If you have questions or comments, contact us. Pour toute question ou tout commentaire, nous contacter. Si tiene dudas o comentarios, contáctenos. 1-800-4-DEWALT • www.dewalt.com INSTRUCTION MANUAL GUIDE D’UTILISATION MANUAL DE INSTRUCCIONES D25980 Heavy-Duty Pavement Breaker Brise-béton robuste Martillo rompedor para trabajos pesados INSTRUCTIVO DE OPERACIÓN, CENTROS DE SERVICIO Y PÓLIZA DE GARANTÍA. ADVERTENCIA: LÉASE ESTE INSTRUCTIVO ANTES DE USAR EL PRODUCTO.
3) PERSONAL SAFETY a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury. b) Use safety equipment. Always wear eye protection. Safety equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.
WARNING: ALWAYS wear proper personal hearing protection that conforms to ANSI S12.6 (S3.19) during use. Under some conditions and duration of use, noise from this product may contribute to hearing loss. • The label on your tool may include the following symbols. The symbols and their definitions are as follows: V.................. volts A .................... amperes Hz................ hertz W ................... watts .................. alternating current min .............. minutes no ...................
Use either of the above methods to insert combination steel (notch and ring bit) English ASSEMBLY Side Handle (Fig. 1) FIG. 2A FIG. 2B CAUTION: Always operate the tool with the side handle properly assembled. Hold tool with both hands to maximize control. Attach left side handle (C) with four hex head screws (H, supplied). Tighten with hex wrench supplied. FEATURES (FIG.
Repairs Specifications Three Year Limited Warranty DEWALT will repair, without charge, any defects due to faulty materials or workmanship for three years from the date of purchase. This warranty does not cover part failure due to normal wear or tool abuse. For further detail of warranty coverage and warranty repair information, visit www. dewalt.com or call 1-800-4-DEWALT (1-800-433-9258). This warranty does not apply to accessories or damage caused where repairs have been made or attempted by others.
SI VOUS AVEZ DES QUESTIONS OU VOULEZ NOUS FAIRE PART DE VOS COMMENTAIRES CONCERNANT CET OUTIL OU TOUT AUTRE OUTIL DEWALT, COMPOSEZ SANS FRAIS LE : 1 800 433-9258.
tées d’aucune condition susceptible de nuire au bon fonctionnement de l’outil. En cas de dommage, faire réparer l’outil électrique avant toute nouvelle utilisation. Bien des accidents sont causés par des outils mal entretenus. f) Maintenir tout outil de coupe bien aiguisé et propre. Les outils de coupe bien entretenus et affûtés sont moins susceptibles de se coincer et sont plus faciles à contrôler. g) Utiliser un outil électrique, ses accessoires, mèches, etc.
COMPOSANTS (FIG. 1) SHOCKSTM – dispositif antivibrations actif REMARQUE : toutes les indications qui font référence à la droite ou la gauche correspondent au point de vue de l’opérateur qui est debout, derrière le brise-béton. L’avant de l’outil est à l’opposé de l’opérateur. A. Interrupteur marche/arrêt F. Correcteur antivibrations actif B. Poignée droite G. Avant de l’outil C. Poignée gauche H. Vis à tête hexagonale D. Dispositif de retenue de l’embout I. Évents E.
POUR INSÉRER DES TRÉPANS MÉTALLIQUES (TRÉPAN À ENCOCHE SEULEMENT) 1. Retirer le dispositif de retenue du trépan (D) comme le montre la figure 3a. 2. Insérer le trépan de manière à ce que l’encoche (J) soit vers le haut, dans le portemèche (E). 3. Relever le dispositif de retenue du trépan pour le verrouiller en place comme le montre la figure 3b. Utiliser une des méthodes précédentes pour insérer les trépans métalliques combinés (encoche et anneau). par la présente garantie, visiter le site www.dewalt.
Reglas de seguridad generales Calibre mínimo para juegos de cables Voltios Largo total del cable en metros (en pies) Capacidad nominal 120V 7,6 (25) 15,2 (50) 30,5 (100) 45,7 (150) en amperios 240V 15,2 (50) 30,5 (100) 61,0 (200) 91,4 (300) Desde Hasta AWG 0 6 18 16 16 14 6 10 18 16 14 12 10 12 16 16 14 12 12 16 14 12 No recomendado ¡ADVERTENCIA! Para reducir el riesgo de lesiones, el usuario debe leer el manual de instrucciones.
e) Mantenga su máquina herramienta. Revise la máquina herramienta para verificar que no esté mal alineada, que sus piezas móviles no estén trabadas o rotas y que no exista otra condición que pudiera afectar su operación. Si está dañada, haga reparar la máquina herramienta antes de utilizarla. Muchos accidentes son causados por usar máquinas herramienta que no han sido bien mantenidas. f) Mantenga máquinas herramienta que son usadas para cortar afiladas y limpias.
............ Construcción Clase II ............... (con aislamiento doble) Arranque suave …/min .......Revoluciones o reciprocidad por minuto BPM ..........golpes por minuto Si sostiene la herramienta con ambos mangos se oprime el interruptor de ENCENDIDO/ APAGADO (A). La función de arranque suave permite que la velocidad de impacto se acumule más lentamente para evitar que la broca o punta rebote en la superficie.
PARA INSERTAR AIRE EN LAS BROCAS DE ACERO (BROCA DE UN SÓLO ANILLO) 1. Tire para abrir el dispositivo de retención de la broca (D) como se observa en la Figura 2. 2. Inserte la broca en el portabrocas (E) y cierre el dispositivo de retención en la broca como se observa en la Figura 2b. PARA REPARACIÓN Y SERVICIO DE SUS HERRAMIENTAS ELÉCTRICAS, FAVOR DE DIRIGIRSE AL CENTRO DE SERVICIO MÁS CERCANO CULIACAN, SIN Av. Nicolás Bravo #1063 Sur - Col. Industrial Bravo (667) 7 12 42 11 GUADALAJARA, JAL Av.
Anexo encontrará una relación de sucursales de servicio de fábrica, centros de servicio autorizados y franquiciados en la República Mexicana, donde podrá hacer efectiva su garantía y adquirir partes, refacciones y accesorios originales. Especificaciones Voltaje ........................................120 V ~ Corriente ....................................15 A Frecuencia .................................60 Hz Entrada ......................................1800 W Goples por minuto .....................
DEWALT Industrial Tool Co., 701 East Joppa Road, Baltimore, MD 21286 (OCT06) Copyright © 2002, 2005, 2006 DEWALT Form No. 491663-01 D25980 The following are trademarks for one or more DEWALT power tools: the yellow and black color scheme; the “D” shaped air intake grill; the array of pyramids on the handgrip; the kit box configuration; and the array of lozenge-shaped humps on the surface of the tool.
