Connections Playback Settings Tips .
Contents Connections Playback Settings 7 8 8 9 9 9 12 13 13 16 18 21 Accessories Inserting the batteries Operating range of the remote control unit Features High quality sound High performance Easy operation Part names and functions Front panel Display Rear panel Remote control unit Front panel Display Rear panel Appendix Connecting a playback device Connecting a DVD player or Blu-ray Disc player Connecting a set-top box (Satellite tuner/cable TV) Connecting a video camcorder or game console Connec
Contents Connections Playback Playing an iPod Listening to music on an iPod iPod Browse Mode settings Performing repeat playback Performing random playback Playing a USB memory device Playing files stored on USB memory devices Listening to music on a Bluetooth device Pairing with a Bluetooth device Playing a Bluetooth device Pairing with the Pairing Mode Listening to FM/AM broadcasts Listening to FM/AM broadcasts Tuning in by entering the frequency (Direct Tune) Changing the tune mode (Tune Mode) Tuning
Contents Connections Playback AirPlay function Playing songs from your iPhone, iPod touch or iPad Playing iTunes music with this unit Selecting multiple speakers (devices) Perform iTunes playback operations with the remote control unit of this unit Spotify Connect function Playing Spotify music with this unit Convenience functions Performing repeat playback Performing random playback Registering to Favorites Playing back content added to the “Save to Favorite” Deleting content added to favorites Searchin
Contents Connections Playback Settings Settings Front panel Inputs Input Assign Source Rename Hide Sources Source Level Input Select Speakers Audyssey® Setup Procedure for speaker settings (Audyssey® Setup) Error messages Retrieving Audyssey® Setup settings Manual Setup Amp Assign Speaker Config.
Contents Connections Playback Display Rear panel Tips Appendix Tips 174 174 174 175 177 178 179 179 180 180 180 182 183 183 183 184 185 186 188 Network Information Connection Wi-Fi Setup Settings IP Control Friendly Name Diagnostics General Language ECO ZONE2 Setup Zone Rename Quick Sel.
Contents Connections Playback Settings Tips Thank you for purchasing this Denon product. To ensure proper operation, please read this owner’s manual carefully before using the product. After reading this manual, be sure to keep it for future reference. Accessories . . . . Check that the following parts are supplied with the product.
Connections Contents Playback Settings Inserting the batteries 1 Tips Appendix NOTE 0 To prevent damage or leakage of battery fluid: 0 Do not use a new battery together with an old one. 0 Do not use two different types of batteries. 0 Remove the batteries from the remote control unit if it will not be in use for long periods. 0 If the battery fluid should leak, carefully wipe the fluid off the inside of the battery compartment and insert new batteries.
Contents Connections Playback Settings Tips Appendix Features High quality sound High performance 0 With discrete circuit technology, the power amplifier provides 0 4K 60Hz input/output supported identical quality for all 7-channels (110 Watts x 7-channels) For optimum realism and stunning dynamic range, the power amplifier section features discrete power devices (not integrated circuitry).
Contents Connections Playback Settings 0 HDMI connections enable connection to various digital AV Tips Appendix 0 The device is equipped with a AirPlay® function in addition to devices (6 inputs, 1 output) network functions such as Internet radio etc. (v p. 97) / 6 1 Out . In . This unit is equipped with 6 HDMI inputs and 1 HDMI output enabling connection to various HDMI compatible devices such as Blu-ray Disc players, game consoles and HD video camcorders.
Contents Connections Playback Settings 0 Wireless connection with Bluetooth devices can be carried out Tips Appendix 0 Compatible with the “Denon Remote App”z for performing basic easily (v p.
Contents Connections Playback Settings 0 Multi-Room audio (v p. 110) GMAIN ZONEH Tips Appendix Easy operation GZONE2H 0 “Setup Assistant” provides easy-to-follow setup instructions First select the language when prompted. Then simply follow the instructions displayed on the TV screen to set up the speakers, network, etc. 0 Easy to use Graphical User Interface . This unit is equipped with a Graphical User Interface for improved operability.
Contents Connections Playback Settings Tips Appendix Part names and functions Front panel q w e r t y MASTER VOLUME SOURCE SELECT u ZONE2 ON/OFF i ZONE2 SOURCE o Q0 TUNER PRESET CH TUNE 1 CBL/SAT 2 DVD/Blu-ray 3 GAME Q1 BAND 4 Q2 MODE Q3 DIMMER Q4 STATUS ONLINE QUICK SELECT PHONES MOVIE MUSIC GAME PURE AUX - HDMI SETUP MIC 5V/1A SOUND MODE .
Contents qw Connections er Playback t Settings y MASTER VOLUME D Remote control sensor This receives signals from the remote control unit. (v p. 8) u i o Q0 TUNER PRESET CH ZONE 2 SOURCE 1 CBL/SAT TUNE 2 DVD/Blu-ray 3 GAME BAND 4 MODE DIMMER STATUS E Display This displays various pieces of information. (v p. 16) ONLINE QUICK SELECT PHONES MOVIE MUSIC GAME PURE SOUND MODE AUX - HDMI SETUP MIC F MASTER VOLUME knob This adjusts the volume level. (v p. 53) 5V/1A .
Contents Connections Playback Settings MASTER VOLUME Q1QQ 2 Q 3 4 TUNER PRESET CH ZONE 2 SOURCE 1 CBL/SAT TUNE 2 DVD/Blu-ray 3 GAME BAND 4 MODE DIMMER STATUS ONLINE NOTE QUICK SELECT PHONES MOVIE MUSIC GAME AUX - HDMI PURE . Q6 SETUP MIC To prevent hearing loss, do not raise the volume level excessively when using headphones. 5V/1A SOUND MODE Q5 P SOUND MODE buttons These select the sound mode. (v p.
Contents Connections Playback Settings Tips Appendix Display w e r A Input mode indicators These light according to the audio input mode settings of each input source. (v p. 156) i o Q1 Q2 G Circle indicator This is displayed when the input source is “Online Music” or “iPod/USB” when you are playing back music. D Audyssey® indicator This lights when “MultEQ®”, “Dynamic EQ” or “Dynamic Volume” has been set up. (v p.
Contents Connections Playback Settings Tips o . Q0 Q1 Q2 I MUTE indicator This blinks while the sound is muted. (v p. 53) J Information display The input source name, sound mode, setting values and other information are displayed here. K Input signal indicators The respective indicator will light corresponding to the input signal. (v p. 156) L ZONE2 indicator This lights up when ZONE2 (separate room) power is turned on. (v p.
Connections Contents Playback Settings Tips Appendix Rear panel q w AUDIO IN (ASSIGNABLE) e r t PRE OUT DIGITAL AUDIO IN NETWORK (ASSIGNABLE) y HDMI IN u HDMI (ASSIGNABLE) OUT VIDEO IN (ASSIGNABLE) CBL/SAT MEDIA SUBWOOFER CBL/SAT TV AUDIO MEDIA PLAYER PLAYER 1 2 1 1 1 CBL/SAT 2 1 CBL/SAT DVD/ 2 Blu-ray MEDIA 3 PLAYER 4 Blu-ray 5 GAME MONITOR (4K) (4K) ARC MEDIA 2 PLAYER MONITOR 2 ANTENNA AM COAXIAL OPTICAL VIDEO OUT FM 75Ȑ FRONT FRONT CENTER SURROUND SU
Connections Contents q we r t AUDIO IN (ASSIGNABLE) PRE OUT DIGITAL AUDIO IN y HDMI IN NETWORK (ASSIGNABLE) Playback u HDMI (ASSIGNABLE) OUT 2 1 1 VIDEO IN 1 CBL/SAT 2 1 CBL/SAT DVD/ 2 Blu-ray MEDIA 3 PLAYER 4 Blu-ray 5 GAME MONITOR (4K) (4K) ARC MEDIA 2 PLAYER MONITOR 2 ANTENNA AM COAXIAL OPTICAL VIDEO 75Ȑ FRONT CENTER SURROUND SURROUND SURROUND BACK SURROUND BACK C PRE OUT connectors Used to connect a subwoofer with a built-in amplifier. (v p.
Contents AUDIO IN (ASSIGNABLE) PRE OUT Connections DIGITAL AUDIO IN (ASSIGNABLE) HDMI IN NETWORK Playback HDMI (ASSIGNABLE) OUT 2 1 1 Tips VIDEO IN (ASSIGNABLE) CBL/SAT MEDIA SUBWOOFER CBL/SAT TV AUDIO MEDIA PLAYER PLAYER 1 Settings 1 CBL/SAT 2 1 CBL/SAT DVD/ 2 Blu-ray MEDIA 3 PLAYER 4 Blu-ray 5 GAME MONITOR (4K) (4K) ARC MEDIA 2 PLAYER MONITOR 2 ANTENNA AM COAXIAL OPTICAL VIDEO OUT FM 75Ȑ FRONT FRONT CENTER SURROUND SURROUND SURROUND BACK SURROUND BACK ASSIGN
Contents Connections Playback Settings Tips Appendix Remote control unit q w e r t y u i o ZONE 2 ZO A ZONE2 ON/OFF button (ZONE2 X) This turns the power of ZONE2 (separate room) on/off. (v p. 129) POWER PO B ZONE2 VOLUME buttons (df) This setting adjusts the volume level for ZONE2. (v p.
Contents Connections ZONE 2 ZO POWER PO ECO VOLU LUME SOU OURC RCE SLE LEEP CBL/SAT BL/SAT DVD/ VD/ Blu-ra Blu-ray Blu-r Bl -ray GAME GA AUX MED EDIA PLAYER PLAY iPod/ iP od/USB TV A AUDI DIO Q7 L Remote control signal transmitter This transmits signals from the remote control unit. (v p. 8) TUN UNER OUND ND MO MODE SOU MUSIC GAME PURE M ECO Mode button (G) This switches to ECO mode. (v p. 180) N POWER button (X) This turns the power on/off. (v p.
Contents Connections Playback Settings Tips Appendix R OPTION button This displays the option menu on the TV screen. (v p. 101) ZONE 2 ZO S VOLUME buttons (df) These adjust the volume level. (v p. 53, 130) POWER PO T SETUP button This displays the menu on the TV screen. (v p.
Contents Connections Playback Settings o Contents Tips Appendix o Cables used for connections 25 Connecting a TV 36 Connecting a playback device 40 Connecting an iPod or USB memory device to the USB port 44 Connecting an FM/AM antenna 46 Provide necessary cables according to the devices you want to connect. Speaker cable . Connecting speakers 48 Connecting the power cord 50 Subwoofer cable . Connecting to a home network (LAN) HDMI cable .
Contents Connections Playback Settings Tips Appendix Connecting speakers Install speakers and connect them to this unit. (v p. 25, 28) Speaker installation FL/FR (Front speaker left/right): Place the FRONT left and right speakers an equal distance from the main listening position. The distance between each speaker and your TV should also be the same. C (Center speaker): Place the CENTER speaker in front of and at the center of the TV, between the front left and right speakers.
Contents Connections Playback Settings Tips 0 This unit is compatible with Dolby Pro Logic gz (v p. 225) which offers an even wider and deeper surround sensation. When using Dolby Pro Logic gz, install front height speakers. 0 Use the illustration below as a guide for how high each speaker should be installed. The height does not need to be exactly the same. Front height speaker Point slightly downwards At least 3.
Connections Contents Playback Settings o When 7.1-channel speakers are installed using surround back speakers Tips Appendix o When 7.1-channel speakers are installed using front height speakers FHL FHR FR FL FL SW C SW z2 z1 z3 z3 SL SL SR SBR - 30° z2:90° - 110° z3:135° SR . Listening position z1:22° - 30° z2:22° - 45° z3:90° - 110° o When 5.1-channel speakers are installed .
Contents Connections Playback Settings Speaker connection NOTE 1. Press and hold the main unit’s TUNER PRESET CH + and TUNE + for at least 3 seconds. “V.Format:< NTSC>” appears on the display. 2. Press DIMMER on the main unit twice. NOTE 0 Disconnect this unit’s power plug from the power outlet before connecting the speakers. Also, turn off the subwoofer. 0 Connect so that the speaker cable core wires do not protrude from the speaker terminal.
Contents Connections Playback Settings o Connecting the speaker cables Appendix o Connecting the subwoofer Carefully check the left (L) and right (R) channels and + (red) and – (black) polarities on the speakers being connected to this unit, and be sure to connect the channels and polarities correctly. 1 Tips Use a subwoofer cable to connect the subwoofer. Two subwoofers can be connected to this unit. The same signal is output from the respective subwoofer terminals.
Contents Connections Playback Settings o About the speaker cable label (supplied) for channel identification Speaker terminals Speaker This unit Color Red CENTER Green SURROUND L Light blue SURROUND R Blue SURROUND BACK L Beige SURROUND BACK R Brown SUBWOOFER Black . White FRONT R Attach the speaker cable label for each channel to its speaker cable as shown in the diagram. Refer to the table above and attach the label to each speaker cable.
Contents Connections Playback Settings Tips Appendix Speaker configuration and Amp Assign settings This unit has a built-in 7-channel power amplifier. In addition to the basic 5.1-channel system, a variety of speaker systems can be configured by changing the “Amp Assign” (v p. 167) settings to suit the application, such as 7.1-channel systems, bi-amp connections and 2-channel systems for multi-zone playback. Perform “Amp Assign” (v p.
Contents Connections Playback Settings Tips Appendix o Standard configuration and connection n 5.1-channel This serves as a basic 5.1-channel surround system. Sound modes such as Dolby Pro Logic g are supported.
Contents Connections Playback Settings Tips Appendix n 7.1-channel (surround back) This 7.1-channel surround system is the same as a basic 5.1-channel system but with surround back speakers. Sound modes such as Dolby Pro Logic gx are supported.
Contents Connections Playback Settings Tips Appendix n 7.1-channel (front height) This 7.1-channel surround system is the same as a basic 5.1-channel system but with front height speakers. Sound modes such as Dolby Pro Logic gz are supported.
Contents Connections Playback Settings Tips Appendix o Applied configuration and connection n 5.1-channel (MAIN ZONE) + 2-channel (ZONE2) This connection method constructs a 5.1-channel speaker system in the MAIN ZONE and a 2-channel system in ZONE2.
Contents Connections Playback Settings Tips Appendix Connecting a TV Connect a TV to this unit so that the input video is output to the TV. You can also enjoy audio from the TV on this unit. How to connect a TV depends on the connectors and functions equipped on the TV. ARC (Audio Return Channel) function plays TV audio on this unit by sending the TV audio signal to this unit via HDMI cable.
Contents Connections Playback Settings Tips Appendix Connection 1 : TV equipped with an HDMI connector and compatible with the ARC (Audio Return Channel) Use an HDMI cable to connect a TV that is compatible with the ARC function to this unit. Set “HDMI Control” (v p. 149) to “On” when using a TV that supports the ARC function.
Contents Connections Playback Settings Tips Appendix Connection 2 : TV equipped with an HDMI connector and incompatible with the ARC (Audio Return Channel) Use an HDMI cable to connect the TV to this unit. To listen to audio from TV on this unit, use an optical cable to connect the TV to this unit.
Contents Connections Playback Settings Tips Connection 3 : TV equipped without an HDMI connector Use a video cable to connect the TV to this unit. To listen to audio from TV on this unit, use an optical cable to connect the TV to this unit.
Contents Connections Playback Settings Tips Appendix Connecting a playback device This unit is equipped with two types of video input connectors (HDMI and composite video) and two types of audio input connectors (digital audio, audio). Select input connectors on this unit according to the connectors equipped on the device you want to connect. If the device connected to this unit is equipped with an HDMI connector, it is recommended to use HDMI connections.
Contents Connections Playback Settings Tips Connecting a DVD player or Blu-ray Disc player This explanation uses the connection with a DVD player or Blu-ray disc player as an example. When connecting a 4K compatible player, connect to either the HDMI 4 or HDMI 5 input connector.
Contents Connections Playback Settings Tips Connecting a set-top box (Satellite tuner/cable TV) This explanation uses the connection with a satellite tuner/cable TV STB as an example. Select the input connectors on this unit to match the connectors on the device that you want to connect to.
Contents Connections Playback Settings Tips Connecting a video camcorder or game console This explanation uses the connection with a video camcorders as an example. Connect a playback device to this unit, such as a video camcorder or game console. Video camcorder HDMI OUT MASTER VOLUM TUNE 3 GAME BAND 4 MODE DIMMER E STATUS ONLINE SELECT URE AUX - HDMI SETUP MIC .
Contents Connections Playback Settings Tips Appendix Connecting an iPod or USB memory device to the USB port To connect an iPod to this unit, use the USB adapter cable that was supplied with the iPod. For operating instructions see “Playing an iPod” (v p. 54) or “Playing a USB memory device” (v p. 59). iPod USB memory device MASTER VOLUME or TUNE y 3 GAME BAND 4 MODE DIMMER STATUS ONLINE K SELECT AUX - HDMI PURE SETUP MIC .
Contents Connections Playback Settings Tips o Supported iPod/iPhone models • iPod classic • iPod nano • iPod touch .
Contents Connections Playback Settings Tips Appendix Connecting an FM/AM antenna Connect the antenna, tune in to a broadcast and then move the antenna to the location where there is least noise. Then use tape, etc. to fix the antenna in this location. (“Listening to FM/AM broadcasts” (v p. 68)) AM loop antenna (supplied) If you are unable to receive a good broadcast signal, we recommend installing an outdoor antenna. For details, inquire at the retail store where you purchased the unit.
Contents Connections Playback Settings Tips o AM loop antenna assembly o Using the AM loop antenna 1 Suspending on a wall Suspend directly on a wall without assembling. 2 Put the stand section through the bottom of the loop antenna from the rear and bend it forward. Insert the projecting part into the square hole in the stand. Stand Nail, tack, etc. Square hole . Loop antenna Projecting part . . Standing alone Use the procedure shown above to assemble.
Contents Connections Playback Settings Tips Appendix Connecting to a home network (LAN) This unit can connect to a network using a wired LAN or wireless LAN. You can connect this unit to your home network (LAN) to enable various types of playback and operations as described below.
Contents Connections Playback Settings Wireless LAN Tips Appendix 0 When using this unit, we recommend you use a router equipped with the following functions: When connecting to a wireless LAN network, stand the rod antenna for wireless LAN/Bluetooth connection upright on the rear panel. See “Wi-Fi Setup” (v p. 175) on how to connect to a wireless LAN router. Internet Modem 0 0 To WAN side 0 0 0 Built-in DHCP server This function automatically assigns IP addresses on the LAN.
Contents Connections Playback Settings Tips Connecting the power cord After completing all the connections, insert the power plug into the power outlet. HDMI IN HDMI (ASSIGNABLE) OUT VIDEO IN (ASSIGNABLE) 1 CBL/SAT DVD/ 2 Blu-ray MEDIA 3 PLAYER 4 Blu-ray 5 GAME MONITOR (4K) (4K) ARC MEDIA 2 PLAYER MONITOR VIDEO D SURROUND BACK OUT SURROUND BACK ASSIGNABLE IMPEDANCE : 4㨪16ǡ CLASS 2 WIRING Power cord .
Contents Connections Playback Settings Tips Appendix o Contents Playback network audio/service Basic operation Listening to Internet Radio 75 Playing back files stored on a PC and NAS 79 Viewing photographs on the Flickr site 83 Listening to Pandora® 87 Turning the power on 52 Selecting the input source 52 Adjusting the volume 53 Turning off the sound temporarily (Muting) 53 Selecting a sound mode 111 53 Playing an iPod 54 Playing a USB memory device 59 Playing a Bluetooth de
Contents Connections Playback Settings Tips Appendix Basic operation POWER PO ZONE 2 ZO ECO VOLU LUME SOU OURC RCE Input source select buttons 1 SLE LEEP CBL/SAT BL/SAT DVD/ VD/ Blu-ra Blu-ray Blu-r Bl -ray GAME GA AUX MED EDIA PLAY PLAYER iPod/ iP od/USB TV AUDI A DIO INTERNET INTERNET luetoo etooth RADI Blu ADIO AGE PAG MOVIE OUND ND MO MODE SOU MUSIC GAME PURE INF NFO Press POWER X to turn on power to the unit.
Contents Connections Playback Settings Adjusting the volume 1 Use VOLUME df to adjust the volume. The following describes the procedure for playing DVD player/Blu-ray Disc player. 1 2 3 Turning off the sound temporarily (Muting) Press MUTE :. 4 0 MUTE indicator on the display flashes. 0 : appears on the TV screen. Prepare for playback. A Turn on the power of the TV, subwoofer and player. B Change the TV input to the input of this unit. Press POWER X to turn on power to the unit.
Contents Connections Playback Settings Tips Appendix Playing an iPod 0 You can use the USB cable provided with the iPod to connect the iPod with the unit’s USB port and enjoy music stored on the iPod. ZONE 2 ZO 0 For information on the iPod models that can be played back with this POWER PO ECO unit, see “Supported iPod/iPhone models” (v p. 45).
Contents Connections Playback Settings This can be operated when the “iPod Browse Mode” (v p. 56) is set to “From iPod”. 0 “iPod Browse Mode settings” (v p. 56) 0 “Adjusting the volume of each channel to match the input source (Ch Level Adjust)” (v p. 107) 0 “Adjusting the tone (Tone Control)” (v p. 108) 0 “Displaying your desired video during audio playback (Video Select)” (v p. 109) 0 “Playing the same music in all zones (All Zone Stereo)” (v p. 110) Connect the iPod to the USB port. (v p.
Contents Connections Playback Settings iPod Browse Mode settings Operation buttons 2 3 89 The option menu screen is displayed. 0 Operations available for “On-Screen” and “From iPod” are listed below. Playable files Active buttons From iPod On-Screen Music file P P Video file z Remote control unit (This unit) P iPod Switch to the previous page/next page in the list display 0 The display switches between track title, artist name, and album title etc.
Contents Connections Playback Settings Tips o Operations accessible through the option menu This can be operated when the “iPod Browse Mode” is set to “OnScreen”. (v p. 56) 0 “iPod Browse Mode settings” (v p. 56) 0 “Performing repeat playback” (v p. 58) 0 “Performing random playback” (v p. 58) 0 “Adjusting the volume of each channel to match the input source (Ch Level Adjust)” (v p. 107) 0 “Adjusting the tone (Tone Control)” (v p.
Contents Connections Playback Settings 1 Press OPTION with “iPod Browse Mode” set to “OnScreen”. 4 Press OPTION with “iPod Browse Mode” set to “OnScreen”. The option menu screen is displayed. The option menu screen is displayed. 2 3 Appendix Performing random playback Performing repeat playback 1 Tips 2 3 Use ui to select “Repeat”, then press ENTER. Use o p to select repeat playback mode. Use ui to select “Random”, then press ENTER. Use o p to select random playback mode.
Contents Connections Playback Settings Tips Appendix Playing a USB memory device 0 Playing back music or viewing still picture (JPEG) files stored on a USB memory device. ZONE 2 ZO 0 Only USB memory devices conforming to mass storage class standards POWER PO ECO can be played on this unit. VOLU LUME SOU OURC RCE iPod/USB SLE LEEP CBL/SAT BL/SAT DVD/ VD/ Blu-ra Blu-ray Blu-r Bl -ray GAME GA AUX MED EDIA PLAY PLAYER iPod/ iP od/USB TV A AUDI DIO “FAT32” format.
Contents Connections Playback Settings Playing files stored on USB memory devices 1 2 Operation buttons 89 Skip to previous track / Skip to next track (Press and hold) Fast-reverse / Fast-forward (Press and hold) Stop Skip to previous track / Skip to next track ui (Press and hold) Fast-reverse / Fast-forward PAGE d f [1/9] Function Playback / Pause ENTER Press iPod/USB to switch the input source to “iPod/ USB”. Appendix Playback / Pause 1/3 Connect the USB memory device to the USB port.
Contents Connections Playback Settings Tips o Operations accessible through the option menu 0 “Performing repeat playback” (v p. 102) 0 “Performing random playback” (v p. 102) 0 “Searching content with keywords (Text Search)” (v p. 104) 0 “Playing back music and a favorite picture at the same time (Slideshow)” (v p. 105) 0 “Setting the Slideshow Interval” (v p. 106) 0 “Adjusting the volume of each channel to match the input source (Ch Level Adjust)” (v p.
Contents Connections Playback Settings Tips Appendix Listening to music on a Bluetooth device ZONE 2 ZO Music files stored on Bluetooth devices such as smartphones, digital music players, etc. can be enjoyed on this unit by pairing and connecting this unit with the Bluetooth device. Communication is possible up to a range of about 32.8 ft/10 m.
Contents Connections Playback Settings Pairing with a Bluetooth device 2 In order to enjoy music from a Bluetooth device on this unit, the Bluetooth device must first be paired with this unit. Once the Bluetooth device has been paired, it does not need to be paired again. Appendix Select this unit when its name appears in the list of devices displayed on the screen of the Bluetooth device. At the end of the pairing, the device name appears on the display of this unit.
Contents Connections Playback Settings Playing a Bluetooth device Operation buttons 89 The unit will automatically connect to the most recently used Bluetooth device. 2 Function Skip to previous track / Skip to next track (Press and hold) Fast-reverse / Fast-forward Playback / Pause ENTER Press Bluetooth to switch the input source to “Bluetooth”. Appendix Playback / Pause 1/3 Check the following before you play back music.
Contents Connections Playback Settings Tips NOTE 0 To operate the Bluetooth device with the remote control of this unit, the Bluetooth device needs to support the AVRCP profile. 0 The remote control of this unit is not guaranteed to work with all Bluetooth devices. 0 Depending on the type of Bluetooth device, this unit outputs audio that is coupled to the volume setting on the Bluetooth device. o Operations accessible through the option menu 0 “Performing repeat playback” (v p.
Contents Connections Playback Settings Pairing with the Pairing Mode 2 3 Press OPTION when the input source is “Bluetooth”. The option menu screen is displayed. Use ui to select “Pairing Mode”, then press ENTER. The device will go into the pairing mode. Select this unit when its name appears in the list of devices displayed on the screen of the Bluetooth device. At the end of the pairing, the device name appears on the display of this unit.
Contents Connections Playback Settings Tips Appendix Listening to FM/AM broadcasts ZONE 2 ZO You can use the built-in tuner of this unit to listen to FM broadcasts and AM broadcasts. Make sure the FM antenna and AM loop antenna are connected to this unit first.
Contents Connections Playback Settings Listening to FM/AM broadcasts 1 2 5 Connect the antenna. (“Connecting an FM/AM antenna” (v p. 46)) 6 Press TUNER to switch the input source to “Tuner”. G TV screen H CH 1 Preset OPTION Option . CH+/CH +/- G Display of this unit H 3 4 FM: When listening to an FM broadcast. AM: When listening to an AM broadcast. Press TUNE + or TUNE - to select the station you want listen to. Operation buttons 92.10MHz .
Contents Connections Playback Settings 0 “Tuning in by entering the frequency (Direct Tune)” (v p. 69) You can enter the receiving frequency directly to tune in. 0 “Changing the tune mode (Tune Mode)” (v p. 70) 1 0 “Tuning in to stations and presetting them automatically (Auto 0 0 0 0 0 0 Preset)” (v p. 70) “Presetting the current broadcast station (Preset Memory)” (v p. 71) “Specify a name for the preset broadcast station (Preset Name)” (v p.
Contents Connections Playback Settings Changing the tune mode (Tune Mode) 2 3 A maximum of 56 radio stations can be automatically preset. 1 Press OPTION when the input source is “Tuner”. The option menu screen is displayed. 2 3 Use ui to select “Tune Mode”, then press ENTER. Use o p to select the tune mode, then press ENTER. Auto: Automatically search for and tune to a receivable radio station. Manual: Manually change the frequency one step at a time each time the button is pressed.
Contents Connections Playback Settings Presetting the current broadcast station (Preset Memory) 2 3 4 Appendix Channel Default settings 1–8 92.10 / 92.30 / 92.50 / 92.70 / 93.10 / 93.50 / 93.70 / 94.10 MHz 9 – 16 94.30 / 94.50 / 94.70 / 94.90 / 95.10 / 95.30 / 95.50 / 95.70 MHz 17 – 24 Tune in the broadcast station you want to preset. (“Listening to FM/AM broadcasts” (v p. 68)) 98.10 / 98.30 / 98.50 / 98.70 / 98.90 / 99.10 / 100.10 / 100.30 MHz 25 – 32 100.50 / 100.70 / 100.90 / 101.
Contents Connections Playback Settings Specify a name for the preset broadcast station (Preset Name) 5 You can set the name to the preset broadcast station or change it. Up to eight characters can be input. 1 2 3 4 6 Press OPTION when the input source is “Tuner”. The option menu screen is displayed. Tips Use ui to select a name label, then press ENTER. The screen that lets you edit the Preset Name is displayed. 0 If you select “Set Defaults”, then the unit returns to displaying the frequency.
Contents Connections Playback Settings A Use o p to select the group of broadcast stations you want to skip. B Use ui to select the broadcast station you want to skip. C Use o p to select “Skip”. The station you selected is not displayed. Perform auto preset memory to save all the broadcasting stations that can be received in the memory. Selecting a broadcast station becomes easier by skipping unnecessary memories. 2 3 4 Press OPTION when the input source is “Tuner”.
Contents Connections Playback Settings Tips Cancelling Preset Skip 1 2 3 While the Preset Skip screen is displayed, use o p to select a group containing a broadcast station to cancel the skip for. Use ui to select a broadcast station to cancel the skip for. Use o p to select “On”. The skip is cancelled. NOTE Preset skip cannot be cancelled for groups.
Contents Connections Playback Settings Tips Appendix Listening to Internet Radio 0 Internet Radio refers to radio broadcasts distributed over the Internet. Internet Radio stations from around the world can be received. ZONE 2 ZO 0 The Internet radio station list on this unit the database service provided POWER PO ECO by vTuner radio station.
Contents Connections Playback Settings Listening to Internet Radio 1 4 Prepare for playback. 0 Check the network environment, then turn on this unit’s power. (“Connecting to a home network (LAN)” (v p. 48)) 2 Press ONLINE MUSIC. 0 You can also press INTERNET RADIO to select the input source “Internet Radio” directly. Use uio p to select “Internet Radio”, then press ENTER. Online Music Favorites Name of country: Select the various regions. Displays typical Internet Radio stations.
Contents 5 Connections Playback Settings Operation buttons Function 1 Playback / Stop ENTER (Press and hold) Stop PAGE d f Switch to the previous page/next page in the list display Appendix Playing the last played Internet Radio station Use ui p to select the station, then press ENTER. Playback starts once buffering reaches “100%”. 1/3 Tips Press INTERNET RADIO. The source switches to “Internet Radio” and the last played radio station plays.
Contents Connections Playback Settings Using vTuner to add Internet Radio stations to favorites 4 5 There are many Internet Radio stations in the world, and this unit can tune into these stations. But finding the radio station you want to hear may be difficult, because there are too many stations. If this is the case, then please use vTuner, an Internet Radio station search website specifically designed for this unit.
Contents Connections Playback Settings Tips Appendix Playing back files stored on a PC and NAS 0 This unit can play back music files and playlists (m3u, wpl) stored on a PC and on Network Attached Storage (NAS) that supports DLNA. ZONE 2 ZO 0 The network audio playback function of this unit connects to the server POWER PO ECO using technologies shown below.
Contents Connections Playback Settings Tips Appendix Applying media sharing settings Here, we apply the settings to share music files stored on a PC and NAS on the network. If you are using a Media Server, be sure to apply this setting first. . o When using Windows Media Player 11 o When using Windows Media Player 12 (Windows 7 / Windows 8) 1 2 3 4 5 1 2 3 Start up Windows Media Player 12 on the PC. Select “More streaming options...” in the “Stream”.
Contents Connections Playback Settings Playing back files stored on a PC and NAS 4 5 Use this procedure to play music files, image files or playlists. 2 3 Prepare for playback. Use iu p to select the file, then press ENTER. Playback starts once buffering reaches “100%”. Operation buttons A Check the network environment, then turn on this unit’s power. (“Connecting to a home network (LAN)” (v p. 48)) B Prepare the computer.
Contents Connections Playback Settings Appendix o Operations accessible through the option menu 0 The display switches between track title, artist name, and album title each time the main unit’s STATUS is pressed. 0 When a WMA (Windows Media Audio), MP3 or MPEG-4 AAC file includes album art data, the album art can be displayed while the music files are playing. 0 If you use Ver.11 or later of Windows Media Player, the album art for WMA files can be displayed.
Contents Connections Playback Settings Tips Appendix Viewing photographs on the Flickr site 0 Flickr is an online photo sharing service. You can use this unit to view ZONE 2 ZO photographs that have been made public by Flickr users. You do not need an account to use Flickr. To view photographs that you recorded yourself, you need an account in order to upload these photographs to the Flickr server. For details, see the Flickr homepage. http://www.flickr.
Contents Connections Playback Settings Viewing photographs shared by particular users 1 4 5 Prepare for playback. Use ui to select “Add Flickr Contact”, then press ENTER. Enter the screen name that you wish to add to “Contact” (Screen Name: User name you wish to view). screen” (v p. 136). 6 Press ONLINE MUSIC. Use uio p to select “Flickr”, then press ENTER. Online Music Favorites 7 Internet Radio After inputting the “Contact”, press “OK”.
Contents 8 Connections Playback Settings 9 Use ui to select the folder, then press ENTER. Tips Appendix Use ui p to select the photograph, then press ENTER. The selected photograph is displayed. Favorites : Displays the favorite photographs of the specified user. Photostream : Displays a list of shared photographs. PhotoSets : Displays the folder (photograph album) list. Contacts : Displays the screen name used by the specified user in Contacts.
Contents Connections Playback Settings 0 “Setting the Slideshow Interval” (v p. 106) Use ui to select “All Content”, then press ENTER. 0 “Displaying your desired video during audio playback (Video Use ui to select the folder, and then press ENTER. 0 “Playing the same music in all zones (All Zone Stereo)” (v p. 110) Select)” (v p. 109) Displays photographs that are popular from the Interestingness : number of user comments or number of times they are added as favorites.
Contents Connections Playback Settings Tips Appendix Listening to Pandora® ZONE 2 ZO Pandora is an automated music recommendation and Internet Radio service created by the Music Genome Project. To listen to Pandora you will need a free Pandora account. If you do not have a Pandora account, you can create one at www.pandora.com or from the Pandora smartphone application. Playback of Pandora in this unit requires the Pandora account to be linked to the unit. Therefore, access http://www.pandora.
Contents Connections Playback Settings 4 Listening to Pandora® 1 Appendix If you have a Pandora account, use ui to select “I have a Pandora account”, then press ENTER. 0 If you do not have a Pandora account, to select “I am to new to Prepare for playback. Pandora”. The URL of Pandora and activation code are displayed. Access the Pandora web page from your PC and register the displayed activation code and account information. Then press ENTER.
Contents 5 Connections Playback Settings Tips Input “Email address” and “Password”. 0 For character input, see “Using the keyboard screen” (v p. 136). 0 Press BACK to cancel the input. When “Cancel input?” is displayed, select “Yes”, then press ENTER. After inputting the “Email address” and “Password”, select “OK”, then press ENTER. If the “Email address” and “Password” match, the top menu for Pandora is displayed. My Station [1/4] New Station Shuffle Music1 Radio Sign Out OPTION Option .
Contents Connections Playback Settings Creating a new station Operation buttons You can create up to 100 radio stations. 1 2 Use ui to select “New Station”, then press ENTER. Input a track or artist name, then press “OK”.
Contents Connections Playback Settings Tips Listening to an existing station 1 Use ui and select the radio station that you want to listen to, then press ENTER. You can skip up to 6 tracks that are being played back within 1 hour. Listening to created radio stations at random 1 Use ui to select “Shuffle”, then press ENTER. Created radio stations are selected at random, and tracks are streamed.
Contents Connections Playback Settings Giving feedback and managing stations You can personalize your stations by providing feedback. 1 Press p while a track is playing. The Pandora menu screen is displayed. I like this track : Press when you like the track that is being played. Playback a favorite track. Display the E (Thumbs up) icon. I don’t like this track : Press when you don’t like the track that is being played. Delete that track from the radio station. Display the D (Thumbs down) icon.
Contents Connections Playback Settings Tips Sign Out Disassociate this unit from your Pandora account. 1 2 Use ui to select “Sign Out”, then press ENTER. When the popup menu appears, use o p to select “Yes”, then press ENTER. o Operations accessible through the option menu 0 “Adjusting the volume of each channel to match the input source (Ch Level Adjust)” (v p. 107) 0 “Adjusting the tone (Tone Control)” (v p. 108) 0 “Displaying your desired video during audio playback (Video Select)” (v p.
Contents Connections Playback Settings Tips Appendix Listening to SiriusXM Internet Radio ZONE 2 ZO You can access SiriusXM to enjoy access to a wide range of unique content. An All Access package lets you listen to SiriusXM on your computer, smartphone, tablet or Lynx Portable. For details, see the SiriusXM homepage. http://www.siriusxm.
Contents Connections Playback Settings Listening to SiriusXM Internet Radio 3 Over 155 channels commercial-free music, plus play-by-play sports, exclusive talk, comedy and entertainment. 2 Online Music Prepare for playback. Favorites A Check the network environment, then turn on this unit’s power. (“Connecting to a home network (LAN)” (v p. 48)) B Access the following website from your PC and obtain a SiriusXM account. http://www.siriusxm.
Contents 7 8 Connections Playback Settings Disassociate this unit from your SiriusXM account. Use ui to select the file, then press ENTER. 1 2 The selected file is displayed. 1/3 ENTER PAGE d f Appendix Sign Out Use ui to select the genre, then press ENTER. Operation buttons Tips Function Playback / Stop Use ui to select “Sign Out”, then press ENTER. When the popup menu appears, use o p to select “Yes”, then press ENTER.
Contents Connections Playback Settings Tips Appendix AirPlay function . Music files stored on your iPhone, iPod touch, iPad or iTunes can be played on this unit via the network. PC This unit 0 0 0 0 0 0 + is displayed on the menu screen while AirPlay is being operated. Source input will be switched to “Online Music” when AirPlay playback is started. You can stop AirPlay playback by pressing o or choosing other input source. To see song and artist names together, press STATUS on the main unit.
Contents Connections Playback Settings Playing songs from your iPhone, iPod touch or iPad 1 2 Connect your iPhone, iPod touch or iPad Wi-Fi to the same network as this unit. 0 For details, see your device’s manual. 2 Install iTunes 10, or later, on a Mac or Windows PC that is connected to the same network as this unit. Turn this unit ON. Set “IP Control” (v p. 178) to “Always On” for this unit. NOTE Play the song on your iPhone, iPod touch or iPad.
Contents Connections Playback Settings Selecting multiple speakers (devices) With this unit’s remote control unit, you can perform iTunes song play, pause, and auto search (cue) operations. Click the AirPlay icon ' and select “Multiple”. 1 2 3 Check the speakers you want to use. NOTE In playback using the AirPlay function, the sound is output at the iPhone, iPod touch, iPad or iTunes volume setting level.
Contents Connections Playback Settings Tips Appendix Spotify Connect function Spotify is the world’s most popular streaming service. If you subscribe to Spotify Premium, you can control your new speaker with your phone or tablet. Because Spotify is built-in to your speaker, you can still take calls or use other apps - the music never stops. To try Spotify Premium free for 30 days, or learn more about Connect, please go to www.spotify.
Contents Connections Playback Settings Tips Appendix Convenience functions This section explains how to use convenient functions that can be used for each input source.
Contents Connections Playback Settings Performing repeat playback Tips Performing random playback n Supported input sources : USB / Media Server / Bluetooth n Supported input sources : USB / Media Server / Bluetooth 1 1 2 3 4 Appendix While content is playing, press OPTION. The option menu screen is displayed. 2 3 Use ui to select “Repeat”, then press ENTER. Use o p to select repeat playback mode. While content is playing, press OPTION. The option menu screen is displayed.
Contents Connections Playback Settings Registering to Favorites n Supported input sources : Internet Radio / Media Server / Pandora / SiriusXM 1 2 While content is playing, press OPTION. Press ONLINE MUSIC. Use uio p to select “Favorites”, then press ENTER. The option menu screen is displayed. Online Music Use ui to select “Save to Favorite”, then press ENTER. Favorites “Favorite added” is displayed, and the current content is added to favorites.
Contents Connections Playback Settings Deleting content added to favorites 1 2 3 Appendix Searching content with keywords (Text Search) Press ONLINE MUSIC. Use uio p to select “Favorites”, then press ENTER. n Supported input sources : USB / Internet Radio / Media Server Use ui to select the content you want to delete from favorites, then press OPTION. 1 The option menu screen is displayed. 4 Tips 2 Use ui to select “Remove from Fav.”, then press ENTER.
Contents Connections Playback Settings Tips Appendix Playing back music and a favorite picture at the same time (Slideshow) n Supported input sources : USB 1 n Supported input sources : Internet Radio / Media Server Play back a still picture. 1 0 Playing back still pictures stored on USB memory devices. (v p. 60) 2 3 4 2 Press OPTION. The option menu screen is displayed. 3 Use ui to select “Slideshow”, then press ENTER.
Contents Connections Playback Settings Setting the Slideshow Interval Tips The “Slideshow Time” settings are reflected for all input sources. Set the playback interval when playing back a slideshow of still picture (JPEG) files stored on a USB memory device or media server, or on the Flickr website. n Supported input sources : USB / Media Server / Flickr 1 2 3 While the list is displayed, press OPTION. The option menu screen is displayed. Use ui to select “Slideshow Time”, then press ENTER.
Contents Connections Playback Settings Adjusting the volume of each channel to match the input source (Ch Level Adjust) 2 3 4 Press OPTION. The option menu screen is displayed. Use ui to select “Ch Level Adjust”, then press ENTER. The channel level adjust screen is displayed. Use ui to select the channel that you wish to adjust. Use o p to adjust the volume, then press ENTER. –12.0 dB – +12.
Contents Connections Playback Settings Adjusting the tone (Tone Control) 4 Adjusts the tonal quality of the sound. 1 2 3 Press OPTION. The option menu screen is displayed. 5 Use ui to select “Tone Control”, then press ENTER. The tone control screen is displayed. Tips Appendix Select “On” in step 3 and press i to select the sound range to be adjusted. Bass: Adjust bass. Treble: Adjust treble. Use o p to adjust the tone, then press ENTER.
Contents Connections Playback Settings Displaying your desired video during audio playback (Video Select) 4 5 This unit can display video from a different source on TV during audio playback. You can set this for each input source. n Supported input sources: iPod/USB / Tuner / Online Music / Bluetooth 1 2 3 Tips If you selected “On” in step 3, press i and select “Source”. Use o p to select the input source for video you want to play back, then press ENTER.
Contents Connections Playback Settings 1 You can play back the music being played back in MAIN ZONE simultaneously in ZONE2 (another room). It is useful when you want to enjoy the same music at the same time in multiple rooms during home party or when you want to play back the same BGM in the entire house. 2 3 Appendix o Stopping the All Zone Stereo mode Playing the same music in all zones (All Zone Stereo) 1 Tips During playback in All Zone Stereo mode, press OPTION.
Contents Connections Playback Settings Tips Appendix Selecting a sound mode ZONE 2 ZO This unit allows you to enjoy various kinds of surround and stereo playback modes. Disc formats such as Blu-ray Disc and DVD, as well as being supported by digital broadcasting, and even by streaming movies and music from internet-based subscription services. This unit supports playback of almost all of these multi-channel audio formats.
Contents Connections Playback Settings 0 Press and hold MOVIE, MUSIC or GAME to display a list of the sound modes that can be selected. Each time you press MOVIE, MUSIC or GAME, the sound mode changes. 0 While the list is displayed, you can also use ui to select a sound mode. 0 Try out various sound modes and enjoy sound mode in your favorite mode. GExampleH When MOVIE is pressed Press MOVIE, MUSIC or GAME to select a sound mode.
Contents Connections Playback Settings Direct playback This mode detects the type of input digital signal, and automatically selects the corresponding mode for playback. Perform stereo playback when the input signal is PCM. When the input signal is Dolby Digital or DTS, the music is played back according to the respective channel number. Press PURE to select “Direct”. Direct playback begins. 1 In Direct sound mode, the following items cannot be adjusted. 0 Tone Control (v p. 108) 0 Restorer (v p.
Contents Connections Playback Settings Tips Appendix o Description of sound mode types Dolby sound mode Sound mode type Dolby PLgxz1 Description This mode can be selected when the Dolby PLgx decoder is used to play back 2-channel sources in 6.1/7.1-channel surround sound including the surround back channel(s). By adding the surround back channel(s), a more enveloping surround environment is produced, compared to Dolby Pro Logic g.
Contents Connections Playback Settings Tips Appendix DTS sound mode Sound mode type DTS Neo:6 Description This mode can be selected when the DTS Neo:6 decoder is used to play back 2-channel sources in 6.1/7.1-channel surround sound including the surround back channel(s). There are two playback modes: “Cinema” mode that is optimized for movie playback, “Music” mode that is optimized for music playback. DTS Surround This mode can be selected when playing sources recorded in DTS. DTS ES Dscrt6.
Contents Connections Playback Settings Tips Appendix Original sound mode Sound mode type Description Multi Ch Stereo This mode is for enjoying stereo sound from all speakers. Stereo audio (2-channel) sources are played back via the front (L/R) speakers, the surround speakers and surround back speakers (if connected). Rock Arena This mode simulates the expansive sound of a live concert in an arena. Jazz Club This mode simulates the experience of being in an intimate jazz club.
Contents Connections Playback Settings Tips Appendix Stereo sound mode Sound mode type Stereo Description This mode plays 2-channel stereo audio with no additional surround sound processing. 0 Sound is output from the front left and right speakers, and subwoofer if connected. 0 When multi-channel signals are inputted, they are mixed down to 2-channel audio and are played back with no additional surround sound processing.
Contents Connections Playback Settings Tips Appendix o Sound mode that can be selected for each input signal 0 The following sound modes can be selected using the MOVIE, MUSIC and GAME buttons. 0 Adjust the sound field effect with the menu “Surr.Parameter” (v p. 138) to enjoy surround sound the way you like it.
Contents Connections Input signal Multi-channel z3 Dolby Digital Playback Sound mode Settings MUSIC button S GAME button S Dolby Digital S S S Dolby Digital EX S S S Dolby Digital + PLgx Cinema S S Dolby Digital + PLgz S S S Dolby TrueHD S S S Dolby TrueHD + EX S S S Dolby TrueHD + PLgx Cinema S Dolby TrueHD + PLgx Music Dolby Digital Plus S Dolby TrueHD + PLgz S S S Dolby Digital Plus S S S Dolby Digital Plus + EX S S S Dolby Digital Plus + PLgx Cinema S Do
Contents Connections Input signal Playback Sound mode PCM multi-channel Appendix MUSIC button S GAME button S DTS-HD Mstr S S S DTS Express S S S DTS-HD + PLgx Cinema S DTS-HD + PLgx Music S S DTS-HD + PLgz S S S DTS-HD + Neo:6 S S Multi Ch In S S S Multi Ch In 7.
Contents Connections Playback Settings Tips o Views on the display . + q PL z DVD w A Shows a decoder to be used. 0 A Dolby Digital Plus decoder is displayed as “H”. B Shows a decoder that creates sound output. 0 “+ PLgz” indicates that the PLgz decoder is being used, and that front height channel sound is being created.
Contents Connections Playback Settings Tips Appendix HDMI control function A recent addition to the HDMI standard is CEC (Consumer Electronics Control), which allows control signals from one device to communicate with another device via the HDMI cable connection. Setting procedure 1 2 3 5 Enable the HDMI control function of this unit. Set “HDMI Control” (v p. 149) to “On”. Turn the power on for all the devices connected by HDMI cable.
Contents Connections Playback Settings Tips Appendix Sleep timer function ZONE 2 ZO You can have the power automatically switched to standby once a set time has elapsed. This is convenient for viewing and listening while going to sleep.
Contents Connections Playback Settings Appendix o Checking the remaining time Using the sleep timer 1 Tips Press SLEEP when the sleep timer is in operation. The remaining time appears on the display. Press SLEEP and display the time you want to set. o To cancel the sleep timer 0 The SLEEP indicator lights up on the display and the sleep timer starts. Press SLEEP to select “Off”. The SLEEP indicator on the display turns off.
Contents Connections Playback Settings Tips Appendix Quick select plus function ZONE 2 ZO Settings such as the input source, volume level and sound mode can be registered to the QUICK SELECT 1 - 4 buttons. You can simply press one of the registered QUICK SELECT buttons in subsequent playbacks to switch to the group of saved settings in a batch. By saving frequently used settings at the QUICK SELECT 1 – 4 buttons, you will always be able to easily call up the same playback environment.
Contents Connections Playback Settings Tips Calling up the settings 1 Press QUICK SELECT. The Quick Select settings registered to the button you pressed are called up. 0 The default settings for the input source and volume are as shown below.
Contents Connections Playback Settings Changing the settings 1 2 Tips Press and hold the desired QUICK SELECT until “Quickz Memory” appears on the display. The current settings will be memorized. z is displayed the number for the QUICK SELECT button you pressed. Set the items below to the settings you want to register. The following settings from A to H can be memorized for MAIN ZONE, and settings A and B can be memorized for ZONE2. o Changing the Quick Select Name A Input source (v p.
Contents Connections Playback Settings Tips Appendix Playback in ZONE2 (Separate room) You can operate this unit to enjoy audio in a room (ZONE2) that is different from the room where this unit is placed (MAIN ZONE). You can simultaneously play back the same source in both the MAIN ZONE and ZONE2. You can also play back separate sources in the MAIN ZONE and ZONE2. Connecting ZONE2 o Connecting using a speaker output connector When “Assign Mode” (v p.
Contents Connections Playback Settings Playback in ZONE2 .
Contents Connections Playback Settings Tips o Adjusting the volume Use ZONE2 VOLUME df to adjust the volume. 0 At time of purchase, “Volume Limit” is set to “70 (–10 dB)”. (v p. 182) Turn MASTER VOLUME after pressing ZONE2 SOURCE on the main unit to adjust the sound volume.
Contents Connections Playback Settings Tips Appendix Menu map When using menu operations, connect this unit to a TV and operate this unit while viewing the TV. The recommended settings are configured for this unit by default. You can customize this unit based on your existing system and your preferences. Detailed items Description Page Dialog Level This setting adjusts the output level to clarify the dialogue output from the center channel.
Contents . Setting items Inputs Connections Playback Settings Detailed items Tips Appendix Description Page Input Assign Changes input connector assignment. 153 Source Rename Changes the display name for input source. 155 Hide Sources Removes from the display input sources that are not used. 155 Source Level Adjusts the playback level of the audio input. 155 Input Select Sets the audio input mode and decode mode.
Contents Connections . Setting items General Playback Settings Detailed items Tips Description Page Language Changes the language of the display on the TV screen. 180 ECO Configures the ECO Mode and Auto Standby energy-saving functions. 180 ZONE2 Setup Sets ZONE2 audio playback settings. 182 Zone Rename Changes the display title of each zone to one you prefer. 183 Quick Sel.Names Changes the Quick Select Name display title to one you prefer.
Contents Connections Playback Settings Tips Appendix Menu operations ZONE 2 ZO POWER PO 1 ECO VOLU LUME SOU OURC RCE SLE LEEP CBL/SAT BL/SAT DVD/ VD/ Blu-ra Blu-ray Blu-r Bl -ray GAME GA AUX MED EDIA PLAY PLAYER iPod/ iP od/USB TV A AUDI DIO ONLIN ONLINE MUSIC MOVIE Blu luetoo etooth uio p ENTER BACK TUN UNER INTERNET INTERNET RADI ADIO SOU OUND ND MO MODE MUSIC GAME INF NFO 2 CHA HANN NNEL 3 4 PAG AGE PURE OPTIO OP ION BACK TUNE TU Use o p to change to desired setting.
Contents Connections Playback Settings Tips Inputting characters On this unit, you can change the name displayed on the following screens to the names that you prefer. 0 Preset Name (v p. 72) 0 Text Search (v p. 104) 0 Source Rename (v p. 155) 0 Friendly Name (v p. 179) 0 Zone Rename (v p. 183) 0 Quick Sel.Names (v p.
Contents Connections Playback Settings Tips Appendix Using the keyboard screen 1 3 Display the screen for inputting characters. GExampleH Source Rename screen Source Rename CBL/SAT 4 CBL/SAT Clear Insert Delete A B C D E F G H I J K L M 5 6 N O P Q R S T U V W X Y Z 0 1 2 3 4 5 6 7 8 9 ! “ # $ % & ‘ ( ) z+ , ; < = > Space Cancel OK Select a character to be input with uio p then press ENTER. Repeat steps 2 - 4 to change the name. Use uio p to select “OK”, then press ENTER. .
Contents Connections Playback Settings Tips Appendix Audio Make audio-related settings. Dialog Level Subwoofer Level This setting adjusts the output level to clarify the dialogue output from the center channel. This setting adjusts the volume level for the subwoofer. o Adjustment o Adjustment Set whether to adjust the subwoofer level. Set whether to adjust the dialog level or not. On: Enables the adjustment of the dialog level. Off (Default): Disables the adjustment of the dialog level.
Contents Connections Playback Settings Appendix o Loudness Mngmt Surr.Parameter This sets whether to output as specified in “Dynamic Comp.” or output directly without compressing the dynamic range of audio recorded in the disc. You can adjust the surround audio sound field effects to match your preferences. The items (parameters) that can be adjusted depend on the signal being input and the currently set sound mode.
Contents Connections Playback Settings o Dynamic Comp. Appendix o Center Image Compress dynamic range (difference between loud and soft sounds). Auto: Automatic dynamic range compression on/off control according to source. Low / Medium / High: These set the compression level. Off: Dynamic range compression is always off. Distributes the dialogue output from the center channel to the front left and right channels and widens the sound image in the front. 0.0 – 1.0 (Default : 0.
Contents Connections Playback Settings o Dimension Tips Appendix o Delay Time Shift sound image center to front or rear to adjust playback balance. Adjust the audio delay time against video to extend the sound field image. 0 – 6 (Default : 3) 0 ms – 300 ms (Default : 30 ms) 0 You can set this when the sound mode is Dolby PLg/gx in the “Music” mode. 0 As you set a smaller number, the surround sound field shifts backward; as you set a larger number, the surround sound field shifts forward.
Contents Connections Playback Settings o Room Size Tips Appendix o Subwoofer Determine size of acoustic environment. Turn subwoofer output on and off. Small: Simulate acoustics of a small room. On (Default): The subwoofer is used. Medium small: Simulate acoustics of a medium-small room. Off: The subwoofer is not used. Medium (Default) : Simulate acoustics of a medium room. Medium large: Simulate acoustics of a medium-large room. Large: Simulate acoustics of a large room.
Contents Connections Playback Settings Tips Appendix Restorer 0 This item can be set with analog signals or PCM signal (Sample Rate = 44.1/48 kHz) is input. 0 This item default setting for “Online Music”, “iPod/USB” and “Bluetooth” is “Low”. All others are set to “Off”. 0 This cannot be set when the sound mode is set to “Direct”. 0 “Restorer” settings are stored for each input source.
Contents Connections Playback Settings Appendix o Limit Audio Delay Make a setting for maximum volume. Compensates for incorrect timing between video and audio. 60 (–20 dB) / 70 (–10 dB) / 80 (0 dB) 0 ms – 200 ms (Default : 0 ms) Off (Default) o Power On Level “Audio Delay” settings are stored for each input source. Define the volume setting that is active when the power is turned on. Volume Set the MAIN ZONE (room where the unit is located) volume setting.
Contents Connections Playback Settings Tips Appendix o MultEQ® Audyssey MultEQ® compensates for both time and frequency characteristics of the listening area based on “Audyssey® Setup” measurement results. Selection is done from three types of compensation curves. We recommend the “Reference” setting. Set Audyssey MultEQ®, Audyssey Dynamic EQ® and Audyssey Dynamic Volume®. These can be selected after Audyssey® Setup has been performed.
Contents Connections Playback Settings o Dynamic EQ Tips Appendix o Ref.Lev.Offset Solves the problem of deteriorating sound quality as volume is decreased by taking into account human perception and room acoustics. Works with MultEQ®. On (Default): Use Dynamic EQ. Off: Do not use Dynamic EQ. Audyssey Dynamic EQ® is referenced to the standard film mix level. It makes adjustments to maintain the reference response and surround envelopment when the volume is turned down from 0 dB.
Contents Connections Playback Settings o Dynamic Volume Most adjustment to softest and loudest sounds. Medium: Medium adjustment to loudest and softest sound. Light: Least adjustment to loudest and softest sounds. Off (Default): Do not use Dynamic Volume. Uses the graphic equalizer to adjust the tone of each speaker. 0 Speakers for which “Manual EQ” can be set differ according to the sound mode. 0 This can be set when the “MultEQ®” setting is “Off”. (v p.
Contents Connections Playback Settings o Speaker Select Tips o Curve Copy Select whether to adjust tones for individual speakers or for all speakers. All: Adjust all speaker tones together. Left/Right (Default) : Adjust the left and right speaker tones together. Each: Adjust the tone for each speaker. Copy the flat correction curve created in the Audyssey® Setup. “Curve Copy” is displayed after Audyssey® Setup has been performed.
Contents Connections Playback Settings Tips Appendix Video Make video-related settings. o HDMI Audio Out HDMI Setup Select HDMI audio output device. Make settings for HDMI video/audio output. NOTE When “HDMI PassThrough” and “HDMI Control” is set to “On”, it consumes more standby power. If you are not using this unit for an extended period, it is recommended that you unplug the power cord from the power outlet. o Auto Lip Sync Correct automatically. Off: Do not correct automatically.
Contents Connections Playback Settings o HDMI Control Tips o Pass Source You can link operations with devices connected to HDMI and compatible with HDMI Control. On: Use HDMI control function. Off (Default): Do not use HDMI control function. Sets the HDMI connector that inputs HDMI signals when in standby. 0 Please consult the operating instructions for each connected device to check the settings. 0 Refer to “HDMI control function” for more information about the HDMI control function. (v p.
Contents Connections Playback Settings Tips o TV Audio Switching Sets automatic switching to the “TV Audio” input when a TV connected via HDMI sends an appropriate CEC control command to the AVR. On (Default): Select the TV Audio input automatically when receiving a command from the TV. Off: Do not select the TV Audio input automatically when receiving a command from the TV. o Pow.Off Control Links the power standby of this unit to external devices.
Contents Connections Playback Settings Tips Appendix o Now Playing On Screen Disp. Select the on-screen display user interface preferences. Sets the display time for the playback display when the input source is “Online Music”, “iPod/USB”, “Bluetooth” or “Tuner”. o Volume Always On (Default) : Show display continuously. Auto Off: Show display for 30 seconds after operation. Sets where to display the volume level. Bottom (Default): Top: Off: Display at the bottom. Display at the top.
Contents Connections Playback Settings Tips TV Format Set the video signal format to be output for the TV you are using. o Format NTSC (Default): Select NTSC output. PAL: Select PAL output. “Format” can also be set by the following procedure. However, the menu screen is not displayed. Following the display content to make the setting. 1. Press and hold the main unit’s TUNER PRESET CH + and TUNE + for at least 3 seconds. “V.Format:” appears on the display. 2.
Contents Connections Playback Settings Tips Appendix Inputs Perform settings related to input source playback. You do not have to change the settings to use the unit. Make settings when needed. Input Assign By default, each item is set as follows. By making connections as indicated by the input sources printed on the audio/video input connectors of this unit, you can just press one of the input source select buttons to easily play back audio or video from a connected device.
Contents Connections Playback Settings o HDMI Tips Appendix o ANALOG Set this to change the HDMI input connectors assigned to the input sources. Set this to change the analog audio input connectors assigned to the input sources. 1 / 2 / 3 / 4(4K) / 5(4K) / FRONT: Assign an HDMI input connector to the selected input source. 1/2: –: Do not assign an HDMI input connector to the selected input source. –: Assign a analog audio input connector to the selected input source.
Contents Connections Playback Settings Source Rename This function corrects the playback level of the selected input source’s audio input. Make this setting if there are differences in the input volume levels between the different sources. -12 dB – +12 dB (Default : 0 dB) CBL/SAT / DVD/Blu-ray / Blu-ray / Game / AUX / Change the display name for input source. Media Player / TV Audio: “Source Level” settings are stored for each input source.
Contents Connections Playback Settings Tips o Decode Mode Input Select Set the audio decode mode for input source. It is normally recommended to set the audio input mode to “Auto”. But we recommend changing it to “PCM” or “DTS” if the start of the source is clipped or noise occurs. Set the audio input mode and decode mode of each input source. The input modes available for selection may vary depending on the input source. “Input Select” settings are stored for each input source.
Contents Connections Playback Settings Tips Appendix Speakers The acoustic characteristics of the connected speakers and listening room are measured and the optimum settings are made automatically. This is called “Audyssey® Setup”. You do not have to perform Audyssey® Setup when you have already performed “Sp.Calibration” in “Setup Assistant”. To set up the speakers manually, use “Manual Setup” on the menu. (v p.
Contents Connections Playback Settings o About the main listening position Display Appendix NOTE The main listening position is the position where listeners would normally sit or where one would normally sit alone within the listening environment. Before starting Audyssey® Setup, place the Sound calibration microphone in the main listening position.
Contents Connections Playback Settings Procedure for speaker settings (Audyssey® Setup) 1 Tips Appendix Attach the Sound calibration microphone to the supplied 3-legged stand or enclosed stand and install it at the main listening position. When installing the Sound calibration microphone, point the tip of the microphone toward the ceiling and adjust the height to match the height of the ears of a listener in a seated position.
Contents Playback Settings 4 Connect the Sound calibration microphone to the SETUP MIC jack of this unit. Tips Appendix Select “Next”, then press ENTER. Audyssey Setup Set the following items if necessary. Amp Assign Channel Select Check Results Restore... When the Sound calibration microphone is connected, the following screen is displayed. Start . Back 5 .
Contents Settings 8 Follow the instructions on the screen display and press “Next” to proceed further. Tips When the following screen is displayed, select “Begin Test” and then press ENTER. Audyssey Setup Speaker Detection Start the measurement of the first position. Front Center Subwoofer Surround S. Back Speaker Calibration Place the microphone at ear level at the main listening position. Make sure you are always 20 inches (50cm) from the back wall of your room for each test.
Contents Playback Settings 10 11 Move the Sound calibration microphone to position 2, select “Continue”, then press ENTER. The measurement of the second position starts. Measurements can be made in up to six positions. Tips Appendix Repeat step 9, measuring positions 3 to 6. Select “Complete”, then press ENTER. Audyssey Setup Measurements Complete Select “Continue” to analyze the data...
Contents 12 Connections Playback Settings Perform the settings for Audyssey Dynamic EQ® and Audyssey Dynamic Volume®. Tips 0 Dynamic EQ corrects the frequency response in consideration of the audio characteristics of the room and human hearing ability so that sound can be heard even at low volume. This is recommended when using the unit with the volume turned down, e.g. when enjoying a movie or TV program in the middle of the night.
Contents 13 Connections Playback Settings 14 When the analysis and storage ends, unplug the Sound calibration microphone from the SETUP MIC jack on the main unit and then press “Next”. Tips Appendix Select “Details” and press ENTER to verify the measurement results. 0 Subwoofers may measure a greater reported distance than the actual distance due to added electrical delay common in subwoofers. Audyssey Setup Now Analyzing and correcting the your room data.
Contents Connections Playback Settings Tips Appendix Error messages An error message is displayed if Audyssey® Setup could not be completed due to speaker placement, the measurement environment, etc. If an error message is displayed, check the relevant items and perform the necessary measures. Be sure to turn off the power before checking speaker connections. Examples Error details No speakers found.
Contents Connections Playback Settings Tips Retrieving Audyssey® Setup settings If you set “Restore...” to “Restore”, you can return to Audyssey® Setup measurement result (value calculated at the start by MultEQ®) even when you have changed each setting manually. Audyssey Setup Set the following items if necessary. Amp Assign Channel Select Check Results Restore... Start .
Contents Connections Playback Settings Manual Setup Appendix Amp Assign Select power amplifier usage method to match your speaker system. See “Speaker configuration andAmp Assignsettings” (v p. 31) regarding the speaker configuration and connection. Perform when setting the speakers manually or when changing settings made in Audyssey® Setup.
Contents Connections Playback Settings Appendix o Subwoofer Speaker Config. Set the presence of a subwoofer. Select whether or not speakers are present, playback capacity for low bass frequencies and speaker size. o Front Set the front speaker size. Large (Default): Use a large speaker that can adequately play back very low bass frequencies. Small: Use a small speaker that has inadequate playback capacity for very low bass frequencies.
Contents Connections Playback Settings o Surround Back Tips Appendix o Front Height Set the presence, size and number of surround back speakers. Set the presence and size of the front height speakers. Large: Use a large speaker that can adequately play back very low bass frequencies. Large: Use a large speaker that can adequately play back very low bass frequencies. Small (Default): Use a small speaker that has inadequate playback capacity for very low bass frequencies.
Contents Connections Playback Settings Tips o Set the distance Distances 0.0 ft – 60.0 ft / 0.00 m – 18.00 m Set distance from listening position to speakers. Measure beforehand the distance from the listening position to each speaker. 0 The speakers that can be selected differ depending on the “Amp Assign” and “Speaker Config.” settings. (v p. 167, 168) 0 Default settings : Front L / Front R / Front Height L / Front Height R / Center / Subwoofer: 12.0 ft (3.
Contents Connections Playback Settings Tips Levels Set the volume of the test tone to be the same at the listening position when it is output from each speaker. o Test Tone Start A test tone is output from the selected speaker. While listening to the test tone, adjust the volume output from the selected speaker. –12.0 dB – +12.0 dB (Default : 0.0 dB) 0 The set “Levels” are reflected in all sound modes.
Contents Connections Playback Settings Tips Appendix o Set the crossover frequency Crossovers 40 Hz / 60 Hz / 80 Hz / 90 Hz / 100 Hz / 110 Hz / 120 Hz / 150 Hz / 200 Hz / 250 Hz (Default : 80 Hz) Set in accordance with the lower limit frequency of the base frequencies that can be played back through each speaker. See the speaker manual for information concerning speaker crossover frequency.
Contents Connections Playback Settings Tips o LPF for LFE Bass Set LFE signal playback range. Set this when you want to change the playback frequency (low pass filter point) of the subwoofer. Set subwoofer and LFE signal range playback. 80 Hz / 90 Hz / 100 Hz / 110 Hz / 120 Hz / 150 Hz / 200 Hz / 250 Hz (Default : 120 Hz) o Subwoofer Mode Select low range signals to be reproduced by subwoofer.
Contents Connections Playback Settings Tips Appendix Network To use this unit by connecting it to a home network (LAN), you must configure network settings. If you set up your home network (LAN) via DHCP, set “DHCP” to “On”. (Use the default setting.) This allows this unit to use your home network (LAN).
Contents Connections Playback Settings Appendix n When connecting using Wi-Fi Wi-Fi Setup 1. Select “Wireless connection” on the TV screen. 2. Check that your iOS device is connected to the wireless LAN (Wi-Fi) router and select “Denon AVR-S700W” from “SET UP NEW AIRPLAY SPEAKER...” at the bottom of the Wi-Fi configuration screen of your iOS device. 3. Tap “Next” on the screen of the iOS device. Connect to a wireless LAN (Wi-Fi) router. The router can be connected in the following ways.
Contents Connections Playback Settings o WPS Router Tips Appendix o Manual Use a WPS-compatible router to connect. There are two ways to connect, using the push button method or the PIN code method. Select the connection method to match your router. Enter the name (SSID) and password of the network you wish to connect to. 1. Set the following items. n When connecting using the push button method 1. Select “Push Button” on the TV screen. 2.
Contents Connections Playback Settings Tips o IP Address Settings Set the IP address within the ranges shown below. Configure the proxy settings and IP address. 0 If you are using a broadband router (DHCP function), the information required for network connection such as the IP address will be automatically configured since the DHCP function is set to “On” in the default settings of this unit.
Contents Connections Playback Settings o Proxy Select when inputting by address. On(Name): Select when inputting by domain name. Off (Default): Disables the proxy server. Enables network communication in standby power mode. Off In Standby: Suspend network function during standby. Always On (Default) : Network is on during standby. Main unit operable with a network compatible controller. When using Denon Remote App use with the “IP Control” setting set to “Always On”.
Contents Connections Playback Settings Friendly Name Tips Appendix Diagnostics The Friendly Name is the name of this unit displayed on the network. You can change the Friendly Name according to your preferences. Used to check the network connection. o Physical Connection o Name Checks the physical LAN port connection. Selects Friendly Name from the list. When you select “Other”, you can change the Friendly Name according to your preferences. OK Error: The LAN cable is not connected.
Contents Connections Playback Settings Tips Appendix General Make various other settings. Language ECO Set the language for display the menu on the TV screen. Configure the settings of the ECO Mode and auto standby mode. English / Français / Español (Default : English) o ECO Mode This can reduce the power consumption when the power of the unit is on. “Language” can also be set up by the following operation. However, the menu screen is not displayed.
Contents Connections Playback Settings o Pow.On Default Set so the unit power automatically switches to standby. Last (Default) : The ECO Mode will be set to the previous setting before the power was switched off. On: When power is turned on, the mode will always be switched to the ECO Mode in “On”. Auto: When power is turned on, the mode will always be switched to the ECO Mode in “Auto”.
Contents Connections Playback Settings Appendix o Volume Limit ZONE2 Setup Make a setting for maximum volume. Configure the settings for audio playback on ZONE2. 60 (-20 dB) / 70 (-10 dB) / 80 (0 dB) (Default : 70 (-10 dB)) Off: Values set for “Volume Limit” and “Pow.On Volume” are displayed according to the setting specified for the volume “Scale” (v p. 143). o Volume Level Do not set a maximum volume. This can be set when “Volume Level” is set to “Variable”. (v p.
Contents Connections Playback Settings Zone Rename Tips Front Display Change the display title of each zone to one you prefer. Makes settings related to the display on this unit. MAIN ZONE / ZONE2 o Dimmer Set Defaults: The default setting is restored for the edited zone name. Adjust the display brightness of this unit. Bright (Default) : Up to 10 characters can be input. For character input, see “Using the keyboard screen” (v p. 136). Quick Sel.
Contents Connections Playback Settings Tips o Video Information Show the HDMI input/output signals and HDMI monitor information for MAIN ZONE. HDMI Signal Show information about this unit settings, input signals, etc. o Audio Resolution / Color Space / Pixel Depth Show the audio information for MAIN ZONE. Sound Mode: The currently set sound mode. HDMI Monitor Input Signal: The input signal type.
Contents Connections Playback Settings o Notifications To help us improve our products and customer service, Denon collects anonymous information about how you use your AV receiver (such as frequently used input sources and sound modes and speaker settings). Denon will never provide any information we collect to third parties. n Notif.Alerts Notification messages are displayed. Off: Notification messages are not displayed. Yes: Provide information on the operating status of this unit.
Contents Connections Playback Settings Tips o Notifications Firmware When the latest firmware is available, a notification message is displayed on the TV screen at power on. The notification message is displayed for about 40 seconds when the power is turned on. Update Checks for the latest firmware information about updates and upgrades, updates the firmware, and sets up the notification message display for updates and upgrades. o Update Updates the firmware of this unit.
Contents Connections Playback Settings o Add New Feature Appendix Notes concerning use of “Update” and “Add New Feature” Display new features that can be downloaded to this unit and perform an upgrade. Upgrade Package: Display the items to be upgraded. Upgrade Status: Display a list of the additional functions provided by the upgrade. Upgrade Start: Execute the upgrade process. When the upgrade starts, the menu screen is shut down.
Contents Connections Playback Settings Tips Setup Lock Protect settings from inadvertent changes. o Lock On: Turn protection on. Off (Default): Turn protection off. When cancelling the setting, set “Lock” to “Off”. NOTE When “Lock” is set to “On”, no setting items are displayed except for “Setup Lock”.
Contents Connections Playback Settings Tips Appendix o Contents Troubleshooting Tips Power does not turn on / Power is turned off 193 Operations cannot be performed through the remote control unit 194 Display on this unit shows nothing 194 No sound comes out 195 Desired sound does not come out 196 Sound is interrupted or noise occurs 198 199 I want the volume not to become too loud by mistake 190 I want to keep the volume at the same level when I turn the power on 190 I want to have
Contents Connections Playback Settings Tips Appendix Tips I want the volume not to become too loud by mistake 0 Set the volume upper limit for “Volume Limit” in the menu beforehand. This prevents children or others from increasing the volume too much by mistake. You can set this for each zone. (v p.
Contents Connections Playback Settings Tips Appendix I want to set the optimized listening environment after changing the configuration/position of the speakers or changing a speaker to a new one. 0 Perform Audyssey® Setup. This automatically makes the optimized speaker settings for the new listening environment. (v p. 157) I want to combine a desired video with the current music 0 Set “Video Select” in the option menu to “On”.
Contents Connections Playback Settings Tips Appendix Troubleshooting If a problem should arise, first check the following: 1. Are the connections correct? 2. Is the set being operated as described in the owner’s manual? 3. Are the other devices operating properly? If this unit does not operate properly, check the corresponding symptoms in this section. If the symptoms do not match any of those described here, consult your dealer as it could be due to a fault in this unit.
Contents Connections Playback Settings Tips Appendix o Power does not turn on / Power is turned off Symptom Cause / Solution Page Power does not turn on. 0 Check whether the power plug is correctly inserted into the power outlet. 50 Power automatically turns off. 0 The sleep timer is set. Turn on the power again. 123 0 “Auto Standby” is set. “Auto Standby” is triggered when there is no operation for a set amount of time. To 181 Power turns off and the power indicator flashes in red approx.
Contents Connections Playback Settings Tips Appendix o Operations cannot be performed through the remote control unit Symptom Operations cannot be performed through the remote control unit. Cause / Solution Page 0 Batteries are worn out. Replace with new batteries. 8 0 Operate the remote control unit within a distance of about 23 ft/7 m from this unit and at an angle of within 8 30°. 0 Remove any obstacle between this unit and the remote control unit.
Contents Connections Playback Settings Tips Appendix o No sound comes out Symptom No sound comes out of speakers. Cause / Solution Page 0 Check the connections for all devices. 28 0 Insert connection cables all the way in. - 0 Check that input connectors and output connectors are not reversely connected. - 0 Check cables for damage. - 0 Check that speaker cables are properly connected.Check that cable core wires come in contact with the 28 0 Securely tighten the speaker terminals.
Contents Connections Playback Settings Tips Appendix o Desired sound does not come out Symptom The volume does not increase. Cause / Solution Page 0 The maximum volume is set too low. Set the maximum volume using “Limit” on the menu. 0 Appropriate volume correction processing is performed according to the input audio format and settings, so the volume may not reach the upper limit. No sound comes out with the HDMI connection. 0 Check the connection of the HDMI connectors.
Contents Connections Playback Symptom Settings Tips Cause / Solution Appendix Page Dolby PLg mode or DTS Neo:6 mode cannot be selected. 0 It cannot be selected when “Speaker Config.” - “Center” or “Surround” is set for “None”. Audyssey MultEQ®, Audyssey Dynamic EQ® and Audyssey Dynamic Volume® cannot be selected. 0 These cannot be selected when you have not performed Audyssey® Setup. 157 0 Switch to a sound mode other than “Direct”. 113 “Restorer” cannot be selected.
Contents Connections Playback Settings Tips Appendix o Sound is interrupted or noise occurs Symptom During playback from the Internet radio or USB memory device, sound is occasionally interrupted. Cause / Solution Page 0 When the transfer speed of the USB memory device is slow, sound may occasionally be interrupted. - 0 The network communication speed is slow or the radio station is busy. - When making a call on iPhone, noise occurs in audio output on this unit.
Contents Connections Playback Settings Tips Appendix o No video is shown on the TV Symptom No picture appears. Cause / Solution Page 0 Check the connections for all devices. 37 0 Insert connection cables all the way in. - 0 Check that input connectors and output connectors are not reversely connected. - 0 Check cables for damage. - 0 Match the input settings to the input connector of the TV connected to this unit. 153 0 Check that the proper input source is selected.
Contents Connections Playback Settings Tips Appendix o The menu screen is not displayed on the TV Symptom The menu screen or status information screen is not displayed on the TV. Cause / Solution Page 0 The menu screen is only displayed on this unit and a TV connected with an HDMI cable. If this unit is connected to a TV using a different video output connector, operate while watching the display on this unit.
Contents Connections Playback Settings Tips Appendix o iPod cannot be played back Symptom Cause / Solution Page iPod cannot be connected. 0 When using iPod by connecting it to the USB port, some iPod variations are not supported. 0 When iPod is connected by using a USB cable other than the genuine cable, iPod may not be - 0 This unit and PC / iPhone / iPod touch / iPad are not connected to the same network (LAN).
Contents Connections Playback Settings Tips Appendix o USB memory devices cannot be played back Symptom “No connection” is displayed. Cause / Solution Page 0 This unit cannot recognize the USB memory device. Disconnect and reconnect the USB memory device. 44 0 Mass storage class compatible USB memory devices are supported. - 0 This unit does not support a connection through a USB hub. Connect the USB memory device directly to - 0 The USB memory device must be formatted to FAT16 or FAT32.
Contents Connections Playback Settings Tips Appendix o File names on the iPod/USB memory device are not displayed properly Symptom The file names are not displayed properly (“...”, etc.). Cause / Solution Page 0 Characters that cannot be displayed have been used. On this unit, characters that cannot be displayed are replaced with a “. (period)”. - o Bluetooth cannot be played back Symptom Bluetooth devices cannot be connected to this unit. The sound is cut off.
Contents Connections Playback Settings Tips Appendix o The Internet radio cannot be played back Symptom Cause / Solution Page A list of broadcasting stations is not displayed. 0 The LAN cable is not properly connected, or the network is disconnected. Check the connection status. Internet Radio cannot be played. 0 The selected radio station is broadcasting in a format that is not supported by this unit. Formats that can 0 Perform the network diagnostic mode.
Contents Connections Playback Settings Tips Appendix o Music files on PC or NAS cannot be played back Symptom Files stored on a computer cannot be played. Cause / Solution Page 0 Files are stored in a non-compatible format. Record in a compatible format. 214 0 Files that are copyright protected cannot be played on this unit. - 0 The set’s USB port cannot be used for connection to a computer. - 0 Media sharing settings are not correct.
Contents Connections Playback Settings Tips Appendix o The HDMI control function does not work Symptom The HDMI control function does not work. Cause / Solution Page 0 Check that “HDMI Control” in the menu is set to “On”. 149 0 You cannot operate devices that are not compatible with the HDMI control function. In addition, 122 0 Check that the HDMI control function setting is enabled on all devices connected to this unit.
Contents Connections Playback Settings Tips Appendix o Cannot connect to a wireless LAN network Symptom Cannot connect to the network. Cause / Solution Page 0 The network name (SSID), password and encryption setting have not been set up correctly. Configure the 176 0 Shorten the distance from the wireless LAN access point and remove any obstructions to improve access - network settings according to the setting details of this unit. first before re-connecting again.
Contents Connections Playback Settings Tips Appendix Resetting factory settings Perform this procedure if the display is abnormal or if operations cannot be performed. Various settings are reset to the factory default values. Make settings again. X 1 2 TUNER PRESET CH – . 3 Front panel Press X while simultaneously pressing TUNER PRESET CH + and TUNER PRESET CH -. Remove your fingers from the two buttons when “Initialized” appears on the display.
Contents Connections Playback Settings Tips Appendix About HDMI HDMI is an abbreviation of High-Definition Multimedia Interface, which is an AV digital interface that can be connected to a TV or amplifier. With the HDMI connection, high definition video and high quality audio formats adopted by Blu-ray Disc players (Dolby Digital Plus, Dolby TrueHD, DTS-HD, DTS-HD Master Audio) can be transmitted, which is not possible with the analog video transmission.
Contents Connections Playback Settings 0 Auto Lip Sync 0 ARC (Audio Return Channel) This function can automatically correct delay between the audio and video. Use a TV that is compatible with the Auto Lip Sync function. Even when the power to this unit is set to standby, signals input from the HDMI input connector are output to a TV or other device that is connected to the HDMI output connector.
Contents Connections Playback Settings o Supported audio formats 2-channel, 32 kHz – 192 kHz, 16/20/24 bit Multi-channel Linear PCM 7.1-channel, 32 kHz – 192 kHz, 16/20/24 bit In order to play back digital video and audio such as BD video or DVD video via HDMI connection, both this unit and the TV or player must to support the copyright protection system known as HDCP (Highbandwidth Digital Content Protection System).
Contents Connections Playback Settings Tips Appendix Playing back a USB memory devices 0 This unit is compatible with MP3 ID3-Tag (Ver. 2) standard. 0 This unit can show the artwork that was embedded by using MP3 ID3-Tag Ver. 2.3 or 2.4. 0 This unit is compatible with WMA META tags. 0 If the image size (pixels) of an album artwork exceeds 500 × 500 (WMA/MP3/WAV/FLAC) or 349 × 349 (MPEG-4 AAC), then music may not be played back properly.
Contents Connections Playback Settings o Maximum number of playable files and folder Item Memory capacity USB memory device 8 levels Number of folders 500 filesz2 5000 Number of This unit supports the following Bluetooth profile. 0 A2DP (Advanced Audio Distribution Profile): When a Bluetooth device that supports this standard is connected, monaural and stereo sound data can be streamed at a high quality.
Contents Connections Playback Settings Tips Appendix Playing back a file saved on a PC or NAS 0 This unit is compatible with MP3 ID3-Tag (Ver. 2) standard. 0 This unit can show the artwork that was embedded by using MP3 ID3-Tag Ver. 2.3 or 2.4. 0 This unit is compatible with WMA META tags. 0 If the image size (pixels) of an album artwork exceeds 500 × 500 (WMA/MP3/WAV/FLAC) or 349 × 349 (MPEG-4 AAC), then music may not be played back properly.
Contents Connections Playback Settings Tips Appendix Playing back Internet Radio Personal memory plus function o Playable broadcast station specifications The most recently used settings (input mode, HDMI output mode, sound mode, tone control, channel level, MultEQ®, Dynamic EQ, Dynamic Volume, Restorer and audio delay, etc.) are saved for each input source. WMA (Windows Media Audio) MP3 (MPEG-1 Audio Layer-3) MPEG-4 AAC Front panel Sampling frequency 32/44.
Contents Connections Playback Settings Tips Appendix Sound modes and channel output S This indicates the audio output channels or surround parameters that can be set. D This indicates the audio output channels. The output channels depend on the settings of “Speaker Config.”. (v p. 168) Channel output Sound mode (v p.
Contents Connections Playback Settings Tips Appendix Sound modes and surround parameters Surr.Parameter (v p. 138) Sound mode (v p. 111) Dialog Level (v p. 137) Subwoofer Level (v p. 137) Direct (2-channel) Direct (Multi-channel) S Stereo Cinema EQ (v p. 138) Loudness Mngmt z1 (v p. 138) Dynamic Comp. z2 (v p. 139) S z5 S S S S S S S S Low Frequency z3 (v p. 139) Delay Time (v p. 140) Effect Level (v p. 140) Room Size (v p. 141) Height Gain z4 (v p.
Contents Connections Playback Settings Tips Surr.Parameter (v p. 138) Sound mode (v p. 111) Pro Logicg/gx Music mode only Neo: 6 Music mode only Panorama Dimension Center Width Center Image (v p. 139) (v p. 140) (v p. 140) (v p. 139) Tone Control z6 (v p. 108) Appendix Audyssey (v p. 144) MultEQ®z7 (v p. 144) z8 Dynamic EQ (v p. 145) Dynamic Volume (v p. 146) z8 Restorer z9 (v p.
Contents z1 z2 z3 z4 z5 z6 z7 Connections Playback Settings Tips This item can be selected when a Dolby TrueHD signal is played. This item can be selected when Dolby TrueHD, Dolby Digital or DTS signal is played. This item can be selected when a Dolby Digital or DTS signal or DVD-Audio is played. This setting is available when the set sound mode name contains “+PLgz”. This setting is available when “Subwoofer Mode” in the menu is set to “LFE+Main”. (v p.
Contents Connections Playback Settings Tips Appendix Types of input signals, and corresponding sound modes F This indicates the default sound mode. S This indicates the selectable sound mode. 2-channel signal Sound mode (v p. 111) NOTE Analog /PCM Multi-channel signal Dolby Digital PCM DTS-HD DTS Express (+/HD)/DTS (-HD) Multi DTS DTS DTS Dolby TrueHD Dolby Digital Plus Dolby Digital EX Dolby Digital ES ES DSCRT MTRIX 6.1 6.1 DTS Surround DTS-HD Mstr Fz6 DTS-HD Hi Res Fz7 DTS ES Dscrt6.
Contents Connections Playback Settings Tips 2-channel signal Sound mode (v p. 111) NOTE Analog /PCM Appendix Multi-channel signal Dolby Digital PCM DTS-HD DTS Express (+/HD)/DTS (-HD) Multi DTS DTS DTS Dolby TrueHD Dolby Digital Plus Dolby Digital EX Dolby Digital ES ES DSCRT MTRIX 6.1 6.1 Multi Ch In Multi Ch In Multi Ch In + Dolby EX Multi Ch In + PLgx F z1 S z1z2 S Multi Ch In + PLgz z3 S Multi Ch In 7.
Contents z1 z2 z3 z4 z5 z6 z7 z8 z9 z10 Connections Playback Settings Tips This item can be selected when surround back speakers are used. The “Cinema” mode or “Music” mode can be selected. When using a single surround back speaker, the “Music” mode is used. This item can be selected when front height speakers are used. The “Cinema” mode or “Music” mode can be selected. The “Cinema” mode, “Music” mode or “Game” mode can be selected.
Contents Connections Playback Settings Tips Appendix Explanation of terms o Audyssey Audyssey MultEQ® Audyssey MultEQ® is a room equalization solution that calibrates any audio system so that it can achieve optimum performance for every listener in a large listening area. Based on several room measurements, MultEQ® calculates an equalization solution that corrects for both time and frequency response problems in the listening area and also performs a fully automated surround system setup.
Contents Connections Playback Settings Tips Appendix Dolby Digital Plus Dolby Pro Logic g Dolby Digital Plus is an improved Dolby Digital signal format that is compatible with up to 7.1-channels of discrete digital sound and also improves sound quality thanks to extra data bit rate performance. It is upwardly compatible with conventional Dolby Digital, so it offers greater flexibility in response to the source signal and the conditions of the playback device.
Contents Connections Playback Settings Appendix o DTS Dolby Pro Logic gz Dolby Pro Logic gz introduces a new dimension to Home Entertainment through the addition of a pair of front height channels. This supports various sources such as 2-channel sources and 7.1/5.1 multi-channel sources. By adding height speakers to the upper left and right locations in the front of the listening environment, you can enjoy more spatial spread feel and depth feel when you play back movies/music/games.
Contents Connections Playback Settings Tips Appendix DTS-ES™ Discrete 6.1 DTS-HD High Resolution Audio DTS-ES™ Discrete 6.1 is a 6.1-channel discrete digital audio format adding a surround back (SB) channel to the DTS digital surround sound. Decoding of conventional 5.1-channel audio signals is also possible according to the decoder.
Contents Connections Playback Settings o Audio This is a codec for lossless audio compression method developed by Apple Inc. This codec can be played back on iTunes, iPod or iPhone. Data compressed to approximately 60 – 70 % can be decompressed to exactly the same original data. FLAC (Free Lossless Audio Codec) FLAC stands for Free lossless Audio Codec, and is a lossless free audio file format. Lossless means that the audio is compressed without any loss in quality. The FLAC license is as shown below.
Contents Connections Playback Settings Tips Appendix MPEG (Moving Picture Experts Group), MPEG-2, MPEG-4 Sampling frequency These are the names for digital compression format standards used for the encoding of video and audio. Video standards include “MPEG-1 Video”, “MPEG-2 Video”, “MPEG-4 Visual”, “MPEG-4 AVC”. Audio standards include “MPEG-1 Audio”, “MPEG-2 Audio”, “MPEG-4 AAC”.
Contents Connections Playback Settings Tips Appendix o Video o Network ISF AES (Advanced Encryption Standard) ISF (Imaging Science Foundation) is an organization that certifies video technicians who are then qualified to carry out calibration and adjustment to match the installation conditions. It also sets quality standards for the optimization of device video performance.
Contents Connections Playback Settings Tips Appendix TKIP (Temporal Key Integrity Protocol) Wi-Fi® This is a network key used for WPA. The encryption algorithm is RC4, the same as for WEP, but the security level is increased by changing the network key used for encryption for each packet. Wi-Fi Certification assures tested and proven interoperability by the Wi-Fi Alliance, a group certifying interoperability among wireless LAN devices.
Contents Connections Playback Settings When forming wireless LAN networks, groups are formed to prevent interference, data theft, etc. These groups are based on “SSID (network names)”. For enhanced security, a WEP key is set so that communication is unavailable unless both the “SSID” and the WEP key match. This is suitable for temporarily constructing a simplified network. iTunes iTunes is the name of the multimedia player provided by Apple Inc.
Contents Connections Playback Settings o Others Tips Pairing Pairing (registration) is an operation that is required in order to connect a Bluetooth device to this unit using Bluetooth. When paired, the devices authenticate each other and can connect without mistaken connections occurring. When using Bluetooth connection for the first time, you need to pair this unit and the Bluetooth device to be connected. This unit can store pairing information for a maximum of 8 devices.
Contents Connections Playback Settings Tips Appendix Trademark information . . Manufactured under license from Audyssey Laboratories™. U.S. and foreign patents pending. Audyssey MultEQ®, Audyssey Dynamic EQ® and Audyssey Dynamic Volume® are registered trademarks of Audyssey Laboratories. .
Connections Playback Settings Tips Appendix . Contents Manufactured under a license from U.S. Patent No’s: 5,956,674; 5,974,380; 6,226,616; 6,487,535; 7,212,872; 7,333,929; 7,392,195; 7,272,567 & other U.S. and worldwide patents issued & pending. DTS-HD, the Symbol, & DTS-HD and the Symbol together are registered trademarks & DTS-HD Master Audio is a trademark of DTS, Inc. Product includes software. ©DTS, Inc. All Rights Reserved. . .
Contents Connections Playback Settings Tips Specifications o Audio section 0 Power amplifier Rated output: Front: 75 W + 75 W (8 Ω/ohms, 20 Hz – 20 kHz with 0.08 % T.H.D.) 110 W + 110 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.) Center: 75 W (8 Ω/ohms, 20 Hz – 20 kHz with 0.08 % T.H.D.) 110 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.) Surround: 75 W + 75 W (8 Ω/ohms, 20 Hz – 20 kHz with 0.08 % T.H.D.) 110 W + 110 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.) Surround back: 75 W + 75 W (8 Ω/ohms, 20 Hz – 20 kHz with 0.
Contents Connections Playback Settings Tips o Video section 0 Standard video connectors Input/output level and impedance: 1 Vp-p, 75 Ω/ohms Frequency response: 5 Hz – 10 MHz — 0, –3 dB o Tuner section [FM] [AM] (Note: μV at 75 Ω/ohms, 0 dBf = 1 x 10 –15 W) Reception frequency range: 87.5 MHz – 107.9 MHz 520 kHz – 1710 kHz Effective sensitivity: 1.2 μV (12.8 dBf) 18 μV 50 dB sensitivity: MONO ― 2.8 μV (20.
Contents Connections Playback Settings Tips o Wireless LAN section Network type (wireless LAN standard): Conforming to Wi-Fi®z1 Security: WEP 64 bit, WEP 128 bit WPA/WPA2-PSK (AES) WPA/WPA2-PSK (TKIP) Radio frequency: 2.4 GHz No. of channels: 1 – 11 ch z1 The Wi-Fi® CERTIFIED Logo and the Wi-Fi CERTIFIED On-Product Logo are registered trademarks of the Wi-Fi Alliance.
Contents Connections Playback Settings Tips Appendix o Bluetooth section Communications system: Bluetooth Version 2.1 + EDR (Enhanced Data Rate) Transmission power: Maximum 2.5 mW (Class 2) Maximum communication range: Approx. 32.8 ft/10 m in line of sightz2 Frequency band: 2.4 GHz band Modulation scheme: FHSS (Frequency-Hopping Spread Spectrum) Supported profiles: A2DP (Advanced Audio Distribution Profile) 1.2 AVRCP (Audio Video Remote Control Profile) 1.
Contents Connections Playback Settings Tips Appendix 1 27/32 (47) 3/4 (19) 1 47/64 (44) 7 3/4 (197) 13 11/32 (339) 11 11/32 (288) 1 7/32 (32) o Dimensions (Unit : in. (mm)) 2 23/64 (60) .1 49/64 (45) 13 35/64 (344) 8 15/32 (215) 5 15/16 (151) 19/32 (15) 5 23/64 (136) 17 3/32 (434) 1 49/64 (45) o Weight : 18 lbs 15 oz (8.
Contents Connections Index Playback Settings vC v Numerics 3D ................................................................ 209 4K ................................................................ 209 5.1-channel .............................................. 27, 32 7.1-channel ........................................ 27, 33, 34 Accessories ..................................................... 7 Add New Feature ......................................... 187 Adjusting the volume .....................
Contents Connections vI Settings vO Input Assign ................................................. 153 Input signal ................................................... 220 Input source settings ............................ 132, 153 Inputting characters ...................................... 135 Inserting the batteries ....................................... 8 iPod Browse Mode ......................................... 56 iTunes ..........................................................
Contents Connections Playback Settings Tips vT Text Search .................................................. 104 Tips .............................................................. 190 Tone Control ................................................ 108 Troubleshooting ........................................... 192 Turning off the sound temporarily (Muting) ..... 53 Turning the power on ..................................... 52 vV Video Select .................................................
