User`s guide

Configuration
4-3
6700-A2-GY31-70
July 1999
When you are ready to set up your network, select Config from the Main Menu.
The Config pull-down menu commands are described below:
 Network describes personnel contacts and network elements.
 Alerts and Events defines alert reporting parameters.
 System sets system attributes and options, and identifies the system’s users.
 Call Security sets VF passwords and security control. These options are
detailed in the
COMSPHERE 6700 Series Network Management System
Security Manager Feature Supplement .
Common Configuration Commands
Network configuration has some functions common to all types of configuration:
 Action commands (see Using the Action Commands on page 4-3)
 Info command (see Information Display in Appendix A, NMS Windows
Conventions )
 Selection Browser (see Device Selection in Appendix A, NMS Windows
Conventions
)
 Selection List Button (see Glossary)
Using the Action Commands
Use the Action commands (Table 4-1), accessed from the configuration menus,
with the configuration input forms to create, change, delete, and print
configuration information.
Table 4-1. Common Action Commands from Configuration Menus (1 of 2)
Action
Commands
Functions Procedures
Save Stores contents of input form to the
network database. Use this
command for updating or adding
elements to the database.
1. Complete the input form.
2. Choose Save.
Delete Removes the element from the
network database.
1. Access an existing element
name on the input form.
2. Choose Delete.
Clear Removes the current field entries of
the input form without affecting the
network database.
1. Choose Clear.
