Users Guide
Table Of Contents
- Revision History
- Table of Contents
- Regulatory and Safety Approvals
- Functional Description
- Network Link and Activity Indication
- Features
- Software and Hardware Features
- Virtualization Features
- VXLAN
- NVGRE/GRE/IP-in-IP/Geneve
- Stateless Offloads
- UDP Fragmentation Offload
- Stateless Transport Tunnel Offload
- Multiqueue Support for OS
- SR-IOV Configuration Support Matrix
- SR-IOV
- Network Partitioning (NPAR)
- RDMA over Converged Ethernet – RoCE
- Supported Combinations
- Installing the Hardware
- Software Packages and Installation
- Windows Driver Advanced Properties and Event Log Messages
- Teaming
- System-level Configuration
- ISCSI Boot
- VXLAN: Configuration and Use Case Examples
- SR-IOV: Configuration and Use Case Examples
- NPAR – Configuration and Use Case Example
- RoCE – Configuration and Use Case Examples
- DCBX – Data Center Bridging
Windows Driver Advanced Properties and Event Log MessagesNetXtreme-E User’s Manual
September 4, 2019 • NetXtreme-E-UG103 Page 41
0x001A Incompatible speed selection between Port 1 and Port
2. Reported link speeds are correct and might not
match Speed and Duplex setting.
0x001B Incompatible speed selection between Port 1 and Port
2. Link configuration became illegal.
0x001C Network controller configured for 25Gb full-duplex link.
0x0020 RDMA support initialization failed.
0x0021 Device's RDMA firmware is incompatible with this
driver.
0x0022 Doorbell BAR size is too small for RDMA.
0x0023 RDMA restart upon device reset failed.
0x0024 RDMA restart upon system power up failed
0x0025 RDMA startup failed. Not enough resources.
0x0026 RDMA not enabled in firmware.
0x0027 Start failed, a MAC address is not set.
0x0028 Transmit stall detected. TX flow control will be disabled
from now on.
Table 26: Event Log Messages (Cont.)
