Device Management
7-21
6700-A2-GY31-70
July 1999
Disable
Choose Disable from the Commands pull-down menu to disable a DSU or APL
transmitter; DBM; or the TDM, MSM, or MCMP ports. This command is not
available if the selected device or port is already disabled. A message box
appears to announce the completion of the request.
Enable
Choose Enable from the Commands pull-down menu to enable a DSU or APL
transmitter; DBM; or the TDM, MSM, or MCMP ports. This command is not
available if the selected device or port is already enabled. A message box
appears to announce the completion of the request.
External Leads
Choose External Leads from the Commands pull-down menu to either display the
state of the four general purpose leads or to change the state of the two output
leads on the EIA-232-D/V.24 interface. When you choose External Leads, the
External Leads window appears.
The current state of the external leads is read from the device and appears in the
drop-down list box. You can change the value, either On or Off, if desired.
Choose Display to read the current state of the external leads from the device.
Choose Update to send the current value of the output leads as shown to the
device.
NOTE:
This command is not applicable to a Dial device within a carrier.
