:MEASure:LFRDelay
Query
Description
Returns the delay between the first falling edge of
source1 and the last rising edge of source2.
Same as: Measure key → F1~F5 → F3 (DelayLFR)
Syntax
< Long >
< Short >
:measure:lfrdelay?
:meas:lfrd?
Returns
<NR3>
Before this
command
Select the two delay channels before entering this
command: :measure:delay1 <NR1>
and :measure:delay2 <NR1>. See pagexx.
Example
:measure:delay1 1
:measure:delay2 2
:measure:lfrdelay?
Select channel 1 and 2
as delay source1/2, and
then measure LFR.
:MEASure:LRFDelay
Query
Description
Returns the delay between the first rising edge of
source1 and the last rising edge of source2.
Same as: Measure key → F1~F5 → F3 (DelayLRF)
Syntax
< Long >
< Short >
:measure:lrfdelay?
:meas:lrfd?
Returns
<NR3>
Before this
command
Select the two delay channels before entering this
command: :measure:delay1 <NR1>
and :measure:delay2 <NR1>. See pagexx.
Example
:measure:delay1 1
:measure:delay2 2
:measure:lrfdelay?
Select channel 1 and 2
as delay source1/2, and
then measure LRF.
