Safe Operation Practices • Set-Up • Operation • Maintenance • Service • Troubleshooting • Warranty Operator’s Manual Hydrostatic Garden Tractor — GT1554 WARNING READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL BEFORE ATTEMPTING TO OPERATE THIS MACHINE. FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY. CUB CADET LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019 Printed In USA Form No.
1 To The Owner Thank You Thank you for purchasing a Lawn Tractor manufactured by Cub Cadet LLC. It was carefully engineered to provide excellent performance when properly operated and maintained. Please read this entire manual prior to operating the equipment. It instructs you how to safely and easily set up, operate and maintain your machine. Please be sure that you, and any other persons who will operate the machine, carefully follow the recommended safety practices at all times.
Important Safe Operation Practices 2 WARNING: This symbol points out important safety instructions which, if not followed, could endanger the personal safety and/or property of yourself and others. Read and follow all instructions in this manual before attempting to operate this machine. Failure to comply with these instructions may result in personal injury. When you see this symbol.
12. A missing or damaged discharge cover can cause blade contact or thrown object injuries. 13. Stop the blade(s) when crossing gravel drives, walks, or roads and while not cutting grass. 14. Watch for traffic when operating near or crossing roadways. This machine is not intended for use on any public roadway. 15. Do not operate the machine while under the influence of alcohol or drugs. 16. Mow only in daylight or good artificial light. 17. Never carry passengers. 18.
Children a. Use only an approved gasoline container. 1. b. Never fill containers inside a vehicle or on a truck or trailer bed with a plastic liner. Always place containers on the ground away from your vehicle before filling. c. When practical, remove gas-powered equipment from the truck or trailer and refuel it on the ground. If this is not possible, then refuel such equipment on a trailer with a portable container, rather than from a gasoline dispenser nozzle. d.
5. 6. Check the blade(s) and engine mounting bolts at frequent intervals for proper tightness. Also, visually inspect blade(s) for damage (e.g., excessive wear, bent, cracked). Replace the blade(s) with the original equipment manufacturer’s (O.E.M.) blade(s) only, listed in this manual. “Use of parts which do not meet the original equipment specifications may lead to improper performance and compromise safety!” Mower blades are sharp.
or a corner of a building... a 1 5 ° slop or a fence post ine (r ep r e s e nts dl o n g d otte l Fold a Sight and hold this level with a vertical tree... 15° Use this page as a guide to determine slopes where you may not operate safely. e) WARNING: Do not operate your lawn mower on such slopes. Do not mow on inclines with a slope in excess of 15 degrees (a rise of approximately 2-1/2 feet every 10 feet). A riding mower could overturn and cause serious injury.
3 Assembly & Set-Up Contents of Crate • One Garden Tractor • One Oil Drain Tube • One Deck Wash Hose Coupler • One Garden Tractor Operator’s Manual • One Kohler Engine Operator’s Manual • One Product Registration Card Tractor Set-Up Shipping Brace Removal Warning! Make sure the garden tractor’s engine Moving The Tractor Manually Your tractor’s transmission is equipped with a hydrostatic relief valve for occasions when it is necessary to move the tractor manually.
Attaching the Negative Battery Cable Setting the Deck Gauge Wheels and Roller NOTE: The positive battery terminal is marked Pos. (+). The negative battery terminal is marked Neg. (–). Move the tractor on a firm and level surface, preferably pavement, and proceed as follows The positive cable (heavy red wire) is secured to the positive battery terminal (+) with a hex bolt and hex nut at the factory. 1.
Adjusting the Seat To adjust the position of the seat forward or backward, move the seat adjustment lever to the left and slide the seat forward or rearward. See Fig. 3-5. Warning! Before operating the tractor, make sure the seat is engaged in the seat-stop. Engage the parking brake. Stand behind the machine and pull back on seat until it clicks into place. Figure 3-5 Gas and Oil The fuel tank is located under the fender and has a capacity of three and-a-half gallons.
4 Controls and Features Systems Indicator Monitor Ignition Switch Module PTO (Blade Engage) Knob Throttle Control Brake Pedal Choke Control Drive Pedal Parking Brake Lever Cruise Control Lever Deck Lift Lever Seat Adjustment Lever Fuel Tank Cap Cup Holder Figure 4-1 Lawn Tractor controls and features are illustrated in Fig 4-1 and described on the following pages.
Throttle Control Lever The throttle control lever is located on the left side of the tractor’s dash panel. This lever controls the speed of the engine. When set in a given position, the throttle will maintain a uniform engine speed. Ignition Switch Module Fast NOTE: When operating the tractor with the cutting deck engaged, be certain that the throttle lever is always in the FAST (rabbit) position.
Systems Indicator Monitor / Hour Meter Brake If the Brake light illuminates when attempting to start the tractor’s engine, depress the brake pedal. PTO (Blade Engage) If the PTO light illuminates when attempting to start the tractor’s engine, move PTO lever into the disengaged (OFF) position. Oil 42.
Parking Brake Lever Cruise Control Lever Located in the center of the tractor’s dash panel below the steering wheel, the parking brake lever is used to engage the parking brake. Refer to the Operation section of this manual for detailed instructions regarding the parking brake. The cruise control lever is located in the center of the tractor’s dash panel. Engaging the cruise control allows the tractor to remain at a constant ground speed without applying pressure to the drive pedal.
5 Operation Starting the Engine Warning! Do not operate the tractor if the TO AVOID SERIOUS INJURY OR DEATH • • • • • • • • • GO UP AND DOWN SLOPES, NOT ACROSS. AVOID SUDDEN TURNS. DO NOT OPERATE THE UNIT WHERE IT COULD SLIP OR TIP. IF MACHINE STOPS GOING UPHILL, STOP BLADE(S) AND BACK DOWNHILL SLOWLY. KEEP SAFETY DEVICES (GUARDS, SHIELDS, AND SWITCHES, ETC.) IN PLACE AND WORKING. REMOVE OBJECTS THAT COULD BE THROWN BY THE BLADE(S). KNOW LOCATION AND FUNCTION OF ALL CONTROLS.
Reverse Caution Mode Driving The Tractor WARNING! Avoid sudden starts, excessive speed The REVERSE CAUTION MODE position of the key switch module allows the tractor to be operated in reverse with the blades (PTO) engaged. and sudden stops. NOTE: Mowing in reverse is not recommended. Warning! Use extreme caution while operating the tractor in the REVERSE CAUTION MODE. Always look down and behind before and while backing. Do not operate the tractor when children or others are around.
Driving On Slopes Setting The Cruise Control warning! Never engage the cruise control lever Refer to the SLOPE GAUGE on page 7 to help determine slopes where you may operate the tractor safely. while traveling in reverse. WARNING! Do not mow on inclines with a slope in excess of 15 degrees (a rise of approximately 2-1/2 feet every 10 feet). The tractor could overturn and cause serious injury. To set the cruise control: 1.
Engaging the PTO Mowing Warning! To help avoid blade contact or a Engaging the PTO transfers power to the cutting deck or other (separately available) attachments. To engage the PTO: 1. Move the throttle control lever to the FAST (rabbit) position. 2. Pull the PTO/Blade Engage knob outward into the engaged (ON) position. See Fig. 5-3.
6 Maintenance & Adjustments Maintenance Warning! Before performing any maintenance or repairs, disengage PTO, set parking brake, stop engine and remove key to prevent unintended starting. Engine Refer to the Kohler Owner’s Manual for all engine maintenance procedures and instructions. NOTE: Maintenance, repair, or replacement of the emission control devices and systems which are being done at owner’s expense may be performed by any engine repair establishment or individual.
Cleaning the Tractor 7. Any fuel or oil spilled on the machine should be wiped off promptly. Do NOT allow debris to accumulate around the cooling fins of the engine, the transmission’s cooling fan or on any other part of the machine, especially the belts and pulleys. Remain in the operator’s position with the cutting deck engaged for a minimum of two minutes, allowing the underside of the cutting deck to thoroughly rinse. 8. Move the tractor’s PTO (Blade Engage) into the OFF position. 9.
Adjustments Pivot Points & Linkage Lubricate all the pivot points on the drive system, parking brake and lift linkage at least once a season with light oil. WARNING! Shut the engine off, remove the ignition key and engage the parking brake before making adjustments. Protect your hands by using heavy gloves when handling the blades. Deck Wheels Each of the tractor deck’s front gauge wheels is equipped with a grease fitting. Lubricate with a No.
Leveling the Deck (Side to Side) Steering Adjustment If the cutting deck appears to be mowing unevenly, a side to side adjustment can be performed. Adjust if necessary as follows: If the tractor turns tighter in one direction than the other, or if the ball joints are being replaced due to damage or wear, the steering drag links may need to be adjusted. 1.
Maintenance Schedule Before Each use Check Air Filter for Dirty, Loose or Damaged Parts Every 25 Hours Every 50 Hours P P P Replace Air Filter Element P Change Engine Oil and Replace Oil Filter P P P P P Lube Front Axles and Rims Clean Engine Cooling Fins Lube Front Deck Wheels Lube Deck Spindles Lube Pedal Pivot Points Check Spark Plug Condition & Gap Replace Fuel Filter Prior to Storing P P Clean and Re-oil Air Filter’s Foam Precleaner Clean Battery Terminals Every 100 Hours P Clean Hood/
Maintenance Log Please keep a record of the maintenance performed on your tractor.
7 Service Cutting Deck Removal 8. To remove the cutting deck, proceed as follows: 1. Place the PTO/Blade Engage knob in the disengaged (OFF) position and engage the parking brake. 2. Lower the deck by moving the deck lift lever into the bottom notch on the right fender. 3. Remove the deck belt from around the tractor’s electric PTO clutch. 4. Looking at the cutting deck from the left side of the tractor, locate the deck support pin on the rear left side of the deck. 5.
Cutting Blades 4. WARNING! Shut the engine off and remove ignition key before removing the cutting blade(s) for sharpening or replacement. Protect your hands by using heavy gloves when grasping the blade caution: If the cutting edge of the blade has WARNING! Periodically inspect the blade and/or previously been sharpened, or if any metal separation is present, replace the blades with new ones. spindle for cracks or damage, especially after you’ve struck a foreign object.
Battery Fuse California Proposition 65 Warning: Battery posts, terminals, and related accessories contain lead and lead compounds, chemicals known to the State of California to cause cancer and reproductive harm. Wash hands after handling. caution: If removing the battery, disconnect the NEGATIVE (Black) wire from it’s terminal first, followed by the POSITIVE (Red) wire. When reinstalling the battery, always connect the POSITIVE (Red) wire its terminal first, followed by the NEGATIVE (Black) wire.
Changing the Deck Belt Note: If there is too much tension on the belt for it to be easily removed from the electric PTO clutch, carefully insert a 3⁄8-inch drive ratchet wrench (set to loosen) into the square hole found in the left-hand deck idler bracket and pivot it toward the tractor’s right side to relieve tension on the belt. See Fig. 7-6. WARNING! Shut the engine off and remove ignition key before removing the cutting blade(s) for sharpening or replacement.
Figure 7-7 Section 7 — Service 29
8 Troubleshooting Problem Engine fails to start Remedy 1. PTO/Blade Engage knob engaged. 1. Place knob in disengaged (OFF) position. 2. Parking brake not engaged. 2. Engage parking brake. 3. Spark plug wire(s) disconnected. 3. Connect wire(s) to spark plug(s). 4. Throttle control lever not in correct starting position. 4. Place throttle lever to FAST position. 5. Choke not activated 5. Pull the CHOKE control outward. 6. Fuel tank empty, or stale fuel. 6.
9 Replacement Parts Component Part Number and Description 759-3336 Spark Plug (Champion RC12YC) KH-32-883-03-S1 Kohler Air Filter Element and Precleaner KH-25-050-25-S Kohler Oil Filter KH-25-050-22-S1 Kohler Fuel Filter 954-0642 Drive Belt (Mowing Deck) 942-0677B 2-in-1 Deck Blade 918-0671B Deck Spindle Phone (800) 965-4CUB to order replacement parts or a complete Parts Manual (have your full model number and serial number ready).
Component Part Number and Description 734-04155 Deck Wheel (Front) 925-1707D Battery 951-3111 Fuel Tank Cap 746-04120 Choke Control/Cable 746-04352 Throttle Control/Cable 725-2054 Ignition Key 631-04070A Discharge Chute Assembly Phone (800) 965-4CUB to order replacement parts or a complete Parts Manual (have your full model number and serial number ready). Parts Manual downloads are also available free of charge at www.cubcadet.
10 Attachments & Accessories The following attachments and accessories are compatible for Cub Cadet GT1554. See your Cub Cadet dealer or the retailer from which you purchased your tractor for information regarding price and availability.
Notes 34 11
CALIFORNIA EMISSION CONTROL WARRANTY STATEMENT YOUR WARRANTY RIGHTS AND OBLIGATIONS The California Air Resources Board and MTD Consumer Group Inc are pleased to explain the evaporative emission control system warranty on your 2007 lawn mower. In California, new lawn mower must be designed, built and equipped to meet the State’s stringent anti-smog standards.
CUB CADET LLC MANUFACTURER’S LIMITED WARRANTY FOR SERIES 1000 & SERIES 1500 TRACTORS IMPORTANT: To obtain warranty coverage owner must present an original proof of purchase and applicable maintenance records to the servicing dealer. Please see the operator’s manual for information on required maintenance and service intervals. In the U.S.A.: Check your Yellow Pages, or contact Cub Cadet LLC at P.O. Box 361131, Cleveland, Ohio 44136-0019, call 1-877-282- 8684 or log on to our website at www.cubcadet.com.
Medidas importantes de seguridad • Configuración • Funcionamiento • Mantenimiento • Servicio • Solución de problemas • Garantía Manual del Operador Tractor Corta Césped Hidrostático — GT1554 ADVERTENCIA LEA Y SIGA TODAS LAS INSTRUCCIONES DE ESTE MANUAL ANTES DE PONER EN FUNCIONAMIENTO ESTA MÁQUINA. SI NO RESPETA ESTAS INSTRUCCIONES PUEDE PROVOCAR LESIONES PERSONALES. CUB CADET LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019 Impreso en Estados Unidos de América Formulario No.
1 Al propietario Gracias Gracias por comprar un tractor corta césped fabricado por Cub Cadet LLC. El mismo ha sido diseñado cuidadosamente para brindar excelente rendimiento si se lo opera y mantiene correctamente. Por favor lea todo este manual antes de operar el equipo. Le indica cómo configurar, operar y mantener la máquina con seguridad y fácilmente.
2 Medidas importantes de seguridad ADVERTENCIA: La presencia de este símbolo indica que se trata de instrucciones importantes de seguridad que se deben respetar para evitar poner en peligro su seguridad personal y/o material y la de otras personas. Lea y siga todas las instrucciones de este manual antes de poner en funcionamiento esta máquina. Si no respeta estas instrucciones puede provocar lesiones personales. Cuando vea este símbolo.
12. 13. 14. 15. 16. 17. 18. 19. 20. 21. 22. 23. 24. 25. 26. 27. 28. 29. 36 Una cubierta de descarga faltante o dañada puede provocar el contacto con la cuchilla o lesiones por objetos arrojados. Detenga la(s) cuchilla(s) cuando atraviese senderos, sendas o caminos de grava y cuando no esté cortando el césped. Vigile el tránsito vehicular cuando esté operando cerca de o en cruces de caminos. Esta máquina no debe utilizarse en la vía pública.
Niños 1. 2. a. b. Utilice sólo los recipientes para gasolina autorizados. Nunca llene los recipientes en el interior de un vehículo o camión o caja de remolque con recubrimiento plástico. Coloque siempre los recipientes en el piso y lejos del vehículo antes de realizar la carga. c. Cuando sea factible, retire el equipo a gasolina del camión o remolque y llénelo en el suelo.
5. 6. 7. 8. 9. 10. 11. 12. 13. 14. Revise los pernos de montaje de la(s) cuchilla(s) y del motor a intervalos frecuentes para verificar que estén bien apretados. Además, inspeccione visualmente la(s) cuchilla(s) en busca de daños (por ejemplo, desgaste excesivo, abolladuras, rajaduras, etc.). Reemplace la(s) cuchilla(s) únicamente con las cuchillas de fabricantes de equipos originales (O.E.M.) listadas en este manual.
Mire y mantenga este nivel con un árbol vertical o la esquina de un edificio... p °) endi e n t e d e 15 o el poste de una empalizada e pun t o s ( r epre s e n t a una ad Doble p o r l a líne 15° Use esta página como guía para determinar en qué pendientes no puede operar el tractor de manera segura. ADVERTENCIA: No opere la cortadora de césped en dichas pendientes. No corte en inclinaciones mayores de 15 grados (elevación aproximada de 2 1/2 pies por cada 10 pies).
3 Montaje y Configuración Contenido del cajón • Un tractor corta césped • Un tubo de drenaje de aceite • Un acoplador de manguera para lavado de plataforma • Un Manual del operador del tractor corta césped • Un Manual del operador del motor Kohler • Una tarjeta para registrar el producto Montaje del tractor Extracción de la traba de seguridad utilizada en el envío ¡Advertencia! Asegúrese de que el motor del Movimiento manual del tractor La transmisión de su tractor viene equipada con una válv
Instalación del cable negativo de la batería Ajuste de las ruedas de calibración de la plataforma NOTA: El borne positivo de la batería está marcado como Pos (+). El borne negativo de la batería está marcado como Neg (-). Mueva el tractor a una superficie firme y nivelada, preferentemente sobre el pavimento, y realice lo siguiente.
Ajuste del asiento Para ajustar el asiento hacia adelante o hacia atrás, deslice la palanca de ajuste del asiento hacia la izquierda y deslice el asiento hacia delante o hacia atrás. Vea la Fig. 3-5. ¡Advertencia! Antes de operar el tractor, asegúrese de que el asiento esté enganchado en el tope del asiento. Coloque el freno de mano. Párese detrás de la máquina y tire del asiento hacia atrás hasta que encaje en su lugar haciendo clic.
4 Controles y Características Monitor del indicador de sistemas Módulo del interruptor de encendido Perilla de potencia de arranque (PTO) (enganche de cuchilla) Control del regulador Pedal de freno Control del obturador Palanca de freno de mano Palanca de control de crucero Palanca de ajuste del asiento Pedal de la transmisión Palanca de elevación de la plataforma Tapón del depósito de combustible Portacubeta Figura 4-1 Los controles y características del tractor corta césped se ilustran en la F
Palanca de control del regulador Módulo del interruptor de encendido Rápido La palanca de control del regulador está ubicada del lado izquierdo del panel de instrumentos del tractor. Esta palanca controla la velocidad del motor. Cuando se lo coloca en una posición determinada, el regulador mantiene una velocidad de motor uniforme.
Monitor indicador de sistemas/ medidor horario Freno Si se ilumina la luz de freno al intentar encender el motor del tractor, presione el pedal del freno. Potencia de arranque (PTO) (enganche de cuchilla) BAT. ACEITE Si la luz de la potencia de arranque (PTO) se ilumina al intentar encender el motor del tractor, presione la perilla de potencia de arranque (PTO) en la posición desenganchada (OFF). Aceite 42.
Palanca de freno de mano Palanca de control de crucero La palanca de freno de mano, ubicada en el centro del tablero de control del tractor, debajo del volante, se utiliza para enganchar el freno de mano. Consulte la sección Funcionamiento de este manual para ver instrucciones detalladas sobre el freno de mano. La palanca de control de crucero está ubicada en el centro del tablero de instrumentos del tractor.
5 Funcionamiento ADVERTENCIA Encendido del motor ¡Advertencia! No opere el tractor si el sistema PARA EVITAR LESIONES PERSONALES GRAVES O LA MUERTE • EN LAS PENDIENTES CONDUZCA HACIA ARRIBA Y HACIA ABAJO, NO DE FORMA TRANSVERSAL. • EVITE MANIOBRAS DE GIRO BRUSCAS. • NO OPERE LA UNIDAD EN ÁREAS DONDE PUEDE DERRAPAR O TROPEZAR. • SI LA MÁQUINA SE DETIENE AL DESPLAZARSE CUESTA ARRIBA, DETENGA LA(S) CUCHILLA(S) Y CONDUZCA MARCHA ATRÁS, CUESTA ABAJO, LENTAMENTE.
Modo de precaución en marcha atrás Conducción del tractor La posición MODO DE PRECAUCIÓN EN MARCHA ATRÁS del módulo del interruptor de llave permite operar el tractor en marcha atrás con las cuchillas (toma de fuerza - PTO) enganchadas. NOTA: No se recomienda cortar el césped en marcha atrás. ¡Advertencia! Tenga mucho cuidado cuando opere el tractor en MODO DE PRECAUCIÓN EN MARCHA ATRÁS. Mire siempre hacia abajo y hacia atrás antes y mientras opera marcha atrás.
Operación en pendientes Activación del control de crucero ¡advertencia! Nunca enganche la palanca de Consulte la sección INDICADOR DE PENDIENTE en la página 7 para determinar en qué pendientes puede operar el tractor de manera segura. control de crucero mientras se desplaza en marcha atrás. ¡ADVERTENCIA! No corte en inclinaciones mayores de 15 grados (elevación aproximada de 2 1/2 pies por cada 10 pies). El tractor podría voltearse y causar lesiones severas.
Conexión de potencia de arranque (PTO) Al conectar la potencia de arranque (PTO) se suministra alimentación a la plataforma de corte o a otros accesorios (disponibles por separado). Para conectar la PTO: 1. Mueva la palanca de control del regulador a la posición FAST (VELOCIDAD RÁPIDA, representada por una liebre). 2. Tire de la perilla de la potencia de arranque (PTO) (enganche de cuchilla) hacia afuera en la posición ON (conectada). Vea la Fig. 5-3.
6 Mantenimiento y Ajustes Mantenimiento 4. ¡Advertencia! Antes de realizar tareas de mantenimiento o reparaciones, desconecte la potencia de arranque (PTO), coloque el freno de mano, apague el motor y retire la llave, para evitar que alguien encienda accidentalmente el motor. Motor 5. Consulte las instrucciones y procedimientos de mantenimiento del motor en el Manual del Propietario/Operador Kohler.
Limpieza del tractor 8. Si se derrama combustible o aceite sobre la máquina, debe limpiarse de inmediato. NO permita que se acumulen desechos alrededor de las aletas de refrigeración del motor, el ventilador de refrigeración de la transmisión ni en ninguna otra parte de la máquina, especialmente las correas y poleas. Permanezca en la posición del operador con la plataforma de corte enganchada durante dos minutos como mínimo, permitiendo que el lado inferior de la plataforma de corte se lave a fondo. 9.
Puntos de pivote y varillaje Lubrique todos los puntos de pivote del sistema de impulsión, el freno de mano y el varillaje de elevación al menos una vez por temporada con aceite ligero. Ajustes ¡ADVERTENCIA! Apague el motor, retire la llave Cada una de las ruedas de calibración frontales de la plataforma del tractor viene equipada con un accesorio de engrasado. Lubrique con una grasa multiuso No. 2 aplicada con una pistola de engrase cada 25 horas de funcionamiento del tractor.
Nivelación de la plataforma (lado a lado) Ajuste del volante Si la plataforma de corte estuviera realizando el corte de césped de forma despareja, puede realizarse un ajuste lado a lado. De ser necesario, realice un ajuste de la siguiente manera: 1. Con el tractor estacionado sobre una superficie firme y nivelada, coloque la palanca de elevación de la plataforma en la muesca superior (posición más alta) y rote ambas cuchillas para que se sitúen de forma perpendicular al tractor. 2.
Calendario de mantenimiento Antes de cada uso Controle el filtro de aire para ver si hay piezas sucias, sueltas o dañadas Cada 25 horas Cada 50 horas P P P Reemplace el elemento del filtro de aire Cambie el aceite del motor y reemplace el filtro de aceite P P P P P P Lubrique los ejes frontales y las llantas Limpie las aletas de refrigeración del motor Lubrique las ruedas delanteras de la plataforma Lubrique los husillos de la plataforma Lubrique los puntos de pivote del pedal Inspeccione la condici
Registro de mantenimiento Lleve un registro del mantenimiento realizado a su tractor.
7 Servicio Extracción de la plataforma de corte 8. Para extraer la plataforma de corte, proceda de la siguiente manera: 1. Coloque la perilla de la potencia de arranque (PTO) (enganche de cuchilla) en la posición OFF (desconectada) y coloque el freno de mano. 2. Baje la plataforma colocando la palanca de elevación de la plataforma dentro de la muesca inferior en el guardabarros derecho. 3. Extraiga la correa de la plataforma de alrededor del embrague de la potencia de arranque eléctrica del tractor.
Cuchillas de corte 4. ¡ADVERTENCIA! Apague el motor y extraiga la llave de contacto antes de retirar las cuchillas de corte para afilado o reemplazo. Proteja sus manos utilizando guantes reforzados cuando maneje las cuchillas. precaución: Si el borde de corte de la cuchilla ¡ADVERTENCIA! Inspeccione periódicamente la ha sido afilado previamente o si existe una separación de metal, reemplace las cuchillas por otras nuevas.
Batería Advertencia Proposición 65 de California: Los bornes de la batería y los accesorios afines contienen plomo y compuestos de plomo, sustancias químicas que según lo establecido por el Estado de California causan cáncer y daños en el sistema reproductivo. Lávese las manos después de estar en contacto con estos componentes. precaución: Si extrae la batería, desconecte primero el cable NEGATIVO (negro) de su borne y a continuación el cable POSITIVO (rojo).
Cambio de la correa de la plataforma Nota: Si hay demasiada tensión sobre la correa y esto impide la extracción de la misma fácilmente del embrague de la potencia de arranque eléctrica, Inserte una llave de trinquete de 3/8” (configurada para aflojar) dentro del orificio cuadrado que se encuentra en la ménsula intermedia, del lado izquierdo de la superficie de la plataforma. Vea la Fig. 7-6.
Figura 7-7 Sección 7 — Servicio 29
8 Solución de Problemas Problema El motor no arranca Causa 1. Perilla de potencia de arranque (PTO) (enganche de cuchilla) conectada. 2. No está colocado el freno de mano. 3. Se ha desconectado el cable de la bujía. 4. La palanca de control del regulador no está en la posición de arranque correcta. 5. No se ha activado el cebador 6. El depósito de combustible está vacío o el combustible se ha echado a perder. 7. La línea del combustible está bloqueada. 8. La bujía no funciona correctamente. 9.
9 Piezas de reemplazo Componente Número de pieza y Descripción 759-3336 Bujía (Champion RC12YC) KH-32-883-03-S1 Depurador y elemento de filtro de aire Kohler KH-25-050-25-S Filtro de aceite Kohler KH-25-050-22-S1 Filtro de combustible Kohler 954-0642 Correa de transmisión (plataforma de corte) 942-0677B Cuchilla de plataforma 918-04126A Husillo de plataforma Llame por teléfono al (800) 965-4CUB para solicitar piezas de reemplazo o un Manual de Piezas de Repuesto completo (tenga el número de mod
Componente Número de pieza y Descripción 734-04155 Rueda de plataforma (delantera) 925-1707D Batería 951-3124B Tapón del depósito de combustible 746-04120 Control/cable del cebador 746-04352 Control/Cable del regulador 725-2054 Llave de encendido 631-04070A Conjunto de canal de descarga Llame por teléfono al (800) 965-4CUB para solicitar piezas de reemplazo o un Manual de Piezas de Repuesto completo (tenga el número de modelo y número de serie de su tractor a mano). En www.cubcadet.
10 Aditamentos y Accesorios Los siguientes aditamentos y accesorios son compatibles con la unidad Cub Cadet GT1554. Consulte con su distribuidor Cub Cadet o con el representante al cual le ha comprado el tractor para obtener más información con respecto a precios y disponibilidad.
Notas 34 11
DECLARACIÓN DE GARANTÍA DE CONTROL DE EMISIONES DE CALIFORNIA DERECHOS Y OBLIGACIONES DE SU GARANTÍA El Departamento de los Recursos de Aire de California y MTD Consumer Group Inc, se complacen en explicar la garantía del sistema de control de emisiones por evaporación de su cortadora de césped 2007. En California, las nuevas máquinas para cortar césped se deben diseñar, construir y equipar de modo de cumplir con las rigurosas normas contra la polución del estado.
GARANTÍA LIMITADA DEL FABRICANTE CUB CADET LLC PARA TRACTORES DE SERIE 1000 Y SERIE 1500 IMPORTANTE: Para obtener cobertura de garantía, el propietario debe presentar una evidencia original de la compra y los registros de mantenimiento correspondientes al centro de servicio técnico autorizado del distribuidor. Consulte el manual del operador para obtener información sobre los intervalos de mantenimiento y servicio requeridos.
