System-level ConfigurationNetXtreme-E User’s Manual
September 4, 2019 • NetXtreme-E-UG103 Page 53
Table 32 and Table 33 show the link results with the Media Auto Detect feature enabled.
Table 32: Media Auto Detect for the BCM5730X and BCM5740X
Link Partner Link Training Setting
Link Partner Settings Media Auto Detect
Speed FEC No FEC Base-R FEC
10G No FEC Link Link with Base-R
Base-R No Link Link with Base-R
25G No FEC Link Link
Base-R No Link Link with Base-R
AN Disabled Link Link
Auto FEC Link Link with Base-R
Base-R Link with Base-R Link with Base-R
Table 33: Media Auto Detect for the BCM5741X
Link Partner Link Training Setting
Link Partner Settings Media Auto Detect
Speed FEC No FEC Base-R FEC RS-FEC
10G No FEC Link Link with Base-R No Link
Base-R No Link Link with Base-R No Link
RS No Link No Link Link with RS-FEC
25G No FEC Link No Link No Link
Base-R No Link Link with Base-R No Link
RS No Link No Link Link with RS-FEC
AN Disabled Link Link Link
Auto FEC Link Link with Base-R Link with RS-FEC
Base-R Link with Base-R Link with Base-R Link with RS-FEC
RS Link with RS Link with RS-FEC Link with RS-FEC
