User’s Manual MMX 42/62 Series www.extron.com Extron Electronics, USA Extron Electronics, Europe Extron Electronics, Asia Extron Electronics, Japan 1230 South Lewis Street Anaheim, CA 92805 USA 714.491.1500 Fax 714.491.1517 Beeldschermweg 6C 3821 AH Amersfoort The Netherlands +31.33.453.4040 Fax +31.33.453.4050 135 Joo Seng Road, #04-01 PM Industrial Building Singapore 368363 +65.6383.4400 Fax +65.6383.4664 Daisan DMJ Building 6F 3-9-1 Kudan Minami Chiyoda-ku, Tokyo 102-0074 Japan +81.3.3511.
Precautions Safety Instructions • English This symbol is intended to alert the user of important operating and maintenance (servicing) instructions in the literature provided with the equipment. This symbol is intended to alert the user of the presence of uninsulated dangerous voltage within the product's enclosure that may present a risk of electric shock. Caution Read Instructions • Read and understand all safety and operating instructions before using the equipment.
Quick Start Guide — MMX 42/62 Installation Step 1 VersaTools Rack Shelf Turn all of the equipment off and disconnect it from the power source. Half Rack Width False Front Face Plate Step 2 Select your mounting option, install the appropriate brackets and mount the switcher. Otherwise, install the four rubber feet (included) and place the switcher on a desktop. OUT PUT S 1 1 2 2 INPU TS 3 4 CON FIG VIDE O AUD IO Use 2 mounting holes on opposite corners.
Quick Start Guide — MMX 42/62, cont’d Quick Start Guide — MMX 42/62, cont’d Operation connectors appropriate for your model (BNC or 4-pin mini DIN). Connecting an input to an output Step 6 To switch to a different input, repeat steps 1 through 3. Step 1 Attach the audio output cable(s). Connect up to two audio output devices to the switcher using connectors appropriate for your model (5pole, captive screw or RCA - see illustrations above and at right).
Quick Start Guide — MMX 42/62, cont’d Table of Contents Chapter 1 • Introduction .......................................................... 1-1 About the MMX 42/62 Series Matrix Switchers .... 1-2 Features ...................................................................................... 1-3 Composite video (AV) models ............................................... 1-3 S-video (SV) models ............................................................... 1-3 All models ...................................
Table of Contents, cont’d Windows-Based Control Program ................................. 4-7 Installing the software .......................................................... 4-7 Using the software ................................................................ 4-7 Input selection ....................................................................... 4-8 Muting the audio and video signals .................................... 4-9 Setting audio levels ......................................................
Introduction, cont’d Introduction About the MMX 42/62 Series Matrix Switchers The Extron MMX 42/62 series of compact matrix switchers consists of four models of 4-input, 2-output video and audio matrix switchers, and four models of 6-input, 2-output video and audio matrix switchers, including the following: RS-232 Control OU 1 TP UTS 2 RS- 23 2 RX 6 TX L 5 IN MMX switcher model 3 TS 4 R MAV 62 AV RC A 2 Description 1 OU TP UTS 1 5 IN 4 x 2 composite video (BNC) and audio (captive sc
Introduction, cont’d All models Audio inputs — MMX switchers accept up to four (MMX 42) or six (MMX 62) stereo audio inputs. AV and SVA models accept balanced or unbalanced stereo on 3.5 mm, 5-pole captive screw terminals. RCA models accept unbalanced stereo on RCA terminals. Audio outputs — MMX switchers output two stereo audio outputs. AV and SVA models output balanced or unbalanced stereo on 3.5 mm, 5-pole captive screw terminals. RCA models output unbalanced stereo on RCA terminals.
Installation, cont’d Installation Installation Overview To install and set up an Extron MMX 42/62 switcher for operation, follow these steps: 1 Turn off all of the equipment. Ensure that the video sources and the output display are all turned off and disconnected from the power source. 2 Mount the switcher. See Mounting the switcher in this chapter. 3 Attach the cables. See Rear Panel Cabling in this chapter. 4 Plug in the power supply, then turn on the display devices and the input devices.
Installation, cont’d 7. Slide the unit slightly forward or back, then tighten all four screws to secure the unit in place. 1 3 5 OUTPUTS INPUTS 1 Rear Panel Cabling 4 6 10 8 POWER - + 2 INPUTS OUTPUTS 1 3 5 1 2 4 6 2 L POWER L 1 4 R L R L 2 5 R L R L 3 6 R L R L 1 2 5 3 5 RS-232 TX RX - + 2 4 INPUTS 4 5 OUTPUTS 1 2 6 6 2 L 1 4 8 INPUTS OUTPUTS L R L 2 5 R L R L 3 6 R L R L R - + 12V 0.
Installation, cont’d Video signal output connections 7 4 Composite video output connectors — Connect composite video displays to these two female BNC connectors. 5 S-video output connectors — Connect S-video displays to these two 4-pin mini DIN connectors. RCA audio connectors — Connect unbalanced stereo audio inputs to these RCA connectors. See figure 2-10 for an illustration on how to wire the RCA connector.
Installation, cont’d RS-232 connection 10 MMX 42/62 Series Matrix Switchers Remote connector — Connect a host device, such as a computer or a touch control panel, to the MMX switcher via this 3-pole captive screw connector for remote control using the Simple Instruction Set (SIS).
Operation, cont’d Operation Front Panel Controls and Indicators Figure 3-1 shows the controls and indicators on the front panel of the MMX 62 compact matrix switcher. 1 2 3 OUTPUTS 4 INPUTS 1 2 3 5 CONFIG 4 5 6 1 VIDEO 2 AUDIO Create video and/or audio ties using the front panel buttons as follows: 1. Press and release the Outputs button to select the desired output. The LED for the selected output lights. 2.
Operation, cont’d System Reset To reset the unit to factory defaults, press and hold the Config button while power is applied. This resets the audio input settings to unity (0dB) and connects input 1 to outputs 1 and 2, audio and video. The audio and video Config LEDs are lit. Troubleshooting — If no image appears 1. Ensure that all devices are plugged in and powered on. The switcher is receiving power if the Power LED is lit. 2. Ensure an active input and output are selected on the MMX switcher. 3.
Remote Control, Remote Controlcont’d The switcher’s rear panel Remote connector (figure 4-1) can be connected to the serial port output of a host device. Remote communications with the switcher are via Extron’s Simple Instruction Set or using Extron’s Windows-based control program.
4-4 MMX 42/62 Series Matrix Switchers • Remote Control Read Video mute Global -Video mute all Video unmute all MMX 42/62 Series Matrix Switchers • Remote Control B/b 1*B/b 0*B/b X3 Vmt X2 *1 Vmt1 Vmt0 X9 Vmt X2 *0 x.
4-6 X2 X4 X3 $ X1 G Gain for input MMX 42/62 Series Matrix Switchers • Remote Control Information request Request part number Query software version Miscellaneous commands Reset all audio gains to 0dB Unmute all audio Unmute all video System reset to factory default Reset commands Lock front panel Unlock front panel Lock status Front panel executive mode Set gain (+dB) Example: Set attenuation (-dB) Increment gain Decrement gain I/i N/n Q/q Esc ZA Esc ZZ Esc ZB Esc ZXXX 1 X/x 0 X/x X/x X1 * X5
Remote Control, cont’d 3. The Extron Universal Switcher Control Program window (figure 4-3) displays the selected inputs for each output and the audio gain for the selected audio inputs. Muting the audio signals To mute one or both of the switcher’s outputs: 1. Click on the MUTE button for the selected output(s) on the Universal Switcher Control Program main window (figure 4-3). An associated orange indicator will “light” to indicate that the audio and/or video output is muted. 2.
Remote Control, cont’d 3. 4. Move the slider up (increase gain), or down (decrease gain) for selected audio input. Use the ALL slider control to change all input settings simultaneously. Settings are changed in 1 dB increments between -18 dB and +24 dB, and affect both left and right channels equally. Click the Take button (in Verify mode) to make the entered changes effective. The Changes: Immediate or Changes: Verify buttons control how the audio configuration changes are applied to the switcher.
Remote Control, cont’d Click on Upload Firmware File. A dialog box asking you to select the update file is displayed (see Figure 4-7). 3. Figure 4-7 — Select update file box Click OK. When the Browser window (figure 4-8) opens, find the updated firmware file (where you previously saved it) and select the file, then click Open to load it. 4. MMX 42/62 Series Matrix Switchers A Appendix A Figure 4-8 — Browser window The firmware update file must have an .s19 extension.
Specifications, cont’d Specifications Video Routing MMX 42 Series ................. MMX 62 Series ................. Gain ............................................... Bandwidth .................................... Phase between I/Os .................... Differential phase error ............... Differential gain error ................. Max. propagation of delay ......... Crosstalk ....................................... Switching speed ...........................
Accessories and Part Numbers, cont’d Impedance .................................... >10 kohms unbalanced/balanced, DC coupled Nominal level ............................... -10dBV (316mV) Maximum level ............................ +19.5dBu, (balanced or unbalanced) at 1%THD+N Input gain adjustment ................. –18dB to +24dB, adjustable per input via RS-232 only Audio output Number/signal type Captive screw models ..... 2 stereo, balanced/unbalanced RCA connector models ...
Accessories and Part Numbers, cont’d Cables Extron’s SVHS cable is suitable for S-video and Super High Resolution SHR 1 cable is suitable for composite video. Both these families of Extron cables have male connectors on both ends. S-video Cable SVHS 6’ (6 feet/1.8 meters) 26-316-02 SVHS 12’ (12 feet/3.7 meters) 26-316-03 SVHS 20’ (20 feet/6.1 meters) 26-316-01 SVHS 30’ (30 feet/9.1 meters) 26-316-04 SVHS 50’ (50 feet/15.2 meters) 26-316-05 SVHS 75’ (75 feet/22.
