RS-232C Interface Configuration
RS-232C
configuration
Connector
DB-9, Male
Baud rate
2400, 4800, 9600, 19200, 38400
Parity
None, Odd, Even
Data bit
8 (fixed)
Stop bit
1, 2
Panel operation
1. Press the Utility key.
Utility
2. Press F2 (Interface Menu).
Interface
Menu
F 2
3. Press F1 (Type) repeatedly
to select RS-232C.
Type
RS232
F 1
4. The interface icon at the top
of the display changes into
RS-232C type.
5. To change the baud rate,
press F2 (Baud Rate)
repeatedly.
Baud Rate
9600
F 2
Range
2400, 4800, 9600, 19200, 38400
6. To change the stop bit, press
F3 (Stop Bit) repeatedly.
Stop Bit
2
F 3
Range
1, 2
7. Data bit is fixed at 8.
8. To change the parity, press
F4 (Parity) repeatedly.
Parity
None
F 4
