QuickSpecs HP ProLiant SL335s Generation 7 (G7) Overview The HP ProLiant SL335s G7 Server is the first AMD half-width server node for the HP ProLiant SL6500 Scalable System. The SL335s G7 is an independently serviceable 2P server node using AMD Opteron 4100 series processors with 12 DDR3 DIMM sockets. The SL6500 is the latest family of HP server solutions optimized for scale-out customers to greatly reduce costs, maximize power efficiency, and maintain total flexibility.
QuickSpecs HP ProLiant SL335s Generation 7 (G7) Standard Features NOTE: For the Standard Features shipped in the Factory Integrated Models, please see the "Configuration Information - Factory Integrated Models" section. Processor Six-Core Processors One of the following AMD Opteron™ 4184 (2.80GHz/6-core/6MB/75W) Processor depending on Model AMD Opteron™ 4176HE (2.40GHz/6-core/6MB/50W) Processor AMD Opteron™ 4162EE (1.70GHz/6-core/6MB/32W) Processor Quad-Core Processor AMD Opteron™ 4130 (2.
QuickSpecs HP ProLiant SL335s Generation 7 (G7) Standard Features Storage Controller HP Embedded Smart Array B110i SATA RAID Controller (RAID 0, 1, 10) per server node NOTE: To enable RAID on Embedded SATA, use the HP Smart Array B110i SATA Raid controller, To enable use of the B110i, enter the ROM based setup utility(RBSU). The option for enabling RAID can be found in the advanced section of the RBSU. For additional details www.hp.com/go/SATARAID NOTE: Transfer rate: 3.0 Gb/s SATA.
QuickSpecs HP ProLiant SL335s Generation 7 (G7) Standard Features Industry Standard Compliance ACPI 2.0b Compliant PCI 2.2 Compliant WOL Support Microsoft® Logo certifications PXE Support USB 1.1 and 2.0 Compliant SMBIOS 2.6.1 Graphics ATI RN50/ES1000 w/ 64MB memory HP Common Slot Power Supplies HP has a new design for ProLiant power.
QuickSpecs HP ProLiant SL335s Generation 7 (G7) Standard Features HP Insight management software HP Insight Foundation HP provides management solutions that are designed to simplify a server's installation, configuration and maintenance throughout the entire server lifecycle. This provides the customer with higher levels of operational efficiency and highly reliable systems: www.hp.com/go/foundation.
QuickSpecs HP ProLiant SL335s Generation 7 (G7) Standard Features Warranty This product is covered by a global limited warranty and supported by HP Services and a worldwide network of HP Authorized Channel Partners. Hardware diagnostic support and repair is available for one year from date of purchase. Support for software and initial setup is available for 90 days from date of purchase. Enhancements to warranty services are available through HP Care Pack services or customized service agreements.
QuickSpecs HP ProLiant SL335s Generation 7 (G7) Optional Features HP Insight management software HP Insight Control HP Insight Control, a product option, delivers essential infrastructure management that can help save time and money by making it easy to deploy, migrate, monitor, remote control, and optimize your IT infrastructure through a single, simple management console.
QuickSpecs HP ProLiant SL335s Generation 7 (G7) Optional Features High Performance Clusters HP Cluster Platforms HP Cluster Platforms are specifically engineered, factory-integrated largescale ProLiant clusters optimized for High Performance Computing, with a choice of servers, networks and software. Operating system options include specially priced offerings for Red Hat Enterprise Linux and Novell SLES, as well as Microsoft Windows HPC Server. A Cluster Platform Configurator simplifies ordering.
QuickSpecs HP ProLiant SL335s Generation 7 (G7) Service and Support Service and Support For increased uptime, productivity and ROI - HP Care Pack packaged services for Servers These days, you need to get the most out of your server investment - you can't afford not to. When you buy HP server products and solutions, it's also a good time to think about what levels of service and support you may need.
QuickSpecs HP ProLiant SL335s Generation 7 (G7) Service and Support NOTE: Care Pack Services availability may vary by product and country. Optimized Care Optimized Care Package: Supports maintaining servers at optimum performance availability HP ProLiant Server Hardware Installation Provides for the basic hardware installation of HP branded servers, storage devices and networking options to assist you in bringing your new hardware into operation in a timely and professional manner http://h20195.www2.hp.
QuickSpecs HP ProLiant SL335s Generation 7 (G7) Service and Support Basic Care Basic Care Package: delivers minimum recommended support service level HP ProLiant Server Hardware Installation Provides for the basic hardware installation of HP branded servers, storage devices and networking options to assist you in bringing your new hardware into operation in a timely and professional manner http://h20195.www2.hp.com/V2/GetPDF.
QuickSpecs HP ProLiant SL335s Generation 7 (G7) Configuration Information - Factory Integrated Models NOTE: This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for information on configurable product offerings and requirements. NOTE: Configure-to-order (CTO) servers must start with a CTO Chassis.
QuickSpecs HP ProLiant SL335s Generation 7 (G7) Configuration Information - Factory Integrated Models HP 16GB (1x16GB) Dual Rank x4 PC3L-10600 (DDR3-1333) Registered CAS-9 LP Memory Kit Unbuffered with ECC DIMMs (UDIMMs) HP 2GB (1x2GB) Dual Rank x8 PC3-10600 (DDR3-1333) Unbuffered CAS-9 Memory Kit HP 4GB (1x4GB) Dual Rank x8 PC3-10600 (DDR3-1333) Unbuffered CAS-9 Memory Kit NOTE: All DDR3 memory option kits consist of one DIMM per kit.
QuickSpecs HP ProLiant SL335s Generation 7 (G7) Core Options NOTE: Some options may not be integrated at the factory. To ensure only valid configurations are ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for additional information. HP s6500 Half-width Tray Node Blank Kit 622372-B21 HP Unique Options NOTE: Node blank is needed when removing half width tray for service. NOTE: Node blank is needed when not completely filling s6500 chassis.
QuickSpecs HP ProLiant SL335s Generation 7 (G7) Core Options HP Memory Registered DIMMs (RDIMMs) HP 2GB (1x2GB) Dual Rank x8 PC3-10600 (DDR3-1333) Registered CAS-9 Memory Kit HP 4GB (1x4GB) Single Rank x4 PC3-10600 (DDR3-1333) Registered CAS-9 Memory Kit HP 4GB (1x4GB) Single Rank x4 PC3L-10600 (DDR3-1333) Registered CAS-9 Low Power Memory Kit HP 8GB (1x8GB) Dual Rank x4 PC3-10600 (DDR3-1333) Registered CAS-9 Memory Kit HP 8GB (1x8GB) Dual Rank x4 PC3L-10600 (DDR3-1333) Registered CAS-9 Low Power Memory
QuickSpecs HP ProLiant SL335s Generation 7 (G7) Core Options SAS Non-Hot Plug SFF (2.5-inch) Enterprise (ENT) Drives - with quick-release (QR) carrier NOTE: the HP s6500 SFF Enablement Kit (607247-B21) must be ordered when ordering SFF HDDs. This kit includes the hardware which holds two SFF HDDs and includes the power cable for the drives. Order one kit for every 2 SFF HDDs. HP 300GB 6G SAS 10K rpm SFF (2.5-inch) Quick-release Dual Port Enterprise 3yr Warranty Hard Drive SAS Non-Hot Plug LFF (3.
QuickSpecs HP ProLiant SL335s Generation 7 (G7) Core Options HP Power Supplies NOTE: Prior to making a power supply selection it is highly recommended that the HP Power Advisor is run to determine the right size power supply for your server configuration. The HP Power Advisor is located at: www.hp.
QuickSpecs HP ProLiant SL335s Generation 7 (G7) Additional Options NOTE: Some options may not be integrated at the factory. To ensure only valid configurations are ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for additional information. HP Insight Software HP Insight Control HP Insight Management Media Kit 436222-B21 NOTE: HP Insight Management Media Kit contains DVDs without licenses.
QuickSpecs HP ProLiant SL335s Generation 7 (G7) Additional Options NOTE: Licenses ship without media. The Insight Control Media Kit can be ordered separately, or can be downloaded at: http://www.hp.com/go/insightupdates. NOTE: Electronic licenses can be used to purchase multiple licenses with a single activation key, and is available in all countries except China and Japan. Customers in China and Japan should order the physical equivalent.
QuickSpecs HP ProLiant SL335s Generation 7 (G7) Additional Options HP SL Advanced Power Manager The SL Advanced Power Manager is an optional rack level solution for the HP ProLiant SL6500 which enables server-level DC (or hardware) power on and off and serverlevel monitoring. In addition, the SL APM will automatically discover SL hardware components which are connected into the SL APM solution.
QuickSpecs HP ProLiant SL335s Generation 7 (G7) Additional Options HP 512MB P-Series Battery Backed Write Cache Upgrade NOTE: Supported on HP Smart Array P410 Controller only. HP 1GB Flash Backed Cache NOTE: Please see the following QuickSpecs for Technical Specifications and additional information: http://h18000.www1.hp.com/products/quickspecs/13203_na/13203_na.html (Smart Array P212 Controller) http://h18000.www1.hp.com/products/quickspecs/13201_na/13201_na.
QuickSpecs HP ProLiant SL335s Generation 7 (G7) Memory HP ProLiant SL335s G7 Server NOTE: Memory configurations listed do not apply to "Factory Integrated Models". NOTE: Chart does not represent all possible memory configurations. DDR3 memory population guidelines For detailed memory configuration rules and guidelines, please use the Online DDR3 Memory Configuration Tool: www.hp.
QuickSpecs HP ProLiant SL335s Generation 7 (G7) Memory PC3-10600 DIMMs have a maximum speed of 1333MHz.
QuickSpecs HP ProLiant SL335s Generation 7 (G7) Memory Chnl 1 Chnl 2 slot # 1 2 3 CPU1 population order A; 4GB DIMM E; Empty C; 4GB DIMM 4 5 6 B; 4GB DIMM F; Empty D; 4GB DIMM slot # 1 2 3 CPU2 population order A; 4GB DIMM E; Empty C; 4GB DIMM 4 5 6 B; 4GB DIMM F; Empty D; 4GB DIMM Chnl 1 Chnl 2 NOTE: Capacity references are rounded to the common Gigabyte values.
QuickSpecs HP ProLiant SL335s Generation 7 (G7) Memory HP 16GB (1x16GB) Quad Rank x4 PC3-8500 (DDR3-1066) Registered CAS-7 Memory Kit HP 16GB (1x16GB) Dual Rank x4 PC3L-10600 (DDR3-1333) Registered CAS-9 LP Memory Kit Unbuffered with ECC DIMMs (UDIMMs) HP 2GB (1x2GB) Dual Rank x8 PC3-10600 (DDR3-1333) Unbuffered CAS-9 Memory Kit HP 4GB (1x4GB) Dual Rank x8 PC3-10600 (DDR3-1333) Unbuffered CAS-9 Memory Kit NOTE: All DDR3 memory option kits consist of one DIMM per kit.
QuickSpecs HP ProLiant SL335s Generation 7 (G7) Storage 1-4 Non-hot plug LFF SATA or SAS hard drive bays - Using quick release carrier 1-8 Non-hot plug SFF SATA or SAS hard drive bays - Using quick release carrier Drive Support Hard Drives NOTE: The components of a storage subsystem (e.g. the drive, the HBA/controller, firmware, and the server backplane) should operate at the same data transfer rate or the system bandwidth will be negotiated down to an acceptable level for all components.
QuickSpecs HP ProLiant SL335s Generation 7 (G7) Storage NOTE: HP s6500 SAS Enablement Kit and HP s6500 SFF Enablement Kit are required when adding SFF SAS hard drives using a P410 Smart Array controller. P212 requires the HP SAS/PWR Cable P212 Half Width Kit and HP s6500 SFF Enablement Kit. SAS Hot Plug LFF (3.5-inch) Midline (MDL) Drives - with quick-release (QR) carrier Quantity Position Supported Supported Controller 2TB 6G SAS 7.
QuickSpecs HP ProLiant SL335s Generation 7 (G7) Power Specifications HP 750W Common Slot Gold Hot Plug Power Supply Kit Part Number 512327-B21 Input Voltage Range ( V rms ) 100 to 240 Frequency Range (Nominal) ( Hz ) 50/60 Nominal Input Voltage ( Vrms ) 120 100 Maximum Rated Output Wattage Rating 750 750 Nominal Input Current ( A rms ) 8.9 7.4 Maximum Rated Input Wattage Rating ( Watts ) 857 847 Maximum Rated VA ( Volt-Amp ) 894 884 Efficiency ( % ) 87.5 88.5 Power Factor Leakage Current ( mA ) 0.42 0.
QuickSpecs HP ProLiant SL335s Generation 7 (G7) Power Specifications HP 1200W Common Slot Silver Hot Plug Power Supply Kit Part Number 500172-B21 Input Voltage Range ( V rms ) 100 to 240 Frequency Range (Nominal) ( Hz ) 50/60 Nominal Input Voltage ( Vrms ) 120 100 Maximum Rated Output Wattage Rating 800 900 Nominal Input Current ( A rms ) 9.7 9.
QuickSpecs HP ProLiant SL335s Generation 7 (G7) Technical Specifications System Unit Dimensions (H x W x D) (with bezel) Weight (approximate) Input Requirements (per power supply) 6.96 x 17.638 x 35.236in (17.68 x 44.8 x 89.55cm) Maximum (all hard drives, power supplies, and processors installed) Rated Line Voltage Rated Input Current Rated Input Frequency 220lb (99.8kg) 90 to 140 VAC 180 to 264 VAC 7.31A at 115VAC 3.6A at 230VAC 47 to 63 Hz Rated Input Power 855W (at 100 VAC), 840.
QuickSpecs HP ProLiant SL335s Generation 7 (G7) Technical Specifications Idle Emissions Classification (EMC) LWAd LpAm Operating LWAd LpAm FCC Rating Normative Standards 6.4 45dBA 6.7 51dBA Class A CISPR 22; EN55022; EN55024; FCC CFR 47, Pt 15; ICES-003; CNS13438; GB9254; K22;K24; EN 61000-3-2; EN 61000-3-3; EN 60950-1; IEC 60950-1 NOTE: Product conformance to cited product specifications is based on sample (type) testing, evaluation, or assessment.
