Form No. 769-25908

(November 17, 2020)

Models

Zero Turn Stand On Mower

Parts/Warranty Supplement

Warranty

This document contains information for all listed models. Warranty

information included in this document is specific to your purchased

Customer Support

For machines needing service or parts replacement please contact your local DeWALT

Service Center or the Customer Support Department before attempting

to return the machine.

If you have difficulty assembling this product, have questions regarding the controls, operation, or maintenance of this machine, want to order replacement parts/

attachments/accessories, or want to view an online How-To video; you can seek help from the experts. Have your full model number and serial number ready.

Choose from the options below:

◊ Web: www.DeWALT.com

◊ Phone: (855) 971-1123

product.

Part Number Description

754-06514

954-04327

Deck Belt (48” Deck)

Deck Belt (54” Deck)

754-06034

754-06074

PTO Belt (48” Deck)

PTO Belt (54” Deck)

754P05914A Drive Belt

742-05534

742-05533

Blade, 17.0 (48” Deck)

Blade, 19.0 (54” Deck)

618-07406 Spindle

734-04155 Deck Wheel

731-11926 Deck Skid Guard

725-17130 Battery

Replacement Parts

Part Number Description

735-12725A Gas Cap

725-07443 Throttle Control Lever (If Equipped)

725-04660 Multifunction Indicator Light (MIL)

925-06908 Ignition Key

946-05103A Park Brake Cable

631-08120 Chute Assembly

634- 07611

634-07612

Rear Wheel Assembly, 24x9.5-12 (48” Decks)

Rear Wheel Assembly, 24x12-12 (54” Decks)

634-07610 Front Wheel Assembly, 13 x 5-6

741-05262 Front Axle Ball Bearings

Accesories Parts

Part Number Description

59A50013038 Grass Collector

19B70064000 48" Mulch Kit

19B70065000 54" Mulch Kit

Part Number Description

59C30052000 Deck Stripe Kit

59B30021000 12-Volt Outlet

59B50005000 Light Kit

Summary of content (4 pages)

PAGE 1
Parts/Warranty Supplement Warranty Models Zero Turn Stand On Mower This document contains information for all listed models. Warranty information included in this document is specific to your purchased product. Customer Support For machines needing service or parts replacement please contact your local DeWALT® Service Center or the Customer Support Department before attempting to return the machine.
PAGE 2
DeWALT® -- LIMITED WARRANTY The limited warranty set forth herein is given by DeWALT® with respect to a new DeWALT® product (hereinafter “Product”) purchased and used in the United States and/or Canada to the Initial Purchaser (as defined herein). This limited warranty does not cover Emission Control Systems and is not a Federal Emission Control Warranty Statement, as defined by U.S. federal law.
PAGE 3
How to Get Service Under This Limited Warranty Limitations In order to qualify for the limited warranty, as set forth herein, the repairs made under this warranty must be performed by an authorized DeWALT® service provider. To locate a DeWALT® service provider, contact your authorized DeWALT® dealer, distributor, or retailer, or contact DeWALT® at www.DeWALT.com, or call 855-971-1123. This limited product warranty is provided by DeWALT® and is the only product warranty provided by DeWALT® for the Product.
PAGE 4
© 2020 DEWALT. DEWALT® and GUARANTEED TOUGH® are registered trademarks of the DEWALT Industrial Tool Co., used under license. All rights reserved. The yellow and black color scheme is a trademark for DEWALT Power Tools and Accessories.
