installation

Tools

• Adjustable wrench

• Groove joint plier

• Phillips screwdriver

• Pipe tape

Maintenance

Your new faucet is designed for years of trouble-free performance.

Keep it looking new by cleaning it periodically with a soft cloth.

Avoid abrasive cleaners, steel wool and harsh chemicals as these will dull the finish

and void your warranty.

Safety Tips

• If you use soldering for the installation of the faucet, the seats, cartridges and

washers will have to be removed before using flame. Otherwise, warranty will be

void on these parts.

• Protect your eyes with safety glasses when cutting or soldering water supply line.

• Cover your drain to avoid losing parts.

Important points

Prior to beginning installation, turn off the cold and hot water lines and open the

old faucet to release built-up pressure. When installing your new faucet, turn the

connector nuts finger-tight, then use one wrench to anchor the fitting and a second

wrench to tighten the nut an additional turn. Connections that are too tight will

reduce the integrity of the system. Wrap all threaded connections with Teflon tape

available at your local hardware or plumbing supply store. Always wrap in a

clockwise direction.

Things You May Need

All installations can vary depending on how your previous faucet was installed.

Necessary supplies to install your faucet are not all included; however, they are

available wherever plumbing supplies are sold. When choosing your installation

supplies, make sure they are IAPMO and/or CSA approved products.

For Models: N300 01, N300 02

Summary of content (5 pages)

PAGE 1
installation Tools • Adjustable wrench • Groove joint plier • Phillips screwdriver • Pipe tape Maintenance Your new faucet is designed for years of trouble-free performance. Keep it looking new by cleaning it periodically with a soft cloth. Avoid abrasive cleaners, steel wool and harsh chemicals as these will dull the finish and void your warranty. Safety Tips • If you use soldering for the installation of the faucet, the seats, cartridges and washers will have to be removed before using flame.
PAGE 2
Preparation/Assembly 1 Shut off water supply before installation. 1 2 Spout Remove rubber washer, metal washer, lock nut, spout connector and nut from spout shank. Position the spout in the faucet hole of the sink. Slide the rubber and metal washers up the shank and secure spout with the lock nut. Reattach spout connector and secure with nut.
PAGE 3
Preparation/Assembly 5 Wrap spout connector inlets with pipe tape, and connect to valve bodies with flexible spout connector hoses. Spout connector inlets Flexible spout connector hoses 6 5 Valve body inlets Wrap valve body inlets with pipe tape and connect to water supply. Pipe tape 6-1 Water supply 6-2 7 Install handles. Cap Screw Cross handle 7 8 Remove aerator and turn on water for 1 minute to flush the lines. Replace aerator. Check for leaks.
PAGE 4
Installation - Pop-Up drain 1 Flange Remove flange from pop up main body. Leave large black washer and nut on drain body. 1 2 Place a ring of putty around drain opening of sink. Insert threaded end of drain body up through drain hole and attach flange to body with ball rod pointing to rear of sink. Flange Rubber washer Lock nut 3 Thread locknut from underside of sink until rubber washer seats securely inside opening of sink. Tighten locknut with a wrench. Wipe excess putty.
PAGE 5
Parts Breakdown Lift-rod cap Lever handle Spout Cross handle Aerator Canopy Retainer nut Cartridge Flange O-ring Washers Body Lock nut Washers Pop-up assembly Spout connector Lock nut Coupling nut Spout connector hose Trouble-Shooting PROBLEM Leaks underneath handle. CAUSE Retainer nut is loose or O-ring on cartridge is dirty or twisted. SOLUTION Tighten the retainer nut. Clean or replace o-ring. PROBLEM Aerator leaks or has an inconsistent water flow pattern.
