Hard Disk and System Recommendations
13-3
6700-A2-GY31-70
July 1999
Table 13-1 shows the sample configuration disk space requirements by function
and the total space required.
Table 13-1. Sample Configuration
Function
Formula Required Disk Space
Call Detail Display 128 x 480 x 30 x 20 36.9 Mb
Call Summary Display 128 x 13 x 31 x 350 18.1 Mb
Alert History 1000 x 1 x 30 x 80 2.4 Mb
Device Configuration 1000 x 800 0.8 Mb
Total Required Disk Space = 78.2 Mb
Start-Up and Ongoing Requirements
NMS checks the system resources before start-up and while running. If any
problems are encountered, a dialog box appears indicating the resource, the
amount required, and the amount available.
Start-Up Requirements
Each time NMS is started, the free disk space available for NMS is checked.
NMS will not load if the size of the database log files exceeds the amount of free
space on the partition or if the amount of free space is less than approximately
five megabytes. Instead, a dialog box appears, indicating the available space and
the required space. You should make the required disk space available before
restarting NMS.
NOTE:
Do not delete any files in the COMSPHERE 6700 directory. Such an action
can cause the system to become inoperable, forcing you to restore from a
backup.
