Preface This preface describes the objectives, audience, organization, and conventions of this guide and describes related documents that have additional information.
Preface Organization This guide is organized into the following chapters and appendix. Chapter Name Description Chapter 1 Chapter 1, “Product Overview” Describes the router models and the hardware features available. Chapter 2 Chapter 2, “Installing the Router” Lists the items shipped with the router, the equipment and tools necessary for installing the router, the safety warnings and guidelines, and the procedures for installing the router.
Preface Warning IMPORTANT SAFETY INSTRUCTIONS This warning symbol means danger. You are in a situation that could cause bodily injury. Before you work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard practices for preventing accidents. Use the statement number provided at the end of each warning to locate its translation in the translated safety warnings that accompanied this device.
Preface Avvertenza IMPORTANTI ISTRUZIONI SULLA SICUREZZA Questo simbolo di avvertenza indica un pericolo. La situazione potrebbe causare infortuni alle persone. Prima di intervenire su qualsiasi apparecchiatura, occorre essere al corrente dei pericoli relativi ai circuiti elettrici e conoscere le procedure standard per la prevenzione di incidenti. Utilizzare il numero di istruzione presente alla fine di ciascuna avvertenza per individuare le traduzioni delle avvertenze riportate in questo documento.
Preface Cisco 819 Integrated Services Router Hardware Installation Guide OL-23125-02 9
Preface Aviso INSTRUÇÕES IMPORTANTES DE SEGURANÇA Este símbolo de aviso significa perigo. Você se encontra em uma situação em que há risco de lesões corporais. Antes de trabalhar com qualquer equipamento, esteja ciente dos riscos que envolvem os circuitos elétricos e familiarize-se com as práticas padrão de prevenção de acidentes. Use o número da declaração fornecido ao final de cada aviso para localizar sua tradução nos avisos de segurança traduzidos que acompanham o dispositivo.
Preface Cisco 819 Integrated Services Router Hardware Installation Guide OL-23125-02 11
Preface Warning When installing the product, please use the provided or designated connection cables/power cables/AC adaptors. Using any other cables/adaptors could cause a malfunction or a fire. Electrical Appliance and Material Safety Law prohibits the use of UL-certified cables (that have the “UL” shown on the code) for any other electrical devices than products designated by CISCO.
Preface Warning If the symbol of suitability with an overlaid cross appears above a port, you must not connect the port to a public network that follows the European Union standards. Connecting the port to this type of public network can cause severe personal injury or can damage the unit. Statement 1031 Warning Connect the unit only to DC power source that complies with the safety extra-low voltage (SELV) requirements in IEC 60950 based safety standards.
Preface Warning Read the installation instructions before connecting the system to the power source. Statement 1004 Warning Ultimate disposal of this product should be handled according to all national laws and regulations. Statement 1040 Warning The covers are an integral part of the safety design of the product. Do not operate the unit without the covers installed. Statement 1077 Warning Hot surface.
Preface Subscribe to the What’s New in Cisco Product Documentation as a Really Simple Syndication (RSS) feed and set content to be delivered directly to your desktop using a reader application. The RSS feeds are a free service and Cisco currently supports RSS Version 2.0.
Preface Cisco 819 Integrated Services Router Hardware Installation Guide 16 OL-23125-02
CH A P T E R 1 Product Overview This chapter provides an overview of the features available for the Cisco 819 and Cisco 819H Integrated Services Routers (ISRs) and contains the following sections: Note • General Description, page 1-1 • SKU Information, page 1-5 • Hardware Features, page 1-10 For compliance and safety information, see Regulatory Compliance and Safety Information Roadmap that ships with the router and Regulatory Compliance and Safety Information for Cisco 800 Series and SOHO Series
Chapter 1 Product Overview General Description The Cisco 819 ISR is a standard form factor with a commercial operating range. The 3G Cisco 819 ISRs support the 3G speeds (High-Speed PacketAccess Plus [HSPA+] enabling up to 4G speeds and Evolution Data Optimized [EVDO Rev A]). They are backward-compatible with High-Speed Packet Access (HSPA), Universal Mobile Telecommunications Service (UMTS), Enhanced Data Rates for Global Evolution (EDGE), General Packet Radio Service (GPRS), and EVDO Rev 0/1xRTT.
Chapter 1 Product Overview General Description Cisco 819HGW Integrated Services Router 285479 Figure 1-2 Figure 1-3 shows the front panel details of the Cisco 819HG ISR.
Chapter 1 Product Overview General Description 4 3G mini-USB diagnostic port 10 5 VDC molex power input 5 Diversity/GPS antenna 11 Power switch 6 12-in-1 serial port 12 Ground Figure 1-4 shows the front panel details of the Cisco 819HGW ISR.
Chapter 1 Product Overview SKU Information Figure 1-5 shows the front panel details of the Cisco 819 4G LTE ISR.
Chapter 1 Product Overview SKU Information Table 1-1 Supported 3G SKUs for Cisco 819HG and Cisco 819G ISRs(continued) SKU ID Description C819HG-B-K9 Compact Hardened 3G IOS Router with Bharat generic EVDO Rev A based on MC5728V C819G+7-K9 C ompact Non-hardened 3G IOS Router with Global HSPA + Release 7 based on MC8705 C819G-U-K9 Compact Non-hardened 3G IOS Router with GLOBAL HSPA Release 6 based on MC8795V C819G-V-K9 Compact Non-hardened 3G IOS Router with Verizon EVDO Rev A based on MC5728V
Chapter 1 Product Overview SKU Information Table 1-2 lists the different SKUs available for the Cisco 819HGW, Cisco 819H, and Cisco 819HWD ISRs. Table 1-2 Supported SKUs for Cisco 819HGW, Cisco 819H, and Cisco 819HWD ISRs SKU ID WLAN ID WiFi External Antenna Support C819HGW+7-E-K9 AP802H-AGN-E-K9 Yes Cisco 819 Secure Hardened M2M GW (non-US) 3.7G HSPA + Release 7 with SMS/GPS and Dual WiFi Radio with ETSI C819HGW+7-N-K9 AP802H-AGN-N-K9 Yes Cisco 819 Secure Hardened M2M GW (non-US) 3.
Chapter 1 Product Overview SKU Information Table 1-3 lists the different 4G LTE SKUs available for the Cisco 819HG and Cisco 819G ISRs. Table 1-3 Supported 4G LTE SKUs for the Cisco 819HG-4G and Cisco 819G-4G ISRs SKU ID Mode Operating Regions Frequency Band Description C819HG-4G-V-K9 LTE—DOrA North America Compact Hardened Cisco 819 router with multimode LTE feature dedicated to Verizon Wireless networks. This comes with a Sierra Wireless MC7750 modem.
Chapter 1 Product Overview SKU Information Table 1-3 Supported 4G LTE SKUs for the Cisco 819HG-4G and Cisco 819G-4G ISRs (continued) SKU ID Mode Operating Regions Frequency Band Description C819HG-4G-G-K9 LTE—HSPA+/ Global Hardened Cisco 819 router with multimode LTE feature for global wireless networks. This comes with a Sierra Wireless MC7710 modem.
Chapter 1 Product Overview Hardware Features Rebranding of C8xx-B and EHWIC-3G-EVDO-B The C881G-B-K9, C819G-B-K9, and EHWIC-EVDO-B (Bharat) SKUs are introduced as an umbrella SKU to cover BSNL, Tata, and Reliance service providers in India. Software based mechanism is introduced to identify specific carrier. Carrier ID and name are displayed under "show cellular hardware".
Chapter 1 Product Overview Hardware Features • Note Accessories, page 1-25 The WAAS Express feature is not supported. This feature will be supported for 3G and 4G interfaces with later IOS releases. Platform Features for Cisco 819 ISRs Table 1-4 lists the platform features comparison for the Cisco 819 ISRs.
Chapter 1 Product Overview Hardware Features Table 1-4 Cisco 819 ISRs Platform Features (continued) Cisco 819HG Cisco 819G Cisco 819HGW Cisco 819HWD Cisco 819HG-4G Cisco 819G-4G Platform Features (with 3G) (with WiFi) (with 4G LTE) LED indicators for the platform Yes Yes Yes Onboard crypto acceleration Yes Yes — Power cord retention — lock Yes Yes Power switch lock — Yes Cisco 819HG-4G ISRs only Reset button Yes Yes Yes Real Time Clock (RTC)1 Yes Yes Yes ScanSafe Yes Yes
Chapter 1 Product Overview Hardware Features • Omnidirectional Power Switch The power switch shuts down the router. A power switch lock is available to prevent accidental turning off of the router in the hardened SKUs. Reset Button The Reset button resets the router configuration to the default configuration set by the factory. To restore the router configuration to the default configuration set by the factory, use a standard size #1 paper clip with wire gauge 0.
Chapter 1 Product Overview Hardware Features Table 1-5 3G LED Descriptions (continued) LED Color Description RSSI Green (solid) Signal > –60 dBm Very strong signal Green (three blinks and then a long pause) Signal <= –60 to 74 dBm Green (two blinks and then a long pause) Signal <= –75 to –89 dBm Green (one blink and then a long pause) Signal <= –90 to –109 dBm Off Signal <= –110 dBm Strong signal Fair signal Marginal signal Unusable signal SIM 1,2 Green / Yellow (one SIM in slot 0 acti
Chapter 1 Product Overview Hardware Features Table 1-6 WLAN LED Descriptions WLAN LED Color Description Boot loader status sequence Blinking Green Board initialization in progress. Initializing FLASH file system. Initializing Ethernet. Ethernet is OK. Starting Cisco IOS. Initialization is successful. Association status Operating status Boot loader errors Green Normal operating condition with no wireless client associated.
Chapter 1 Product Overview Hardware Features Table 1-7 describes the 4G LTE LEDs for the Cisco 819 ISR. Table 1-7 4G LTE LED Descriptions LED Color Description SYS Yellow FPGA download is complete. Green (blinking) ROMMON is operational. Green (solid) IOS is operational. Green (four blinks during bootup) Reset button has been pushed during the bootup. Off After powering up, when FPGA is being downloaded (in ROMMON).
Chapter 1 Product Overview Hardware Features Table 1-7 4G LTE LED Descriptions (continued) LED Color Description SIM Green / Yellow (one SIM in slot 0 is active, SIM in slot 1 is not. green blink followed by two yellow blinks) Yellow / Green (one yellow blink followed by two green blinks) SIM in slot 1 is active, SIM in slot 0 is not. Off / Green (two green No SIM in slot 0, SIM present in slot 1. blinks and then a pause) Green / Off (Slow single SIM present in slot 0, no SIM in slot 1.
Chapter 1 Product Overview Hardware Features Embedded 3G Modem The 3G cellular interface is the primary WAN data link, but it can also be used as a backup data link. The 3G technology is third-generation wide-area cellular technology that is used in broadband wireless data in a mobile environment. Embedded 4G LTE Modem The Cisco 819HG-4G and Cisco 819G-4G routers have an embedded 4G LTE modem provided by Sierra Wireless.
Chapter 1 Product Overview Hardware Features Supported Cisco Antennas and Cables The Cisco 819 ISR provides two standard panel-mount TNC connectors to support the 3G antenna and the diversity and GPS external antenna. The main antenna is used for the primary 3G antenna. The second can be used as a diversity receive only 3G antenna or GPS antenna that does not require power supply from the router. Table 1-10 lists the Cisco 3G antennas that are supported for use on Cisco 819 ISRs.
Chapter 1 Product Overview Hardware Features Table 1-11 lists the supported Cisco WiFi antenna for Cisco 819HGW and Cisco 819HWD ISRs. Table 1-11 Supported Cisco WiFi Antenna Antenna Frequency band(s) Mounting Mechanical AIR-ANTM2050D-R 2.4–2.5 GHz Faceplate IP Rating Peak Gain Peak Gain 2.4 GHz (dBi) 5 GHz (dBi) Description IP 41 1.4 4.5 This is the default antenna. For more information, see Cisco Multiband Swivel-Mount Dipole Antenna (AIR-ANTM2050D-R). 4.9–5.
Chapter 1 Product Overview Hardware Features Table 1-12 lists the Cisco 4G LTE antennas that are supported for use on Cisco 819 ISRs. Table 1-12 Supported 4G LTE Antennas Cisco Part Number Description 4G-LTE-ANTM-D Indoor 4G dipole omnidirectional antenna Maximum Gain and Frequency Ranges • 2 dBi – 698 to 806 MHz – 824 to 894 MHz Description Multiband dipole antenna. For more information, see Cisco 4G/3G Omnidirectional Dipole Antenna (4G-LTE-ANTM-D).
Chapter 1 Product Overview Hardware Features Table 1-13 to Table 1-15 list the extension cables for use with 3G, WiFi, and 4G LTE antennas. The tables include the insertion loss information for the ultra-low-loss (ULL) LMR 400 extension cables. Table 1-13 Cisco Extension Cables for Use with 3G Antennas Cisco Product Number Cable Length Insertion Loss Frequency (MHz) 3G-CAB-ULL-20 20 ft (6 m) 1.50 dB max 2100 3G-CAB-ULL-50 50 ft (15 m) 3.50 dB max 2100 3G-CAB-LMR240-25 25 ft (7.5 m) 3.
Chapter 1 Product Overview Hardware Features Table 1-15 Cisco Extension Cables for Use with 4G LTE Antennas (continued) Cisco Product Number Cable Length Maximum Insertion Loss Frequency (MHz) Color Plenum Rated?1 4G-CAB-LMR240-50 50 ft (15 m) 4.1 dB at 700 MHz 700 to 1000 MHz Black Yes 7.4 dB at 2.6 GHz 1700 to 2600 MHz 6.1 dB at 700 MHz 700 to 1000 MHz Black Yes 11.0 dB at 2.6 GHz 1700 to 2600 MHz 2.1 dB at 700 MHz 700 to 1000 MHz Black No 4.
Chapter 1 Product Overview Hardware Features 12-in-1 Serial Port 344749 Figure 1-6 Power Supply All SKUs require a 5 VDC power source. Cisco 819HG and Cisco 819G ISRs have a self-locking Molex mini-fit connector. Cisco 819HGW and Cisco 819HWD ISRs use a 5.5 mm barrel-type connector with separate locking clip. An external AC power adapter is supported by default.
Chapter 1 Product Overview Hardware Features DC Power Adapters The optional external DC power adapters are available for 12 VDC and 24 VDC nominal vehicle power. • 12 VDC vehicle adapter has a 10 VDC to 36 VDC operating range • 24 VDC vehicle adapter has an 18 VDC to 75 VDC operating range The vehicle power adapters may be used for fixed or mobile installations. They do not provide electrical isolation; the input negative is connected to the output negative (chassis ground).
Chapter 1 Product Overview Hardware Features Cisco 819 Integrated Services Router Hardware Installation Guide 1-26 OL-23125-02
CH A P T E R 2 Installing the Router This chapter describes the equipment and the procedures for successfully installing the Cisco 819 ISR and contains the following sections: • Equipment, Tools, and Connections, page 2-2 • Installing the Router, page 2-4 • Mounting the DC Power Supply, page 2-17 Note For compliance and safety information, see the Regulatory Compliance and Safety Information Roadmap that ships with the router and the Regulatory Compliance and Safety Information for Cisco 800 Series
Chapter 2 Installing the Router Equipment, Tools, and Connections Warning The covers are an integral part of the safety design of the product. Do not operate the unit without the covers installed. Statement 1077 Warning Do not locate the antenna near overhead power lines or other electric light or power circuits, or where it can come into contact with such circuits.
Chapter 2 Installing the Router Equipment, Tools, and Connections Items Shipped with your Router Unpack the box and verify that all items listed on the invoice were shipped with the Cisco 819 ISR.
Chapter 2 Installing the Router Installing the Router Ethernet Devices Identify the Ethernet devices that you will connect to the router: hub, servers, and workstations or PCs. Ensure that each device has a network interface card (NIC) for connecting to Ethernet ports. If you plan to configure the software using Cisco IOS commands through the console port, provide an ASCII terminal or a PC that is running terminal emulation software to connect to the console port.
Chapter 2 Installing the Router Installing the Router Warning Read the wall-mounting instructions carefully before beginning installation. Failure to use the correct hardware or to follow the correct procedures could result in a hazardous situation to people and damage to the system. Statement 378 Warning Do not cover or obstruct the router vents located on both sides of the router; otherwise, overheating could occur and cause damage to the router.
Chapter 2 Installing the Router Installing the Router Accessing the SIM Cards 245829 Figure 2-1 Step 5 Replace the panel and the screws. Installing Antennas Note Before you install the Cisco 819 ISR on a table, wall, or DIN rail, install the antennas on the front panel. It is difficult to install the antennas after the router is installed. Orient the antennas. For optimum wireless performance, the antennas should be perpendicular with respect to the floor.
Chapter 2 Installing the Router Installing the Router Installing the Antenna 245548 Figure 2-2 Step 2 Orient the antennas. For optimum wireless performance, antennas should be generally perpendicular to each other. Installing a WiFi External Antenna This section describes how to install a WiFi external antenna. Step 1 Install the lightning arrestor. For details in installing lightning arrestor, see Cisco Aironet Lightning Arrestor (AIR-ACC245LA-R).
Chapter 2 Installing the Router Installing the Router Figure 2-3 Cisco WiFi Antenna Assembly 1 3 1 3G Dipole External Antenna 2 WiFi 2.4/5 Ghz Dipole External Antenna 3 344030 2 RP-TNC Connector Installing on a Table To install the router on a table or other flat horizontal surface, firmly place the router on a table or other horizontal surface. Keep at least 1 inch (2.5 centimeters) of clear space for heat dissipation. Connect the chassis to a reliable earth ground.
Chapter 2 Installing the Router Installing the Router Tip When choosing a location for wall-mounting the router, consider cable limitations and wall structure. To mount the router on a wall, follow these steps: Step 1 Remove the screws on the sides of the routers. Step 2 Attach the standard brackets to the chassis using the three screws provided for each bracket. (See Figure 2-4.
Chapter 2 Installing the Router Installing the Router Installing the Router to the Wall 282623 Figure 2-5 Note Step 4 For hollow-wall mounting, each bracket requires two wall anchors with washers. Wall anchors and washers must be size number 10. Route the cables so that they do not put a strain on the connectors or mounting hardware. To comply with IP 41, cables should be routed down relative to the router to prevent water from travelling on the cables.
Chapter 2 Installing the Router Installing the Router To attach the Cisco 819 ISR to a 35-mm wide DIN rail, follow these steps. Step 1 Attach the DIN rail to the back of the router using the three screws provided. (See Figure 2-6.) Attaching the DIN Rail to the Cisco 819 ISR 282624 Figure 2-6 Step 2 Find the tab on the end of the DIN rail that extends past the router. (See Figure 2-7.) Press the tab in and slide the DIN rail out while the tab is pressed down.
Chapter 2 Installing the Router Installing the Router Cisco 819 ISR Installed with the DIN Rail 282626 Figure 2-8 Installing the Router Ground Connection The router must be connected to a reliable earth ground. Install the ground wire in accordance with local electrical safety standards. Warning • For NEC-compliant grounding, use size 14 AWG (2 mm2) or larger copper wire and a ring terminal with an inner diameter of 1/4 in. (5 to 7 mm).
Chapter 2 Installing the Router Installing the Router Chassis Ground Connection Using Ring Terminal 245828 Figure 2-9 1 1 Ring terminal Step 5 Install the power switch lock, see the “Installing the Power Switch Lock” section on page 2-15. Tighten the screws to a torque of 8 to 10 in-lb (0.9 to 1.1 N-m). Torque the hex standoff to the same torque. Step 6 Connect the other end of the ground wire to a known reliable earth ground point at your site.
Chapter 2 Installing the Router Installing the Router Figure 2-10 Pre-assemble the O-Ring onto the Barrel 1 2 285515 3 Step 2 1 O-ring 3 2 Power cord connector Power cord lock Place the power cord lock onto the power cord behind the connector overmold as shown in Figure 2-11. Slide the power cord lock forward so that it captures the overmold and is fully seated.
Chapter 2 Installing the Router Installing the Router Installing Power Cord Lock onto the Router 285517 Figure 2-12 Step 4 To remove the power cord lock, use your thumb and index fingers to squeeze ends of tabs while pulling away from the router. (See Figure 2-13.) End of Tabs 285518 Figure 2-13 1 1 End of tabs Installing the Power Switch Lock The Cisco 819 ISRs have a power switch lock as an accessory.
Chapter 2 Installing the Router Installing the Router Figure 2-14 Installing Power Switch Lock 1 2 3 4 344033 5 1 Ring terminal 4 Power switch lock 2 Power switch lock washer 5 Pan-head screw 3 Power switch lock standoff Power Switch Lock Installed 344034 Figure 2-15 Cisco 819 Integrated Services Router Hardware Installation Guide 2-16 OL-23125-02
Chapter 2 Installing the Router Mounting the DC Power Supply Mounting the DC Power Supply Warning Read the wall-mounting instructions carefully before beginning installation. Failure to use the correct hardware or to follow the correct procedures could result in a hazardous situation to people and damage to the system. Statement 378 The Cisco 800 ISR DC power supply may be mounted to a wall using four #6 pan- or round-head wood screws for the mounting holes on the supply.
Chapter 2 Installing the Router Mounting the DC Power Supply Note The DC supply is IP 41 compliant in all six orthogonal directions. The mounting orientation will not affect IP 41 compliance.
CH A P T E R 3 Connecting the Router This chapter describes how to connect Cisco 819 Integrated Services Router (ISRs) to Ethernet devices and a network.
Chapter 3 Connecting the Router Connecting a PC, Server, or Workstation Connecting a PC, Server, or Workstation To connect a PC (or other Ethernet devices) to an Ethernet switch port, follow these steps: Step 1 Connect one end of the yellow Ethernet cable to an Ethernet switch port on the router. See Figure 3-1.
Chapter 3 Connecting the Router Connecting an External Ethernet Switch To connect an external Ethernet switch to an Ethernet switch port on the router, complete the following steps: Step 1 Connect one end of the yellow Ethernet cable to an Ethernet switch port on the router. (See Figure 3-2.
Chapter 3 Connecting the Router Connecting a Terminal or PC to the Console Port Connecting a Terminal or PC to the Console Port Connect a terminal or PC to the Console port either to configure the software by using the CLI or to troubleshoot problems with the router. To connect a terminal or PC to the console port on the router and access the CLI, follow these steps: Step 1 Connect the RJ-45 end of a DB-9-to-RJ-45 serial cable to the RJ-45 Console port on the router.
Chapter 3 Connecting the Router Connecting a Modem to the Console Port Terminal Emulator Settings Use the following settings for the terminal emulator connection: • 9600 baud • 8 data bits, no parity • 1 stop bit • No flow control When the terminal emulator establishes communications, the router prompt is displayed. For more information on terminal emulation settings, see Applying Correct Terminal Emulator Settings for Console Connections.
Chapter 3 Connecting the Router Connecting the AC Adapter Connecting the AC Adapter Warning The device is designed to work with TN power systems. Statement 19 Warning This product relies on the building’s installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 120VAC, 20A U.S (240VAC, 16 to 20A international).
Chapter 3 Connecting the Router Connecting the DC Adapter To connect the DC power on your Cisco 819 ISR, follow these steps: Step 1 Connect the black and white lead wires to a 12 VDC source. The black lead is negative or ground and the white lead is positive. The output cable is 1.3 meters while the input cable is 1 meter in length. (See Figure 3-5 and Figure 3-6.). For the complete list of supported power adapters, see the “Supported Power Adapters” section on page A-6.
Chapter 3 Connecting the Router Verifying Connections Step 2 1 Black wire (negative) 2 White wire (positive) 3 Adapter Plug the adapter cord into the router. Verifying Connections To verify that all devices are properly connected to the router, first turn on all the connected devices, then check the LEDs. To verify router operation, refer to Table 3-1. For full LED description, see Table 1-5.
CH A P T E R 4 Initial Configuration This chapter provides instructions for initial configuration of the Cisco 819 Integrated Services Routers (ISRs). For the initial configuration, we recommend using Cisco Configuration Professional (CP) Express. Cisco CP Express is a web-based GUI that guides you through initial configuration. You may also initially configure your router by using the Cisco IOS command-line interface (CLI) or by using the setup command facility.
Chapter 4 Initial Configuration Cisco IOS CLI Step 2 Press Return. The following message is displayed: Cisco Configuration Professional Express (Cisco CP Express) is installed on this device. This feature requires the one-time use of the username "username1" with the password "password1." The default username and password have a privilege level of 15. Please change these publicly known initial credentials using Cisco CP Express or the Cisco IOS CLI. Here are the Cisco IOS commands.
Chapter 4 Initial Configuration Setup Command Facility Setup Command Facility The setup command facility guides you through the configuration process by prompting you for the specific information that is needed to configure your system. Use the setup command facility to configure a hostname for the router, to set passwords, and to configure an interface for communication with the management network.
Chapter 4 Initial Configuration Setup Command Facility Step 6 Enter an enable secret password. This password is encrypted (more secure) and cannot be seen when viewing the configuration. The enable secret is a password used to protect access to privileged EXEC and configuration modes. This password, after entered, becomes encrypted in the configuration. Enter enable secret: xxxxxx Step 7 Enter an enable password that is different from the enable secret password.
Chapter 4 Initial Configuration Verifying the Initial Configuration Step 12 Respond to the following prompts. Enter 2 to save the initial configuration. [0] Go to the IOS command prompt without saving this config. [1] Return back to the setup without saving this config. [2] Save this configuration to nvram and exit. Enter your selection [2]: 2 Building configuration... Use the enabled mode 'configure' command to modify this configuration. Press RETURN to get started! RETURN The user prompt is displayed.
Chapter 4 Initial Configuration Verifying the Initial Configuration Cisco 819 Integrated Services Router Hardware Installation Guide 4-6 OL-23125-02
A P P E N D I X A Technical Specifications This appendix provides router, port, cabling specifications, and power adapters for the Cisco 819 Integrated Services Router (ISRs) and contains the following sections: Warning Note • Router Specifications, page A-1 • Mean Time Between Failure Ground Benign Environment, page A-5 • Supported Power Adapters, page A-6 Ultimate disposal of this product should be handled according to all national laws and regulations.
Appendix A Technical Specifications Router Specifications Table A-1 Cisco 819 ISR Specifications (continued) Hardened Design Specification Non-Hardened Design Specifications (Cisco 819HG and Cisco 819HG-4G ISRs) (Cisco 819G and Cisco 819G-4G ISRs) Hardened Design Specifications Description Maximum Power Consumption 11 W (C819HGW and C819HWD ISRs) 20 W Environmental Operating Ranges Operating Temperature and –13 to 140°F Altitude (–25 to 60°C) 32 to 104°F –13 to 140°F (0 to 40°C) (–25 to 60°C
Appendix A Technical Specifications Router Specifications Table A-1 Cisco 819 ISR Specifications (continued) Hardened Design Specification Non-Hardened Design Specifications (Cisco 819HG and Cisco 819HG-4G ISRs) (Cisco 819G and Cisco 819G-4G ISRs) Hardened Design Specifications Description (C819HGW and C819HWD ISRs) EMC Emissions EN55022/CISPR22, CFR 47 Part 15, ICES003, VCCI-V-3, AS/NZS CISPR22, CNS13438, CISPR22, CNS13438, EN300-386, EN61000-3-2, EN61000-3-3, and EN61000-6-1 EMC Immunity EN55
Appendix A Technical Specifications Router Specifications Table A-1 Cisco 819 ISR Specifications (continued) Hardened Design Specification Non-Hardened Design Specifications Description (Cisco 819HG and Cisco 819HG-4G ISRs) (Cisco 819G and Cisco 819G-4G ISRs) Thermal Shock Operating: –20 to 60°C at 0.5°C per minute Hardened Design Specifications (C819HGW and C819HWD ISRs) Non-operating: –40 to 85°C with change over time between 2 and 3 minutes. Vibration Operating: 0.
Appendix A Technical Specifications Mean Time Between Failure Ground Benign Environment 1. AC Power Adapter is not IP 41 rated. Installation must include protection of the adapter and power plug from water. 2. Contact Martek Power directly for details. Mean Time Between Failure Ground Benign Environment Table A-2 lists the Mean Time Between Failire (MTBF) values for Cisco 819 ISRs. The MTBF is calculated based on the Ground Benign condition. The values may be adjusted based on the different router usage.
Appendix A Technical Specifications Supported Power Adapters Table A-2 MTBF Values (continued) SKUs MTBF (hours) C819HG-4G-A-K9 226,000 C819G-4G-A-K9 C819HG-4G-G-K9 293,000 C819G-4G-G-K9 Supported Power Adapters Table A-3 and Table A-4 list the supported power adapters for Cisco 819 ISRs. The PWR1 AC and DC adapters uses molex connector while PWR2 uses barrel-type connector. Note Table A-3 The 24 VDC and Martek power adapters will be available on Q1CY131.
Appendix A Technical Specifications Supported Power Adapters Table A-4 Cisco 819H ISR Power Adapters C819HG+7-K9 C819HGW-S-A-K9 C819HG-4G-A-K9 C819HG-B-K9 C819HGW-V-A-K9 C819HG-4G-V-K9 C819HG-S-K9 C819HGW+7-E-K9 C819HG-4G-G-K9 C819HG-U-K9 C819HGW+7-N-K9 C819HWD-E-K9 C819HG-V-K9 C819HGW+7-A-A-K9 C819HWD-A-K9 C819H-K9 Power Adapter Nominal Input Range (4G LTE SKUs) (3G SKUs) (3G + WiFi SKUs) (WiFi SKUs) (Serial SKU) PWR1-20W-AC 100–240 VAC — Yes — — — PWR2-20W-AC 100–240 VAC Yes — Yes Ye
Appendix A Technical Specifications Supported Power Adapters Cisco 819 Integrated Services Router Hardware Installation Guide OL-23125-02 A-8
