ISCSI BootNetXtreme-E User’s Manual
September 4, 2019 • NetXtreme-E-UG103 Page 57
• Secondary DNS
• iSCSI Name (corresponds to the iSCSI initiator name to be used by the client system)
5.
Select ESC to return to the Main menu.
6. From the Main menu, select 1st Target Parameters.
7.
From the 1st Target Parameters screen, enable Connect to connect to the iSCSI target. Type values for
the following using the values used when configuring the iSCSI target:
• IP Address
•TCP Port
•Boot LUN
• iSCSI Name
8. Select ESC to return to the Main menu.
9. Select ESC and select Exit and Save Configuration.
10. Select F4 to save the MBA configuration.
Dynamic iSCSI Boot Configuration
In a dynamic configuration, specify that the system's IP address and target/initiator information are provided by
a DHCP server (see IPv4 and IPv6 configurations in “Configuring the DHCP Server to Support iSCSI Boot” on
page 60. For IPv4, with the exception of the initiator iSCSI name, any settings on the Initiator Parameters, 1st
Target Parameters, or 2nd Target Parameters screens are ignored and do not need to be cleared. For IPv6, with
the exception of the CHAP ID and Secret, any settings on the Initiator Parameters, 1st Target Parameters, or
2nd Target Parameters screens are ignored and do not need to be cleared. For information on configuration
options, see Table 35 on page 55.
Note: Enter the IP address. There is no error-checking performed against the IP address to check for
duplicates or incorrect segment/network assignment.
Note: For the initial setup, configuring a second target is not supported.
Note: When using a DHCP server, the DNS server entries are overwritten by the values provided by
the DHCP server. This occurs even if the locally provided values are valid and the DHCP server
provides no DNS server information. When the DHCP server provides no DNS server information,
both the primary and secondary DNS server values are set to 0.0.0.0. When the Windows OS takes
over, the Microsoft iSCSI initiator retrieves the iSCSI Initiator parameters and configures the
appropriate registries statically. It will overwrite whatever is configured. Since the DHCP daemon runs
in the Windows environment as a user process, all TCP/IP parameters have to be statically configured
before the stack comes up in the iSCSI Boot environment.
