Installation & Assembly

PR34-“Carnival” Rack

Enclosed you will find everything needed for the assembly

and use of your storage rack. Two people make assembly

and installation easier. The parts and hardware included are:

Hardware included:

12 – 3/8” x ½” Button head Screws

2 – Plastic End Caps

2 – 3/8” Eye Bolts

2 – Large Ceiling Screw Hooks

2 – 7” Extension Hooks

12 – Straight Pot Hooks

6 – Angled Pot Hooks

1 – 7/32” – Allen Wrench

Toggle Kit

Components included:

1 – Rack Body - Rectangle

1 – Upper Square Tube

2 – End Arms

4 – Side Arms

1 – Grid

See reverse side for ASSEMBLY AND INSTALLATION INSTRUCTIONS

Thank you for choosing Enclume!

Enclume racks are the ultimate quality,

design, strength and function.

WARNING: READ ALL OF THE

INSTRUCTIONS BEFORE

ASSEMBLING AND USING YOUR

RACK

If you need help, please call 1-877-ENCLUME

Enclume Design Products

24 Colwell Street, Port Hadlock, WA 98339

Phone 360-385-6100  Fax 360-385-6156

www.enclume.com

PAGE 1
PR34-“Carnival” Rack Thank you for choosing Enclume! Enclume racks are the ultimate quality, design, strength and function. WARNING: READ ALL OF THE INSTRUCTIONS BEFORE ASSEMBLING AND USING YOUR RACK If you need help, please call 1-877-ENCLUME Enclume Design Products 24 Colwell Street, Port Hadlock, WA 98339 Phone 360-385-6100  Fax 360-385-6156 Enclosed you will find everything needed for the assembly and use of your storage rack. Two people make assembly and installation easier.
PAGE 2
ASSEMBLY AND INSTALLATION INSTRUCTIONS Rack Assembly: 1) Place rack on firm surface 2) Using two (2) of the 12 3/8” x ½” button head screws, attach the 2 end arms, one to each end of the rack body. (NOTE: The 2 end arms can be identified as having the ends of the arms facing in the same direction and in the horizontal plane. Square the two end arms up and tighten securely with the Allen wrench provided. 3) Locate the “square tube” upper and the two 3/8” eyebolts.
