QuickSpecs HP ProLiant DL180 Generation 6 Overview The HP ProLiant DL180 G6 is a low cost high capacity storage optimized 2-way server that delivers on a history of design excellence and 2U density for a variety of rack deployments and applications. Front View: 1. Access panel 2. Front LED Indicators 3. Power on/off 4. Optional DVD-RW or DVD-ROM drive 5. Front USB Ports (2) 6. Non-Hot Plug Non Redundant fans (4 fans) 7. Air Baffle 8. PCI Cage 9. System Board Rear View: 1.
QuickSpecs HP ProLiant DL180 Generation 6 Standard Features NOTE: For the Standard Features shipped in the Factory Integrated Models, please see the "Configuration Information - Factory Integrated Models" section. Processor Six-Core Processors One of the following Intel® Xeon® Processor X5675 (3.06 GHz, 12MB L3 Cache, 95W, DDR3-1333, HT, Turbo 2/2/2/2/3/3) depending on Model FIO NOTE: Available through Configure To Order only. See Factory Integration Models section for more details.
QuickSpecs HP ProLiant DL180 Generation 6 Standard Features Intel® Xeon® Processor E5540 (2.53 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2) Intel® Xeon® Processor E5520 (2.26 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2) Intel® Xeon® Processor E5506 (2.13 GHz, 4MB L3 Cache, 80W, DDR3-800) Intel® Xeon® Processor L5630 (2.13 GHz, 12ML L3 Cache, 40W, DDR3-1066, HT, Turbo 1/1/2/2/) FIO NOTE: Available through Configure To Order only. See Factory Integration Models section for more details.
QuickSpecs HP ProLiant DL180 Generation 6 Standard Features Memory Type DDR3 Registered (RDIMM) or Unbuffered (UDIMM) DIMM slots Total 12 DIMM slots Standard (Entry Models) 4GB (1 x 4GB) Standard (Base Models) 8GB (2 x 4GB) Standard (Performance 16GB (4 x 4GB) Models) Maximum (RDIMM) 192GB (12 x 16GB) Maximum (UDIMM) 48GB (12 x 4GB) NOTE: Half DIMM slots are available when one processor is installed.
QuickSpecs HP ProLiant DL180 Generation 6 Standard Features Storage Controller 4HDD Models 8HDD Models 12HDD Models HP Smart Array B110i SATA RAID NOTE: To enable RAID on Embedded SATA, use the HP Smart Array B110i SATA RAID Controller, To enable use of the B110i, enter the ROM based setup utility(RBSU). The option for enabling RAID can be found in the Advanced section of the RBSU.
QuickSpecs HP ProLiant DL180 Generation 6 Standard Features Interfaces Network RJ-45 (Ethernet) 2 10/100/1000 NIC ports (plus 1 dedicated for the HP ProLiant Lights Out 100i Remote Management) Serial 1 Graphics 1 USB 5 total ports: (2) front, (2) rear, (1) optional internal NOTE: In order to connect a USB device internally, the internal USB Cable G6 Kit must be used (P/N 536769-B21). NOTE: Please see the following URL for additional information regarding USB support: http://h18004.www1.hp.
QuickSpecs HP ProLiant DL180 Generation 6 Standard Features Common Slot ProLiant It is highly recommended that you use the HP Power Advisor in defining the "Right-Size" power supply for your needs. HP offers Power Supply Options: 460Watts, Common Slot, 92% Efficiency 750Watts, Common Slot, 92% Efficiency 460Watts, Common Slot, 94% Efficiency 750Watts, Common Slot, 94% Efficiency HP's ProLiant Common Slot Power supplies (460W & 750W) meet multiple Energy Efficiency Initiatives.
QuickSpecs HP ProLiant DL180 Generation 6 Standard Features Embedded Manageability HP Lights-Out 100 (LO100) Advanced HP LO100 with Optional LO100 Advanced Licenses for Virtual KVM and Virtual Media. Features: Embedded IPMI standard reporting System event log access Remote Serial console (serial redirection) Browser, Telnet access SMASH-CLP compliant IPMI 2.0 compliant Secure Socket Layer Encryption Secure Shell Encryption Virtual media (Floppy, CD, USB 2.
QuickSpecs HP ProLiant DL180 Generation 6 Standard Features Health monitoring capabilities, including monitoring for drives, fans, network, power supplies, and temperature Alerting capabilities, including basic alert notification for Smart Array drive pre-failure only Performance monitoring capabilities providing information on processor, memory, disk free space, network utilization Easy Set-up CD NOTE: For additional information, please see: http://www.hp.
QuickSpecs HP ProLiant DL180 Generation 6 Standard Features www.hp.com/servers/easysetup.
QuickSpecs HP ProLiant DL180 Generation 6 Optional Features HP Insight Control management software HP Insight Control for Linux HP Insight Control for Linux, as a product option, delivers essential infrastructure management that can help save time and money by making it easy to deploy, monitor, remote control, and optimize your IT infrastructure through a single, simple management console.
QuickSpecs HP ProLiant DL180 Generation 6 Optional Features HP Cluster Management HP Cluster Management Utility (CMU) is an HP-licensed and HPUtility supported suite of tools that are used to manage large-scale Linux ProLiant systems. CMU includes software for the centralized provisioning, management and monitoring of nodes. CMU makes the administration of clusters user friendly, efficient, and effective. http://www.hp.
QuickSpecs HP ProLiant DL180 Generation 6 Service and Support Service and Support HP Care Pack Services: Packaged server and storage services for increased uptime, productivity and ROI When you buy HP server and storage products and solutions, it's also a good time to think about what levels of support you may need. Our portfolio of service options reduce deployment and management worries while helping you get the most out of your server and storage investments.
QuickSpecs HP ProLiant DL180 Generation 6 Service and Support Recommended HP Care Pack Services for optimal satisfaction with your HP product Recommended Services 3-Year HP Hardware Support Onsite Service, 4-hour response, 13x5 Delivers increased equipment availability and productivity with rapid remote support and onsite response for your HP server and storage hardware. Help improve or maintain system uptime Convenient onsite support Committed response time http://h20195.www2.hp.com/V2/GetPDF.
QuickSpecs HP ProLiant DL180 Generation 6 Service and Support http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-6636ENN HP Proactive Select Service Customer needs on demand access to consulting, technical proactive services and education courses Provides a flexible way to purchase HP best-in-class consultancy and technical services. You can buy Proactive Select Service Credits when you purchase your hardware and then use the credits over the next 12 months. http://h20195.www2.hp.com/V2/GetPDF.
QuickSpecs HP ProLiant DL180 Generation 6 Pre-configured Models Four Drive Serial ATA (SATA) Models NOTE: For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information - Factory Integrated Models" section. NOTE: Pre-configured models ship with the configurations below. Options can be selected from the Core or Additional options section of this QuickSpecs. NOTE: HP does not allow factory integration of options into pre-configured models.
QuickSpecs HP ProLiant DL180 Generation 6 Pre-configured Models HP DL180G6 L5520 2x2GB 4LFF 487506-xx1 Processor Cache Memory Memory Network Controller Storage Controller Hard Drive Internal Storage Optical Drive HP DL180G6 E5506 1x4GB 4LFF 590637-xx1 Intel® Xeon® Processor L5520 (2.
QuickSpecs HP ProLiant DL180 Generation 6 Pre-configured Models Hard Drive Internal Storage Optical Drive Power Supply Form Factor Warranty HP DL180G6 E5520 3x2GB 8LFF 487503-xx1 Processor Cache Memory Memory Network Controller Storage Controller Hard Drive Internal Storage Optical Drive Power Supply Form Factor Warranty HP DL180G6 L5630 1x4 Processor GB 8LFF 590636-xx1 Cache Memory Memory Network Controller Storage Controller Hard Drive Internal Storage Optical Drive Power Supply Form Factor Warrant
QuickSpecs HP ProLiant DL180 Generation 6 Pre-configured Models Twelve Drive Serial ATA (SATA) Models NOTE: Internal Storage expandable to 14 SAS/SATA drives with 2 Rear Drive Option Kit (P/N 488234-B21) HP DL180G6 E5620 Processor Intel® Xeon® Processor E5620 (2.
QuickSpecs HP ProLiant DL180 Generation 6 Pre-configured Models Network Controller Storage Controller Hard Drive Internal Storage Optical Drive Power Supply Form Factor Warranty HP NC362i Integrated Dual Port Gigabit Server Adapter HP Smart Array P212 /256MB Controller (RAID 0/1/1+0/5/5+0) NOTE: The minimum of 256 MB cache, battery kit, and Smart Array Advanced Pack License Key upgrade (P/N 516471-B21) is required to enable RAID 6, 6+0 None ship standard (up to 12 Hot Plug SATA or SAS drives supported)
QuickSpecs HP ProLiant DL180 Generation 6 Pre-configured Models Country Code Key Optical Drive Power Supply Form Factor Warranty None ship standard 750 W common slot ,power supply Rack (2U) Server Warranty includes 3-Years Next Business Day Parts replacement, 0-Years Labor, 0-Years Onsite support xx=00 xx=29 xx=37 xx=42 xx=AA U.S.
QuickSpecs HP ProLiant DL180 Generation 6 Configuration Information - Factory Integrated Models NOTE: This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for information on CTO product offerings and requirements. NOTE: Configure-to-order (CTO) servers must start with a CTO Chassis.
QuickSpecs HP ProLiant DL180 Generation 6 Configuration Information - Factory Integrated Models Step 2: Choose Required Options (only one of the following from each list unless otherwise noted) HP Processors NOTE: If 2 processors are desired, select one xxxxxx-L21 and one xxxxxxB21. Six-Core Processors HP DL180 G6 Intel® Xeon® X5675 (3.06GHz/6-core/12MB/95W) FIO Processor Kit HP DL180 G6 Intel® Xeon® X5670 (2.93GHz/6-core/95W/12MB) FIO Processor Kit HP DL180 G6 Intel® Xeon® X5660 (2.
QuickSpecs HP ProLiant DL180 Generation 6 Configuration Information - Factory Integrated Models HP Memory Registered RDIMMs HP 2GB (1x2GB) Dual Rank x8 PC3-10600 (DDR3-1333) Registered CAS-9 Memory Kit HP 4GB (1x4GB) Dual Rank x4 PC3-10600 (DDR3-1333) Registered CAS-9 Memory Kit HP 4GB (1x4GB) Quad Rank x8 PC3-8500 (DDR3-1066) Registered CAS-7 Low Power Memory Kit HP 4GB (1x4GB) Single Rank x4 PC3-10600 (DDR3-1333) Registered CAS-9 Memory Kit HP 16GB (1x16GB) Quad Rank x4 PC3-8500 (DDR3-1066) Registered
QuickSpecs HP ProLiant DL180 Generation 6 Configuration Information - Factory Integrated Models HP Power Supplies NOTE: Many HP ProLiant Servers now offer new power options, including Common Slot Power Supplies. These power supplies come in multiple power ratings and higher efficiency levels to offer the Right Size solution to fit your configuration. This provides improved power delivery and the advantage of reclaiming lost power.
QuickSpecs HP ProLiant DL180 Generation 6 Core Options NOTE: Some options may not be integrated at the factory. To ensure only valid configurations are ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for additional information. HP Unique Options HP DL180G6 Redundant Fan Kit 516009-B21 HP DL180G6 Rear DVD Cage Kit 515826-B21 NOTE: The x16 low profile slot is not available when this option is configured.
QuickSpecs HP ProLiant DL180 Generation 6 Core Options HP DL180 G6 Intel® Xeon® E5540 (2.53GHz/4-core/8MB/80W) Processor Kit HP DL180 G6 Intel® Xeon® E5520 (2.26GHz/4-core/8MB/80W) Processor Kit HP DL180 G6 Intel® Xeon® E5506 (2.13GHz/4-core/4MB/80W) Processor Kit HP DL180 G6 Intel® Xeon® E5504 (2.00GHz/4-core/4MB/80W) Processor Kit Two-Core Processors HP DL180 G6 Intel® Xeon® E5503 (2.
QuickSpecs HP ProLiant DL180 Generation 6 Core Options NOTE: All DDR3 memory option kits consist of one DIMM per kit. For detailed memory configuration rules and guidelines, please use the Online DDR3 Memory Configuration Tool: www.hp.com/go/ddr3memory-configurator NOTE: Kits described as LP include Low Power DIMMs. For more information on ProLiant Energy Efficient Features, see: http://h18004.www1.hp.
QuickSpecs HP ProLiant DL180 Generation 6 Core Options SAS Hot Plug LFF (3.5-inch) Midline (MDL) Drives NOTE: 3G Hard Drives will operate at up to 3.0 Gb/s in 4 drive models that use the embedded controller. HP 2TB 6G SAS 7.2K rpm LFF (3.5-inch) Dual Port Midline 1yr Warranty Hard Drive HP 1TB 6G SAS 7.2K rpm LFF (3.5-inch) Dual Port Midline 1yr Warranty Hard Drive SATA Hot Plug SFF (2.5-inch) Midline (MDL) Drives HP 500GB 3G SATA 7.2K rpm SFF (2.5-inch) Midline 1yr Warranty Hard Drive HP 160GB 3G SATA 7.
QuickSpecs HP ProLiant DL180 Generation 6 Core Options HP InfiniBand HP NC523SFP 10Gb 2-port Server Adapter HP NC550SFP Dual Port 10GbE Server Adapter NOTE: Please see the QuickSpecs for Technical Specifications and additional information: www.hp.com/go/ProLiantNICs. 593717-B21 581201-B21 QLogic IB 4X QDR PCI-e G2 Dual-port HC HP IB 4X QDR CX-2 PCI-e G2 Dual Port HCA HP IB 4X DDR CX-2 PCI-e G2 Dual Port HCA NOTE: Please see the QuickSpecs for additional information: http://h18000.www1.hp.
QuickSpecs HP ProLiant DL180 Generation 6 Additional Options NOTE: Some options may not be integrated at the factory. To ensure only valid configurations are ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for additional information.
QuickSpecs HP ProLiant DL180 Generation 6 Additional Options High Performance Clusters HP I/O Accelerator Options HP Graphics Options HP Cluster Management Utility HP Cluster Management Utility Compute Node Flexible License NOTE: This part number can be used to purchase one certificate for multiple licenses with a single activation key. Each license is for one node (server). Customer will receive a printed end user license agreement and license entitlement certificate via physical shipment.
QuickSpecs HP ProLiant DL180 Generation 6 Additional Options HP Security - TPM HP Trusted Platform Module Option Kit NOTE: The TPM (Trusted Platform Module) is a microcontroller chip that can securely store artifacts used to authenticate the server platform. These artifacts can include passwords, certificates and encryption keys. Windows® BitLocker™ Drive Encryption (BitLocker) is a data protection feature available in Windows Server® 2008.
QuickSpecs HP ProLiant DL180 Generation 6 Additional Options HP 650 mAh P-Series Battery NOTE: To enable BBWC on the 256MB cache. NOTE: Supported on HP Smart Array P212 Controller, HP Smart Array P410 Controller, and HP Smart Array P411 Controller only. HP 8484 to Mini SAS 33in Cable Assembly NOTE: Cable for use connecting the Smart Array P800 Controller to internal hard disk drives on select HP ProLiant G6 Servers.
QuickSpecs HP ProLiant DL180 Generation 6 Additional Options HP Backup & Recovery Data Protector Express Software HP Data Protector Express V5.0 for 1 Server E-LTU HP Data Protector Express V5.0 for 3 Servers E-LTU HP Data Protector Express V5.0 for 10 Servers E-LTU HP Basic Upgrade to Data Protector Express V5 for 1 Server E-LTU NOTE: Only one of these Data Protector Express base products is required. To see available options: http://www.hp.
QuickSpecs HP ProLiant DL180 Generation 6 Additional Options HP Disk Backup NOTE: For the complete range of StorageWorks D2D Backup Systems see: http://www.hp.com/go/d2d. For the complete range of StorageWorks RDX drives and media see: http://www.hp.com/go/rdx. For hardware and software compatibility of HP StorageWorks disk backup products see: http://www.hp.com/go/connect. HP StorageWorks D2D Backup Systems with Backup Data Deduplication HP StorageWorks D2D2502i Backup System NOTE: 1.
QuickSpecs HP ProLiant DL180 Generation 6 Additional Options HP StorageWorks CN1000Q Dual Port Converged Network Adapter HP Disk Storage Systems HP Uninterruptible Power Systems MSA SAN Storage Arrays HP StorageWorks MSA60 Array NOTE: Please see the QuickSpecs for additional options and configuration information at: http://h18000.www1.hp.com/products/quickspecs/12627_div/12627_div.
QuickSpecs HP ProLiant DL180 Generation 6 Additional Options HP Power Distribution Monitored PDUs Units HP Monitored Power Distribution Unit: Full Rack Version HP 8.6 kVA S1324 Monitored PDU- single input, 3Ø, 24A (NA/JPN) HP 16.6 kVA S2140 Monitored PDU- dual input, 1Ø, 40A (NA/JPN) HP 8.3 S1140 Monitored PDU- single input, 1Ø, 40A (NA/JPN) HP 11 kVA S1316 Monitored PDU- single input, 3Ø, 16A (INTL) HP 7.
QuickSpecs HP ProLiant DL180 Generation 6 Additional Options HP Rack Series HP Rack 10000 G2 Series (Carbon/Graphite Metallic) HP 10642 G2 1200mm deep Shock Rack HP 10647 G2 1200mm deep Shock Rack HP 10642 G2 Pallet Universal Rack HP 10642 G2 Shock Universal Rack NOTE: It is mandatory to use a shock pallet when shipping racks with equipment installed. NOTE: Please see the Rack 10000 G2 QuickSpecs for Technical Specifications such as height, width, depth, weight, and color: http://h18000.www1.hp.
QuickSpecs HP ProLiant DL180 Generation 6 Additional Options HP Rack Options HP USB and SD Options HP KVM Switch Options HP 0x2x8 KVM Server Console G2 Switch HP 0x2x16 KVM Server Console G2 Switch NOTE: Cat5e cables are required to connect Interface Adapters to Console Switches. Cat5e cables can be found at the following URL: http://www.hp.com/go/kvm.
QuickSpecs HP ProLiant DL180 Generation 6 Memory NOTE: Memory configurations listed do not apply to "Factory Integrated Models". HP ProLiant DL180 G6 Standard Memory (depending on model) 4GB (1 x 4GB) PC3-10600R-9 Registered memory, with Advanced ECC Capabilities Memory installed. 8GB (2 x 4GB) PC3-10600R-9 Registered memory, with Advanced ECC Capabilities Memory installed. 16GB (4 x 4GB) PC3-10600R-9 Registered memory, with Advanced ECC Capabilities Memory installed.
QuickSpecs HP ProLiant DL180 Generation 6 Memory DIMM Type -> Registered DIMMS (RDIMMs) Single DIMM Rank -> Rank (1R) DIMM Capacity -> 4GB DIMM Native Speed 1333 (MHz) -> Voltage LV/Std 2GB 1333 Std Dual Rank (2R) 4GB 8GB 1333 1333 Std LV/Std 16GB 1333 Quad Rank (4R) 4GB 16GB 1066 1066 Unbuffered with ECC DIMMs (UDIMMs) Single Rank (1R) Dual Rank (2R) 1GB 2GB 4GB 1333 1333 1333 LV/Std Std Std Std Std Std 12 slot servers SLOTS THAT CAN BE POPULATED 12 12 12 12 12 12 12 12 12 12 12 sl
QuickSpecs HP ProLiant DL180 Generation 6 Memory Standard memory configuration (1 CPU model) 6GB, consisting of three (3) 2GB dual-rank PC3-10600 RDIMMs Chnl 1 slot # 1 2 CPU1 population order D: empty A: 2GB DIMM slot # 1 2 CPU2 population order D: empty A: empty Chnl 1 Chnl 2 3 4 E: empty B: 2GB DIMM 3 4 E: empty B: empty Chnl 2 Chnl 3 5 6 F: empty C: 2GB DIMM 5 6 F: empty C: empty Chnl 3 Standard memory plus optional memory (1 CPU model) 30GB, consisting of three (3) 2GB RDIMMs plus
QuickSpecs HP ProLiant DL180 Generation 6 Memory Chnl 1 slot # 1 2 CPU1 population order D: 4GB DIMM A: 4GB DIMM slot # 1 2 CPU2 population order D: empty A: empty Chnl 1 Chnl 2 3 4 E: 4GB DIMM B: 4GB DIMM 3 4 E: empty B: empty Chnl 2 Chnl 3 5 6 F: 4GB DIMM C: 4GB DIMM 5 6 F: empty C: empty Chnl 3 Standard memory replaced with optional memory (2 CPU model) RDIMM maximum configuration 192GB, consisting of twelve (12) 16GB quad-rank PC3-8500 RDIMMs and twelve (12) 16 GB dual rank PC3L1060
QuickSpecs HP ProLiant DL180 Generation 6 Memory www.hp.
QuickSpecs HP ProLiant DL180 Generation 6 Memory NOTE: All DDR3 memory option kits consist of one DIMM per kit. For detailed memory configuration rules and guidelines, please use the Online DDR3 Memory Configuration Tool: www.hp.com/go/ddr3memory-configurator. NOTE: Kits described as LP include Low Power DIMMs. For more information on ProLiant Energy Efficient Features, see: http://h18004.www1.hp.
QuickSpecs HP ProLiant DL180 Generation 6 Storage 8 Drive Cage with DVD-Drive bay 1-8 9 Eight 3.5" Hot Plug SAS/SATA Hard Drive Bays DVD-ROM, DVD RW 12 Drive Cage 1-12 Twelve 3.5" Hot Plug SAS/SATA Hard Drive Bays 13-14 Two Rear 3.
QuickSpecs HP ProLiant DL180 Generation 6 Storage HP Smart Array Hot Plug Advance Pack for B110i SATA Hot Plug LFF (3.5-inch) Midline (MDL) Drives Quantity Position Supported Supported 2TB 3G SATA 7.2K Up to 8 with 8 1-8 1TB 3G SATA 7.2K drive cage 500GB 3G SATA 7.2K Up to 14 with 12 drive cage + Rear Drive Cage 1-14 SATA Hot Plug LFF (3.5-inch) Entry (ETY) Drives Quantity Position Supported Supported 250GB 3G SATA 7.2K Up to 8 with 8 1-8 160GB 3G SATA 7.
QuickSpecs HP ProLiant DL180 Generation 6 Storage HP Smart Array P410/512 MB FBWC Controller HP Smart Array P410/1G FBWC Controller HP Smart Array P812/1G FBWC Controller HP Smart Array Hot Plug Advance Pack for B110i SATA Hot Plug 3.5" Midline (MDL) Solid State Drives Quantity Position Supported Supported 60GB 3.0G SATA SSD Up to 8 with 8 1-8 120GB 3.0G SATA SSD drive cage SAS Hot Plug SFF (2.5-inch) Midline (MDL) Drives Quantity Position Supported Supported 500GB 6G SAS 7.
QuickSpecs HP ProLiant DL180 Generation 6 Storage 600GB 6G 10K SAS 450GB 6G 19K SAS 300GB 6G 10K SAS 146GB 6G 15K SAS 146GB 6G 10K SAS 72GB 6G 15K SAS Quantity Supported Up to 8 with 8 drive cage Position Supported 1-8 Up to 25 with 25 drive cage 1-25 SAS Hot Plug LFF (3.
QuickSpecs HP ProLiant DL180 Generation 6 Storage External Storage 60 Modular Smart Array 70 Modular Smart Array Quantity Supported Up to 4 Position Supported External Up to 8 External Up to 2 Up to 4 External External Controller HP Smart Array P212/256 MB Controller HP Smart Array P800/512 BBWC Controller HP Smart Array P411/256 MB Controller HP Smart Array P411/512 FBWC Controller HP Smart Array P411/512 MB FBWC Controller HP Smart Array P411/1G FBWC Controller HP Smart Array P812/1G Flash Back
QuickSpecs HP ProLiant DL180 Generation 6 Storage LTO-2 Ultrium 448 LTO-3 Ultrium 920 LTO-4 Ultrium 1760 LTO-4 Ultrium 1840 LTO-5 Ultrium 3000 LTO-5 Ultrium 3280 1U Rack-Mount Kit 3U Rack-Mount Kit HP StorageWorks SCSI Tape Autoloaders DAT 72x10 Autoloader 1/8 G2 Autoloader External HP SC11Xe Ultra320 Single Channel/ PCIe x4 SCSI Host Bus Adapter HP StorageWorks SCSI Tape Libraries MSL2024 MSL4048 MSL8096 MSL6000 External HP StorageWorks U320e SCSI Dual Channel Host Bus Adapter HP StorageWorks SAS T
QuickSpecs HP ProLiant DL180 Generation 6 Storage HP 460W HE 12V Hot Plug AC Power Supply Kit Part Number 503296-B21 Input Voltage Range (Vrms) 100 to 240 Frequency Range (Nominal) 50/60 (Hz) Nominal Input Voltage (Vrms) 100 120 Maximum Rated Output Wattage 460 460 Nominal Input Current (A rms) 5.5 4.5 Max Rated Input Wattage Rating 526 520 (Watts) Max. Rated VA (Volt-Amp) 548 542 Efficiency (%) at Max. Rated 87.5 88.5 Output Wattage Power Factor 0.97 0.97 Leakage Current (mA) 0.42 0.50 Max.
QuickSpecs HP ProLiant DL180 Generation 6 Power Specifications HP 460W Common Slot Platinum Power Supply Kit Part Number 593188-B21 Input Voltage Range (Vrms) 100 to 240 Frequency Range (Nominal) 50/60 (Hz) Nominal Input Voltage (Vrms) 100 120 Maximum Rated Output Wattage 460 460 Nominal Input Current (A rms) 5.3 4.3 Max Rated Input Wattage Rating 512 505 (Watts) Max. Rated VA (Volt-Amp) 526 518 Efficiency (%) at Max. Rated 89.8 91.2 Output Wattage Power Factor Leakage Current (mA) Max.
QuickSpecs HP ProLiant DL180 Generation 6 Technical Specifications System Unit Dimensions (H x W x D) 3.45" x 17.64" x 28.23" in (8.76 x 44.80 x 71.71 cm) (with bezel) Weight Maximum 45.0 lb (16.80 kg) (approximate) (all hard drives, power supplies, and processors installed) Minimum 32.0 lb (11.94 kg) (one hard drive, power supply, and processor installed) Input Requirements Rated Line Voltage 90 -- 132 VAC, (per power supply) 180 - 264 V Rated Input Current 460 Watt 7.1 A (at 120 VAC) 3.
QuickSpecs HP ProLiant DL180 Generation 6 Technical Specifications Non-operating Relative Humidity (non-condensing) Operating Non-operating Altitude Operating Non-operating Acoustic Noise -30° to 60°C (-22° to 140°F). Maximum rate of change is 20°C/hr (36°F/hr). 10 to 90% relative humidity (Rh), 28°C (82.4°F) maximum wet bulb temperature, noncondensing. 5 to 95% relative humidity (Rh), 38.7°C (101.7°F) maximum wet bulb temperature, non-condensing. 3050 m (10,000 ft).
QuickSpecs HP ProLiant DL180 Generation 6 Technical Specifications HP 160GB 3G SATA 7.2K rpm LFF (3.5-inch) Entry 1yr Warranty Hard Drive 458945-B21 Capacity Height Width Depth Interface Transfer Rate (Maximum) Native Command Queuing Seek Time (typical reads, including settling) 160,041MB 1.04 in (26.4 mm) 4.36 in (110.7 mm) 7.25 in (184.2 mm) Serial ATA 3Gb/s Supported Single Track Average Full-Stroke Rotational Speed 2.0 ms <11 ms 23.
QuickSpecs HP ProLiant DL180 Generation 6 Technical Specifications Smart Array P410/410i Disk Drive and Controller Enclosure Interface 6Gb/s SAS (Serial Attached SCSI) 3Gb/s SATA (Serial ATA) SAS Connectors 2 internal (Mini-SAS) x8 wide port connectors Cache Memory Speed DDR2-533MHz with 40 or 72-bit wide bus provides up to 4.2 GB/s maximum bandwidth. Server Interface x8 2.5G PCIe 2.0 provides 2GB/s maximum bandwidth SAS Speed x8 6Gb/s SAS provides 24.
