DS-2CD4A24FWD-IZ(H)(S)(T) 2MP Anti-Corrosion Low Light Smart Camera 1/2.8"Progressive Scan CMOS IR light range up to 120 m 1920 × 1080 @ 60fps 6 behavior analyses Color: 0.005 Lux @ (F1.2, AGC ON), 0.008 Lux @ Built-in microSD/SDHC/SDXC card slot, up to 128 (F1.5, AGC ON) H.265, H.265+, H.264, H.
Specifications Camera Image Sensor 1/2.8" Progressive Scan CMOS Min. Illumination Color: 0.005 lux @ (F1.2, AGC ON), 0.008 lux @ (F1.5, AGC ON) B/W: 0.0005 lux @ (F1.2, AGC ON), 0.0008 lux @ (F1.5, AGC ON), 0 lux with IR Shutter Speed 1 s to 1/100,000 s Slow Shutter Yes Auto-Iris DC drive Day & Night IR Cut Filter Digital Noise Reduction 3D DNR WDR 120 dB Angle Adjustment Pan: 0 to 360°, tilt: 0 to 100°, rotation: 0 to 360° Lens Focal length 4.7 to 94 mm Aperture F1.5 to F3.
Third Stream 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288, 320 × 240) 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240, 320 × 240) Image Enhancement BLC, HLC, 3D DNR, Defog, EIS Image Settings Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser Target Cropping Yes Day/Night Switch Day/Night/Auto/Schedule/Triggered by Alarm In (with –S model) Picture Ov
Dimensions Camera: 348.4 × 114.2 ×111.7 mm (13.7" × 4.5" × 4.4") With package: 386 × 156 × 155 mm (15.2" × 6.1" × 6.1") Weight -IZ: Camera: 1300 g (2.9 lb.) With package: 1800 g (4 lb.) -IZH, -IZS: Camera: 1500 g (3.3 lb.) With package: 2100 g (4.6 lb.) -IZHS: Camera: 2000 g (4.4 lb.) With package: 2600 g (5.7 lb.) Available Model DS-2CD4A24FWD-IZ (4.7-94 mm) (T), DS-2CD4A24FWD-IZH(4.7-94mm) (4.7-94 mm) (T), DS-2CD4A24FWD-IZS(4.7-94mm) (4.7-94 mm) (T), DS-2CD4A24FWD-IZHS(4.
Dimension 348.4(13.7") 223.1(8.8") 88.5(3.5") 103.9(4.1") Φ105(4.1") 59.5(2.3") 100(3.9") 114.2(4.5") 4-Φ5.5(0.2") 88.5(3.5") 111.7(4.4") 59.5(2.3") 329.
05058020181026
