Operation Manual

Instructions for use, mounting and connection
23
Switching the complete hob off
The hob is switched off by pressing the main ON/OFF sensor.
The sound signal beeps and all indicators go off, except for
those hotplates which are still hot and display the warning "H"
sign as an indication of the remaining heat. When all hotplates
indicate power level "0", or when this is the result of the preset
timer operation, the complete hob is switched off after a 10
second lapse, with only the remaining heat warning "H" still
illuminated.
Timer function
Once the hob is on you have two timer operation alternatives:
1. time countdown without the switch off function
2. setting the timer controlled period of operation for a
particular hotplate
Timer is activated by pressing the timer sensor, the display
indicates "00". Set the time between 1 and 99 minutes: this
setting may be altered at any time in 1 minute intervals by
pressing the (+) or (-) sensor. Constant press of either sensor
changes the setting faster, in 5 minute intervals.
Countdown of preset time
By activating the timer (indicator "00") you have switched on
the time countdown By pressing the (+) sensor the countdown
starts with 1 minute, and by pressing the sensor (-) the
countdown starts from 99 minutes. Desired time is selected by
pressing either the (+) or (-) sensor. The sound signal indicates
the beginning of the countdown operation. Preset time may be
changed at random during the countdown. The sound signal
indicates that the time has elapsed and the indicator displays
flashing "00" which may be switched off by pressing any
sensor.
Timer controlled period of operation for a particular
hotplate
In this mode you are able to select the exact operation time for
any hotplate. After the time has elapsed the hotplate
automatically turns off. Time may be preset parallel for one
hotplate which must be switched on. First switch the timer on
by pressing the timer sensor. Next touch of the timer sensor
brings the decimal dot on the time indicator showing which
hotplate is being preset. If more than one hotplate is in
operation you may select the particular hotplate by several
consequent pressing on the timer sensor until your desired
hotplate is indicated with the decimal dot. Now set the desired
preset time by pressing the (+) or (-) sensor.
Once the preset time has elapsed the selected hotplate is
automatically switched off, time indication flashes for a while
and the beep is heard. Power regulation display indicates "0"
and the remaining heat warning "H" appears.
Other hotplates without the preset operation time continue with
normal operation.
Limited time of operation
This function is incorporated for safer operation of your hob.
Each hotplate is equipped with the time limit switch. The period
of operation is calculated in accordance with the last selected
power setting of a particular hotplate.
If the power setting is not changed for a while, the hotplate will
be switched off automatically after a certain period of time,
depending upon the power setting level (higher power setting –
shorter time - see chart).
Power setting Maximum operation time in
hrs
110
25
35
44
53
62
72
82
91
Safety functions and error display
If both the (+) and (-) sensor are preset together the hotplate is
switched off.
If all the hotplates indicate the "0" power setting, the hob is
switched off after 10 seconds.
If any of the sensors is activated for more than 10 seconds the
hob is switched off, the beep sounds, and the indicator
displays the flashing "F" signal.
If the sensors are covered with an object, or the surface is
covered with spilt liquid, the hob is switched off.
Error may occur also during the period of initial synchronization
or during the operation. In such cases the display indicates
relevant combination of symbols. If the fault can not be
removed, call the after sale assistance.
