Table 7-5 lists the possible Device Identification fields with a brief description of
each. These fields differ, depending on the device selected. Refer to the specific
device’s operating manual for a detailed description. Use the vertical scroll bar to
view any fields not in the window.
Table 7-5. Device Identification Fields
Information Field
Description
Model Number The Paradyne assigned model number.
Line Speed The current operating line speed.
Software Revision The current software level (Major, Minor, PTF) of the
firmware residing in the device.
Firmware Version The current firmware level (Major, Minor) of the firmware
residing within the device.
Serial Number The Paradyne assigned serial number.
Application Module Identifies if the type of application module is installed in
the device.
Features Installed Optional Features currently installed in the device. Refer
to the appropriate device type user’s guide for valid
features.
Restoration Installed The type of restoration that the device will use for backup.
Refer to the appropriate device type user’s guide for valid
restoration features.
Configuration The current configuration options of the device. For
example: DDD, 2-wire APL, 4-wire APL.
Country The current international option.
Hardware Part Number The Paradyne assigned hardware part number.
Software Part Number The Paradyne assigned software part number.
NOTE:
If the information concerning firmware version, serial number or features
received from the device does not agree with the Device Profile, an Invalid
profile window appears to allow you to update the Device Profile record.
Call Setup
Choose CallSetup from the Commands pull-down menu bar to connect a local
device to a remote device. The CallSetup function is disabled for DSUs without
the DBM feature installed. The CallSetup command displays the Dial window.
See Chapter 8,
Dial Function , for more information.
