3CTP-226-AB Second Edition Chrysler Group LLC Printed in the USA UCONNECT ® TOUCH 8.
SECTION TABLE OF CONTENTS PAGE 1 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 1 2 UCONNECT® 4.3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 2 3 UCONNECT® 8.4 & 8.4N . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37 3 4 SAFETY GUIDELINES . . . . . . . . . . . . .
Introduction CONTENTS 䡵 Uconnect® 4.3 . . . . . . . . . . . . . . . . . . . . . . . . . . .4 䡵 Uconnect® 8.4 . . . . . . . . . . . . . . . . . . . . . . . . . . .7 ▫ Uconnect® 4.3 System . . . . . . . . . . . . . . . . . . . .4 ▫ Uconnect® 8.4 System . . . . . . . . . . . . . . . . . . . .
4 Introduction Uconnect® 4.3 Uconnect® 4.
Introduction 5 Uconnect® 4.3 System (4) PLAYER Press the PLAYER hard-key to access media sources such as: Disc, USB Device and AUX as long as the requested Press the ON/OFF button to turn the system ON or OFF. media is present. Rotate the rotary knob to adjust the Volume. (5) RADIO NOTE: If the ignition is switched OFF with the radio in standby mode, the radio memorizes the standby mode Press the RADIO hard-key to enter the Radio Mode. The when the ignition is turned ON again.
6 Introduction (7) MORE (9) ENTER/BROWSE & TUNE/SCROLL Press the MORE hard-key to access additional options. Options available such as: Uconnect® Phone and Compass can be accessed by touching the corresponding soft-key in the More Menu. Press the ENTER/BROWSE button to accept a highlighted selection on the screen. Rotate the TUNE/ SCROLL rotary knob to scroll through a list or tune a radio station.
Introduction 7 Uconnect® 8.4 1 Uconnect® 8.
8 Introduction Uconnect® 8.4 System (3) RADIO Press the Radio soft-key to enter the Radio Mode. The different tuner modes; AM, FM and SAT can be selected Press the ON/OFF button to turn the unit ON or OFF. by touching the corresponding soft-keys in the Radio Rotate the rotary knob to adjust the Volume. Mode. NOTE: If the ignition is switched OFF with the radio in (4) PLAYER standby mode, the radio memorizes the standby mode when the ignition is turned ON again.
Introduction 9 (6) CLIMATE (On-Screen Controls) (10) ENTER/BROWSE & TUNE/SCROLL Refer to Climate Controls in your vehicles Owner’s Press the ENTER/BROWSE button to accept a highManual on the DVD for further details. lighted selection on the screen. Rotate the TUNE/ SCROLL rotary knob to scroll through a list or tune a (7) NAV radio station. Press the Nav soft-key to access the Navigation feature. (11) SD CARD SLOT Refer to the Navigation section in this manual for further details.
Uconnect® 4.3 2 CONTENTS 䡵 Radio Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . .13 ▫ Browse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 ▫ Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 ▫ Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 ▫ Common Radio Functions . . . . . . . . . . . . . . . .13 ▫ Info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 ▫ Seek and Direct Tune Functions . . . . . . . . . . . .
12 Uconnect® 4.3 ▫ Info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27 ▫ Seek Up/Down. . . . . . . . . . . . . . . . . . . . . . . .29 ▫ Shuffle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27 ▫ Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30 ▫ Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27 ▫ Info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30 䡵 AUX Mode . . . . . . . . . . . . . . . . . . . . . . . . . . .
Uconnect® 4.3 13 Radio Mode Overview Touch the Radio hard-key, upper left corner, to enter the Radio Mode. The different tuner modes; AM, FM, and SAT, can then, be selected by touching the corresponding soft-keys on the screen. Common Radio Functions The following operations offer the same functionality across all Radio Modes, and further instructions are provided where differences exit. ON/OFF & Volume Control Push the ON/OFF Volume control knob to turn on the radio.
14 Uconnect® 4.3 When the audio system is turned on, the sound will be Go set at the same volume level as last played. Touch the green GO soft-key to allow you to commit an entry, at which time, the radio will tune to the entered Enter/Browse & Tune/Scroll Control Channel, and close the Direct Tune Screen. The GO Turn the rotary TUNE/SCROLL control knob soft-key is only for SiriusXM™ Satellite radio mode. clockwise to increase or counterclockwise to decrease the radio station frequency.
Uconnect® 4.3 15 Fast Seek Up Direct Tune Touch and hold the Seek Up soft-key to advance the radio through the available stations or channels at a faster rate, the radio stops at the next available station or channel when the soft-key is released. Seek Down Touch and release the Seek Down soft-key to tune the radio to the next listenable station or channel.
16 Uconnect® 4.3 Press the available number soft-key to begin selecting a Setting Presets desired station. Once a number has been entered, any numbers that are no longer possible (stations that cannot be reached) will become deactivated / grayed out. If you accidently entered the wrong station number, touch the CLR soft-key to clear the radio station numbers and reenter the correct station number.
Uconnect® 4.3 17 When you are receiving a station that you wish to All Presets Button commit into memory, press and hold the desired numbered soft-key for more that 2 seconds or until you hear a confirmation beep. The Radio stores up to 12 presets in each of the Radio modes. A set of 4 presets are visible at the top of the radio screen. Touching the ⬙all⬙ soft-key on the radio home screen will display all of the preset stations for that mode.
18 Uconnect® 4.3 Return to Main Radio Screen • Balance/Fade You can return to the Main Radio Screen, by either touching Exit soft-key or pressing the Radio hard-key. Touch the Balance/Fade soft-key to adjust the sound from the speakers. Use the arrow soft-key to adjust the sound level from the front and rear or right and left side speakers. Touch the Center ⬙C⬙ soft-key to reset the balance and fade to the factory setting. Press the back arrow soft-key when done.
Uconnect® 4.3 19 This functionality is only available for radios equipped SiriusXM™ Satellite radio uses direct satellite-to-receiver with a Satellite receiver. In order to receive satellite radio, broadcasting technology to provide clear digital sound, the vehicle needs to be outside with a clear view to the coast to coast. The subscription service provider is sky. SiriusXM™ Satellite Radio.
20 Uconnect® 4.3 Acquiring SiriusXM™ Subscription When in SiriusXM™ Satellite mode: • The SiriusXM™ Presets are displayed at the top of the screen. • The SiriusXM™ Channel Number is displayed along with Artist and Song name. • The SiriusXM™ function soft-keys are displayed on the bottom. In addition to the tuning functions common to all Radio modes, the browse ,info, and more hard-key functions are available in SiriusXM™ Mode.
Uconnect® 4.3 21 Browse Gamezone Touch the browse soft-key at the bottom left of the screen Touch the more... soft-key and then the gamezone softto enter the Browse screen. key to access the gamezone feature. This feature provides you with the ability to Select teams, edit the selection, The Browse screen in SAT mode provides you the ability and set Alerts. to browse by All, Favorites or Genres. You can also access Gamezone, and Traffic and Weather settings in the Replay Browse screen.
22 Uconnect® 4.3 Play/Pause Forward Touch the Pause or Play soft-key to pause playing of the content at any time that the content is playing live or rewound content. Play can be resumed again by touching of the Pause/Play soft-key. Each touch of the FW soft-key forwards the content in steps of 5 seconds. Forwarding of the content can only be done when the content is previously rewound, and therefore, can not be done for live content. A continuous touch of the FW soft-key also forwards the content.
Uconnect® 4.3 23 If you insert a disc with the ignition ON and the radio ON, the unit will switch to Disc mode and begin to play Overview when you insert the disc. The display will show the track Disc Mode is entered by either inserting a Disc or by number, and index time in minutes and seconds. Play touching the Player hard-key located left of the display. will begin at the start of track 1. Once in Player Mode, touch the source soft-key and select Disc.
24 Uconnect® 4.3 EJECT Button - Ejecting a Disc Press the EJECT button to eject the Disc. Fast Seek Up Touch and hold the right arrow soft-key and the Disc player will begin to fast forward through the current track until the soft-key is released. If you have ejected a disc and have not removed it within Fast Seek Down 10 seconds, it will be reloaded. If the Disc is not removed, Touch and hold the left arrow soft-key and the Disc the radio will reinsert the Disc but will not play it.
Uconnect® 4.3 25 Source Shuffle Touch the Source soft-key to select the desired audio source, CD, AUX or USB. This screen will time out after a few seconds and return to the main radio screen if no selection is made. Touch the more... soft-key then the shuffle soft-key to play the selections on the compact disc in random order to provide an interesting change of pace. Touch the soft-key a second time to turn this feature off.
26 Uconnect® 4.3 USB/iPod Mode Seek Up/Down Overview Touch and release the right arrow soft-key for the next selection on the USB/iPod device. Touch and release the left arrow soft-key to return to the beginning of the current selection, or return to the beginning of the previous selection if the USB/iPod device is within the first second of the current selection.
Uconnect® 4.3 27 Browse Info Touch the Browse soft-key to select Artist, Albums, Genres, Songs, Playlists or Folders from the USB/iPod device. Once the desired selection is made you can chose from the available media by touching the soft-key. Touch the exit soft-key if you wish to cancel the browse function. Touch the Info soft-key to display the current track information. Touch the ⬙X⬙ soft-key to cancel this feature. Shuffle Touch the more...
28 Uconnect® 4.3 AUX Mode Overview AUX Mode is entered by inserting a AUX device using a cable with a 3.5 mm audio jack into the AUX port or by touching the Player hard-key located left of the display. Once in Player Mode, touch the source soft-key and select AUX. Inserting Auxiliary Device radio; use the device controls instead. Adjust the volume with the ON/OFF VOLUME rotary knob, or with the volume of the attached device.
Uconnect® 4.3 29 Bluetooth® Mode Seek Up/Down Touch and release the right arrow soft-key for the next selection on the Bluetooth device. Touch and release the Bluetooth Streaming Audio (BTSA) or Bluetooth Mode is left arrow soft-key to return to the beginning of the entered by pairing a Bluetooth device, containing music, current selection, or return to the beginning of the to the Uconnect® System.
30 Uconnect® 4.3 Fast Seek Down Info Touch and hold the left arrow soft-key and the Bluetooth Touch the Info soft-key to display the current track device will begin to rewind through the current track information. Touch the Info soft-key a second time to until the soft-key is released. cancel this feature. Source Audio Touch the Source soft-key to select the desired audio Refer to Operating Instructions – Radio Mode for adjustsource, CD, USB/iPod, AUX or Bluetooth. This screen ing the audio settings.
Uconnect® 4.3 31 More & Settings • Time More Main Menu Refer to this section for details. Press the More hard-key to display the More Main Menu. • Compass The More Main Menu contains the following options: Refer to ⬙Understanding Your Instrument Panel⬙, • Economy (If Equipped) ⬙Uconnect® System⬙ section in your vehicle Owner’s Refer to ⬙Understanding Your Instrument Panel⬙, Manual on the DVD for details. ⬙Uconnect® System⬙ section in your vehicle Owner’s Clock Setting Manual on the DVD for details. 1.
32 Uconnect® 4.3 2. Touch the Up or Down arrows to adjust the hours or minutes, next select the AM or PM soft-key. You can also select 12hr or 24hr format by touching the desires soft-key. Settings Main Menu Press the Settings hard-key to display the Settings Main Menu. The Settings Main Menu contains the following options: • Display Refer to this section for details. • Clock Refer to this section for details.
Uconnect® 4.3 33 • Lights • Compass Settings Refer to ⬙Understanding Your Instrument Panel⬙, Refer to ⬙Understanding Your Instrument Panel⬙, ⬙Uconnect® System⬙ section in your vehicle Owner’s ⬙Uconnect® System⬙ section in your vehicle Owner’s Manual on the DVD for details. Manual on the DVD for details. • Doors & Locks • Audio Refer to ⬙Understanding Your Instrument Panel⬙, Refer to the Operating Instructions – Radio section in this ⬙Uconnect® System⬙ section in your vehicle Owner’s manual for details.
34 Uconnect® 4.3 3. The Display Menu shows the following options for you to customize your display. Your Uconnect® display can be customized by following • Brightness the steps: Touch the Brightness soft-key and use the + or 1. Press the SETTINGS hard-key on the right side of the soft-keys to adjust the brightness of the display screen display. with the headlights on or off. Press the back arrow soft-key when done.
Uconnect® 4.3 35 • Language • Touch Screen Beep Touch the Language soft-key to select between EngTouch the Touch Screen Beep soft-key to turn the ON lish, French or Spanish. Press the back arrow soft-key or OFF the sound heard when a screen soft-key is when done. pressed. Press the back arrow soft-key when done. • Units 4. Touch the Exit soft-key to exit from the Display Menu. Touch the Units soft-key to select between U.S. and Metric units of measure. Press the back arrow soft-key when done.
Uconnect® 8.4 & 8.4N CONTENTS 䡵 Radio Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . .40 䡵 Disc Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . .57 ▫ Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . .40 ▫ Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . .57 ▫ Common Radio Functions . . . . . . . . . . . . . . . .40 ▫ Seek Up/Down. . . . . . . . . . . . . . . . . . . . . . . .58 ▫ Seek and Direct Tune Functions . . . . . . . . . . . .41 ▫ Browse . . . .
38 Uconnect® 8.4 & 8.4N 䡵 USB/iPod Mode . . . . . . . . . . . . . . . . . . . . . . . .61 ▫ Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69 ▫ Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . .61 ▫ Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69 ▫ Seek Up/Down. . . . . . . . . . . . . . . . . . . . . . . .61 䡵 SD Card Mode. . . . . . . . . . . . . . . . . . . . . . . . . .70 ▫ Browse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Uconnect® 8.4 & 8.4N 39 䡵 Bluetooth® Mode . . . . . . . . . . . . . . . . . . . . . . . .77 ▫ About the Map Pages . . . . . . . . . . . . . . . . . . .94 ▫ Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . .77 ▫ Using the Tools . . . . . . . . . . . . . . . . . . . . . . .100 ▫ Seek Up/Down. . . . . . . . . . . . . . . . . . . . . . . .77 ▫ Traffic. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .102 ▫ Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
40 Uconnect® 8.4 & 8.4N Radio Mode Overview Touch the RADIO Soft Key, bottom left corner, to enter the Radio Mode. The different tuner modes; AM, FM, and SAT, can then, be selected by touching the corresponding soft-keys in the Radio mode. Common Radio Functions The following operations offer the same functionality across all Radio Modes, and further instructions are provided where differences exit. ON/OFF & Volume Control Push the ON/OFF Volume control knob to turn on the radio.
Uconnect® 8.4 & 8.4N 41 When the audio system is turned on, the sound will be Seek Up set at the same volume level as last played. Touch and release the Seek Up soft-key to tune the radio to the next listenable station or channel. Tune/Scroll Control Turn the rotary TUNE/SCROLL control knob During a Seek Up function, if the radio reaches the clockwise to increase or counterclockwise to starting station after passing through the entire band two decrease the radio station frequency.
42 Uconnect® 8.4 & 8.4N Seek Down Direct Tune Touch and release the Seek Down soft-key to tune the radio to the next listenable station or channel. During a Seek Down function, if the radio reaches the starting station after passing through the entire band two times, the radio will stop at the station where it began.
Uconnect® 8.4 & 8.4N 43 The selected Station or Channel number is displayed in the Direct Tune text box. Undo You can backspace an entry by touching the bottom left Undo soft key. GO When touched, the green GO soft key allows the you to commit an entry, at which time the radio will tune to the entered station or channel and close the Direct Tune Screen. Press the available number soft-key to begin selecting a Screen Close desired station.
44 Uconnect® 8.4 & 8.4N Setting Presets Browse in AM/FM The Presets are available for all Radio Modes, and are activated by touching any of the six Preset soft keys, located at the top of the screen. When you are receiving a station that you wish to commit into memory, press and hold the desired numbered soft-key for more that 2 seconds or until you hear a confirmation beep. The Radio stores up to 12 presets in each of the Radio modes. A set of 6 presets are visible at the top of the radio screen.
Uconnect® 8.4 & 8.4N 45 Scrolling Preset List Preset Selection from List A Preset can be selected by touching any of the listed Presets, or by pressing the ENTER/BROWSE button on the Tune Knob to select the currently highlighted Preset. When selected, the radio tunes to the station stored in the Preset and returns to the main radio screen. Deleting Presets A Preset can be deleted in the Presets Browse screen by touching the Trash Can Icon for the corresponding Preset.
46 Uconnect® 8.4 & 8.4N SiriusXM™ Satellite Radio Mode programming for children, directly from its satellites and broadcasting studios. A one-year SiriusXM™ Satellite Radio subscription is included. SiriusXM™ and all related marks and logos are trademarks of SiriusXM™ Radio Inc. and its subsidiaries. SiriusXM™ Radio requires a subscription, sold separately after trial subscription included with vehicle purchase. Prices and programming are provided by SiriusXM™ and are subject to change.
Uconnect® 8.4 & 8.4N 47 If the screen shows Acquiring Signal, you might have to When in SiriusXM™ Satellite mode: change the vehicle’s position in order to receive a signal. • The SAT button is highlighted. In most cases, the satellite radio does not receive a signal • The SiriusXM™ Presets are displayed at the top of the in underground parking garages or tunnels. screen. No Subscription • The Genre is displayed below the Presets Bar.
48 Uconnect® 8.4 & 8.4N In addition to the tuning Operation functions common to Rewind all Radio modes, the replay, Traffic/Weather Jump, and Touch the RW soft-key to rewind the content in steps of fav soft-key functions are available in SiriusXM™ Mode. 5 seconds. Touching the RW soft-key for more than 2 seconds rewinds the content. The Radio begins playing Replay the content at the point at which the touch is released.
Uconnect® 8.4 & 8.4N 49 Fav. Song While the song is playing to set a Favorite Song, touch the fav. soft-key and then the Fav Song Touch the fav. soft-key to activate the favorites menu, soft-key. which will time out in 5 seconds in absence of user interaction. Traffic & Weather Favorites You can exit the Favorites Menu by a touch of the X in the Touch the Traffic & Weather soft-key to tune to a SiriusXM™ Traffic & Weather channel. To set a Traffic & top right corner.
50 Uconnect® 8.4 & 8.4N Browse in SAT This Screen contains many sub menus. You can exit a sub menu to get back to a parent menu by a touch of the Back Arrow. All Touch the All soft-key at the left of the Browse Screen. Channel List Touch the Channel List to display all the SIRIUS Channel Numbers along with the corresponding Genre. You can scroll the Channel list by touching the up and down arrows, located on the right side of the screen. Scrolling can also be done by operating the Tune/Scroll Knob.
Uconnect® 8.4 & 8.4N 51 Genre Preset Selection Touch the Genre button to display a list of Genres. You can select any desired Genre by touching the Genre list, at which point, the Radio tunes to a channel with the content in the selected Genre. A Preset can be selected by touching any of the listed Presets, or by pressing the ENTER/BROWSE button on the Tune Knob to select the currently highlighted Preset.
52 Uconnect® 8.4 & 8.4N Favorites Remove Favorites Touch the Favorites soft-key, located at the left of the Touch the Remove Favorites tab at the top of the screen. Browse screen. Touch the Delete All soft-key to delete all of the Favorites or touch the Trash Can icon next to the Favorite to be The Favorites menu provides a means to Edit the Favorites list and to configure the Alert Settings, along with deleted. providing a list of Channels currently airing any of the items in the Favorites list.
Uconnect® 8.4 & 8.4N 53 On Air Remove Selection Touch the On-Air tab at the top of the screen. The On-Air list provides a list of Channels currently airing any of the items in the Selections list, and touching any of the items in the list tunes the radio to that channel. Touch the Remove Selection tab at the top of the screen. Touch the Delete All soft-key to delete all of the Selections or touch the Trash Can icon next to the Selection to be deleted.
54 Uconnect® 8.4 & 8.4N Traffic & Weather Balance/Fade Touch the Traffic & Weather soft-key to tune to a Touch the Balance/Fade soft-key to Balance audio beSiriusXM™ Traffic & Weather channel. tween the front speakers or fade the audio between the rear and front speakers. Touch the Up and Down arrows to the right side of the list to view all the available cities. This operation can also be done with operation of the Scroll/Tune Knob. Touch the check box next to the desired City.
Uconnect® 8.4 & 8.4N 55 Equalizer Speed Adjusted Volume Touch the Equalizer soft-key to activate the Equalizer screen. 3 Touch the Speed Adjusted Volume soft-key to activate the Speed Adjusted Volume screen. Touch the + or - soft-keys, or by touching and dragging over the level bar for each of the equalizer bands. The level value, which spans between ±9, is displayed at the bottom of each of the Bands.
56 Uconnect® 8.4 & 8.4N Music Info Cleanup Surround Sound Touch the On soft-key to active the Music Info Cleanup. Touch the On soft-key to activate Surround Sound. Touch Touch Off to deactivate this feature. Off to deactivate this feature. When Music Cleanup is On, the radio uses the Gracenotes When Surround Sound is On, you can hear audio coming database to display standard normalized information for from every direction as in a movie theatre or home song title, artist, album, etc. theatre system.
Uconnect® 8.4 & 8.4N 57 Disc Mode Overview A “No Disc” message will be displayed on the screen in the Disc mode when a Disc is not present in the Radio. Inserting Compact Disc Disc Mode is entered by either inserting a Disc or by touching the Player soft-key located on the bottom of the Gently insert one Disc into the Disc player with the Disc display. Once in Player Mode, touch the source soft-key label facing up.
58 Uconnect® 8.4 & 8.4N CAUTION! • This CD Player will accept 4-3/4 in (12 cm) discs only. The use of other sized discs may damage the CD player mechanism. • Do not use adhesive labels. These labels can peel away and jam the player mechanism. • Uconnect® 8.4 is a single Disc player. Do not attempt to insert a second Disc if one is already loaded. EJECT Button - Ejecting a Disc Press the EJECT button to eject the Disc. A disc can be ejected with the radio and ignition OFF.
Uconnect® 8.4 & 8.4N 59 Browse Repeat Touch the browse soft-key to display the browse window. The left side of the browse window displays a list of ways you can browse through the contents of the Disc. If supported by the device, you can browse by Folders, Artists, Playlists, Albums, Songs, etc. Touch the desired soft-key on the left side of the screen. The center of the browse window shows items and it’s sub-functions, which can be scrolled by touching the Up and Down soft-keys to the right.
60 Uconnect® 8.4 & 8.4N Touching the trks soft-key while the pop up is displayed Touch the trks soft-key to display a pop up with the Song will close the pop up. List. The currently playing song is indicated by an arrow Audio and lines above and below the song title. Refer to Operating Instructions – Radio Mode for adjusting the audio settings.
Uconnect® 8.4 & 8.4N 61 USB/iPod Mode Inserting USB/iPod Device Gently insert the USB/iPod device into the USB Port. If you insert a USB/iPod device with the ignition ON and USB/iPod Mode is entered by either inserting a USB device the radio ON, the unit will switch to USB/iPod mode and or iPod and cable into the USB Port or by touching the begin to play when you insert the device. The display Player soft-key located on the bottom of the display.
62 Uconnect® 8.4 & 8.4N desired soft-key on the left side of the screen. The center of the browse window shows items and it’s subTouch and hold the right arrow soft-key and the USB functions, which can be scrolled by touching the Up and device/iPod will begin to fast forward through the Down soft-keys to the right. The Scroll/Tune knob can current track until the soft-key is released. also be used to scroll.
Uconnect® 8.4 & 8.4N 63 NOTE: Many features of this system are speed dependent. For your own safety these features may be grayed out and not accessible while the vehicle is in motion. Pull over at a safe location to complete your task. Search Touch the Search soft-key tab at the top of the screen to display the Keyboard. This allows you to enter a folder or file name to be searched.
64 Uconnect® 8.4 & 8.4N Up Arrow Touch the Up Arrow soft-key to toggle between Upper Case and Lower Case keys. ABC, ÅØÜ and 1234!&#@ Touch the ABC key to activate a keyboard with Alphabetic characters, or touch the ÅØÜ to activate a keyboard with accented characters or touch the 1234!&#@ key to activate a keyboard with Numeric plus Special characters. Folders – If Equipped Touch the Folders soft-key on the left side of the screen to display the Folders scroll menu.
Uconnect® 8.4 & 8.4N 65 Artist Songs Touch the Artist soft-key on the left side of the screen to display the Artists list in which you can Scroll, Search, and Jump to operations. Playlists – If Equipped 3 Touch the Playlists soft-key on the left side of the screen to display the current playlist information. Touch the Songs soft-key on the left side of the screen to display the Songs list in which the user can Scroll, Search, and Jump to operations.
66 Uconnect® 8.4 & 8.4N Albums Repeat Touch the Albums soft-key on the left side of the screen to Touch the repeat soft-key to toggle the repeat functiondisplay the Albums list in which you can Scroll, Search, ality. The Repeat soft-key is highlighted when active. The and Jump to operations. Radio will continue to play the current track, repeatedly, as long as the repeat is active.
Uconnect® 8.4 & 8.4N 67 Info Touch the Info soft-key to display the current track information. Touch the Info soft-key a second time to cancel this feature. Tracks 3 Touch the trks soft-key to display a pop up with the Song List. The currently playing song is indicated by an arrow and lines above and below the song title.
68 Uconnect® 8.4 & 8.4N AUX Mode Inserting Auxiliary Device Gently insert the Auxiliary device cable into the AUX Port. If you insert an Auxiliary device with the ignition AUX Mode is entered by inserting an AUX device using ON and the radio ON, the unit will switch to AUX mode a cable with a 3.5 mm audio jack into the AUX port or by and begin to play when you insert the device cable. touching the Player soft-key located at the bottom of the display.
Uconnect® 8.4 & 8.4N 69 NOTE: The vehicle radio unit is acting as the amplifier Audio for audio output from the Auxiliary device. Therefore if Refer to Operating Instructions – Radio Mode for adjustthe volume control on the Auxiliary device is set too low, ing the audio settings. there will be insufficient audio signal for the radio unit to play the music on the device. Source Touch the Source soft-key to select the desired audio source, Disc, USB/iPod, SD Card, AUX or Bluetooth.
70 Uconnect® 8.4 & 8.4N SD Card Mode Inserting SD Card Overview Gently insert the SD Card into the SD Card slot. If you insert a SD Card with the ignition ON and the radio ON, the unit will switch to SD Card mode and begin to play when you insert the card. The display will show the track number, and index time in minutes and seconds. Play will begin at the start of track 1.
Uconnect® 8.4 & 8.4N 71 Albums, Songs, etc. Touch the desired soft-key on the left side of the screen. The center of the browse window Touch and hold the right arrow soft-key and the SD Card shows items and it’s sub-functions, which can be scrolled will begin to fast forward through the current track until by touching the Up and Down soft-keys to the right. The the soft-key is released. Scroll/Tune knob can also be used to scroll.
72 Uconnect® 8.4 & 8.4N NOTE: Many features of this system are speed dependent. For your own safety these features may be grayed out and not accessible while the vehicle is in motion. Pull over at a safe location to complete your task. Search Touch the Search soft-key tab at the top of the screen to display the Keyboard. This allows you to enter a folder or file name to be searched.
Uconnect® 8.4 & 8.4N 73 of a sub-folder by touching the Folder Name in the list. Touch the Back Arrow soft-key to return or back up to a Touch the Up Arrow soft-key to toggle between Upper previous folder level. Case and Lower Case keys. Up Arrow ABC, ÅØÜ and 1234!&#@ Touch the ABC key to activate a keyboard with Alphabetic characters, or touch the ÅØÜ to activate a keyboard with accented characters or touch the 1234!&#@ key to activate a keyboard with Numeric plus Special characters.
74 Uconnect® 8.4 & 8.4N Artist Songs Touch the Artist soft-key on the left side of the screen to display the Artists list in which you can Scroll, Search, and Jump to operations. Playlists – If Equipped Touch the Playlists soft-key on the left side of the screen to display the current playlist information. Touch the Songs soft-key on the left side of the screen to display the Songs list in which the user can Scroll, Search, and Jump to operations.
Uconnect® 8.4 & 8.4N 75 Albums Repeat Touch the Albums soft-key on the left side of the screen to Touch the repeat soft-key to toggle the repeat functiondisplay the Albums list in which you can Scroll, Search, ality. The Repeat soft-key is highlighted when active. The and Jump to operations. Radio will continue to play the current track, repeatedly, as long as the repeat is active.
76 Uconnect® 8.4 & 8.4N Info Touch the Info soft-key to display the current track information. Touch the Info soft-key a second time to cancel this feature. Tracks Touch the trks soft-key to display a pop up with the Song List. The currently playing song is indicated by an arrow and lines above and below the song title.
Uconnect® 8.4 & 8.4N 77 Bluetooth® Mode Seek Up/Down Touch and release the right arrow soft-key for the next selection on the Bluetooth device. Touch and release the Bluetooth Streaming Audio (BTSA) or Bluetooth Mode is left arrow soft-key to return to the beginning of the entered by pairing a Bluetooth device, containing music, current selection, or return to the beginning of the to the Uconnect® system.
78 Uconnect® 8.4 & 8.4N Source Touch the Source soft-key to select the desired audio source, Disc, USB/iPod, SD Card, AUX or Bluetooth. This screen will time out after a few seconds and return to the main radio screen if no selection is made. Repeat Touch the repeat soft-key to toggle the repeat functionality. The Repeat soft-key is highlighted when active. The Radio will continue to play the current track, repeatedly, as long as the repeat is active.
Uconnect® 8.4 & 8.4N 79 Navigation (8.4N Only) Safety Precautions and Important Information WARNING • Do not input destinations, change settings, or access any functions requiring prolonged use of the navigation system controls while driving. Pull over in a safe and legal manner before attempting such operations.
80 Uconnect® 8.4 & 8.4N • Be careful of the ambient temperature. Using the navigation system at extreme temperatures can lead to malfunction or damage. Also note that the unit can be damaged by strong vibration, by metal objects, or by water getting inside the unit. subject to changes that could affect the accuracy and performance of all GPS equipment, including the navigation system. NOTICE This navigation system can be used when the ignition key is turned to ON or ACC.
Uconnect® 8.4 & 8.4N 81 Getting Started Main Menu To access the Navigation system, touch the Nav soft-key on bottom of the screen. Setting up Your System 3 When using your navigation system for the first time, complete the following tasks. 1. Acquire satellites. 2. Understand the main menu. Acquiring Satellites The bars indicate satellite strength. Go to an open area, away from tall buildings and trees. Acquiring satellite signals can take a few minutes. 1. Touch to find a destination. 2.
82 Uconnect® 8.4 & 8.4N 5. Touch to open the menu of tools. 4. Select a destination. 6. Touch to open the menu of settings. 5. Touch Go!. Using the On-screen Buttons Finding a Location by Spelling the Name • Touch and hold to quickly return to the main menu. 1. From the main menu, touch Where To? > Points of Interest > Spell Name. and to see more choices. • Touch 2. Enter all or part of the name. and to scroll faster. • Touch and hold 3. Touch Done.
Uconnect® 8.4 & 8.4N 83 • Touch and hold • Touch to erase the entire entry. to select the keyboard language mode. Changing the Destination of the Active Route Before you can change destinations, you must be navigating a route. to enter special characters, such as punctua• Touch 1. Touch tion marks. 2. Touch Where To?. Adding Points to the Active Route 1. While navigating a route, touch main menu. to return to the 3. Search for the location. 2. From the main menu, touch Where To?. 3.
84 Uconnect® 8.4 & 8.4N NOTE: If the route you are currently taking is the only Finding an Address reasonable option, the navigation system might not calNOTE: Depending on the version of the built in map data culate a detour. on your navigation system, the button names and the . order of steps could be different than the steps below. 1. While navigating a route, touch 2. From the main menu, touch Detour. 1. From the main menu, touch Where To? > Address. Stopping the Route 2.
Uconnect® 8.4 & 8.4N 85 6. If necessary, select the city/postal code. NOTE: Not all map data provides postal code searching. 7. Enter the number of the address. 8. Touch Done. 3 9. Enter the street name. 10. Touch Done. 11. If necessary, select the street. 12. If necessary, select the address. 1. Touch to call the selected location when your device is connected to phone, or to save the location to your The Go! page opens when you select a location to favorites. navigate to. 2.
86 Uconnect® 8.4 & 8.4N 5. Touch to zoom in and out. Resetting Your Home Location 6. Touch to return to the previous page. Touch and hold 1. From the main menu, touch Where To? > Home Location. to return to the main menu. 7. Touch to create a turn-by-turn route to this location. 2. Select an option to change your address. Setting a Home Location Editing Your Home Location Information > Set You can set your home location for the location you 1.
Uconnect® 8.4 & 8.4N 87 Viewing a List of Recently Found Locations Saving Your Current Location to Favorites Your navigation system stores the last 50 locations you 1. From the map, touch the vehicle icon. have found. 2. Touch Save. • From the main menu, touch Where To? > Recently 3. Enter a name. Found. 4. Touch Done. Clearing the List of Recently Found Locations The location is saved in Favorites. • From the main menu, touch Where To? > Recently Saving Locations to Favorites > Clear > Yes.
88 Uconnect® 8.4 & 8.4N Editing Favorites Planning a Trip 1. From the main menu, touch Where To? > Favorites. You can use Trip Planner to create and save a trip with multiple destinations. 2. Select a category. 3. Select a favorite. 4. Touch the information box. 5. Touch > Edit. 6. Select an option: • Name • Phone Number • Categories • Change Map Symbol 1. From the main menu, touch Where To? > Trip Planner. 2. Touch . 3. Touch Select Start Location. 4. Search for a location. 5. Touch Select. 6.
Uconnect® 8.4 & 8.4N 89 Navigating to a Saved Trip Using the Map Buttons 1. From the main menu, touch Where To? > Trip Planner. 1. From the main menu, touch Where To? > Browse Map. 2. Select a saved trip. 1. From the main menu, touch Where To? > Trip Planner. 2. Touch anywhere on the map. and to zoom in and out. • Touch to switch between 2D and 3D views. • Touch to rotate the view. • Touch 2. Select a saved trip. Browsing the Map by Touching the Screen 3. Touch Go!. Editing a Saved Trip 3.
90 Uconnect® 8.4 & 8.4N Finding a Location Using the Map Setting a Simulated Location 1. From the main menu, touch Where To? > Browse You can use the GPS simulator to select another location, near which you can search for and save points of interest. Map. This may be helpful when planning trips. 2. Touch a location. 1. From the main menu, touch Tools > Settings > System An information box appears next to the location. > GPS Simulator > On. 3. Touch the information box. 2.
Uconnect® 8.4 & 8.4N 91 Entering Coordinates Speaking Commands If you know the geographic coordinates of your destina- About Voice Commands tion, you can use your navigation system to navigate to NOTE: The voice command feature is not available for the destination using the latitude and longitude coordiall languages or regions. nates. The voice commands allow you to use your navigation 1. From the main menu, touch Where To? > Coordisystem by speaking the words you see on the screen or by nates.
92 Uconnect® 8.4 & 8.4N About Icons and Tones • Respond to voice prompts from the navigation system as needed. • The navigation system sounds two tones when it • Speak “Exit” to exit voice command. enters and exits voice recognition mode. red icon appears in the upper-right corner of the Navigating to a Popular Location Using Voice • A screen when the navigation system is not ready for Commands your command. You can speak the names of very popular, well-known icon is green to speak your command.
Uconnect® 8.4 & 8.4N 93 3. Listen for the voice prompt and speak the name of the location. 4. Speak the line number. A list of locations appears.
94 Uconnect® 8.4 & 8.4N 5. Speak an option: Speaking an Address • Speak “Go!” to navigate to the location. 1. Speak “Voice Command.” • Speak “Call” to call the location when connected to a 2. Speak “Find Address.” compatible mobile phone. 3. Follow the on-screen prompts.
Uconnect® 8.4 & 8.4N 95 Your route is marked with a magenta line. A checkered Using the Navigation Map flag marks your destination. As you travel, your navigation system guides you to your destination with voice prompts, arrows on the map, and directions at the top of the map. If you depart from the original route, your navigation system recalculates the route and provides new directions. 3 A speed limit icon displaying the current speed limit may appear as you travel on major roadways. 1.
96 Uconnect® 8.4 & 8.4N 3. Touch to zoom in and zoom out. 4. Touch to return to the main menu. 5. Touch to display a different data field. 6. Touch to view information for the location. When myTrends information appears in the navigation bar, you can touch the navigation bar to view route options for the suggested destination. Enabling myTrends 7. Touch to view trip information. • From the main menu, touch Settings > Navigation > myTrends > Enabled.
Uconnect® 8.4 & 8.4N 97 TIP: If you make frequent stops, leave the navigation Resetting Trip Information system turned on so it can accurately measure elapsed 1. From the map, touch the Speed field. time during the trip. . 2. Touch From the map, touch the Speed field. 3. Select an option: • Touch Reset Trip Mileage to reset the information on the trip computer. • Touch Reset Max. Speed to reset the maximum speed.
98 Uconnect® 8.4 & 8.4N 2. Select an option: • Select a turn on the list to view the next turn. When you are navigating a route, you can view all of the > Map to view the entire route on the map. • Touch turns for your entire route and the distance between turns. Viewing the Next Turn Viewing the Turn List 1. From the map, touch the text bar on the top of the Before you can view the next turn, you must be navigatmap. ing a route.
Uconnect® 8.4 & 8.4N 99 Touch the turn indicator in the top left corner of the map. The junction view displays a view of some upcoming junctions and in which lane you should be driving. 3 Viewing the Junction View Before you can view the junction view, you must be navigating a route.
100 Uconnect® 8.4 & 8.4N Using the Tools Using the World Clock Viewing Current Location Information 1. From the main menu, touch Tools > World Clock. Use the Where Am I? page to view information about 2. Touch a city name. your current location. This feature is helpful if you need 3. Enter a new city name. to tell emergency personnel your location. 4. Touch Done. • From the main menu, touch Tools > Where Am I?. Finding Nearby Services 1. From the main menu, touch Tools > Where Am I?. 5.
Uconnect® 8.4 & 8.4N 101 Using the Unit Converter Setting Currency Conversion Rates Manually 1. From the main menu, touch Tools > Unit Converter. You can update the currency conversion rates manually so that you are always using the most current rates. 2. Touch the box with a unit of measure listed. 3. Select a unit of measure. 4. Touch Save. Two units of measure are listed. 5. Touch a unit of measure to change. 6. Select a unit of measure. 1. From the main menu, touch Tools > Unit Converter. 2.
102 Uconnect® 8.4 & 8.4N 8. Touch a box under a currency. 9. Enter a new value for the currency. 10. Touch Done. The FM TMC traffic receiver, which is integrated in the vehicle power cable, is included in some packages and is an optional accessory for all series models. Subscription Activation 11. Repeat steps 8–9, if necessary. You do not need to activate the subscription included with your FM traffic receiver.
Uconnect® 8.4 & 8.4N 103 Color Green Description Low severity Yellow Medium severity Red Gray High severity No data Meaning Traffic is flowing freely. Traffic is moving but there is a delay. There is moderate traffic congestion. Traffic is not moving or moving very slowly. There is a severe delay. Traffic information is not available. Traffic on Your Route When calculating your route, the navigation system examines the current traffic and automatically optimizes the route for the shortest time.
104 Uconnect® 8.4 & 8.4N 3. Touch an item in the list to view delays on the road. Viewing the Traffic Map The traffic map shows color-coded traffic flow and delays 4. If there is more than one delay, touch the arrows to on nearby roads. view additional delays. 1. From the map, touch . Adding a Subsciption 2. Touch Traffic Map to view the traffic incidents on a 1. From the main menu, touch Settings > Traffic. map. 2.
Uconnect® 8.4 & 8.4N 105 4. Go to www.garmin.com/fmtraffic to purchase a sub- Customizing the Navigation System scription and get a 25-character code. 1. From the main menu, touch Settings. 5. Touch Next. 6. Enter the code. 3 7. Touch Done. The traffic subscription code cannot be reused. You must obtain a new code each time you renew your service. If you own multiple FM traffic receivers, you must obtain a new code for each receiver. 2. Touch a setting category. 3. Touch the setting to change it.
106 Uconnect® 8.4 & 8.4N System Settings Changing the Map Settings From the main menu, touch Settings > System. From the main menu, touch Settings > Map. • GPS Simulator—stops the navigation system from • Map Detail—sets the level of detail on the map. More receiving a GPS signal, and saves battery power. detail may result in slower map drawing. • About—displays the software version number, the • Map View—sets the perspective on the Map page.
Uconnect® 8.4 & 8.4N 107 Changing the Map Perspective The route calculation is based on road speeds and vehicle acceleration data for a given route. 1. From the main menu, touch Settings > Map > Map • Faster Time—calculates routes that are faster to drive View. but can be longer in distance. 2. Select an option: • Touch Track Up to display the map in two dimen- • Shorter Distance—calculates routes that are shorter in distance but can take more time to drive.
108 Uconnect® 8.4 & 8.4N About trafficTrends™ Language Settings When the trafficTrends feature is enabled, your naviga- From the main menu, touch Settings > Language. tion system uses historic traffic information to calculate • Voice Personality— sets the language for voice more-efficient routes. Different routes may be calculated prompts. based on traffic trends for the day of the week or based • Keyboard—sets the language for your keyboard. on the time of day.
Uconnect® 8.4 & 8.4N 109 About Traffic Subscriptions Appendix You can purchase additional subscriptions or a renewal if your subscription expires. Go to www.garmin.com/ fmtraffic. About GPS Satellite Signals The navigation system must acquire satellite signals in order to navigate. Viewing traffic Subscriptions When the navigation system has acquired satellite signals, . • From the main menu, touch Settings > Traffic > the signal strength bars on the main menu are full .
110 Uconnect® 8.4 & 8.4N WARNING 3. Read and accept the terms of the Software License Agreement. Garmin and Chrysler Group LLC are not responsible for 4. Follow the instructions on the Web site to complete the the accuracy of, or the consequences of using, a safety camera database. installation of the software update. Safety camera information is available in some locations. Go to http://my.garmin.com for availability.
Uconnect® 8.4 & 8.4N 111 Custom POIs (Points of Interest) WARNING NOTE: Custom POI files must be named “poi.gpi”. and Garmin and Chrysler Group LLC are not responsible for located on the USB storage device in a folder named the consequences of using custom POI databases, or for ‘POI’ within a folder named “Garmin” (Garmin/POI/). the accuracy of custom POI databases. You can manually load custom points of interest (POI) databases, available from various companies on the Internet.
112 Uconnect® 8.4 & 8.4N Finding Custom PoIs SiriusXM™ Travel Link You can view a list of the custom POIs loaded in your Now, in addition to delivering over 130 channels of the best sports, entertainment, talk and 100% commercialnavigation system. free music, SiriusXM™ now offers premium infotain• Touch Where To? > Extras > Custom POIs. ment services that work in conjunction with compatible navigation systems. Deleting Custom PoIs 1. Touch Tools > My Data > Delete Custom POI(s). 2. Touch Yes to confirm.
Uconnect® 8.4 & 8.4N 113 • Route to selected fuel station. Sports Scores • Store a favorite fuel station for quick access to pricing. • View scores and upcoming events for all major sports. Movie Listings • Store your favorite teams for quick access to the scores and schedules. • Check which movies are playing at theaters near your current location.
114 Uconnect® 8.4 & 8.4N after trial subscription included with vehicle purchase. Prices and programming are provided by SiriusXM™ and are subject to change. Subscriptions governed by Terms & Conditions available at sirius.com/serviceterms. SiriusXM™ Radio U.S. service only available to those at least 18 years of age in the 48 contiguous United States, D.C., & PR. Visit www.sirius.com/TravelLink for more information on SIRIUS Travel Link.
Uconnect® 8.4 & 8.4N 115 You acknowledge that the Software is the property of Garmin and/or its third-party providers and is protected under the United States of America copyright laws and international copyright treaties.
116 Uconnect® 8.4 & 8.4N IMPORTANT: READ THIS LICENCE CAREFULLY BEFORE USING THIS PRODUCT. INSTALLING, COPYING OR OTHERWISE USING THIS PRODUCT INDICATES YOUR ACKNOWLEDGEMENT THAT YOU HAVE READ THIS LICENCE AND AGREE TO ITS TERMS. IF YOU DO NOT AGREE, RETURN THE COMPLETE PRODUCT WITHIN 7 DAYS OF THE DATE YOU ACQUIRED IT (IF PURCHASED NEW) FOR A FULL REFUND TO THE DEALER FROM WHICH YOU PURCHASED THIS PRODUCT.
Uconnect® 8.4 & 8.4N 117 Garmin no longer receives Map Data from NAVTEQ, whichever is shorter. The updates you receive under the subscription will be updates to the same geographic Map Data originally included with your Garmin product when originally purchased.
118 Uconnect® 8.4 & 8.4N No warranty. This Product (including the Data) is provided to you “as it is” and you agree to use it at your own risk.
Uconnect® 8.4 & 8.4N 119 THE BREACH OF THESE TERMS OR CONDITIONS, WHETHER IN AN ACTION IN CONTRACT OR TORT OR BASED ON A WARRANTY, EVEN IF GARMIN OR ITS LICENSORS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. GARMIN’S AND ITS LICENSORS’ TOTAL AGGREGATE LIABILITY WITH RESPECT TO ITS OBLIGATIONS UNDER THIS AGREEMENT OR OTHERWISE WITH RESPECT TO THE GARMIN PRODUCT OR THE DATA SHALL NOT EXCEED $1.00.
120 Uconnect® 8.4 & 8.4N including but not limited to lawyer’s fees, arising out of not be liable in any way for loss of revenues or contracts, or in connection with any use or possession by you of the or any other consequential loss of any kind resulting from any defect in the data or the Map Data. You shall Product (including the Data). indemnify and save harmless the licensors, including Her Canadian map data.
Uconnect® 8.4 & 8.4N 121 United States Map Data. NAVTEQ holds a nonexclusive licence from the United States Postal Service® to publish and sell ZIP+4® information. ©United States Postal Service® 2010. Prices are not established, controlled or approved by the United States Postal Service®. The following trademarks and registrations are owned by the USPS: United States Postal Service, USPS and ZIP+4.
122 Uconnect® 8.4 & 8.4N for Contracts for the International Sale of Goods, which is explicitly excluded. You agree to submit to the jurisdic(a) For European Union NAVTEQ Data tion of Illinois for any and all disputes, claims and actions The above terms and conditions shall be governed by the arising from or in connection with the NAVTEQ Data laws of the Netherlands, without giving effect to (i) its provided to you hereunder.
Uconnect® 8.4 & 8.4N 123 Government end users. If the End User is an agency, department or other entity of the United States Government, or funded in whole or in part by the U.S. Government, then use, duplication, reproduction, release, modification, disclosure or transfer of the Product and accompanying documentation is subject to restrictions as set forth in DFARS 252.2277014(a)(1) (JUN 1995) (DOD commercial computer software definition), DFARS 27.
124 Uconnect® 8.4 & 8.4N DMTI Spatial, Inc. End User License Agreement The software embedded in your Garmin product is owned by Garmin Ltd. or its subsidiaries (“Garmin”). The third-party postal code data (the “Licensed Product”) embedded in or accompanying your Garmin product is owned by DMTI Spatial, Inc. and is licensed to Garmin. Both the software and Licensed Product are protected under copyright laws and international copyright treaties.
Uconnect® 8.4 & 8.4N 125 incidental or consequential damages, arising out of your possession, use of, or inability to use the Licensed Product(s), even if DMTI Spatial, its third party supplier(s), or any authorized dealer, has been advised of the possibility of the damages, or for any claim by any other party.
126 Uconnect® 8.4 & 8.4N THE LICENSED PRODUCT(S) AND THE ASSOCIATED WRITTEN MATERIALS IN CONNECTION THEREWITH ARE PROVIDED “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, ARISING BY LAW OR OTHERWISE, INCLUDING BUT NOT LIMITED TO WARRANTIES OF EFFECTIVENESS, COMPLETENESS, ACCURACY, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. THE ENTIRE RISK AS TO THE QUALITY AND PERFORMANCE OF THE LICENSED PRODUCT(S) IS WITH YOU, THE END USER.
Uconnect® 8.4 & 8.4N 127 © Copyright, HER MAJESTY THE QUEEN IN RIGHT it, that your agree to be bound by the terms and condiOF CANADA, as represented by the Minister of Industry, tions of this Agreement, and that you are at least 18 years of age. If you do not agree to the terms and conditions of Statistics Canada 1996.
128 Uconnect® 8.4 & 8.4N may contain inaccuracies and/or errors from time to time. To the maximum extent permitted by applicable law, any and all warranties of any kind whatsoever with regard to the Traffic Data are hereby expressly waived and excluded, including, but not limited to, those of The Traffic Data is informational only. You assume all risk merchantability, fitness for a particular purpose, accuracy of use. NAVTEQ (and its affiliates), Garmin Ltd.
Uconnect® 8.4 & 8.4N 129 compensatory, direct, indirect, incidental, special, or consequential damages (including, without limitation, indirect, direct, special, punitive, or exemplary damages for loss of business, loss of profits, business interruption, or loss of business information) arising out of the use of or inability to use the Garmin product or the Traffic Data, even if NAVTEQ or Garmin have been advised of the possibility of such damages. Traffic.
130 Uconnect® 8.4 & 8.4N with the following “Notice of Use,” and shall be treated in NAVTEQ and Traffic.com are trademarks in the U.S. and other countries. © 2011 NAVTEQ; © 2011 Traffic.com. All accordance with such Notice: rights reserved. Notice of Use HD Radio Technology manufactured under license from Contractor (Manufacturer/ Supplier) Name: NAVTEQ iBiquity Digital Corporation. U.S. and Foreign Patents.
Uconnect® 8.4 & 8.4N 131 More & Settings Settings Main Menu More Main Menu The More Main Menu consists of the following options: • Settings 3 Refer to the Settings information in this section for more details. • SiriusXM™ Travel Link Refer to the Navigation section in this manual for more details. Touch the Settings soft-key to display the list of available settings.
132 Uconnect® 8.4 & 8.4N The Setting Main Menu consists of the following options. • Doors & Locks • Display Refer to this section for more details. • Clock Refer to this section for more details. Refer to ⬙Understanding Your Instrument Panel⬙, ⬙Uconnect® System⬙ section in your vehicle Owner’s Manual on the DVD for details.
Uconnect® 8.4 & 8.4N 133 • Compass Display Refer to ⬙Understanding Your Instrument Panel⬙, Your Uconnect® display can be customized by following ⬙Uconnect® System⬙ section in your vehicle Owner’s the steps: Manual on the DVD for details. 1. Press the More soft-key on the bottom of the screen. • Audio 2. Then press the Settings soft-key. Refer to this section for more details. • Phone/Bluetooth Refer to ⬙Understanding The Features Of Your Vehicle⬙, ⬙Uconnect® 8.
134 Uconnect® 8.4 & 8.4N 3. Press the Display soft-key to enter the Display Menu • Set Language • Units • Voice Response Length • Touchscreen Beep • Navigation Turn-by-Turn Displayed in the Cluster (If Equipped) • Fuel Saver Displayed in the Cluster (If Equipped) 5. Touch the + or – soft-key to change the Brightness. Or touch the check mark or empty box to change a selection. NOTE: The check-mark indicates the current selection is 4. The Display Menu shows the following options for active.
Uconnect® 8.4 & 8.4N 135 Clock Setting 1. Press the More soft-key on the bottom of the screen. 2. Then press the Settings soft-key. NOTE: The Clock Setting Menu can also be accessed by touching the time as it is displayed on the screen. 3. Press the Clock soft-key to enter the Clock Menu. 3 4. In the Set Time screen, press the + or – soft-keys to adjust the hours or minutes.
136 Uconnect® 8.4 & 8.4N 5. Other options available: • Sync with GPS Time • Time Format • Show Time in Status Bar 6. Touch the check mark or empty box to change a selection. NOTE: The check-mark indicates the current selection is active.
Safety Guidelines CONTENTS 䡵 Safety Guidelines . . . . . . . . . . . . . . . . . . . . . . .
138 Safety Guidelines • Make certain that the volume level of the system is set to a level that still allows you to hear outside traffic Ensure that all persons read this manual carefully before and emergency vehicles. using the radio system. It contains instructions on how to use the system in a safe and effective manner. • The law in some states prohibits the Front Seat DVD Viewer. As a result, it may be disabled prior to delivery WARNING! to you.
13CTP-226-AB Second Edition Chrysler Group LLC Printed in the USA UCONNECT ® TOUCH 8.
