Signature Features

frigidaire.com

Approved Over Frigidaire®

Electric Wall Ovens

Cooktops are approved for installation

above any of our Single Electric Wall

Ovens.

Quick Boil

Boils water faster.

Express-Select® Controls

Easily go from warm to boil.

Continuous Grates

Continuous grates make it easy to

move heavy pots and pans between

burners without lifting.

30" Gas

Built-In Cooktops

FGGC3045Q S/W/B

Product Dimensions

Width 30"

Depth 21-3/4"

Height 5"

More Easy-To-Use

Features

Low Simmer Burner

Perfect for delicate foods and

sauces.

Electronic Pilotless Ignition

LP Gas Conversion Option

Available in:

Stainless

(S)

White

(W)

Black

(B)

Burners

Right Front

Right Rear

Left Front

Left Rear

BTU

18,000

5,000

12,000

9,500

Summary of content (5 pages)

PAGE 1
Built-In Cooktops FGGC3045Q S/W/B 30" Gas Product Dimensions Width 30" Depth 21-3/4" Height 5" More Easy-To-Use Features Low Simmer Burner Perfect for delicate foods and sauces. Electronic Pilotless Ignition LP Gas Conversion Option Available in: Stainless (S) Signature Features Quick Boil Express-Select® Controls Continuous Grates Approved Over Frigidaire® Electric Wall Ovens Boils water faster. Continuous grates make it easy to move heavy pots and pans between burners without lifting.
PAGE 2
Features Controls Built-In Cooktops Drop-In Gas Cooktops Frigidaire Baseline FGGC3045Q S/W/B 30" Gas Express-Select® Surface Type Stainless Steel Recessed (S), Color-Coordinated Recessed (W/B) Sealed Gas Burners Yes Grates Continuous Cast Iron w/Black Matte Finish Right Front Burner (BTU) 18,000 Right Rear Burner (BTU) 5,000 Left Front Burner (BTU) 12,000 Left Rear Burner (BTU) 9,500 Control Location Front Knob Color Stainless (S), Color-Coordinated (W/B) Knob Type Cast Metal (S), P
PAGE 3
Built-In Cooktops 30" Gas FGGC3045Q S/W/B Required Clearances Product Dimensions A - Width B - Depth C - Height G (min.) H (min.) I (min.) J (min.) 30" 21-3/4" 5" 2" 7" 7" 2-1/4" Product Cutout Dimensions D - Width (min. - max.) E - Depth (min. - max.) F - Height (min.)* 27-1/4" - 28-1/2" 19-1/8" - 19-3/4" 8" Utility Connection Locations K - Cabinet Opening Width (min.
PAGE 4
(excludes side swing wall oven) Gas Cooktop Installation Over 30"/27" Electric Single Wall Oven 30"/ 27" Electric Single Wall Oven Under-Counter Installation Specifications Gas Cooktop Installation Over 30"/ 27" Electric Single Wall Oven Specifications • Single phase 3- or 4-wire cable, 120 / 240 or 120 / 208 Volt, 60 Hertz All Frigidaire® Electric Single Wall Ovens are approved to be used beneath any approved Frigidaire® Gas Cooktop. (This installation page excludes approved wall oven model GLEB27Z7H.
PAGE 5
Frigidaire Gallery Model GLEB27Z7H Gas Cooktop Installation Over 27" Electric Single Wall Oven (GLEB27Z7H) 27" Electric Single Wall Oven (GLEB27Z7H) Under-Counter Installation Specifications Gas Cooktop Installation Over 27" Electric Single Wall Oven (GLEB27Z7H) Specifications • Single phase 3- or 4-wire cable, 120 / 240 or 120 / 208 Volt, 60 Hertz Frigidaire® Single Wall Oven model GLEB27Z7H is approved to be used beneath any approved Frigidaire® Gas Cooktop.
