Displays
5-23
6700-A2-GY31-70
July 1999
The Hunt Group Monitor window is a split window. The upper portion displays the
menus Action, Control, and Commands, and a pictorial diagram of the Hunt
Group. The lower portion displays a listing of information on all devices in the
Hunt Group.
Each device uses the appropriate alert color. If the device is either suspended or
in inventory, the appropriate color will be used. See
System Colors
on page 5-4.
Empty slots use the empty carrier slot color and unsupported devices use the
unsupported device color.
All devices assigned to a hunt group are sorted by device name. If the Hunt
Group contains more devices than can be shown (16 card slots), the forward
button is enabled. If there are previously defined devices in a hunt group, the
backward button is enabled.
If all of the assigned devices are currently connected for the assigned busy
connect duration, the Hunt Group selection line that surrounds the card slots
appears using the alert color assigned to the busy group alert.
Changing the Hunt Group Name
The Hunt Group field displays the name of the current Hunt Group.
Procedure
1. Choose the arrow to the right of the Hunt Group field. The drop-down list box
containing the names of all the Hunt Groups in the network appears.
2. Select a Hunt Group name. The selected name appears in the Hunt Group
field.
