System Colors
The colors used within Displays represent different alerts and items. Table 5-2
lists the alerts and items used in the Displays windows with the default color and
a description. For additional information, see
Defining System Colors in
Chapter 4, Configuration .
Table 5-2. Displays System Colors
Alert or Item Default Color Description
Critical Alert,
Unacknowledged
Red Indicates a Critical Alert.
Critical Alert,
Acknowledged
Red Brown Indicates an acknowledged Critical alert. For
example, a device has failed and a work order has
been issued to repair it. Clear the alert (no alert)
when the device is repaired.
Major Alert,
Unacknowledged
Yellow Indicates a Major alert (not Critical).
Major Alert,
Acknowledged
Olive Indicates an acknowledged Major alert. For
example a device has its configuration changed
and a memo written to find out why. Clear the alert
when the issue is resolved.
Minor Alert,
Unacknowledged
Cyan Indicates a Minor alert (not Critical or Major alert).
Minor Alert,
Acknowledged
Sea Green Indicates an acknowledged device Minor alert has
occurred. For example, a device is in Test mode.
No action is required except noting the current
status. When the device is not in test mode, clear
the alert.
No Alert Green Indicates that no failed conditions have been
reported for the device.
Alert Background Gray (light) Alerts background color.
Land Gray (light) Indicates land masses on the Network Map.
Boundary Purple Indicates country and state (USA only) borders.
Water Blue Outlines bodies of water.
Selected Facility White Indicates selected facility line.
Map Background Black Network Map background color.
Empty Carrier
Slot
Gray (dark) Indicates an empty slot in the Carrier window.
Unsupported
Device
Gray (dark) Indicates an unsupported device in the Carrier
window.
Suspended
Device
Magenta Indicates a device in the suspended state.
Inventory Device White Indicates a device in the inventory state.
