Start-Up
3-3
6700-A2-GY31-70
July 1999
Terminating a Login
To terminate the login at anytime during the login process, choose the Close
command from the NMS Login window’s control menu box in the upper left-hand
corner of the NMS Login window. The NMS Login window closes and NMS
terminates.
Main Menu
After a successful login, the COMSPHERE 6700 Series NMS Main Menu window
appears. This window provides access to all network management functions.
Network Map
Carrier Monitor
Alert Monitor
Front Panel
Device Management
Device Configuration
Device Options
Phone Book
Device Poll List
Dial
Download Firmware
Lock
Distributive Cabinet
These icons enable you to execute a particular function without selecting the item
from a menu. Click the left mouse button to select the desired icon.
