COMMAND SET
73
Syntax
< Long >
< Short >
:ref<x>:display <Boolean>
:ref<x>:display?
:ref<x>disp <Boolean>
:ref<x>disp?
Parameter
<X>
Reference
<Boolean>
Reference on/off
1
A
0
off
2
B
1
on
Example
:ref1:display 1
Turns on the reference
waveform A
:REF<X>:LOCate
Set
Query
Description
Moves or returns the position of a reference
waveform.
Same as: Save/Recall key → F5(More) → F5(More) →
F2 (Display Refs) → Variable knob
Syntax
< Long >
< Short >
:ref<x>:locate <NR1>
:ref<x>:locate?
:ref<x>:loc <NR1>
:ref<x>:loc?
Parameter
<X>
Reference
<NR1>
Position
1
A
–100 to +100
2
B
3
C
4
D
Note
Before using this command, turn on a reference
waveform. See the example below.
Example
:ref1:display 1
:ref1:locate 0
Turns on the reference
waveform A and move
it to ±0 position
