Manual

COMMAND SET
29
:CHANnel<X>:SCALe
Set
Query
Description
Sets or returns the vertical scale for each channel. The
scale is dependent on the probe attenuation factor.
Same as: Volts/Div knob
Syntax
< Long >
< Short >
:channel<X>:scale <NR3>
:channel<X>:scale?
:chan<X>:scal <NR3>
:chan<X>:scal?
Parameter
<X>
Channel
<NR3>
Vertical scale
1/2/3/4
CH1/2/3/4
2e–3 ~ 5e+0
2mV ~ 5V
(Probe x1)
2e–2 ~ 5e+1
20mV ~ 50V
(Probe x10)
2e–1 ~ 5e+2
200mV ~ 500V
(Probe x100)
Example
:channel1:probe 0
:channel1:scale 2.00e–3
Set CH1 probe to x1
Set CH1 scale at 2mV
