Configuration
4-55
6700-A2-GY31-70
July 1999
Use printer selection dialog for report output: Select this check box if you
want the system to prompt with the Printer Selection dialog box (see
Printer
Selection
in Appendix A,
NMS Windows Conventions
) for an alternative to the
default printer whenever the Print command is used.
NOTE:
Select this option when the COMSPHERE 6700 NMS Multiuser feature is
installed to allow each user to print to a desired printer.
4. Select a printer from the Valid System Default Printers list to choose a default
printer.
5. Choose Setup to access options specific to the selected printer (refer to the
Windows user’s guide). Select the Use printer selection dialog for report
output box for the system to prompt with the Printer Selection dialog box for
you to choose an alternate printer (other than the default) whenever the Print
command is used.
6. Choose Save from the Action menu to store your selection in the NMS
database.
Defining Thresholds for VF Impairments
Use the VF Thresholds commands to define or change the thresholds for VF
impairments displayed by NMS.
VF thresholds identify the acceptable level of impairment to the network’s lines.
You define the upper and/or lower limits for each type of impairment. These limits
are the range of values that appear on the VF Status window (accessed through
Device Management).
Use the VF Thresholds Action Commands (Table 4-10) to save, reset, or print
the VF Thresholds.
Table 4-10. Action Commands for VF Thresholds
Action
Commands
Functions Procedures
Save Stores the VF Thresholds to the
network database.
1. Complete the input form.
2. Choose Save.
Reset Restores the display of VF
Thresholds to the values currently
stored in the database.
1. Display the VF Thresholds
input form.
2. Choose Reset.
Default Restores the display of VF
Thresholds to the original values
set by NMS without affecting the
database.
1. Display the VF Thresholds
input form.
2. Choose Default.
Print Prints the VF Thresholds
information currently displayed in
the VF Thresholds input form.
1. Complete the input form.
2. Choose Print.
