MP3 Player User's Guide 页码，1/13 Portable MP3 Player User's Guide Introduction Installing the MP3 Player Transfer data to and from the MP3 Player Listening to your WMA/MP3 music MP3 Player Controls LCD Display Voice Recorder Hold Function Navigation Advanced Settings Upgrade the Firmware Removing the MP3 Player from your computer Trouble Shootings Specifications Safety Introducing the MP3 Player The MP3 Player incorporates a portable WMA/MP3 Player, Voice Recorder and Mass Storage Device.
MP3 Player User's Guide z z z z z z 页码，2/13 USB mass storage device. Integrated USB connector. Backlit display. Superb audio quality. No cable required. Requires 1 AAA / LR03 battery (supplied). System support: z Supports Windows Me/2000/XP. Note for Windows Me/2000/XP users: Installation of the MP3 Player drivers is required only if you wish to upgrade the firmware of the player. Note for Windows 2000 users: Windows Service Pack 3 must be installed before installing MP3 Player drivers.
MP3 Player User's Guide 页码，3/13 1. Make sure that the MP3 Player is turned off. 2. Remove the USB port cover & disconnect the earphone. 3. Plug the MP3 Player into the USB port of your computer. The built-in LCD displays "READY", indicating that the MP3 Player is in USB mode. The MP3 Player is then automatically recognized (in 'My Computer') as a removable media device. 4. Transfer files to or from the internal Flash RAM using Windows explorer. 5.
MP3 Player User's Guide 页码，4/13 Note: The MP3 player supports LRC format only. Note: If the lyric does not synchronize with the music, please download one better lyric file from internet and try again. Note: Make sure the MP3 music and LRC file is located in same directory and the filename is same. If not, the MP3 player can not recognize the lyric file. MP3 Player Controls A. USB Port Cover B. Headphone Socket C. A-B / Menu Button D. Skip Next / Fast Forward E. Skip Previous / Fast Rewind F.
MP3 Player User's Guide 页码，5/13 l. Battery Indicator m. Volume n. A-B Repeat Voice Recorder Record voice 1. Select Record in the LCD menu list to begin recording. 2. Press the Stop or Menu button to stop the recording and enter Voice mode. The voice recording will have been saved as a file named Vxxx.WAV in the Voice folder. Note that the LCD display will read MEMORY FULL when all available memory has been used. Playback voice This operation is similar to the playback of music. 1.
MP3 Player User's Guide 页码，6/13 Hold Function Use the Hold function to deactivate the MP3 Player controls (to avoid accidental activation). 1. To activate the Hold function, slide the Hold switch. 2. Slide the Hold switch back to turn off the Hold function. Note: The MP3 Player will turn off automatically if the key is hold when turning on the power. Navigation Use [Menu] button to enter Menu. 1 Select [Navigation] and press Menu button to enter navigation mode. 1.1 1.
MP3 Player User's Guide 页码，7/13 When a file is selected in navigation mode, press on Menu button, a sub-menu window will pop-up. To play this file, select Play. To erase, select Delete. z Note: The player supports music files & folders up to 500 maximally. z Note: The player supports folders up to 19 levels maximally. z Note: If the number of total music files (WMA/MP3/WMA format only) and/or folders exceeds 500, or the folder is more than 19 levels, some files/folders would be ignored.
MP3 Player User's Guide 页码，8/13 Adjust LCD Contrast To adjust the LCD contrast 1. In the settings menu, select Contrast. 2. Press the Skip buttons to adjust the contrast level. 3. Press the A-B/Menu button to go back to setting menu. Backlight To adjust the backlight 1. In the settings menu, select Back Light. 2. Press the Skip buttons to adjust the delay before the backlight is switched off. Note: Selecting "Disable" would turn off the backlight. Selecting "On" would always turn on the backlight.
MP3 Player User's Guide 页码，9/13 4. Press the Skip buttons to select "Rate". Press the A-B/Menu button repeatedly to cycle through the available Recording Sampling Frequencies. 5. Press the Skip buttons to select "Exit" and press the A-B/Menu button to exit the Record Setting menu. Note: A higher recording sampling frequency brings better recording quantity, but takes more memory space. Sampling Frequency 8000 Hz 11025 Hz 16000 Hz 22050 Hz 32000 Hz Maximum Recording Time per 128MB 8 hours 5.
MP3 Player User's Guide 页码，10/13 5. If you are sure you want to erase the listed file, press the Skip buttons to choose Yes. Then press the A-B/Menu button to confirm. 6. The file is erased. Another file will be listed on the screen and you will be asked again if you want to erase this file. 7. When you have finished erasing the file, the player will automatically exit to Erase Files screen. 8. Select Exit to exit to menu list.
MP3 Player User's Guide 页码，11/13 correct version to update, click on the Start button. 4. The firmware will be transferred to the player. Please wait until it has finished. 5. Click on the Close button to exit. Format Data Area option: When not selected (default): Updates the firmware only. If selected ( recommended): Updates the firmware and formats the storage space. To Format the MP3 Player 1. Connect the MP3 Player to the computer. 2.
MP3 Player User's Guide 页码，12/13 Refresh the firmware 1 On your computer run the Firmware Download utility go to: Start > Programs > SigmaTel MSCN Audio Player > Firmware Download 2 The utility will start to search the MP3 player. Please wait until the Firmware Download w appears. 3 Select "Format Data Area". 4 Click on the Start button to start. 5 The firmware will be transferred to the player. Please wait until it has finished. 6 Click on the Close button to exit.
MP3 Player User's Guide z z z z z z z z z z z z z z 页码，13/13 management) Interface { USB Power { 1 x AAA Battery { Battery continuous playing time: Up to 18 hours Equaliser { Normal, XBass, Rock, Jazz, Classical, Pop Display { 128 x 32 dots Dot-matrix LCD with backlight { ID3 Tag display Controls { Power On / Play / Pause { Stop / OFF { Skip Next { Skip Previous { A-B/Menu button { Volume + { Volume { Hold Switch Processor { 75 MIPS DSP Audio Playback { Windows Media Audio (WMA) { MPEG Audio
