BlueToneTM BTHF102/202 User Manual Bluetooth Handsfree User Manual Model：BlueToneTM BTHF102/202 Declaration: Without written permission from Flaircomm Technologies Inc., reproduction, transfer, distribution or storage of part or all of the contents in this document in any form is prohibited。 The company reserves rights to make any changes and improvements to the product described in this document without prior notice. .
BlueToneTM BTHF102/202 User Manual Notice ： Please make sure your mobile phone and network operator supports the functions described in this manual, otherwise the relative functions can not be realized on this Handsfree device. Certification and Safety Approvals This product has been tested and found to comply with Bluetooth BQB requirements, part 15 of FCC rules, R&TTE Directive（99/5/EC） or CE marked requirements. Warning：Users should not make changes or modify the device in any way.
BlueToneTM BTHF102/202 User Manual Safety z Check the laws and regulations on the use of mobile phones and handsfree equipment in the areas where you drive. Always give full attention to driving and pull off the road and park before making or answering a call if driving conditions require. z Do not allow children to play with your Bluetooth car handsfree since it contains small parts that could become detached and create a choking hazard z This device contains a Li-polymer battery.
BlueToneTM BTHF102/202 User Manual Contents： 1. 1.1 1.2 1.3 1.4 1.5 1.6 2. INTRODUCTION .................................................................................................................................5 BLUETOOTH TECHNOLOGY ..................................................................................................................5 BLUETOOTH HANDSFREE CAR KIT .......................................................................................................5 PRODUCT FEATURES ....
BlueToneTM BTHF102/202 User Manual 1. Introduction 1.1 Bluetooth Technology Bluetooth is an internationally standardized technology supporting short distance wireless communications. Any two Bluetooth-compatible equipment, such as mobile phone, PDA、PC, headset, mouse, keyboard, printer, etc. can wirelessly communicate with each other via Bluetooth connection. To ensure worldwide compatibility, Bluetooth operates on the globally available ISM (Industrial Scientific and Medical) frequency band. Within 2.
BlueToneTM BTHF102/202 User Manual 1.4 Package Content z BlueToneTM BTHF102 (or BlueToneTM BTHF202 ) 1 z Mounting dock 1 z Double-side Sticker 1 z 12/24V Car Charger （or Traveling Charger） 1 z Hanging Strip(for BlueToneTM BTHF202) 1 z User Manual 1 1.5 Overview 8.Charging Port 1.Speaker 4.Button K3 2.Red/Blue LED 5.Button K2 3.Button K4 6. Button K1 7. Microphone Figure 1 BlueTone TM BTHF102 Overview 1.Speaker 2.Red/Blue LED 8.Charging Port 3.Button K4 4.Button K3 5. Button K2 6.
BlueToneTM BTHF102/202 User Manual 1.6 Key Press Duration Definitions z Short press (SP): press and release a button quickly. z Long press (LP): press and hold a button for at least 3 seconds, then release. z Very long press (VP): press and hold a button for at least 6 seconds, then release. .
BlueToneTM BTHF102/202 User Manual 2. Using Your Handsfree 2.1 Battery Charging and Usage 2.1.1 Battery Charging This device contains a rechargeable Li-Polymer battery. First-time charging time is about 4 hours. Later-on recharging time is around 2-3 hours. Detailed charging procedures as follows: 1. Connect the car charger to the cigarette lighter. 2. Referring to Figure 3, plug the connector of the charger to handsfree’s charging port to start charging.
BlueToneTM BTHF102/202 User Manual Hole Stanchion Double-side Sticker Figure 4 Back of the device TM Fixing BlueTone Figure 5 fixing the mounting dock BTHF202 (referring to Figure 6)： 1. Plug the part 1 to the inlet, then tear the paper off the Double-side Sticker, paste the mounting dock on the right place on the vehicle. If using the clamp one, insert the clamp in the air conditioner air outlet in the car.
BlueToneTM BTHF102/202 User Manual Turn off the Handsfree: Long press K1, you will hear 2 power-down tones, and All LEDs are off. This indicates the handsfree is power off. 2.4 Pairing/Connecting your Handsfree with Bluetooth Equipment 2.4.1 Pairing your Handsfree with Bluetooth handset Before making and answering calls, you must pair your handsfree and phone. Paring sets up a unique relationship between your handsfree and your handset. The handset will memorize the handsfree’s unique ID (or passkey).
BlueToneTM BTHF102/202 User Manual 2.4.3 Erase all paired profiles This handsfree can paired with up to 8 Bluetooth equipments. When Handsfree in the Paring Mode, long press K4, it will erase all paired profiles and quit pairing mode. At this time, Blue LED gives 1 blink per 3 seconds. 2.4.
BlueToneTM BTHF102/202 User Manual 2.5.3 Mute You can mute or un-mute an ongoing call by simultaneously quick pressing K3 and K4. 2.5.4 Transferring Calls to/from Your Handset Transferring calls to your handset: long press K2, Blue LED gives 1 blink per 3 seconds. Transferring calls from your handset: short press K2, Blue LED gives 1 blink per 3 seconds. 2.5.
BlueToneTM BTHF102/202 User Manual 3. Quick User Guide 3.1 LED patterns z LED Pattern 1: Blue LED gives 1 blink per 3 seconds; Red LED is off. z LED Pattern 2: Blue LED gives 3 quick blinks per 2 seconds; Red LED is off. z LED Pattern 3: Blue and Red LEDs alternate continuously. z LED Pattern 4: Blue and Red LEDs alternate every 3 seconds. z LED Pattern 5: All LEDs are off. 3.2 Quick User Guide You can follow the instructions listed in Table 1-6 below to operate your handsfree devices.
BlueToneTM BTHF102/202 User Manual Table 2: Pairing/Connections FUNCTION CURRENT STATUS HANDSET Enter pairing mode Erase all paired profiles Pair handsfree with handset Connect (handsfree with handset) Disconnect OPERATION HF HEADSET INDICATOR AUDIO TONE Power Off Very long press K1 Paring Mode Long press K4 Power on Paring mode Standby (disconnected) Standby (disconnected) Follows your handset user guide to complete pairing procedure.
BlueToneTM BTHF102/202 User Manual Table 4: Transfer Functions FUNCTION CURRENT STATUS HANDSET Call Transfer (handsfree to handset) Call Transfer (handset to handsfree) OPERATION HF HEADSET INDICATOR AUDIO TONE LED INDICATOR Talk Talk Long press K2 Key Tone LED Pattern 1 Talk Talk Short press K2 Key Tone LED Pattern 2 Table 5: Low Power Indication FUNCTION CURRENT STATUS HANDSET Low Power Warning OPERATION HF HEADSET INDICATOR AUDIO TONE Except power off Beep every 20 seconds LED I
BlueToneTM BTHF102/202 User Manual 4. Maintenance BlueToneTM BTHF102/202 are well-designed communications devices, careful maintenance and proper use will extend the product life and keep their elite performance in delivering voice. Following maintenance procedures may be helpful to you： z Always turn off power and keep your device in a safe place when it is not in use z Keep the device dry, away from water, precipitation, humidity, moisture, and various liquids which may corrode electronic circuits.
BlueToneTM BTHF102/202 User Manual 5. Important Messages and Frequently Asked Questions 1. Except handsets, what kind of devices can the handsfree communicate with： Besides pairing with a handset for receiving and making phone calls, the handsfree can also communicate with PDA and computer that equipped with Bluetooth. For examples, when communicating with a computer (through a USB Dongle) users can chat and/or listen music over the internet. 2.
