Specification

15777LF
▲
15777LF
▲
With Escutcheon
▲
Designate proper nish sufx
Delta reserves the right (1) to make changes in specications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.deltafaucet.com for nish options and product availability.
DSP-L-15777LF Rev. A
LAVATORY FAUCET
Single Handle Deck Mount
55 E. 111th Street, Indianapolis, Indiana 46280
350 South Edgeware Road, St. Thomas, Ontario Canada N5P 4L1
© 2017 Masco Corporation of Indiana
1 7/8"
(48 mm)
Max. Desk
Thinkness
2 1/8"
(54 mm)
Dia.
1 5/8" (42 mm)
to
2 3/8" (61 mm)
1 1/4"
(32 mm)
Dia.
1 1/8"~1 1/2"
(29~38 mm)
Hole Size
3 1/2"
(89 mm)
4 7/8"
(124 mm)
5 5/8"
(142 mm)
Submitted Model No.:
Specic Features:
Mylan
TM
Collection
3 3/16"
(81 mm)
5 3/8"
(136 mm)
2 1/8"
(53 mm)
2 9/16"
(65 mm)
Min. 2 1/2" (64 mm)
Clearance to Back Splash
Recommended
4 5/16"
(110 mm)
6 13/16"
(173 mm)
9/16 - 24UNEF
30 1/4"
(768 mm)
STANDARD SPECIFICATIONS:
WARRANTY
COMPLIES WITH:
• ASME A112.18.1 / CSA B125.1
• ASME A112.18.2 / CSA B125.2
• EPA WaterSense
®
Indicates compliance to
ICC / ANSI A117.1
• Maximum low rate 1.2 gpm @ 60 psi, 4.5 L/min @ 414 kPa.
• Solid brass cast body.
• One or three hole mount (escutcheon optional, included).
• Polymer braided lexible supply hose with
9/16 - 24UNEF thread connection
• Control mechanism is replaceable cartridge with
ceramic plates.
• Models have drain with pop-up type itting with
plated lange and stopper.
• Lifetime limited warranty on parts (other than
electronic parts and batteries) and inishes; or,
for commercial users, for 5 years from the date
of purchase.
• 5 year limited warranty on electronic parts (other
than batteries); or for commercial users, for 1 year
from the date of purchase. No warranty is provided
on batteries
•
Veri ied compliant with 0.25% weighted
average Pb content regulations
