or Using the handset Ans On Off until display shows Answer Off On, press either OFF or ON .
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 In this guide Note There is a detailed Index at the back of this guide, see page 65.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Introduction Your Quartet 3500 is designed for ease of use and made to the high standards set by BT. You can expect your Quartet 3500 to provide many years of quality service. Please read the instructions carefully before use and keep this user guide for future reference. Unpacking your Quartet 3500 Check that your Quartet 3500 is complete. If anything is missing, please contact your place of purchase immediately. Quartet 3500 handset.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Safety information General Cleaning Only use the power supply unit included with the product. Using an unauthorised power supply will invalidate your guarantee and may damage the telephone. The item code for the power supply unit is 872264, as stated on the underside of the base unit. Simply clean the handset and base station with a damp (not wet) cloth, or an anti-static wipe. Never use household polish as this will damage the product.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Setting up Follow these steps to set up your Quartet 3500 ready for use. Plan the location Situate your Quartet 3500 close enough to the mains power socket and telephone socket so that the cables will reach. Note Avoid touching the aerials during a call as this may cause a clicking sound. Make sure it is at least 1 metre away from other electrical products to avoid interference.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 3 Connect the base unit power supply to a power socket When you first use your Quartet 3500, the rechargeable battery pack in the handset needs charging for 24 hours. Place the handset on the base unit, ensuring the contacts are touching. The red CHARGING light will come on. The green Power/In use light will come on when the power is switched on. The power supply unit must remain plugged in all the time.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Note (cont) 6 To set the day To get the longest possible life from your battery, leave the handset off the base unit for a few hours each day. Press the UP or DOWN button until the display shows Answer Settings. OK 5 When the handset has been charged for 24 hours plug the line cord into the telephone wall socket Press the OK option button. Press the UP or DOWN button until the display shows Day Setting. OK Press the OK option button.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 6 To set the time Press the UP or DOWN button until the display shows Handset Settings. OK Press the OK option button. 7 Changing your handset fascias There are 3 removeable handset fascias to choose from (one is fitted already on the handset). Press in the centre of the fascias and slide upwards to take off. The display will show Time setting. OK Press the OK option button. The first digit will be flashing.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Using the telephone Making and receiving calls To make an external call OPTION buttons Lift the handset off the base unit. Press the TALK button. UP and DOWN buttons u en M AB DE F C Your Quartet 3500 has a menu driven display. The UP and DOWN buttons allow you to scroll through the menu and the OPTION buttons below the display allow you to select options within each menu. Note To quit a menu at any time, press the CLEAR button.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 If you have entered the number correctly, press the TALK button to dial the number. The display will show Calling. Call timer Your handset will automatically time the duration of all external calls. The handset display shows the call duration both during your call and for a few seconds after it is completed.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Note The handset range is up to 250 metres from the base unit in ideal conditions. The stated range of this product is measured in open field conditions. Walls, ceilings and metal structures will reduce the maximum range. If you start to go out of range while using the phone, you will hear warning beeps. Move closer to the base unit. If you do not move back into range your call may be disconnected.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 To adjust the earpiece volume During a call you can adjust the volume of the handset receiver. The earpiece volume will remain at the volume level you set until you adjust it again. Secrecy/Music on hold When on a call you can talk to someone in the same room without your caller hearing. To switch Secrecy on and off During a call: To switch on during a call: Press the UP or DOWN button to increase or decrease the earpiece volume.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 For example, if you wish to enter the name TOM: 50 Name and Number Directory TU MN O MN O You can store fifty of your most frequently used names and telephone numbers in the directory. Please note that numbers can be no longer than 20 digits and names no longer than 13 characters. V NEW OK Press the NEW option button. To enter the letter M, press the 6 button.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 The display will show Entry Saved and then show the name and number you have entered. To view and dial a name and number in the directory Press the CLEAR button until you return to the standby screen. Press the DIRECTORY option button. The first entry in the directory will be displayed (if there are no entries in the directory the display will show Directory Empty).
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 The display shows Entry Saved. To edit a name and number in the directory Press the CLEAR button until you return to the standby screen. Press the DIRECTORY option button. The first entry in the directory will be displayed. To delete a name and number in the directory Use the UP or DOWN button to scroll through the directory to find the entry you want to edit. EDIT Press the DIRECTORY option button. Press the EDIT option button.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Use the UP or DOWN button to scroll through the redial list to the number you require. Redial Your handset automatically saves the last 5 telephone numbers dialled into a redial list. You can then redial any of the last 5 numbers called or copy numbers from the list into the directory or delete them from the redial list. To automatically redial the last number called Press the TALK button when the number you want to redial is displayed.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 COPY Press the COPY option button. The display will show Enter Name. Enter a name using the keypad (as shown on page 18, “To store a name and number in the directory”). OK To delete a number from the redial list Press the LNR button. Pause The last number you called will be shown on the display. Use the UP or DOWN button to scroll through the redial list to the number you require. Press the OK option button.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 To delete all numbers from the redial list Press the LNR button. Pause The last number you called will be shown on the display. DEL Press and hold the DEL option button for 3 seconds. The display will show Delete Paging You can page the handset from the base unit to alert a handset user that they are wanted or to locate a missing handset. However, paging calls cannot be answered by a handset.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Base unit settings You will hear a confirmation tone. To adjust the base ringer volume Press the CLEAR button until you return to the standby screen. The base has 3 ringer volume settings: Off, Low and High. The default setting is High. Press the UP or DOWN button until the display shows Base Settings. OK To change the base ringer melody Press the OK options button. The base has 3 ringer melodies to choose from: 1, 2 and 3.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Use the UP or DOWN button to highlight which melody you require: 1, 2 or 3. You will hear a sample melody on each press. OK Press the OK options button to confirm. You will hear a confirmation tone. Press the CLEAR button until you return to the standby screen.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Handset settings To lock or unlock the keypad To adjust the handset ringer volume You can lock the keypad so that it cannot be used accidentally while carrying it around. The handset has 3 ringer volume settings: Off, Low and High. The default setting is High. IMPORTANT If the keypad is locked you will NOT be able to dial the emergency numbers 999 and 112. Press the UP or DOWN button until the display shows Handset Settings.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 OK Press the OK option button to confirm. Use the UP or DOWN button to highlight which melody you require: 1, 2 or 3. You will hear a sample melody on each press. You will hear a confirmation tone. Press the CLEAR button until you return to the standby screen. OK Press the OK option button to confirm. You will hear a confirmation tone. To change the handset ringer melody The handset has 3 ringer melodies to choose from: 1, 2 and 3.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 The current melody will be highlighted. Use the UP or DOWN button to highlight which melody you require: 1, 2 or 3. You will hear a sample melody on each press. OK Press the OK option button to confirm. You will hear a confirmation tone. Press the CLEAR button until you return to the standby screen. To switch the handset key tones ON or OFF Press the UP or DOWN button until the display shows Handset Settings. OK Press the OK options button.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 BT Select Services Caller Display IMPORTANT To use Caller Display you must first subscribe to the service from your Network Provider. A quarterly fee is payable. For more information on BT’s Select Services call BT free on 0800 800 150. If you have subscribed to your Network Provider’s Caller Display Service, you will be able to see your caller’s number on your handset display (provided it is not withheld) prior to answering the call.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 New 14:51 22 Jul 0800 800152 Del Copy The number will be dialled automatically and the display will show Calling. New icon indicates that there are new unviewed calls in the list. When the display shows NEW after the time and date it means that it is a new call that has not been viewed yet. When all calls have been viewed NEW will disappear and the call counter will return to 0.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 SAVE The display will show Entry Deleted and then return to the next entry in the Calls list. Press the SAVE option button to confirm. The display will show Entry Saved. Press the CLEAR button until you return to the standby screen. Press the CLEAR button until you return to the standby screen. To delete the whole calls list To delete a number from the Calls list Press the CALLS LIST option button.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Call Waiting To use Call Waiting IMPORTANT To use Call Waiting you must first subscribe to the service from your Network Provider. A quarterly fee is payable. For more information on BT’s Select Services call BT free on 0800 800 150. Ca l l Wa itin g Ca l l If an incoming call arrives while you are already engaged on a telephone call, you will hear a soft beep every 5 seconds (this beep is not audible to the person you are speaking to).
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Press the UP or DOWN button until the display shows Base Settings. 1571 Voice mail indication This feature will only work if you have subscribed to BT Answer 1571 or Call Minder and switched the 1571 feature ON. BT Answer 1571 and Call Minder are automated answering services located at your local telephone exchange which will take messages when you are out, engaged on another call or on the internet.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 To access your voice mail Press the TALK button. 1571 Press the 1571 option button if it is displayed on the handset display screen (as this indicates you have a new voice mail message). Or Dial 1571 to access your network answering service and follow the announcements to play, save and delete your messages using the keypad.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Setting up and personalising your answering machine Your Quartet 3500 can digitally record up to 13 minutes of messages, with each message lasting a maximum of 3 minutes. As well as recording incoming messages, you can record memos for other users. You can operate your Quartet 3500 from: Message display on the base station The table (on the next page) provides an explanation of what is shown on the base station display.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Message display LED To switch the answering machine ON/OFF You can switch the answering machine on and off using the base or the handset. 2 Quartet 3500 Switch on/off using the base: Page Play Ans On Off DISPLAY DEFINITION (Blank) Power off. C-0 (flashing) Day/Time needs to be set. 0-9 Answer-on mode, 0-9 messages. 9 (flashing) 10-59 messages. Indicating more than 9 messages stored.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 If you adjust the volume when the answering machine is not being used, a beep sounds at each press. When the volume reaches its highest or lowest level two beeps will sound. Switch on/off using the handset: Press the UP or DOWN button until the display shows Answer Off On. Press either the OFF or ON option button. Your chosen setting will be announced, “Answer on, your outgoing message is…”, or, “Answer off ”.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 When you hear the setting you want, do not press the Skip button again. After a short delay your chosen setting will be announced. Use the UP or DOWN button to highlight the setting you require from between 2 and 9 or TS. OK To check the answer delay setting Skip Press and release the Skip button on the base unit. The current setting will be announced and also shown on the base unit display.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 To set audible message alert via the handset Press the UP or DOWN button until the display shows Answer Settings. OK Press the OK option button. Press the UP or DOWN button until the display shows Message Alert. OK Press the OK option button. The current setting will be highlighted. ON OFF Answer and Record Your Quartet 3500 has a pre-recorded Answer and Record outgoing message that allows your caller to leave a message.
Quartet 3500 User Guide ~ 5th Edition ~ 3rd March ’03 ~ 5271 To record your own Answer and Record outgoing message You can record your own Answer and Record outgoing message to use instead of the pre-recorded message already available. Your outgoing message can be up to 3 minutes long. You can reinstate the pre-recorded outgoing message later if you wish to, see page 44. NEW Press the NEW option button. You will hear, “Please speak after the tone. To end recording, press #”.
Quartet 3500 User Guide ~ 5th Edition ~ 3rd March ’03 ~ 5271 To record your own Answer Only outgoing message You can record your own Answer Only outgoing message to use instead of the pre-recorded message already available. Your outgoing message can be up to the maximum recording capacity of 12 minutes, but it is advisable that you try to keep it shorter to allow time for recording memos, or incoming messages if you decide to set the alternative Answer and Record outgoing message.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 To check or play your outgoing message via the base unit To check or play your outgoing message via the handset You can check and play your current outgoing message at any time via your Quartet 3500 handset You can check and play your current outgoing message at any time via your Quartet 3500 base unit. Ans On Off Pick up the handset. Press the ANS ON/OFF button. Press the UP or DOWN button until the display shows Answer Settings.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Press the CLEAR button until you return to the standby screen. To set the answer mode via the handset Pick up the handset. Press the UP or DOWN button until the display shows Answer Settings. Answer mode You can select either Answer and Record or Answer Only mode. Please note that Answer Only mode does not allow your caller to leave a message.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 outgoing message will be played. To delete your own outgoing message and re-instate the pre-recorded outgoing message via the handset Press the CLEAR button until you return to the standby screen. Note Pick up the handset. Press the UP or DOWN button until the display shows Answer Settings. OK Press the OK option button. Press the UP or DOWN button until the display shows Outgoing Message. OK Press the OK option button.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Using the answering machine via the base unit At the start of each message, the number of the message is announced. The message number will also be shown on the base unit display. Note Press the button at any time during playback to stop messages playing. Stop Quartet 3500 2 Page Play To playback new messages only To playback all messages Play Play Press the PLAY button. The prompt will announce, “You have (n) messages”.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 To pause a message during playback Play While listening to a message, press the PLAY button. The message will be paused. You will hear a beep every 10 seconds and the message display will show P flashing. Play Press the PLAY button again to resume playback. To skip forward and backward through messages (including fast forward playback) During playback: 46 Skip Skip Press the SKIP button to skip forwards to the next message.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 To delete all messages When all messages have been played the prompt will announce, “End of messages. To delete all messages, press delete”. The display counts down from 8 - 0. Del Stop During the countdown, press the red DELETE button. The prompt will announce, “All messages deleted”. At the end of the countdown there will be a confirmation tone. If you decide not to delete, press the STOP button during the 8-0 countdown.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Using the answering machine via the handset e.g., Play messages 03 New NEW Press the NEW options button to play new messages only. The prompt will announce, “You have (n) new messages”, and your new messages will be played back (or “You have no new messages”). ALL Press the ALL option button to play all messages (old and new).
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 During message playback When a message is being played the handset display will show the number of the message and you will have the options to increase or decrease the earpiece volume, delete messages or skip forwards and backwards through your messages. To skip back during message playback During playback: | << Press the |<< option button to skip back to the start of the current message.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Playback of the next message will begin. The message has not actually been deleted at this point but it has been marked for deletion. At the end of message playback there will follow an 8 second countdown. When the countdown reaches 0 all marked messages will be deleted. When all messages have been played back, if all messages have been marked for deletion the prompt will announce, “End of messages. All messages deleted”.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Memos Press the # button to end recording. A personal memo can be recorded on your Quartet 3500 and left as a memo message for another user. Memos can be of any length, up to the maximum recording capacity (12 minutes), but you should try to keep them short to allow time for recording incoming messages. Note You cannot record a memo using the base unit. The display will return to the standby screen.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Call screening/ Call intercept You can let your answering machine pick up a call, even if you are in. This allows you to identify your caller and decide whether to take the call. Make sure the volume is set to an audible level, see page 37. Allow the incoming call to be answered by the answering machine as normal. You will hear the caller begin to leave a message.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Remote access You can turn your Quartet 3500 answering machine on and off and listen to your messages from any Touchtone™ telephone. To protect your privacy, messages can only be accessed by entering a 3-digit security code. OK The pre-set code is 000 and can be changed. If you change the code it is advisable that you make a note of it somewhere safe. To switch your answering machine on remotely Enter a 3-digit PIN code of your choice.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Note You cannot use this feature if you have BT Answer 1571 or Call Minder active, as the call will be intercepted before the 20 rings. Note If you have new messages they will be played after you have entered your security code. Time saver The time saver feature is useful if you are out and want to ring in and check if you have received any new messages.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 WX YZ Operating the answering machine remotely “To set a new security code, press 9” “To hear main menu, press 1”. When you have accessed your answering machine remotely, you can operate it using the keypad numbers on the phone you are using. The remote access main menu The main menu lets you operate a range of answering machine functions remotely. Simply follow the instructions as announced: AB C “To play all messages, press 2”.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Using Quartet 3000 additional handsets You can buy and use up to four more Quartet 3000 additional handsets with your Quartet 3500 to extend your phone system without needing to install extension sockets for each new phone. Note You must charge your additional handset for 24 hours before registering it.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 OK Press the OK options button. To de-register a handset The display will show Press Page On Base Until Base Beeps. Page Press and hold the base unit PAGE button. When you hear a beep release the PAGE button. Press the UP or DOWN button until the display shows De-Register. OK The display will show The display will show Handset Registered.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Transferring calls You can transfer calls between handsets that are registered to the base unit. To transfer a call During your call: TRAN Press the TRAN options button. Your external caller will be put on hold and will hear music. The display will show Transfer To Handset_. Enter the handset number that you want to transfer the call to. OK Press the OK option button. The called handset will ring and the display will show Transferring Call.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 General information Guarantee Your Quartet 3500 is guaranteed for a period of 12 months from the date of purchase. Subject to the terms listed below the guarantee will provide for the repair of, or at BT’s or its agent’s discretion, the option to replace the Quartet 3500 or any component thereof, (other than batteries), which is identified as faulty or below standard, or as a result of inferior workmanship or materials.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 If you have to return your product Prior to returning your product, please read the Help section on page 63, or contact the Helpline on 0870 605 8047 for assistance. If you still feel you have to return your product, pack the base station and handset securely, preferably in the original packaging. All parts must be returned, including line cords, power supplies and original batteries.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Unplug the white connector and remove the old battery pack. Note (cont) To get the longest possible life from your battery, take the handset off the base unit for a few hours each day. Plug the new battery pack connector in and lower the battery pack into recess then replace lid. Note When fully charged and in good condition, the handset will provide up to 7 hours talktime or 72 hours standby.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Switchboard compatibility This product is intended for use within the UK for connection to the public telephone network and compatible switchboards, which support tone and pulse dialling and timed break recall. If in doubt please consult your service provider. OK You will hear a confirmation beep.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Help and advice If you have any problems using your Quartet 3500, this section will give you the most common, easy to follow solutions. Telephone problems Possible cause Solution • Buzzing/poor reception. Handset and base aerials not extended. Extend both aerials. • Answering machine not recording incoming messages. Answering machine set to Answer Only outgoing message.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Telephone problems Possible cause Solution • You have dialling tone but the telephone will not dial out. You may be trying to use tone dialling on a pulse dialling exchange. See page 62 to change to pulse dialling. You are connected to a PBX and are not dialling the access code. Use the PBX access code. See page 62 for more information on switchboard use. Telephone is not connected to the telephone line.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Index 1571 voice mail indication Additional handsets Aerials Answering machine answer delay answer mode audible message alert base unit loudspeaker call screening delete message delete own outgoing message loudspeaker volume memos message display on base on/off outgoing messages pause playback playback messages set day and time skip forward/backward remote access Answer delay set via base set via handset 33 56 10 37 43 38 37 52 47, 49 44 37 5
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Calls list copy to directory delete a number delete whole list dial a number view Call timer Call Waiting Channel selection Charge handset Day – set De-register Dialling mode Delete calls list entry directory name and number message own outgoing message redial list number Directory delete dial edit store view Display icons Earpiece volume End a call Fascias Fast forward message playback 66 29 30 31 31 30 30 15 32 16 11 12 57 62 31 20 46, 49
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 check or play via handset 42 record Answer and Record 40 record Answer only 41 set answer mode via base 43 set answer mode via handset 43 Paging 23 Page melody 27 Pause 19, 62 Phone socket 12 Play messages via base 45 via handset 48 Power supply unit 10 Preparatory dialling 14 Pulse dialling 62 Quick guide to answering machine settings 6 Quick guide to handset settings 5 Range of handset 16 Recall 62 Receive a call 15 Record outgoing message 4
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 R&TTE This product is intended for use within the UK for connection to the public telephone network and compatible switchboards. This equipment complies with the essential requirements for the Radio Equipment and Telecommunications Terminal Equipment Directive 1999/5/EC.
Quartet 3500 User Guide ~ 5th Edition ~ 17th January ’03 ~ 4393 Offices worldwide The telecommunications services described in this publication are subject to availability and may be modified from time to time. Services and equipment are provided subject to British Telecommunications plc’s respective standard conditions of contract. Nothing in this publication forms any part of any contract. © British Telecommunications plc 2003. Registered Office: 81 Newgate Street, London EC1A 7AJ.
