Available in the Displays windows is the advanced feature of double clicking on
different items or icons to perform a specific action. The actual action depends on
the item or icon selected and the current window. Table 5-12 lists the item or icon
selected, the affected window and the action resulting from double clicking. Any
restrictions that apply to the equivalent menu command also apply to the
double-clicking result.
Table 5-12. Double-Clicking Shortcuts
Item or Icon
Name Result
Cluster icon Network Map Zooms in.
Site icon Network Map Open the Device Management window.
Cabinet icon Network Map Opens the Cabinet Monitor window for the selected
cabinet.
Carrier icon Network Map Opens the Carrier Monitor window for the selected
carrier.
Device icon Network Map Opens the Device Management window for the
selected device.
Carrier Cabinet Monitor Opens the Carrier Monitor window for the selected
carrier.
Device Carrier Monitor Opens the Device Management window for the
selected device.
Facility Line Network Map Opens the Connectivity Diagram.
