6500W AVR GENERATOR CROMTECH AVR GENERATOR OPERATION MANUAL
Thank you for purchasing a Cromtech Generator. This manual provides understanding of the operation and maintenance of your generator. Please read this manual carefully before operating. For any questions regarding operation or maintenance, please consult your local service agent. Find your local service agent at www.crommelins.com.au. IMPORTANT ICONS Important information is distinguished by the notifications below. The Safety Alarm Symbol ( ! ) alerts you to potential hazards.
INDEX: Warranty ..................................................................... 4 Safety Warnings .......................................................... 5 TG6500VE Features ....................................................... 8 Generator Specifications .............................................. 9 Features ..................................................................... 9 Getting Started ............................................................ 10 Unpacking .........................
WARRANTY CROMTECH™and CROMMELINS™ are a registered trademark of The Crommelin Group. Crommelins warrants their goods against defects in materials and workmanship under normal use and service. The Crommelin Group warranty does not cover fair wear commensurate with the age of the product, any damage caused by accident, abuse, misuse, neglect or failure to observe proper operating instructions or proper machinery maintenance as described in the instruction manual.
SAFETY WARNINGS ! WARNING: DO NOT Operate this generator until you have read ALL safety, operation, and maintenance instructions listed in this manual. • Failure to follow the instructions may result in property damage, INJURY or DEATH. • The warnings and precautions discussed in this manual cannot cover all possible conditions and situations that may occur.
• DO NOT operate the generator with known leaks in the fuel system. • Use proper fuel storage and handling procedures. DO NOT store fuel or other flammable materials nearby. • Empty the fuel tank before storing or transporting the generator. • Keep fire extinguisher handy and be prepared if a fire starts. ! DANGER: TOXIC FUMES - The exhaust of the generator engine contains carbon monoxide, an odorless, colorless, poison gas.
charge a battery in a well ventilated place. Avoid spilled battery acid. If contact with skin is made, wash immediately with clean water. ! WARNING: ELECTRICAL SHOCK - This generator produces powerful voltage and the electricity CAN KILL YOU. • This generator must be properly connected to an appropriate ground to help prevent electric shock. Failure to properly ground generator can result in electrocution, especially if the generator is equipped with a wheel kit.
TG6500VE FEATURES & CONTROLS ❶ Fuel cap ❷ Fuel level indicator ❸ Fuel tank ❹ Frame ❺ Wheels ❻ Cylinder head ❼ Muffler guard Pg.
GENERATOR SPECIFICATIONS Model TG6500VE Max. Output (W) 6500w Cont. Rated Output (W) 6000w Rated Voltage 230V / 50Hz Power Factor 1.0 Engine Cromtech Engine Features OHV, air cooled Displacement 420cc Fuel Type Petrol Fuel Tank 25L Oil Capacity 1.
GETTING STARTED ! NOTE: DO NOT Operate this generator until you have read ALL safety, operation, and maintenance Instructions listed in this manual. 1. UNPACKING - Remove the generator from the shipping carton I. Place the shipping carton on a solid, flat surface. Ii. Carefully cut each corner of the carton box from top to bottom. Fold each side flat on the ground. Iii. Remove everything from the carton except the generator. 2. ASSEMBLY - Your generator requires some assembly.
SUPPORT BRACKET INSTALL THE HANDLE - Place the push handle in the bracket. Push the pin through the bracket and handle and fix with the clip provided. ❶ Clip ❷ Pin ❸ Push handle ATTACH NEGATIVE BATTERY WIRE - The sealed battery on the generator is fully charged and pre-installed except for the negative (black) battery cable. 1. 2. 3. Cut off tie wrap securing loose end of negative (black) cable. Connect the negative (black) battery cable to the negative(-) terminal on the battery.
OPERATING CHECKLIST 1. OPERATING AREA - This generator is for outdoor use. • Only use OUTSIDE and place the generator in a well-ventilated area. • Only operate the generator on a flat, level surface and in a clean, dry operating environment. • Allow one metre clearance on all side of the generator while operating it outdoors. • Generators used for construction sites may be subject to additional rules and regulations.
CHECK ENGINE OIL ! WARNING: This engine is not filled with oil from the factory. Any attempt to crank or start the engine before it has been properly filled (with the recommended type and amount of oil) may result in engine damage and void your warranty. 1. ENGINE OIL - Place the generator on a level surface with engine stopped. • Remove the dipstick and wipe it clean. • Reinstall dipstick into tube; rest on oil fill neck, DO NOT thread cap into tube. 2. Remove the dipstick again and check oil level.
CHECK FUEL LEVELS ! CAUTION: Pressure can build up in the fuel tank. Allow the generator to cool for at least two minutes before removing fuel cap. Loosen the fuel cap slowly to relieve any pressure in the tank • ENGINE FUEL - With the engine stopped, check the fuel level gauge. Refill the fuel tank if necessary. • Use clean, fresh, regular unleaded gasoline only. • DO NOT mix oil with gasoline.
• Gasoline/Alcohol Blends: up to 10% alcohol, 90% unleaded gasoline by volume is approved as a fuel. Other gasoline/alcohol blends are not approved. Effects of old, stale or contaminated fuel may void your warranty. ! CAUTION: To minimise gum deposits in your fuel system and to insure easy starting, do not use gasoline left over from the previous season. ELECTRICAL DEVICES ! NOTE: Disconnect all electrical devices from the generator and switch off the AC circuit breaker before start the engine.
STARTING THE GENERATOR 1. 2. Perform the operating checklist (page 12). Turn the fuel valve to the ‘ON’ position 3. Put the choke valve switch to ‘CLOSE’ position ! NOTE: Choke position for starting may vary depending upon temperature and other factors. If restarting a warm engine, the choke should be left in the HALF or OFF position. 4. ELECTRIC START - Push the rocker ignition switch to ‘I’ run position. Then push fully and hold switch in ‘II’ position until the engine is started.
! WARNING: Rapid retraction of the starter cord will pull hand and arm towards the engine faster than you can let it go. Unintentional startup could result in an injury. ! CAUTION: ENGINE FAILURE - If the engine fails to start after 3 attempts or stops after starting; inspect and ensure that the generator is placed on horizontal surface and check the engine oil levels. • • • • DURING STARTING - DO NOT hold the ignition switch in the ‘II’ position for more than 5 seconds.
CONNECT TO ELECTRICAL DEVICES ! WARNING: This generator is fitted with an RCD Circuit Breaker. ALWAYS test RCD switch before every use. ! CAUTION: Inspect power cords for damage before using. There is a hazard of electrical shock from crushing, cutting or heat damage. 1. 2. Allow the engine to stabilise and warm up for a few minutes after starting. Make sure the electrical devices are in their ‘OFF’ position and the load current is not higher than the maximum withstanding current of single socket.
! CAUTION: If connected devices overheat. Immediately turn them off and disconnect from the generator. ! NOTE: AC OVERLOAD RESET BUTTON/S - If the AC power outlet is overloaded, the AC circuit breaker will cut out the power to the device. If tripped remove device/load and reset button. ! NOTE: Not all motors start at the same time, total surge watts can be estimated by adding only the electrical device(s) with the highest additional surge watts to the total rated watts from step 2.
CHARGING A BATTERY (APPLICABLE TYPES) ! WARNING: Batteries give off explosive hydrogen gas while recharging. An explosive mixture will remain around the battery for a long time after it has been charged. The slightest spark can ignite the hydrogen and cause an explosion, resulting in blindness or other serious injury. • Charge the battery only with battery charging sockets provided Charge the battery in dry environment.
STOPPING THE GENERATOR ! WARNING: NEVER stop the engine with electrical devices connected and the connected devices turned ‘ON’. 1. Turn off all electrical equipment and disconnect all from the generator. 2. 3. Allow the generator to run at no load for a few minutes to stabilize internal temperatures of the engine and generating set. Press the rocker ignition switch to the ‘O’ off position. 4. Turn the fuel valve to the ‘OFF’ position. Pg.
GENERAL MAINTENANCE ! NOTE: It’s the operator’s responsibility to complete all scheduled maintenance in a timely manner. Correct any issue before operating the generating set. Always follow the inspection and maintenance recommendations and schedules in this manual. • Before servicing the generator, stop the generator, disconnect all electric devices and battery (if equipped) and allow the generator to cool down. ! DANGER: Accidental starts can cause severe injury or death.
Each time before use Engine oil Inspection Air filter Spark plug Replacement 50 Hours or every three months (Note 2) 100 Hours or every six months (Note 2) (Note 3) Inspection and adjustment Replacement Spark arrester (Note 1) Inspection and adjustment Idle speed Inspection and adjustment 300 hours or every year (Note 4) Replacement Inspection 10 Hours or the first month (Note 2) Valve clearance (Note 4) (Note 4) ! NOTE 1: Applicable types (if available).
ENGINE OIL ! CAUTION: Oil level check - Reinstall dipstick into tube; rest on oil fill neck, DO NOT thread cap into tube. ! WARNING: The engine is not filled with oil at the factory. Any operation before it has been properly filled with the recommended type and amount of oil may result in engine damage and void your warranty. 1. ENGINE OIL - SAE30 is recommended for general, alltemperature use.
4. 5. 6. 7. 8. Remove the oil drain plug and allow the oil to drain completely. Replace and fully tighten the drain plug. Add recommended oil to the upper limit. Reinstall and fully tighten the dipstick. Dispose of used oil at an approved waste management facility. AIR FILTER ! WARNING: DO NOT run the engine without the air filter, as serious damage can result. 1. AIR FILTER - Loosen the filter fix clamp and remove the cover of the air filter. 2. 3. 4. 5. 6. Remove the foam filter element.
SPARK PLUG ! WARNING: Only use recommended spark plug or equivalent. DO NOT use spark plugs that have improper heat range. 1. 2. 3. 4. 5. SPARK PLUG - Clean any dirt from the spark plug cap and spark plug base. Remove the spark plug cap. Using socket wrench to loosen and remove the spark plug. Inspect the spark plug and spark plug washer, if it’s damaged or worn, replace with a new one. Clean the spark plug with wire brush before replacing. Check spark plug gap.
SPARK ARRESTER 1. 2. 3. 4. 5. 6. 7. SPARK ARRESTER - Fitted to exhaust outlet pipe Allow the engine to cool completely before servicing the spark arrester. Loosen the clamp that holds the spark arrester to the exhaust outlet. Remove the spark arrester from the outlet. Carefully clean the carbon deposits from the spark arrester screen with a wire brush. Replace the spark arrester if it is damaged. Reinstall the spark arrester to the exhaust outlet and attach with the clamp.
TROUBLE SHOOTING ! WARNING: Turn off the generator before starting maintenance work. FAULT POSSIBLE CAUSE 1. Engine switch set to ‘OFF’ 2. No fuel 3. Inadequate engine oil 4. No ignition. Engine wont start Generator has no output 1. No power. 2. Inadequate power cord or extension cord REMEDY 1. Turn engine switch to the ‘ON’ position 2. Fill tank as per instructions 3. Check oil level. This engine is equipped with a low oil sensor.
in the Maintenance section. Iii. Drain all fuel completely from the fuel hose and carburetor to prevent gum from forming. Iv. Turn off the fuel supply at the fuel valve. V. Change the oil. Vi. Remove the spark plug and pour about 15 ml of oil into the cylinder. Crank the engine slowly to distribute the oil and lubricate the cylinder. Vii. Reattach the spark plug. Viii. Store the unit in a clean, dry area out of direct sunlight. 3.
