Data Sheet
![](/manual/hikvision/ds-2cd4a24fwd-iz-h-s-t/data-sheet-english/images/img-2.png)
Specifications
Camera
Image Sensor
1/2.8" Progressive Scan CMOS
Min. Illumination
Color: 0.005 lux @ (F1.2, AGC ON), 0.008 lux @ (F1.5, AGC ON)
B/W: 0.0005 lux @ (F1.2, AGC ON), 0.0008 lux @ (F1.5, AGC ON), 0 lux with IR
Shutter Speed
1 s to 1/100,000 s
Slow Shutter
Yes
Auto-Iris
DC drive
Day & Night
IR Cut Filter
Digital Noise Reduction
3D DNR
WDR
120 dB
Angle Adjustment
Pan: 0 to 360°, tilt: 0 to 100°, rotation: 0 to 360°
Lens
Focal length
4.7 to 94 mm
Aperture
F1.5 to F3.0
FOV
Horizontal FOV: 55° to 3°, vertical FOV: 31.6° to 1.8°, diagonal FOV: 62° to 3.6°
Lens Mount
Integrated
IR
IR Range
Up to 120 m
Wavelength
850 nm
Compression Standard
Video Compression
Main stream: H.265/H.264
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
H.264 Type
Baseline Profile/Main Profile/High Profile
H.264+
Main stream supports
H.265 Type
Main Profile
H.265+
Main stream supports
Video Bit Rate
32 Kbps to 16 Mbps
SVC
H.264 and H.265 encoding
Smart Feature-set
Perimeter Protection
Line crossing detection, intrusion detection, region entrance detection, region exiting
detection, unattended baggage detection, object removal detection
Exception Detection
Scene change detection, defocus detection, audio detection (with –S model)
Statistics
Counting
Face Detection
Yes
Region of Interest
4 fixed regions for main stream, sub stream, third stream and dynamic tracking
Max. Resolution
1920 × 1080
Main Stream
50Hz: 50fps (1920 × 1080, 1280 × 960, 1280 × 720)
60Hz: 60fps (1920 × 1080, 1280 × 960, 1280 × 720)
Sub Stream
50Hz: 25fps (704 × 576, 640 × 480, 352 × 288, 320 × 240)
60Hz: 30fps (704 × 480, 640 × 480, 352 × 240, 320 × 240)
