- Ascom Phone User's Guide

12
Basic Operation
Figure 5.1
Power on
Press and hold the blue Off Hook key. An audible tone
is heard, and
ascom
appears on the display. Once the
handset is powered on, the Standby mode display is
visible (see Figure 5.1). The System Indicator icon will be
steady when the handset is locked to the system.
Power off
Press and hold the gray On Hook key until a tone is
sounded. Once the handset is powered off, the main
Standby mode display is no longer visible.
Place a call
The handset must be powered on and locked to a
system. Place a call using one of two methods:
Option 1
Press the Off Hook key to hear a dial tone, then dial the
number. The number being dialed will appear in the
display.
Option 2
Dial the number, then press the Off Hook key. To erase an
incorrectly entered digit while dialing, press the up arrow
on the Scroll key.
End an active call
To end an active call, press the On Hook key.
Answer an incoming call
Press the Left Soft key to choose Accept from the menu
options displayed or press the Off Hook key.
Decline an incoming call
Press the Right Soft key to choose Decline from the
menu options displayed.
Re-dial
The 9p23 portable handset stores the last 20 numbers
dialed. From the Standby mode display (see Figure 5.1),
press the up arrow of the Scroll key twice to display the
last number dialed or use the Scroll key to browse all
dialed numbers on the list. Once the desired handset
number is displayed, press the Off Hook key to dial the
number.
The number may need to be edited before dialing. For
instance, dialing “9” for an outside line.
Figure 5.2
Retrieve messages
Receipt of a message is indicated with a ring tone and by
displaying a Text Message or Voice Mail icon.
1. Press the Left Soft key to enter the menu.
2. Press the Left Soft key to select Messages.
3. Use the Scroll key to choose from the Messages
menu options: Inbox, Voice Mail, Send New Msg,
Delete All, Options*. The active menu option is
highlighted in brackets (see Figure 5.2).
4. Use the Left Soft key to choose Select from the
available options. This will present the function
options for that item.
Text messages
1. An audible ring tone and the text message indicate
when a new text message is received.
2. To read stored text messages, use the Left Soft
key to select Inbox from the Messages menu. Text
messages will be displayed in the order they were
received. Use the up and down arrows of the Scroll
key to view all text messages in the list.
*Please see the Short Message Service (SMS) section for additional details.
