Configuration
4-22
6700-A2-GY31-70
July 1999
7. Select an option button in the Left Column to choose one of the following:
Device: Selecting this button activates the Left Device list box. Use the
Device Names button to access the Selection Browser. Refer to
Device
Selection
in Appendix A,
NMS Windows Conventions
. Select a device and
the device options area from the list box to compare the device options of the
selected device.
User File: Selecting this button activates the File Name field. Select a User
File with the selection list button to compare the device options of the
selected user file.
Edit Area: Selecting this button uses the current device option information
read from a User File or uploaded from a device for comparison.
8. Select an option button in the Right Column to activate one of the following:
Device: Selecting this button activates the Right Device list box and gives
you access to the Selection Browser. Refer to
Device Selection
in
Appendix A,
NMS Windows Conventions
, for additional information on using
the Selection Browser. Select a device from the Available Devices list box
and a device option from the Device Option Areas list box to compare device
options of the selected device.
User File: Selecting this button activates the File Name field. Select a User
File with the selection list button to compare the device options of the
selected user file.
If the selected device is a DSU and
you want to compare . . .
Then choose Yes in the . . .
Device options Dial Backup Module box.
Port options Port Box.
9. Choose Compare. A device options comparison appears with a side-by-side
view of the two sets of device options.
