N02210F ISS4 DO2.qxd 24/4/02 1:12 PM Page 7 Introduction This manual is for users of the SPrint™ Speech ® Processor, which is part of the Nucleus 24 cochlear implant system. The SPrint is used with the following Nucleus 24 cochlear implant systems: ® • Nucleus 24 ® • Nucleus 24k ® • Nucleus 24 Contour™ The SPrint is also used with the auditory brainstem ® implant, the Nucleus 24 ABI.
N02210F ISS4 DO2.qxd 24/4/02 1:12 PM Page 8 I N T R O D U C T I O N This manual is intended for use by adult and adolescent implant users. It may also assist caregivers, teachers and other adults involved with children who use the implant.
24/4/02 1:12 PM Page 9 I N T R O D U C T I O N External input socket Earphone socket Indicator light ➤ ➤ ➤ Headset cable cover ➤ Headset cable cover release latch ➤ ➤ LCD panel Battery cover ➤ ➤ Battery cover release latch ➤ N02210F ISS4 DO2.
N02210F ISS4 DO2.
N02210F ISS4 DO2.qxd 24/4/02 1:12 PM Page 11 I N T R O D U C T I O N • The Select button ( ) provides access to the button lock, the microphone sensitivity and the volume controls (provided your clinician has enabled the volume control for the current program). • The Options button ( ) provides access to the alarm features of the speech processor. • The Up ( ) and Down ( ) buttons adjust the microphone sensitivity and the volume, and turn the button lock and alarm features on or off.
N02210F ISS4 DO2.qxd 24/4/02 1:12 PM Page 12 I N T R O D U C T I O N Transmitting Coil The transmitting coil is attached to the microphone by the transmitting cable and is held securely in place by magnetic attraction between a magnet in the coil and a magnet in the implanted unit. Note: Your transmitting coil may look slightly different to the one shown.
24/4/02 1:12 PM Page 13 I N T R O D U C T I O N Transmitting coil Microphone case ➤ ➤ ➤ Transmitting cable ➤ N02210F ISS4 DO2.qxd Headset cable Figure 4: The HS8 headset Cables The HS8 headset cable and the HS8 transmitting cable are described below. Both cables come in a variety of lengths. • The HS8 headset cable features a 4 pin female plug that attaches to the HS8 microphone and a 4 pin large female plug that attaches to the SPrint speech processor.
N02210F ISS4 DO2.qxd 24/4/02 1:12 PM Page 14 I N T R O D U C T I O N High Energy NiCad Charger The High Energy NiCad Charger recharges the nickel cadmium (NiCd) batteries supplied for use with the speech processor. The charger includes the following features: • A charge time of six hours (overnight). • Protection against overcharging. • Charging of one or two NiCd batteries on separate charging and timing circuits.
N02210F ISS4 DO2.qxd 24/4/02 1:12 PM Page 15 I N T R O D U C T I O N TV/Hi-Fi Cable TV/Hi-Fi cable is for use with equipment that is powered from a wall outlet, particularly a TV, stereo or personal computer. Personal Audio Cable The personal audio cable is for use with battery powered equipment such as a personal stereo. FM Cable The FM cable is for use with FM listening systems.
N02210F ISS4 DO2.
N02210F ISS4 DO2.qxd 24/4/02 1:12 PM Page 17 Using the System At the initial programming session, your clinician will help you set up your speech processor and headset using the following procedure: 1. Insert batteries into the speech processor. 2. Assemble the headset and connect it to the speech processor. 3. Fit the speech processor and headset so they are comfortable to wear. 4. Turn on the speech processor and select the appropriate program. 5. Adjust the microphone sensitivity. 6.
N02210F ISS4 DO2.qxd U S I N G 24/4/02 1:12 PM T H E Page 18 S Y S T E M Fitting the Speech Processor Changing the Battery Case The speech processor comes fitted with a two battery case. Cochlear also supplies an alternative one battery case. With the one battery case, the speech processor is smaller but you will need to replace the battery more frequently. To replace the battery case: 1. Grasp the body of the speech processor in your left hand. 2.
N02210F ISS4 DO2.qxd 24/4/02 1:12 PM Page 19 U S I N G T H E S Y S T E M 4. Slide the replacement battery case along the runner at the base of the speech processor until it clicks into position. Inserting the batteries Before inserting NiCd batteries into the speech processor, ensure they are fully charged (see 'Recharging NiCd Batteries'). To insert batteries into the speech processor: 1. Put your thumbnail in the battery cover release latch. Slide the latch and pull the battery cover back.
N02210F ISS4 DO2.
N02210F ISS4 DO2.qxd 24/4/02 1:12 PM Page 21 U S I N G T H E S Y S T E M Fitting the Headset Assembling the Headset When assembling the headset, do not pull on the headset or transmitting cables – grasp only the connectors. If you have trouble assembling the headset, ask your clinician to help you. Connecting the transmitting coil Plug the two-pin connector on the transmitting cable into the socket in the transmitting coil. Connecting the microphone cables 1.
N02210F ISS4 DO2.qxd U S I N G 24/4/02 T H E 1:12 PM Page 22 S Y S T E M 2. Plug the orange connector on the headset cable (A) into the orange socket at the bottom of the microphone case. A 3. Plug the transmitting cable (B) into the socket at the top of the microphone case. B A 4. Slide the cover hinge over the cables and then over the plastic lip at the bottom of the microphone case. Do not force the hinge over the lip. Ensure the cables extend from the bottom of the microphone case. 5.
N02210F ISS4 DO2.qxd 24/4/02 1:12 PM Page 23 U S I N G T H E S Y S T E M Connecting the Headset to the Speech Processor 1. Turn off the speech processor. 2. Hold the speech processor with one hand and put your thumbnail in the headset cable cover release latch. Slide the latch and pull the headset cable cover back. Headset cable cover release latch ➤ 3. Plug the large end of the headset cable into the socket and lay the cable in the groove just above the socket. 4.
N02210F ISS4 DO2.qxd U S I N G 24/4/02 T H E 1:12 PM Page 24 S Y S T E M Wearing the Headset Hook the microphone ear hook over your ear and place the transmitting coil over the implant. Locking the microphone cover Cochlear supplies a sleeve that slides over the microphone cover to prevent young children tampering with the microphone cover. Ear hook Microphone cover with sleeve Figure 7: The microphone cover with sleeve To use the sleeve: 1. Unscrew the ear hook from the microphone. 2.
N02210F ISS4 DO2.qxd 24/4/02 1:12 PM Page 25 U S I N G T H E S Y S T E M To hold the transmitting coil more firmly against your head, turn the magnet in the coil clockwise. Be careful that this change does not cause skin irritation. To hold the coil less firmly against your head, turn the magnet counter-clockwise. If the magnetic force is too weak, the coil may fall off. In this instance, consult your clinician about receiving a stronger magnet.
N02210F ISS4 DO2.qxd U S I N G 24/4/02 T H E 1:12 PM Page 26 S Y S T E M (60 cm) headset cable for children, but shorter cables are also available. You may wish to carry a spare headset and transmitting cable with you. A small ear hook and a large ear hook are supplied with the headset. Adjusting the Shape of the Ear Hook The shape of the ear hook can be adjusted to obtain a more comfortable fit.
N02210F ISS4 DO2.qxd 24/4/02 1:12 PM Page 27 U S I N G T H E S Y S T E M Turning on the Speech Processor Press the On/Off ( ) button to turn on the speech processor. The speech processor takes about a second to perform its start-up checks. The LCD panel then displays the program number and the listening control settings. Press the On/Off button again to turn off the speech processor.
N02210F ISS4 DO2.qxd U S I N G 24/4/02 T H E 1:12 PM Page 28 S Y S T E M Adjusting the Listening Controls The speech processor features both a microphone sensitivity and a volume control. • The microphone sensitivity controls the softest level of sound picked up by the microphone. Reduce the microphone sensitivity to filter out background noise. Increase the sensitivity in quiet environments to hear very soft sounds. • The volume controls your perception of loudness.
24/4/02 1:12 PM Page 29 U S I N G T H E S Y S T E M The speech processor also displays the signal level picked up by the microphone in a 12 segment meter. The meter fluctuates according to the level of sound received, with 12 being the highest level and 0 the lowest level. To adjust microphone sensitivity: Press the Select ( ) button until the ‘M’ symbol appears on the LCD panel. • To increase the sensitivity, press the Up ( ) button. • To decrease the sensitivity, press the Down ( button.
N02210F ISS4 DO2.qxd U S I N G 24/4/02 T H E 1:12 PM Page 30 S Y S T E M Adjusting the Volume Volume ➤ If you use the volume control, the speech processor displays a small triangle at the top of the LCD panel. Underneath, the LCD panel displays the volume as a number between 0 and 9. To adjust the volume: 1. Press the Select ( ) button until the volume symbol appears on the LCD panel. 2. Adjust the volume to a comfortable listening level. 3. To increase the volume, press the Up ( ) button. 4.
N02210F ISS4 DO2.qxd 24/4/02 1:12 PM Page 31 U S I N G T H E S Y S T E M Changing Speech Processor Settings The speech processor has three features that your clinician may enable during programming. They are: Button lock The button lock ( ) disables the buttons on the speech processor including the On/Off button ( ). Use the button lock to prevent young children from tampering with the controls.
N02210F ISS4 DO2.qxd U S I N G 24/4/02 T H E 1:12 PM Page 32 S Y S T E M Button Lock To lock the buttons, press and hold down the Select Button ( ) for several seconds until the button lock symbol ( ) appears on the LCD panel and you hear a long beep. When the buttons are locked, the On/Off button ( ) has no effect. To turn off the speech processor, you need to unlock the buttons first.
N02210F ISS4 DO2.qxd 24/4/02 1:12 PM Page 33 U S I N G T H E S Y S T E M corresponding to the program number, that is, 1 ping = P1, 2 pings = P2, etc. Other buttons (1 ping) The speech processor emits a single ping each time you press the Up, Down, Options, Autosensitivity or Select buttons. Low battery power (4 pings) The speech processor emits four short pings every minute when the batteries are nearly dead.
N02210F ISS4 DO2.qxd U S I N G 24/4/02 T H E 1:12 PM Page 34 S Y S T E M Press down repeatedly to cycle through the following options as shown in the diagram below: 1. Public and personal alarms off. 2. Public alarm on ( ). 3. Personal alarm on ( ). 4. Public and personal alarms on ( ). Stop pressing the Options button when the LCD panel displays the symbol(s) corresponding to the desired feature. 1. 4. 2. 3.
N02210F ISS4 DO2.qxd 24/4/02 1:12 PM Page 35 U S I N G T H E S Y S T E M Replacing and Recharging Batteries The speech processor is powered by one or two AA batteries. Cochlear recommends using only high energy rechargeable batteries or high quality disposable alkaline batteries. Caution: Carry spare batteries in a closed plastic bag. Otherwise the batteries may short circuit on loose metal objects and burn you. Using NiCd Batteries Cochlear recommends using NiCd batteries rated at least 1000 mAh.
N02210F ISS4 DO2.qxd U S I N G 24/4/02 T H E 1:12 PM Page 36 S Y S T E M Using NiMH batteries For best use of NiMH batteries: • Do not mix fully charged batteries with partly charged batteries. • Do not recharge high energy NiMH batteries in the High Energy NiCad Charger supplied by Cochlear or any other NiCad charger. • Use a charger specifically designed for NiMH batteries. Using Alkaline Batteries For best use of alkaline batteries: • Do not recharge disposable alkaline batteries.
N02210F ISS4 DO2.qxd 24/4/02 1:12 PM Page 37 U S I N G T H E S Y S T E M Replacing the Batteries To replace the batteries: 1. Turn off the speech processor. 2. Put your thumbnail in the battery cover release latch. Slide the latch and pull the battery cover back. Do not attempt to remove the cover completely. Battery cover release latch ➤ – + 3. Remove the old batteries. If the batteries are rechargeable, recharge them in the battery charger. If they are disposable, dispose of them appropriately.
N02210F ISS4 DO2.qxd U S I N G 24/4/02 T H E 1:12 PM Page 38 S Y S T E M Do not leave dead batteries in the speech processor as they may leak corrosive fluids and seriously damage the speech processor. Recharging NiCd Batteries Cochlear supplies a High Energy NiCad Charger to recharge high energy AA size NiCd batteries. Caution: Do not recharge carbon, zinc, alkaline, (including rechargeable alkaline),NiMH or lithium batteries in the High Energy NiCad Charger.
N02210F ISS4 DO2.qxd 24/4/02 1:12 PM Page 39 U S I N G T H E S Y S T E M AC adaptor ➤ ➤ Battery charger The indicator light above the slot turns red when you insert the battery with the correct polarity. If you insert the battery incorrectly, the indicator light may flicker but it will not stay on and the battery will not charge. However, you will not damage the battery or the charger. 3. After approximately six hours, the indicator light turns green, indicating the battery is fully charged.
N02210F ISS4 DO2.qxd U S I N G 24/4/02 T H E 1:12 PM Page 40 S Y S T E M For best use of the battery charger: 1. If a power failure interrupts the charging, remove and reinsert the battery to reactivate the timing circuit. 2. Do not overcharge the batteries, as it will reduce their life. Overcharging may occur if you move the battery while in its charger slot. The charger may restart the charge cycle and overcharge the battery. 3. Use the charger indoors only.
24/4/02 1:12 PM Page 41 U S I N G ➤ N02210F ISS4 DO2.qxd T H E S Y S T E M External input socket Figure 10: External input socket Note: Connect the personal audio cable only to equipment powered by batteries. To connect the speech processor to AC powered equipment (i.e. equipment connected to a wall outlet) use the TV/Hi-Fi cable.
N02210F ISS4 DO2.
N02210F ISS4 DO2.qxd 24/4/02 1:12 PM Page 43 Using the Accessories Using the Lapel Microphone The lapel microphone can improve communication in noisy environments. Contact your clinician for the best program settings in these conditions. 1. Plug the lapel microphone into the speech processor external input socket. 2. Select microphone sensitivity on the speech processor. Adjust the microphone sensitivity to suit the loudness of the speaker and the environmental noise.
N02210F ISS4 DO2.qxd U S I N G 24/4/02 T H E 1:12 PM Page 44 A C C E S S O R I E S Securing the Headset Cable You can use the lapel clip to hold the headset cable to your clothes. 1. Remove the small rubber ring from the lapel clip. 2. Place the cable in the clip as shown and attach the clip to your clothing. 3. Keep the rubber band (and spare band) in a safe place for future use. You can attach the headset cable securely in one position. 1. Remove the rubber band from the lapel clip. 2.
N02210F ISS4 DO2.qxd 24/4/02 1:12 PM U S I N G Page 45 T H E A C C E S S O R I E S 3. Gently pull the cable through the jaws of the clip to fit in the same slot as the rubber band. 4. Attach the clip to your clothing. You can move the cable through the clip by opening the jaws and gently pulling the cable through its slot. You can then attach the clip to a convenient place on your clothing.
N02210F ISS4 DO2.qxd U S I N G 24/4/02 T H E 1:12 PM Page 46 A C C E S S O R I E S 3. Measure the length of tubing required to fit under the ear lobe allowing for approximately 4 in (5 mm) of tubing to be fitted over the ear hook itself. 4. Remove the microphone and mic lock from the ear and cut the tubing at the measured point. 5mm 5. Slide the cut end of the tubing about 4 in (5 mm) over the ear hook. 6.
N02210F ISS4 DO2.qxd 24/4/02 1:12 PM U S I N G Page 47 T H E A C C E S S O R I E S Listening on the Telephone Telephone Adaptor The Nucleus® telephone adaptor (for body worn processors) is used to provide a direct connection from the telephone to your SPrint for the Nucleus cochlear implant system. Note: The telephone adaptor may not be available in your region due to variations in telephone systems. Contact your clinician or your nearest Cochlear office for further information.
N02210F ISS4 DO2.qxd U S I N G 24/4/02 1:12 PM T H E Page 48 A C C E S S O R I E S Installing your telephone adaptor Telephone handset To speech processor Handset selector switch (hidden) Adaptor output cord Handset socket Nucleus Telephone Adaptor Volume control Telephone adaptor Telephone (underneath) Figure 12: Installing the telephone adaptor 1. Unplug the telephone handset cord from the telephone. 2. Plug the adaptor telephone cord into the telephone handset socket.
N02210F ISS4 DO2.qxd 24/4/02 1:12 PM U S I N G Page 49 T H E A C C E S S O R I E S checked by lifting the telephone handset and listening for the dial tone through your cochlear implant. 7. Try position 1 first. If this does not work, try position 2. If neither position works, contact your clinician. 8. Adjust the volume control on the telephone adaptor, using a screwdriver to achieve a suitable volume. Future adjustment should not be necessary once you have done this. 9.
N02210F ISS4 DO2.qxd U S I N G 24/4/02 T H E 1:12 PM Page 50 A C C E S S O R I E S Your telephone service provider may be able to provide you with information about whether it is possible to use the telephone during a storm in the event of an emergency. When you receive your telephone adaptor, please check in your telephone directory or contact your telephone service provider to obtain this information.
N02210F ISS4 DO2.qxd 24/4/02 1:12 PM U S I N G Page 51 T H E A C C E S S O R I E S 5. If a clear signal is not received, reposition the telecoil on the handset to improve the clarity. Using the telecoil in an induction loop environment: 1. Set the microphone sensitivity button on the SPrint to 0. 2. Plug the telecoil into the external input socket on the SPrint. 3. Attach the telecoil to your clothing using the m-clip, so that it is in a vertical position to pick up the induction field. 4.
N02210F ISS4 DO2.qxd 24/4/02 U S I N G 1:12 PM T H E Page 52 A C C E S S O R I E S FM Cable: SPrint A Cochlear FM cable is used to transfer audio signals from a commercially available FM system to the SPrint. There are a variety of FM cables available to suit different systems. The table below indicates the correct FM cable for each compatible system.
N02210F ISS4 DO2.qxd 24/4/02 1:12 PM U S I N G Page 53 T H E A C C E S S O R I E S To connect an FM cable to your SPrint, follow the steps below. 1. Check that the FM system is working. To do this, connect earphones to the FM receiver and ask someone to listen while the FM transmitter is operating. Speech should be clear and background noise minimal. 2. Set the SPrint sensitivity to 0. Switch the processor and the FM receiver off. 3.
N02210F ISS4 DO2.qxd U S I N G 24/4/02 T H E 1:12 PM Page 54 A C C E S S O R I E S 11. Adjust the sensitivity of the SPrint to control the level of environmental sound. 12. To listen to the FM system only, set the sensitivity of the SPrint to 0. 13. The microphone in your headset remains on and you may perceive some environmental sounds.
N02210F ISS4 DO2.qxd 24/4/02 1:12 PM U S I N G Page 55 T H E A C C E S S O R I E S To connect the TV/Hi-Fi cable: 1. Turn off the speech processor and the external audio equipment. 2. Plug the cable connector marked ‘COCHLEAR’ into the speech processor external input socket as shown. Volume control knob 3. Plug the cable connector marked ‘TV1’ into the output socket on your audio equipment. 4. Turn on the speech processor and select the appropriate program.
N02210F ISS4 DO2.qxd U S I N G 24/4/02 T H E 1:12 PM Page 56 A C C E S S O R I E S • To hear less environmental sound and more from the audio equipment, press the Down ( ) button. Note: Like other consumer electrical and communication equipment, devices which connect your speech processor to AC powered equipment (equipment connected to a wall outlet), such as the TV/Hi-Fi cable or telephone adaptor, should not be used during electrical storms.
N02210F ISS4 DO2.qxd 24/4/02 1:12 PM U S I N G Page 57 T H E A C C E S S O R I E S 3. Plug the cable connector labelled ‘WALK 1’ into the output socket on your personal stereo. 4. Turn the speech processor on and select the appropriate program. 5. The microphone in your headset remains on and you may perceive some environmental sounds.
N02210F ISS4 DO2.qxd U S I N G 24/4/02 T H E 1:12 PM Page 58 A C C E S S O R I E S Earphone socket Figure 14: Connecting the monitor earphones To connect the monitor earphones: 1. Leave the SPrint turned on. 2. Align the earphone connector with the earphone socket and insert the connector. Do not use excessive force. The sound you hear is the sound received by the microphone before it is processed by the speech processor. 3. Adjust the microphone sensitivity and volume to the desired levels.
N02210F ISS4 DO2.qxd 24/4/02 1:12 PM U S I N G Page 59 T H E A C C E S S O R I E S Checking the Transmitting Coil The signal check can be used to check that the transmitting coil is sending a signal across the skin to the implant. It is particularly useful for checking the transmitting coil and cable of a child’s SPrint. To use the signal check another person is required. 1. Leave the speech processor on the head and select the normal program settings. 2.
N02210F ISS4 DO2.qxd U S I N G 24/4/02 T H E 1:12 PM Page 60 A C C E S S O R I E S • If the signal check still does not illuminate, change the transmitting cable. Hold the signal check over the transmitting coil and speak into the microphone. If the signal check light illuminates with incoming sound, then the original transmitting cable is faulty. 5.
N02210F ISS4 DO2.qxd 24/4/02 1:12 PM Page 61 Caring for the System Storing the SPrintTM Speech Processor When you are not using your SPrint™ speech processor, store it in the storage case provided. Loosely wrap the headset and cables, tuck them into the pouch in the lid of the storage box and place the speech processor in the box. For long term storage, remove the batteries from the battery case. Keeping the SPrint Speech Processor Clean Avoid getting sand or dirt into any part of the system.
N02210F ISS4 DO2.qxd 24/4/02 C A R I N G F O R 1:12 PM T H E Page 62 S Y S T E M Keeping the SPrint Speech Processor Dry If you live in a humid environment, or perspire heavily, excess moisture may get into the speech processor or headset. Use the dry pack supplied with your speech processor to remove excess moisture. Do not wear any external part of your SPrint speech processor while bathing or swimming. To remove excess moisture from the speech processor and headset: 1.
N02210F ISS4 DO2.qxd 24/4/02 1:12 PM C A R I N G Page 63 F O R T H E S Y S T E M If you drop your speech processor into water, take the following steps to minimise damage: • Remove the battery case immediately. • Return the speech processor and battery case to Cochlear or your implant center for repair. Cochlear cannot guarantee that they will be able to repair any water-damaged part. Troubleshooting Diagnostic Tests There are some tests that you can perform to identify faults.
N02210F ISS4 DO2.qxd 24/4/02 C A R I N G F O R 1:12 PM T H E Page 64 S Y S T E M Headset function check 1. Turn on the speech processor and ensure the coil is directly over the cochlear implant. 2. Set the microphone sensitivity to 10. Speak into the headset microphone. If the segment meter responds to speech, then the headset and its connection to the speech processor are functioning correctly. 3.
24/4/02 1:13 PM C A R I N G Page 65 F O R T H E S Y S T E M Symptoms The Read Manual ( ) and Service Required ( ) symbols are displayed If the LCD panel displays the Read Manual and Service Required symbols together, the current speech processor program is faulty. Turn the speech processor off and then on again. If another program is available, the speech processor automatically selects it and continues to work normally.
N02210F ISS4 DO2.qxd 24/4/02 C A R I N G F O R 1:13 PM T H E Page 66 S Y S T E M If you have the personal alarm enabled, it will sound four short pings each minute when the batteries in your speech processor are nearly dead. Replace the batteries immediately. I don’t hear anything I only hear sounds intermittently Check the display panel troubleshooting symbols and functioning of the headset as described below: 1. Turn on the speech processor. 2. Ensure the headset is properly connected. 3.
N02210F ISS4 DO2.qxd 24/4/02 1:13 PM C A R I N G Page 67 F O R T H E S Y S T E M meter while you speak. If the meter works normally when you speak, and the environment is quiet, turn up the microphone sensitivity. Otherwise, ask the other speaker to talk more loudly. • If the meter consistently displays more than eight segments, try to locate and remove sources of background noise. Try turning the microphone sensitivity down so that the segment meter displays between five and eight segments.
N02210F ISS4 DO2.qxd 24/4/02 C A R I N G F O R 1:13 PM T H E Page 68 S Y S T E M • quick changes of topic in conversation • difficulty in lipreading the speaker, due to poor position of the speaker or poor lighting If you find that you still have problems, contact your implant center for assistance. Sounds are uncomfortably loud If turning down the volume has no effect, remove your headset, turn off the speech processor and consult your clinician.
N02210F ISS4 DO2.qxd 24/4/02 1:13 PM C A R I N G Page 69 F O R T H E S Y S T E M of EMI may not be readily visible. If you hear intermittent buzzing or distorted speech, look for electronic equipment that may be a source of EMI and move away from it. If you still hear buzzing or distorted speech, turn off your speech processor, remove your transmitting coil and consult your clinician. The cochlear implant has been carefully designed to protect users from most sources of EMI.
N02210F ISS4 DO2.
N02210F ISS4 DO2.qxd 24/4/02 1:13 PM Page 71 Warnings and Precautions This section describes the warnings and precautions that apply to your cochlear implant system. Read this section carefully to ensure that you understand the care of your system. Discuss these warnings and precautions with your physician before undergoing any major medical procedure.
N02210F ISS4 DO2.qxd 24/4/02 W A R N I N G S 1:13 PM A N D Page 72 P R E C A U T I O N S damage to the implant. Bipolar electrosurgical instruments may be used on the head and neck of patients. However, the cautery electrodes must not contact the implant and should be kept more than ~ 2 in. (1 cm) from the extracochlear electrodes. • Diathermy: Do not use therapeutic or medical diathermy (thermopenetration) using electromagnetic radiation (magnetic induction coils or microwave).
N02210F ISS4 DO2.qxd 24/4/02 1:13 PM W A R N I N G S Page 73 A N D P R E C A U T I O N S Magnetic Resonance Imaging (MRI) Magnetic Resonance Imaging (MRI) is contraindicated except under the circumstances described below. Do not allow patients with a cochlear implant to be in the room where an MRI scanner is located except under the following special circumstances. The Nucleus 24 cochlear implant has a removable magnet and specific design characteristics to enable it to withstand MRI up to 1.
N02210F ISS4 DO2.qxd 24/4/02 W A R N I N G S 1:13 PM A N D Page 74 P R E C A U T I O N S Loss of Residual Hearing Insertion of the electrode into the cochlea will result in complete loss of residual hearing in the implanted ear. Long-term Effects of Electrical Stimulation Most patients can benefit from electrical stimulation levels that are considered safe, based on animal experimental data. For some patients, the levels needed to produce the loudest sounds exceed these levels.
N02210F ISS4 DO2.qxd 24/4/02 1:13 PM W A R N I N G S Page 75 A N D P R E C A U T I O N S durable but must be treated with care. The speech processor must not be opened by anyone other than Cochlear’s qualified service personnel or the warranty will be invalidated. Each speech processor is programmed specifically for each individual. Do not wear another person’s speech processor or lend yours to another user. Using another person’s speech processor may result in uncomfortably loud or distorted sounds.
N02210F ISS4 DO2.qxd 24/4/02 W A R N I N G S 1:13 PM A N D Page 76 P R E C A U T I O N S reason, recipients should carry the Cochlear Implant Patient Identification Card with them at all times. Electrostatic Discharge A discharge of static electricity can damage the electrical components of the cochlear implant system or corrupt the program in the speech processor.
N02210F ISS4 DO2.qxd 24/4/02 1:13 PM Page 77 General Information SPrint Speech Processor Specifications TM Dimensions: 4.1 x 2.6 x 0.9 in. (103 x 67 x 23 mm) with two batteries) Weight: ~ 4 ozs/114 g (with one battery) ~ 5 ozs/146 g (with two batteries) External audio input: 3.5 mm Audio Input Socket with signal inputs typically in the range of 0.1 – 30 mV (RMS). The ring connection provides a current-limited supply (150 µA) for an external input device.
N02210F ISS4 DO2.qxd 24/4/02 1:13 PM Page 78 Transmission frequency: 5.0 MHz Equipment classification: The speech processor is internally powered equipment type B, with an F type applied part. IP44: Degrees of protection provided by enclosures for electrical equipment. The relevant standards are IEC 529 and AS 1939-1990. HS8 Headset Microphone dimensions: 1.5 x 0.7 x 0.3 in. (38.5 x 17.4 x 7.8 mm) Transmitting coil: 1.4 in. (35.4 mm) in diameter Transmitting frequency: 5.
N02210F ISS4 DO2.qxd 24/4/02 1:13 PM Page 79 Current supply: 6 V DC, 500 mA AC Adaptor Output required: 6 V DC, 500 mA Caution: Be sure to use an AC adaptor that is compatible with the standard power outlet in your country or you may damage your charger.
N02210F ISS4 DO2.qxd 24/4/02 G E N E R A L 1:13 PM Page 80 I N F O R M A T I O N Registration In accordance with international practice and regulatory legislation, each component of the cochlear implant system is shipped with a registration card. Registering your cochlear implant system secures your warranty rights and enables Cochlear to track all devices. Also provided is a patient identification card which you should carry at all times.
