User Guide TouchLink™ TLP VIM TouchLink Video Input Module 68-2055-01 Rev.
Safety Instructions • English This symbol is intended to alert the user of important operating and maintenance (servicing) instructions in the literature provided with the equipment. This symbol is intended to alert the user of the presence of uninsulated dangerous voltage within the product’s enclosure that may present a risk of electric shock. Caution Read Instructions • Read and understand all safety and operating instructions before using the equipment.
FCC Class A Notice This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation.
iv TLP VIM • Contents
Introduction This section gives an overview of the TLP VIM, TouchLink™ Video Input Module describing its operation and features including connection and operation with the Extron line of TouchLink panels. Topics that are covered include: zz About the TLP VIM zz Application Diagrams About the TLP VIM The TLP VIM is a twisted pair transmitter for composite or S-video with audio, designed exclusively for use with compatible Extron TouchLink touchpanels.
Video/Audio Extron TLP VIM POW ER + AUD IO + VID EO - MTP OUT PUT TLP 1000TV Video/ Audio PC or DVD Extron 12 V Power Supply PO Extron TLP VIM WER AU + DIO + VID EO - MTP OU TP UT Audio Video Video/Audio (100´ max) PC or DVD TLP 1000TV Figure 1.
Installation and Operation This chapter shows how to install and operate the TLP VIM Video Input Module. Topics that are covered include: zz Installation Overview zz Mounting the TLP VIM zz TLP VIM Front and Rear Panel Features zz Operation Installation Overview To install and set up the TLP VIM, follow these steps: 1. Turn all equipment off. Make sure the video sources (DSS, cable boxes, PC, laptop, or other devices), the TLP VIM, and the touchpanel are turned off and disconnected from power sources. 2.
TLP VIM Front and Rear Panel Features Front TLP VIM Rear a b POWER 12V 0.5A MAX c d e INPUT VIDEO AUDIO OUTPUT Figure 2. TLP VIM Front and Rear Panel a Front panel LED – Single LED lights to indicate the TLP VIM is properly powered. b DC power input – Single 2-pole, 3.5 mm, orange captive screw connector for connection of a 12 V power supply. Use only the included power supply or an Extron authorized power supply to power the TLP VIM.
POWER 12V 0.5A MAX INPUT VIDEO AUDIO Smooth Ridges A OUTPUT Captive Screw Connector A SECTION A–A Tie Wrap Power Supply Output Cord DC Power Cord Captive Screw Connector 3" 16 (5 mm) Max. Ground +12 VDC External Power Supply (12 VDC, 1 A ) AC Power Cord Figure 3. Power Supply Wiring CAUTION: Always use a power supply supplied or specified by Extron. Use of an unauthorized power supply voids all regulatory compliance certification and may cause damage to the supply and the TLP VIM.
d Video input – Two female BNC connectors on pigtails used to input either S-video (yellow-chroma, white-luma) or composite video (white only). For composite input, connect the composite cable to the white POWER video input cable. 12V For S-video input connect the luma cable to the white video input and the chroma cable to the yellow video input. White: Luma or Composite 0.5A MAX Yellow: Chroma Figure 5.
Reference Information Included Parts Description Part Number TLP VIM 60-1168-01 12 VDC, 1 A power supply 28-071-57LF 3-pole blue 3.5 mm male captive screw connector 10-703-11LF TLP VIM User Guide Optional Accessories Enhanced Skew-Free™ A/V UTP Cable Part Number Skew-Free UTP/3, 3 ft (90 cm) 26-569-01 Skew-Free UTP/6, 6 ft (1.8 m) 26-569-02 Skew-Free UTP/12, 12 ft (3.
Specifications Video Gain ����������������������������������������������� Unity Differential phase error ������������������� <1.0° at 3.58 MHz and 4.43 MHz Differential gain error ��������������������� <1.0% at 3.58 MHz and 4.43 MHz Video input Number/signal type ������������������������ 1 S-video or composite video Connectors ������������������������������������ 2 female BNC on pigtails Nominal level ��������������������������������� 1 Vp-p for Y of S-video and for composite video 0.
Audio input Number/signal type ������������������������ 1 mono, balanced or unbalanced Connector �������������������������������������� (1) 3.5 mm captive screw connector, 3 pole Impedance ������������������������������������� >10k ohms unbalanced, >20k ohms balanced, AC coupled Nominal level ��������������������������������� -10 dBV (0.32 Vrms) Maximum level ������������������������������� >+2.4 dBu (balanced or unbalanced) at 1%THD+N NOTE: 0 dBu = 0.
Regulatory compliance Safety �������������������������������������� EMI/EMC ��������������������������������� MTBF ��������������������������������������������� Warranty ���������������������������������������� CE, c-UL, UL CE, C-tick, FCC Class A, ICES, VCCI 30,000 hours 3 years parts and labor NOTE: All nominal levels are at ±10%.
Extron® Warranty Extron Electronics warrants this product against defects in materials and workmanship for a period of three years from the date of purchase.
