10. Select a box by clicking with the left mouse button, or select a group of boxes
by clicking and dragging the mouse to include desired boxes in a selection
rectangle. Also, you can select a day of the week. A dark gray box indicates
ON, while a light gray box indicates OFF. Individual boxes toggle ON or OFF.
For a group in a rectangular selection box, the value is set to the inverse of
the value of the box in the top left corner. For a group selected by week day,
the value is set to the inverse of the value of that day’s 00 hour.
11. Choose OK to save the values selected.
12. Choose one of the commands from the Action menu (see Table 4-4).
Alert Numbers
Tables 4-4 (APL) and 4-5 (DSU) include alert numbers, description, and severity
level.
Table 4-4. Alert Control Numbers for APL Devices
Alert #
Alert Description Priority Alert # Alert Description Priority
0 Device Failure Critical 13 Firmware Downloading Major
1 Configuration
Change Notify
Minor 14 Make Busy Mode Minor
2 Test Mode Major 15 Service Line Minor
3 Disabled Critical 16 Non-answering Modem Critical
4 Out of Threshold Critical 17 Short Holding Time
Modem
Critical
5 Facility Alarm Critical 18 Sub Tree Truncation Minor
6 External Alarm A Critical 19 Good APL While On
Backup
Minor
7 Streaming Terminal Critical 20 Bad Backup While On
APL
Minor
8 Access Security,1.0 Major 21 PSTN Test Failed Minor
9 Dial Backup Active
for APL
Minor 23 External Alarm B Critical
10 DTE Alarm Major 30 Group Busy Major
11 Sub-normal
Operating Speed
Major 31 No Response Critical
12 Primary Channel
Interrupted
Major
